USB KIA SORENTO PHEV 2022 Features and Functions Guide

2 *IF EQUIPPEDSORENTO HYBRID / PLUG-IN HYBRID FEATURES & FUNCTIONS GUIDE
TABLE OF CONTENTS
VIDEOS & QR CODES . . Inside Front Cover
INSTRUMENT CLUSTERInstrument Cluster Overview . . . . . . . . . . . . . . . . . . . . 03Hybrid / Plug-In Hybrid Indicators at Star tup . . . . . 04Indicators & Warning Lights . . . . . . . . . . . . . . . . . . . . . . 05Tire Pressure Monitoring System (TPMS) . . . . . . . . . 06Fuel Economy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 06Drive Mode Integrated Control System* . . . . . . . . . . 07
VEHICLE SETTINGSTrip Modes / Trip Computer . . . . . . . . . . . . . . . . . . . . . .08LCD Instrument Cluster Modes . . . . . . . . . . . . . . . . . .08User Set tings – Instrument Cluster . . . . . . . . . . . . . . .09Vehicle Set tings* – Audio Head Unit . . . . . . . . . . . . . .09Vehicle Auto-Shut Off System* . . . . . . . . . . . . . . . . . . . 10Service Interval Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
H Y B R I D / P LU G - I N H Y B R I D S YS T E MPlug-In Hybrid Display* . . . . . . . . . . . . . . . . . . . . . . . . . . 11Charging the Plug-In Hybrid Vehicle . . . . . . . . . . . . . 12Energy Flow - Instrument Cluster LCD . . . . . . . . . . . . 14Charging Connector Auto/Lock Mode . . . . . . . . . . . . 16Scheduled Charging* (Plug-In Hybrid only) . . . . . . . 16Plug-In Hybrid Modes (Plug-In Hybrid only) . . . . . . 17
ADVANCED DRIVER ASSISTANCE SYSTEMS (ADAS)Forward Collision-Avoidance Assist (FCA) . . . . . . . . 18Blind-Spot Collision-Avoidance Assist (BCA)* . . . . . 19Lane Keeping Assist (LK A) . . . . . . . . . . . . . . . . . . . . . . .20Intelligent Speed Limit Assist (ISL A) . . . . . . . . . . . . . . 21Driver At tention Warning (DAW)* . . . . . . . . . . . . . . . . . 22Leading Vehicle Depar ture Aler t (LVDA) . . . . . . . . . . 23Safe Exit Assist (SEA)* . . . . . . . . . . . . . . . . . . . . . . . . . . . 23Smar t Cruise Control (SCC) with Stop and Go* . . . . 24Cruise Control (CC)* . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25Lane Following Assist (LFA) . . . . . . . . . . . . . . . . . . . . . . 26Highway Driving Assist (HDA)* . . . . . . . . . . . . . . . . . . . 27Rear View Monitor (RVM) . . . . . . . . . . . . . . . . . . . . . . . . 28Blind-Spot View Monitor (BVM)* . . . . . . . . . . . . . . . . . . 28Surround View Monitor (SVM)* . . . . . . . . . . . . . . . . . . . 29
Rear Cross-Traffic Collision-Avoidance Assist* . . .30Rear Occupant Aler t with Ultrasonic Sensors . . . . . 31Reverse Parking Collision-Avoidance Assist* . . . . . . 32Forward/Reverse Parking Distance Warning* . . . . . 32
DRIVER’S PANELInstrument Cluster Illumination Control . . . . . . . . . . . 33Electronic Stability Control (ESC) . . . . . . . . . . . . . . . . . 33Hill-Star t Assist Control (HAC) . . . . . . . . . . . . . . . . . . . . 33Reverse Parking Aid Function* . . . . . . . . . . . . . . . . . . . 34Engine Star t/Stop But ton* . . . . . . . . . . . . . . . . . . . . . . . 34Power Windows, Window Lock & Central Door Lock / Auto Door Lock/Unlock . . . . . . . . . . . . 35Electronic Child Safety Lock System . . . . . . . . . . . . . . 35Power/Heated Outside Mirrors* . . . . . . . . . . . . . . . . . . 36Manual Folding Mirrors* . . . . . . . . . . . . . . . . . . . . . . . . . 36Power Folding Outside Mirrors* . . . . . . . . . . . . . . . . . .36
STEERING WHEEL CONTROLSTilt/Telescoping Steering Wheel . . . . . . . . . . . . . . . . . . 37Headlights & High Beams . . . . . . . . . . . . . . . . . . . . . . . . 38High Beam Assist / Daytime Running Lights* . . . . . 38Turn Signals & Fog Lights* . . . . . . . . . . . . . . . . . . . . . . . 39Windshield Wipers & Washers . . . . . . . . . . . . . . . . . . . . 39Rear Wiper & Washer* . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
AUDIO SYSTEMSBluetooth® Wireless Technology . . . . . . . . . . . . . . . . . 40 Audio Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41 Android Auto™ / Apple CarPlay® Setup . . . . . . . . . . . 42UVO link Activation* . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43UVO Assistance* . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43Kia Access with UVO link App Download . . . . . . . . .44Kia Access with UVO link App Features Guide . . . .44Standard Audio System - Value with UVO link* . . . .45UVO link with Navigation* . . . . . . . . . . . . . . . . . . . . . . . 46
CENTER PANELDigital Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47Multimedia USB Por t, Power Outlets & USB Charger Por t . . . . . . . . . . . . . . . . . . . . . . . . . . .47Automatic Climate Control . . . . . . . . . . . . . . . . . . . . . . . 48
Wireless Smar tphone Charging System* . . . . . . . . . .50Rotary Dial Shifter Knob – Shift-by-Wire . . . . . . . . . . 51Paddle Shifters* . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51AWD (All-Wheel Drive) Lock* . . . . . . . . . . . . . . . . . . . . . 52Idle, Stop & Go (ISG) System* . . . . . . . . . . . . . . . . . . . . . 52Electronic Parking Brake (EPB)* / Auto Hold . . . . . .53Heated Steering Wheel . . . . . . . . . . . . . . . . . . . . . . . . . .54Seat Warmers/ Ventilated Seats* . . . . . . . . . . . . . . . . .54
SEATINGFront Seat Headrest Adjustment . . . . . . . . . . . . . . . . .55Driver Position Memory System* . . . . . . . . . . . . . . . . .55Power Adjustable Driver ’s Seat / Power Lumbar . .562nd-Row Folding Seat . . . . . . . . . . . . . . . . . . . . . . . . . . .562nd-Row Auto-Folding Seat . . . . . . . . . . . . . . . . . . . . . . 57Unfastening Center Seatbelt . . . . . . . . . . . . . . . . . . . . . 57One-Touch Slide & Fold 2nd-Row Seats . . . . . . . . . . .583rd-Row Folding Seat . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
OTHER KEY FEATURESSunvisor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59Double-Turn Lock/Unlock All . . . . . . . . . . . . . . . . . . . . 59Smar t Key* . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .60Power Liftgate* . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61Smar t Liftgate with Auto Open* . . . . . . . . . . . . . . . . . . 62Map/Room Lamps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .63Panoramic Sunroof with Power Sunshade* . . . . . . .63HomeLink® with Auto-Dimming Rearview Mirror . . 64Hood Release Lever and Latch . . . . . . . . . . . . . . . . . . .65Fuel Cap / Malfunction Indicator . . . . . . . . . . . . . . . . .65Fuel Filler Lid Release . . . . . . . . . . . . . . . . . . . . . . . . . . . .65
SAFETY FEATURESOccupant Detection System (ODS) / Passenger Airbag Off Indicator . . . . . . . . . . . . . . . .66Child-Protector Rear Door Locks* . . . . . . . . . . . . . . . .66Seat Belts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .66
MAINTENANCE CHART . . . . . . . . . .Back Cover
LEGAL DISCLAIMERS . . Inside Back Cover

