Oil KIA PICANTO 2018 Service Manual

LubricantVolumeClassiýication
Brake / clutch ýluid 0.4 ~ 0.44 l (0.42 ~ 0.46 US qt.)FMVSS116 DæT-3 or DæT-4
Fuel 35 l (9.24 US þal.) -
Fuel (FFV) Gasoline reservoir 0.8 l (0.2 US þal.) - Aclohol 38 l (10.03 US þal.) -
*1 Reýer to the recommended SAE viscosity numbers on the next paþe.
*2 Enþine oils labeled Enerþy Conservinþ æil are now available. Alonþ with other additional beneýits, they contribute to ýuel
economy by reducinþ the amount oý ýuel necessary to overcome enþine ýriction. æýten, these improvements are diýýicult to measure in everyday drivinþ, but in a year’s time, they can oýýer siþniýicant cost and enerþy savinþs.

Recommended SAE viscosity number
CAUTION
Always be sure to clean the area around any ýiller pluþ, drain pluþ, or dipstick beýore checkinþ or draininþ any lubricant.This is especially important in dusty or sandy areas and when the vehicle is used on unpaved roads. Cleaninþ the pluþ anddipstick areas will prevent dirt and þrit ýrom enterinþ the enþine and other mechanisms that could be damaþed.
Enþine oil viscosity (thickness) has an eýýect on ýuel economy and cold weather operatinþ (enþine start and enþine oil ýlowabil‐
ity). Lower viscosity enþine oils can provide better ýuel economy and cold weather perýormance, however, hiþher viscosity en‐
þine oils are required ýor satisýactory lubrication in hot weather. Usinþ oils oý any viscosity other than those recommended
could result in enþine damaþe.
When choosinþ an oil, consider the ranþe oý temperature your vehicle will be operated in beýore the next oil chanþe. çroceed to select the recommended oil viscosity ýrom the chart.
Speciýications & Consumer inýormation
9-12

AIR CONDITIONER COMPRESSOR LABEL
A compressor label inýorms you the
type oý compressor your vehicle is equipped with such as model, supplier
part number, production number, re‐
ýriþerant (1) and reýriþerant oil (2).
Speciýications & Consumer inýormation
9-18
