KIA STINGER 2018 Features and Functions Guide

*IF EQUIPPED ALWAYS CHECK THE OWNER’S MANUAL FOR COMPLE TE OPER ATING INFORMATION AND SAFE T Y WARNINGS.49
MAINTENANCE
18,000 Miles
PERFORM:
§ Add fuel additives1
§ Rotate tires
REPLACE:
§ Engine oil and filter
§ Climate control air filter
INSPECT*:
§ Air conditioning refrigerant
§ Air conditioner compressor
§ Battery Condition
§ Brake lines, hoses and connections
§ Disc brakes and pads
§ Drive shafts and boots
§ Exhaust pipe and muffler
§ Intercooler in/out hose, air intake hose
§ Propeller shaft
§ Steering gear rack, linkage and boots
§ Suspension mounting bolts
§ Vacuum hose
*And, if necessary, adjust, correct, clean or replace
1 If TOP TIER detergent gasoline is not available, one bottle of additive is recommended. Additives are available from your authorized Kia dealer along with information on how to use them. Do not mix other additives.
24,000 Miles
PERFORM:
§ Add fuel additives1
§ Rotate tires
REPLACE:
§ Engine oil and filter
§ Climate control air filter
§ Air cleaner filter
INSPECT*:
§ Air conditioning refrigerant
§ Air conditioner compressor
§ Battery Condition
§ Brake fluid
§ Brake lines, hoses and connections
§ Cooling System
§ Disc brakes and pads
§ Drive shafts and boots
§ Exhaust pipe and muffler
§ Fuel tank air filter2
§ Fuel lines, hoses and connections
§ Intercooler in/out hose, air intake hose
§ Parking brake
§ Propeller shaft
§ Steering gear rack, linkage and boots
§ Suspension mounting bolts
§ Vacuum hose
§ Vapor hose, fuel filler cap and fuel tank
*And, if necessary, adjust, correct, clean or replace
1 If TOP TIER detergent gasoline is not available, one bottle of additive is recommended. Additives are available from your authorized Kia dealer along with information on how to use them. Do not mix other additives.2 Fuel tank air filter are considered to be maintenance free but periodic inspection is recommended for this maintenance schedule, depends on fuel quality. If there are some important safety matters like fuel flow restriction, surging, loss of power, hard starting problem etc., replace the fuel filter immediately regardless of maintenance schedule and consult an authorized Kia dealer for details.

50
MAINTENANCE
30,000 Miles
PERFORM:
§ Add fuel additives1
§ Rotate tires
REPLACE:
§ Engine oil and filter
§ Climate control air filter
INSPECT*:
§ Air conditioning refrigerant
§ Air conditioner compressor
§ Battery Condition
§ Brake lines, hoses and connections
§ Disc brakes and pads
§ Drive shafts and boots
§ Exhaust pipe and muffler
§ Intercooler in/out hose, air intake hose
§ Propeller shaft
§ Steering gear rack, linkage and boots
§ Suspension mounting bolts
§ Vacuum hose
*And, if necessary, adjust, correct, clean or replace
1 If TOP TIER detergent gasoline is not available, one bottle of additive is recommended. Additives are available from your authorized Kia dealer along with information on how to use them. Do not mix other additives.
36,000 Miles
PERFORM:
§ Add fuel additives1
§ Rotate tires
REPLACE:
§ Engine oil and filter
§ Climate control air filter
§ Differential oil, rear ( With LSD)
INSPECT*:
§ Air cleaner filter
§ Air conditioning refrigerant
§ Air conditioner compressor
§ Battery Condition
§ Brake fluid
§ Cooling System
§ Differential oil, rear ( Without LSD)3,4
§ Differential oil, front (AWD)3
§ Disc brakes and pads
§ Drive shafts and boots
§ Exhaust pipe and muffler
§ Fuel tank air filter2
§ Fuel lines, hoses and connections
§ Intercooler in/out hose, air intake hose
§ Parking brake
§ Propeller shaft
§ Steering gear rack, linkage and boots
§ Suspension mounting bolts
§ Vacuum hose
§ Vapor hose, fuel filler cap and fuel tank
*And, if necessary, adjust, correct, clean or replace
1 If TOP TIER detergent gasoline is not available, one bottle of additive is recommended. Additives are available from your authorized Kia dealer along with information on how to use them. Do not mix other additives.2 Fuel tank air filter are considered to be maintenance free but periodic inspection is recommended for this maintenance schedule, depends on fuel quality. If there are some important safety matters like fuel flow restriction, surging, loss of power, hard starting problem etc., replace the fuel filter immediately regardless of maintenance schedule and consult an authorized Kia dealer for details.3 Front /rear differential oil should be changed anytime they have been submerged in water.4 When replacing differential oil with LSD, use only specified LSD oil.