42†LEGAL DISCL AIMERS ON BACK INSIDE COVER | *IF EQUIPPEDSORENTO HYBRID / PLUG-IN HYBRID FEATURES & FUNCTIONS GUIDE
AUDIO SYSTEMS
AUDIOSYSTEMS
Android Auto™†3 / Apple CarPlay®†3 Setup
Driving while distracted can result in a loss of vehicle control that may lead to an accident, severe bodily injur y, and death . The driver ’s primar y responsibilit y is in the safe and legal operation of a vehicle, and any handheld devices, other equipment, or vehicle systems which take the driver ’s eyes, at tention and focus away from the safe operation of a vehicle or which are not permissible by law should never be used during operation of the vehicle .
Android Auto™ compatible smartphone setup – D o w n l o a d t h e A n d r o i d A u t o™ app from the Google Play™ Store†1 0 . Open the Android Auto™ app and proceed with the onscreen instructions to complete setup on the mobile device .
Wireless Connection setup for Android Auto™ & Apple CarPlay® (Standard Audio System & Standard Audio System-Value with UVO link):
1 . Press the SETUP key on the audio head unit
2 . Press DEVICE CONNECTION SETTINGS
3 . Press PHONE PROJECTION, then ADD NEW
Cable Connection setup for Android Auto™ (Standard Audio System, Standard Audio System-Value with UVO link & UVO link with Navigation):
1 . Press the SETUP key on the audio head unit
2 . Press DEVICE CONNECTION, select Android Auto™ and then select ENABLE ANDROID AUTO . Review all terms, conditions and requests on the head unit and phone, and, if you agree, accept them in order to use Android Auto™
3 . Connect the Android™ device with the vehicle’s USB port using the manufacturer ’s cable provided with your phone
4 . From the vehicle’s home screen, select the Android Auto™ button, where you’ll see all the Android Auto™ supported apps
Cable Connection setup for Apple CarPlay® (UVO link with Navigation only):
1 . Connect the Apple CarPlay® compatible iPhone®†1 1 with the vehicle’s USB port using the manufacturer ’s cable provided with your iPhone®†1 1
2 . Press the SETUP key on the audio head unit
3 . Press DEVICE CONNECTION on the screen and select Apple CarPlay®
4 . Select ENABLE APPLE CARPL AY . Review all
terms, conditions and requests on the head unit and phone, and, if you agree, accept them in order to use Apple CarPlay®
5 . From the audio head unit home screen, select the Apple CarPlay® button, where you’ll see all the Apple CarPlay® supported apps
REMINDERS:
•Android Auto™ compatibilit y requirements for connection:
-
UVO link with Navigation (USB cable connection only): OS Android™ 5 .0 or higher, phone manufacturer ’s USB cable and data plan for applicable feature(s)
-Standard Audio System-Value (USB cable & wireless connection):
-
USB cable connection - OS Android™ 5 .0 or higher, phone manufacturer ’s USB cable and data plan for applicable feature(s)
-
Wireless connection - OS Android™ 9 .0 or higher with data plan for applicable feature(s)
•Apple CarPlay® compatibilit y requirements for connection:
-
UVO link with Navigation (USB cable connection only): iOS soft ware 8 .0 or higher, phone manufacturer ’s USB cable and data plan for applicable feature(s)
-
Standard Audio System-Value (Wireless connection only): iOS soft ware 10 .0 and higher with data plan for applicable feature(s)
•
It is recommended to always update your phone to the latest operating system release
•
Wireless Android Auto™ system only works for cer tain Android models . Use the manufacturer ’s USB cable when wireless feature is not available
Refer to the Car Infotainment System Quick Reference Guide for more information .
Refer to the inside front cover for more information on QR codes .www .youtube .com/KiaFeatureVideos
Wireless Apple CarPlay & Android Auto Video
QR CODE
•If Android Auto™ / Apple CarPlay® randomly disconnects:
– Ensure the USB cable is cer tified by the phone manufacture for both power and data
– Clean the phone’s por t, which the USB cable connects to, as instructed by the phone’s manufacturer
– The Phone should not be disturbed while driving as this can cause a disconnection at the phone’s USB por t
– Visit the phone manufacturer ’s website for Android Auto™ / Apple CarPlay® app concerns
QUICK TIPS

