13. Once the wheel lug nuts have
been tightened, lower the vehicle
fully to the ground and continue to
tighten the lug nuts until they are
fully secured. Tighten the wheel
lug nuts firmly in a “star” pattern.
If you are unsure of the tightness
of the wheel lug nuts, have them
checked at the nearest service
station. The specified tightening
torque is 9~11 kg m (65-79 lbft,
88-107 N m). Improperly tight-
ened wheel lug nuts could cause
brake pedal vibration while brak-
ing. 14. Reinstall the wheel cover by fit-
ting the boss of the wheel cover
in the groove of the wheel.
To prevent the jack, jack handle,
wheel lug nut, wrench and spare tire
from rattling while the vehicle is in
motion, store them properly.
1GHA409A
CAUTION
Your vehicle has metric threadson the wheel studs and nuts.Make certain during wheelremoval that the same nutsremoved are reinstalled - or, ifreplaced, that nuts with metricthreads and the same chamferconfiguration are used.Installation of a non-metricthread nut on a metric stud orvice-versa will not secure thewheel to the hub properly andwill damage the stud so that itmust be replaced.
Note that most lug nuts do nothave metric threads. Be sure touse extreme care in checkingfor thread style before installingaftermarket lug nuts or wheels.If in doubt, consult anAuthorized Kia Dealer.
WARNING
- Wheel studs
If the studs are damaged, they
may lose their ability to retain
the wheel. This could lead to the
loss of the wheel and a colli-
sion.
WARNING
Check the inflation pressures as
soon as possible after installing
the spare tire. Adjust it to the
specified pressure, if necessary.
Refer to Section 8, Specifications.
Opirus CAN 6-1.qxd 7/8/03 2:22 PM Page 24
Specifications48
1
2
3
4
5
6
7
8
9
Gear ratio
Tires
ItemFrontRear
Tire size 225/60R16 98H 225/60R16 98H
210 (30) 210 (30)
Wheel size 6.5J x 16 6.5J x 16
Wheel lug nut torque 9~11 9~11
kg·m (lb·ft, N·m) (65~79, 88~107) (65~79, 88~107)
Inflation pressure
kPa (psi)
Engine Gasoline
Gear Automatic transmission
1st 3.789
2nd 2.057
3rd 1.421
4th 1.039
5th 0.731
Reverse 3.865
F.G.R 3.333