43†LEGAL DISCL AIMERS ON BACK INSIDE COVER | *IF EQUIPPEDALWAYS CHECK THE OWNER ’S MANUAL FOR COMPLETE OPER ATING INFORMATION AND SAFET Y WARNINGS .
AUDIO SYSTEMS
AUDIOSYSTEMS
UVO link Activation*†1 (Systems equipped with UVO link only):
Follow these steps to activate your UVO link system:
1 . Enter the activation screen on your vehicle’s head unit:
a . Press SETUP key b . Press UVO icon c . Press Activate UVO
2 . Read and agree to Terms of Service and Privacy Policy and press SUBMIT
3 . Enter phone number or email address to receive a verification code, then press SUBMIT
4 . Follow these steps to receive your verification code using your phone text message or email:
a . Check your phone text message or email for verification codeb . Open the link in your text or email . A page will open requesting that you create your account
N o t e : If you already have a Kia Owners Portal account using the email or phone number as your login ID, you will need to provide your password prior to receiving the verification code
REMINDER: This vehicle is not equipped with over-the-air system updates .
c . Enter your first name, last name, email, phone number, an account password, and click CREATE ACCOUNT . A page will open displaying your verification code
d . Enter the code in the head unit and press ACTIVATE
e . Go back to the page with your verification code and press “I have entered my PIN .” A link will be provided to download the Kia Access with UVO link app from your app store . After installing the app, log in and enjoy
(But tons on overhead console*)
UVO
PASSENGEROFFAIR BAG
BCA
Refer to the inside front cover for more information on QR codes .www .youtube .com/KiaFeatureVideos
Kia Access with UVO link App Video
QR CODE
UVO link may be unavailable for model year 2022 vehicles sold or purchased in Massachuset ts . See UVO Terms of Ser vice at owners .kia .com for more information .
Driving while distracted can result in a loss of vehicle control that may lead to an accident, severe bodily injur y, and death . The driver ’s primar y responsibilit y is in the safe and legal operation of a vehicle, and any handheld devices, other equipment, or vehicle systems which take the driver ’s eyes, at tention and focus away from the safe operation of a vehicle or which are not permissible by law should never be used during operation of the vehicle .
Virtual Assistant A – Press to connect to a virtual assistant to hear information about the UVO features
UVO Voice Local Search B (systems with navigation) - Press to connect to the search function to find points of interest or other locations, like “cafe”
UVO Voice Local Search B (non-navigation systems) - Press to activate phone projection with Android Auto™ or Apple CarPlay® (smartphone must be connected via wireless or USB cable — see previous page for availability and setup)
Roadside Assist C – Press to connect to a Roadside Assistant where you can request vehicle towing services
REMINDER: These but tons may be located in the rear view mirror or the overhead console .
For more information, refer to the Car Infotainment System Quick Reference Guide . On cer tain models, UVO Assistance but tons are located on the Rear view Mirror .
UVO Assistance*†1
UVO Assistance Video

45†LEGAL DISCL AIMERS ON BACK INSIDE COVER | *IF EQUIPPEDALWAYS CHECK THE OWNER ’S MANUAL FOR COMPLETE OPER ATING INFORMATION AND SAFET Y WARNINGS .
MEDIARADIO
TRACK >
SETUP
< SEEK
POWERPUSHVOL ENTER
TUNE
FILE
Standard Audio System - Value with UVO link*†1
— FM/AM/SiriusXM®†1 7 / Media (USB, Bluetooth®†3 Audio)*
Press briefly to do the following:• FM/AM mode: Play the previous/next frequency .• SiriusXM® mode: Change the channel .• MEDIA mode: Change the track, file or title (except for AUX) .
Press and hold to do the following (over 0.8 seconds):• FM/AM mode: Move quickly through all of the frequencies . When released, the system seeks the next available frequency .• MEDIA mode: Rewinds or fast for wards the track or file (except for AUX and Bluetooth® Audio) .
A programmable key to provide quick access to one of several available system features
Press to Power ON/OFF . Rotate to adjust Volume
Press to select FM/AM/SiriusXM® modesPress to display SETUP/Set tings mode Press to enter MEDIA modeRotate to change Radio/SiriusXM® Station/Media tracks/files . Press to select
(LCD Display Screen)
Sound Settings – To adjust the sound settings:
1 . Press the SETUP key on the audio head unit or the onscreen MENU button, when in MEDIA mode . Select the onscreen SOUND button
2 .
Select the menu item (Position, Volume, Tone, Priority, Advanced, Default, FM Radio Noise Cancel*)
3 .
Use the onscreen buttons to adjust settings . Press the return button to save settings
Presets – Press the STAR button next to or below the Radio Station display . This saves the current station as a preset .
SiriusXM® Smart Favorites – For the first ten favorite SiriusXM® channels, you may play live or repeat from the beginning of a song or a program segment . In Radio mode, choose SiriusXM®, then select any of the first ten favorites . During song or program play, tap the Skip Backward icon to start from the beginning of the song or program . Tap the Play Live icon to return to the live broadcast .
Custom Key H: A programmable key to provide quick access to one of several available system features . To Program the Custom Key, press the Custom key . Select one of the available features you would like the Custom key to open .
Map/software updates - To keep your map and software up to date, free of charge, visit the official Kia update webpage at https://update .kia .com/US/EN/Main . Note, visiting a dealer for software update may include an additional charge .
REMINDERS:
•
Driving while distracted is dangerous and should be avoided . Drivers should remain at tentive to driving and always exercise caution when using the audio system controls while driving . To help minimize driver distraction, some audio system functionalities have been modified while the vehicle is in Drive, Reverse or moved out of Park .
•Prolonged use of the audio head unit in ACC mode may drain the vehicle’s bat ter y
Your vehicle’s audio system may differ from that in the illustration .
•Volume level bet ween different audio modes:
– When switching bet ween audio modes (AM, FM, Bluetooth® Audio, etc .), the audio system saves the previous volume level you were listening to . For example, if you were listening to FM radio at volume level 20 then switched to Bluetooth® Audio and adjusted the volume level to 30, the volume level will be at 20 when you switch back to FM radio
– When using Bluetooth® Audio, the overall volume is dependent on your device’s volume . If the volume is turned down low on your device it will remain low even if the system volume is turned up
•This system suppor ts Android Auto™ (USB & wireless connection) and Apple CarPlay® (wireless connection only)
•
Navigation may be available when connected to Android Auto™ or Apple CarPlay® suppor ted smar tphones
•When using the voice command feature, wait for the system to BEEP before speaking the command
•
At any time, you can interrupt Command Feedback by pressing the TALK but ton
•Prolonged use of the audio head unit in ACC mode may drain the vehicle’s bat ter y . A warning message may appear periodically on the audio head unit screen
QUICK TIPS
Refer to the inside front cover for more information on QR codes .www .youtube .com/KiaFeatureVideos
Standard Audio System - Value with UVO link Video
QR CODE
AUDIO SYSTEMS
AUDIOSYSTEMS
UVO link may be currently unavailable for model year 2022 vehicles sold or purchased in Massachuset ts . See UVO Terms of Ser vice at owners .kia .com for more information .
For more information, refer to the Car Infotainment System Quick Reference Guide .

46†LEGAL DISCL AIMERS ON BACK INSIDE COVER | *IF EQUIPPEDSORENTO HYBRID / PLUG-IN HYBRID FEATURES & FUNCTIONS GUIDE
AUDIO SYSTEMS
CENTERPA N EL
Sound Settings: To adjust the sound settings (Fader/Balance, Tone, Touch-Screen Beep ON/OFF and Speed-Dependent Volume Control ON/OFF) from any audio mode: 1 . Press the SETUP button on the Audio Head Unit 2 . Select the onscreen SOUND button 3 . Select the menu item to change settings 4 . Use the onscreen buttons to adjust settingsRadio Presets: You can listen to FM, AM and SiriusXM® radio and save frequently used stations . To save a preset, press the STAR button next to or below the Radio Station display . This saves the current station as a preset .SiriusXM® Smart Favorites: For the first ten favorite SiriusXM®
channels, you may play live or repeat from the beginning of a song or a program segment . In Radio mode, choose SiriusXM®, then select any of the first six favorites . During song or program play, tap the Skip Backward icon to start from the beginning of the song or program . Tap the Play Live icon to return to the live broadcast .Custom Key H A programmable button to provide quick access to one of several available system features . To program the Custom Key, press; select an available feature you would like the Custom Key to open .
UVO link†1 with Navigation*†1 4 – F M / A M / S i r i u s X M®†2 1 / Media (USB, Aux, Bluetooth® † 3 A u d i o )
Your vehicle’s audio system may differ from that in the illustration .
For fur ther UVO link with Navigation operations, refer to the Car Infotainment System Quick Reference Guide . For other audio system information, see pages 40-45 .
UVO link may be currently unavailable for model year 2022 vehicles sold or purchased in Massachuset ts .See UVO Terms of Ser vice at owners .kia .com for more information .
REMINDERS:
•
To help minimize driver distraction, some audio system functionalities have been modified while the vehicle is in Drive, Reverse or moved out of Park .
•
Prolonged use of the audio head unit in ACC mode may drain the vehicle’s battery
•
Map/software updates: To keep your map and soft ware up to date, free of charge, visit the of ficial Kia update webpage at ht tps://update .kia .com/US/EN/Main . Note, visiting a dealer for soft ware update may include an additional charge .
Press briefly to do the following:• FM/AM mode: Play the previous/next frequency .• SiriusXM® mode: Change the channel .• MEDIA mode: Change the track, file or title (except for AUX) .
Press and hold to do the following (over 0.8 seconds):• FM/AM mode: Move quickly through all of the frequencies . When released, the system seeks the next available frequency .• MEDIA mode: Rewinds or fast for wards the track or file (except for AUX and Bluetooth® Audio) .
A programmable key to provide quick access to one of several available system features Press to display SETUP/Set tings mode
SETUP
N AV
MAP
MEDIA SEEK
RADIO
TRACK
POWERPUSHVOL ENTER
TUNE
FILE
(LCD Display Screen)
Press to Power ON/OFF . Rotate to adjust Volume
Press to select FM/AM/SiriusXM® modes
Press to enter MEDIA mode
Press to display the Map screen for the current position/ Voice mode
Press to display the Navigation menu screen
Rotate to change Radio/SiriusXM® Station/Media tracks/files . Press to selectRefer to the inside front cover for more information on QR codes .www .youtube .com/KiaFeatureVideos
UVO link with Navigation Video
QR CODE
•Volume level bet ween different audio modes:
– When switching bet ween audio modes (AM, FM, Bluetooth® Audio, etc .), the audio system saves the previous volume level you were listening to . For example, if you were listening to FM radio at volume level 20 then switched to Bluetooth® Audio and adjusted the volume level to 30, the volume level will be at 20 when you switch back to FM radio
– When using Bluetooth® Audio, the overall volume is dependent on your device’s volume . If the volume is turned down low on your device it will remain low even if the system volume is turned up
•When connected to Android Auto™ or Apple CarPlay® on your smar tphone, the smar tphone’s navigation system may also be available
•This system suppor ts Android Auto™ and Apple CarPlay® (USB connection only)
•A warning screen may appear periodically to remind users that the navigation system should be operated when the engine is running to prevent bat ter y discharge
•At any time, you can interrupt UVO link Command Feedback by pressing the TALK but ton on the steering wheel
QUICK TIPS

47†LEGAL DISCL AIMERS ON BACK INSIDE COVER | *IF EQUIPPEDALWAYS CHECK THE OWNER ’S MANUAL FOR COMPLETE OPER ATING INFORMATION AND SAFET Y WARNINGS .
CENTER PANEL
CENTERPA N EL
Multimedia USB Ports, Power Outlets, & USB Charger Ports* Digital Clock
Press SETUP, then select General, scroll down and select Date/Time from the menu to adjust .
Multimedia USB Port*
A Use the Multimedia USB port to connect USB audio devices and smartphones
USB Charger Ports*
B USB charger ports* are located in the Center Panel, inside and on the back of the Center Console
Power Outlets
C Use the power outlets for mobile
phones and other devices designed to operate on a 12V (180W max) power outlet
(Located on Center Console below Climate Controls)
•REMINDERS:
•
Using the Power Outlet (accessor y plug) and USB charger for prolonged periods of time with the Engine Star t/Stop but ton in the ACC position (Engine OFF) for prolonged period time could cause the bat ter y to discharge
•
Use only the charging cables that your device manufacturer supplied . Third par t y cables may cause damage to device
•
The USB data por t (Multimedia USB por t) is located next to the Power Outlets . The USB Charger por ts do not suppor t data transfer
Refer to section 4 in the Owner ’s Manual for more information .
For illustrative purposes only . Your actual display, but tons and/or features may var y .
(Located on Back of Center Console)
Seat warmers / ventilation Wireless charge center console, back seat
USB / Multimedia
USB
180W12V
Seat warmers / ventilationWireless charge center console, back seat
USB / Multimedia
USB
180W12V
Seat warmers / ventilationWireless charge center console, back seat
USB / Multimedia
USB
180W12V
Refer to the Car Infotainment System Quick Reference Guide for more information .ABB
C
•
Press the Return but ton on the audio head unit to ensure changes are saved
•
When needed, Daylight Savings must be enabled in the Clock Set tings screen
•
To access manual date and time set ting, turn GPS time OFF in the Clock Set tings (UVO link with Navigation*)
QUICK TIPS
The power outlets are inactive when the Engine Star t/Stop but ton is OFF .
QUICK TIP

50†LEGAL DISCL AIMERS ON BACK INSIDE COVER | *IF EQUIPPEDSORENTO HYBRID / PLUG-IN HYBRID FEATURES & FUNCTIONS GUIDE
REMINDERS:
•
If the driver door is opened, charging will be disabled
•
Wireless charging technology allows for a device to be charged using inductive charging . See your Owner ’s Manual for more detailed information and the back page for legal disclaimers
•
Inductive charging systems are less ef ficient than conventional charging through a cable . As a result, higher device operating temperatures may be experienced during use
•
Charging Per formance – Device position on the wireless charging system can affect charging per formance . Other factor that may affect the charging rate includes foreign objects, such as coins or pens, and phone case thickness
Charge a compatible smartphone wirelessly by placing it on the tray B at the front of the console, near the Multimedia USB ports and the charging indicator, while the ignition is on .
1 . Enable Wireless Charging in the User Settings
2 . Slide open cover A . Place the smartphone on the center of the charging pad B
3 . Indicator light C may change to amber once wireless charging begins
4 . Once charging is complete, the amber light may change to green
Wireless Smartphone Charging System*
Seat warmers / ventilation Wireless charge center console, back seat
USB / Multimedia
USB
180W12V
Seat warmers / ventilationWireless charge center console, back seat
USB / Multimedia
USB
180W12V
3FGFS
UP
TFDUJPO

JO
UIF
0XOFS sT
.BOVBM
GPS
NPSF
JOGPSNBUJPO

3FGFS
UP
UIF
JOTJEF
GSPOU
DPWFS
GPS

NPSF
JOGPSNBUJPO
PO
23
DPEFT XXXZPVUVCF DPN,JB'FBUVSF7JEFPT
Wireless Charging Video
QR CODE
•
The smar tphone must be a compatible phone with QI function available
•Wireless charging must be enabled in user set tings
•
If wireless charging does not work, move the smar tphone around the pad until the charging indicator turns amber . Avoid placing other metal items in the bin while charging as to not impede the charging area
•
For wireless charging to occur, all doors (excluding the rear hatch) must be closed & the Smar t Key Fob must be detected inside the vehicle
QUICK TIPS
A
B
C
CENTER PANEL
CENTERPA N EL

54†LEGAL DISCL AIMERS ON BACK INSIDE COVER | *IF EQUIPPEDSORENTO HYBRID / PLUG-IN HYBRID FEATURES & FUNCTIONS GUIDE
CENTER PANEL
CENTERPA N EL
Heated Steering Wheel*
Press Heated Steering Wheel button A to turn the Steering Wheel Heater on/off while the Engine Start/Stop button is in the ON position . The Steering Wheel Heater will turn off automatically in 30 minutes, or when button A is pressed again to deactivate .
B Seat Warmers
•Press the button up once for high setting (3 LEDs lit)
•Press the button twice for medium setting (2 LEDs lit)
•Press a third time for low setting (1 LED lit) and again to turn OFF
C Ventilated Seats
•Press the button down once for high setting (3 LEDs lit)
•Press twice for medium setting (2 LEDs lit)
•Press a third time for low setting (1 LED lit) and again to turn OFF
Seat Warmers / Ventilated Seats*†1 6
REMINDER: If the steering wheel becomes too warm, turn the system off . The heated steering wheel may cause burns even at low temperatures, especially if used for long periods of time .
REMINDER: Use extreme caution when using the seat warmers to avoid burns . Refer to the Owner ’s Manual for more information .
(Located below gear shift knob)
DRIVE
SPORT
SMART
AUTO
HOLD
ECO
MUD
SAND SNOW
TERRAIN
COMFORT
Image is for illustrative purposes only and may not reflect actual feature or operation
.
Refer to section 4 in the Owner ’s Manual for more information .
A
Refer to the inside front cover for more information on QR codes .www .youtube .com/KiaFeatureVideos
Heated and Ventilated Seats Video
QR CODE
•If ignition is turned OFF, then ON again within 30 minutes of the Steering Wheel Heater being turned ON, the system will return to its previous state
•The system returns to on when ignition is cycled . To turn off system, press the Heated Steering Wheel but ton A
•With the heated steering switch in the ON position, the heating system in the steering wheel turns OFF or ON automatically depending on the steering wheel temperature
QUICK TIPS
•With the seat warmer switch in the ON position, the heating system in the seat turns OFF or ON automatically depending on the seat temperature
•System is OFF by default
QUICK TIPS
(But tons located on top sides of center console)
Seat warmers / ventilation Wireless charge center console, back seat
USB / Multimedia
USB
180W12V
Seat warmers / ventilationWireless charge center console, back seat
USB / Multimedia
USB
180W12V
Seat warmers / ventilationWireless charge center console, back seat
USB / Multimedia
USB
180W12V
B
C

Multimedia USB Ports, Power Outlets* - page 47 Blind-Spot Collision Avoidance-Assist (BCA)* - page 19 Clock Setup - page 47 Engine Start/Stop Button - page 34 HomeLink
® with Auto-Dimming Rearview Mirror - page 64
Lane Keeping Assist (LK A)* - page 20 Passenger Airbag Off Indicator - page 66
Panoramic Sunroof Operation* - page 63 Rear View Monitor (RVM) - page 28 Seat Warmers* - page 54 Smart Key - page 60 Sunvisor - page 59 Tire Pressure Monitoring System (TPMS)

- page 06
Explain first service process and schedule first service appointment Tour Parts & Service departments, introduce staff and explain value of Kia Parts and Service Review recommended maintenance schedule and maintenance requirements to validate warranty Review business hours Review the Kia 10-year/100,000-mile warranty program Ensure 100% satisfaction with sales and delivery process and no problems with the vehicle Confirm time and best contact number for initial dealer follow-upKEY FEATURE WALKTHROUGHDURING DELIVERY
Demonstrate the following with the customer:
Sales Consultant:
____________________________________________________________________________________
Date:
___________________________
Sales Manager:
_______________________________________________________________________________________
Date:
___________________________
Customer:
____________________________________________________________________________________________
Date:
___________________________
*IF EQUIPPED
Android Auto
™ / Apple CarPlay
®
Setup* - Page 42 UVO link Activation / UVO Assistance* - Page 43 Kia Access with UVO link App Download – page 44 Kia Access with UVO link App

Features Guide – page 44
For more information, refer to the

Car Infotainment System Quick Reference Guide.
Standard Audio System - Value with UVO link* – Page 45For further operational information, refer to the Car Infotainment System Quick Reference Guide.
UVO link with Navigation* - Page 46 For further operational information,

refer to the Car Infotainment System Quick Reference Guide.
Smar t Cruise Control

with Stop & Go – page 24Demonstrate operation.

Bluetooth
® Wireless Technology

– page 40-41Demonstrate operation.MEDIARADIO
TRACK
>SETUP< SEEK
POWERPUSH
VOL ENTER
TUNE
FILE
SETUP
N AV
MAP
MEDIA SEEK
RADIO
TRACK
POWERPUSH
VOL ENTER
TUNE
FILE
OK
MODE
OK CRUISE
MODE
OK
OK
OK
OK
OK
OKOK
OK
CRUISE
CRUISE
CRUISECRUISE
CRUISECRUISE
CRUISECRUISE
CRUISE
OK
MODE
OKCRUISE
MODE
OK
OK
OK
OK
OK
OKOK
OK
CRUISE
CRUISE
CRUISECRUISE
CRUISECRUISE
CRUISECRUISE
CRUISE
SORENTO HYBRID / PLUG-IN HYBRID
DELIVERY CHECKLIST