ALWAYS CHECK THE OWNER’S MANUAL FOR COMPLE TE OPER ATING INFORMATION AND SAFE T Y WARNINGS.51
MAINTENANCE
42,000 Miles
PERFORM:
§ Add fuel additives1
§ Rotate tires
REPLACE:
§ Engine oil and filter
§ Climate control air filter
§ Spark Plugs (Every 42,000 miles)
INSPECT*:
§ Air conditioning refrigerant
§ Air conditioner compressor
§ Battery Condition
§ Brake lines, hoses and connections
§ Disc brakes and pads
§ Drive shafts and boots
§ Exhaust pipe and muffler
§ Intercooler in/out hose, air intake hose
§ Propeller shaft
§ Steering gear rack, linkage and boots
§ Suspension mounting bolts
§ Vacuum hose
*And, if necessary, adjust, correct, clean or replace
1 If TOP TIER detergent gasoline is not available, one bottle of additive is recommended. Additives are available from your authorized Kia dealer along with information on how to use them. Do not mix other additives.
48,000 Miles
PERFORM:
§ Add fuel additives1
§ Rotate tires
REPLACE:
§ Engine oil and filter
§ Climate control air filter
§ Air cleaner filter
INSPECT*:
§ Air conditioning refrigerant
§ Air conditioner compressor
§ Battery Condition
§ Brake fluid
§ Brake lines, hoses and connections
§ Cooling System
§ Disc brakes and pads
§ Drive shafts and boots
§ Exhaust pipe and muffler
§ Fuel tank air filter2
§ Fuel lines, hoses and connections
§ Intercooler in/out hose, air intake hose
§ Parking brake
§ Propeller shaft
§ Steering gear rack, linkage and boots
§ Suspension mounting bolts
§ Vacuum hose
§ Vapor hose, fuel filler cap and fuel tank
*And, if necessary, adjust, correct, clean or replace
1 If TOP TIER detergent gasoline is not available, one bottle of additive is recommended. Additives are available from your authorized Kia dealer along with information on how to use them. Do not mix other additives.2 Fuel tank air filter are considered to be maintenance free but periodic inspection is recommended for this maintenance schedule, depends on fuel quality. If there are some important safety matters like fuel flow restriction, surging, loss of power, hard starting problem etc., replace the fuel filter immediately regardless of maintenance schedule and consult an authorized Kia dealer for details.

52
MAINTENANCE
54,000 Miles
PERFORM:
§ Add fuel additives1
§ Rotate tires
REPLACE:
§ Engine oil and filter
§ Climate control air filter
INSPECT*:
§ Air conditioning refrigerant
§ Air conditioner compressor
§ Battery Condition
§ Brake lines, hoses and connections
§ Disc brakes and pads
§ Drive shafts and boots
§ Exhaust pipe and muffler
§ Intercooler in/out hose, air intake hose
§ Propeller shaft
§ Steering gear rack, linkage and boots
§ Suspension mounting bolts
§ Vacuum hose
*And, if necessary, adjust, correct, clean or replace
1 If TOP TIER detergent gasoline is not available, one bottle of additive is recommended. Additives are available from your authorized Kia dealer along with information on how to use them. Do not mix other additives.
60,000 Miles
PERFORM:
§ Add fuel additives1
§ Rotate tires
REPLACE:
§ Engine oil and filter
§ Climate control air filter
§ Fuel tank air filter2
INSPECT*:
§ Air cleaner filter
§ Air conditioning refrigerant
§ Air conditioner compressor
§ Battery Condition
§ Brake fluid
§ Brake lines, hoses and connections
§ Cooling System
§ Disc brakes and pads
§ Drive Belts3 (Every 60,000 miles, then every 12,000 miles)
§ Drive shafts and boots
§ Exhaust pipe and muffler
§ Fuel lines, hoses and connections
§ Intercooler in/out hose, air intake hose
§ Parking brake
§ Propeller shaft
§ Steering gear rack, linkage and boots
§ Suspension mounting bolts
§ Vacuum hose
§ Valve clearance4 (every 60,000 miles)
§ Vapor hose, fuel filler cap and fuel tank
*And, if necessary, adjust, correct, clean or replace
1 If TOP TIER detergent gasoline is not available, one bottle of additive is recommended. Additives are available from your authorized Kia dealer along with information on how to use them. Do not mix other additives.2 Fuel tank air filter are considered to be maintenance free but periodic inspection is recommended for this maintenance schedule, depends on fuel quality. If there are some important safety matters like fuel flow restriction, surging, loss of power, hard starting problem etc., replace the fuel filter immediately regardless of maintenance schedule and consult an authorized Kia dealer for details.3 The drive belt should be replaced when cracks occur or tension is reduced.4 Inspect for excessive valve noise and/or engine vibration and adjust if necessary. Have an authorized Kia dealer perform the operation

Driving while distracted is dangerous and should be avoided. Drivers should remain attentive to driving and always exercise caution when using the
steering-wheel-mounted controls while driving.
Driving while distracted can result in a loss of vehicle control that may lead to an accident, severe personal injury and death. The driver’s primary
responsibility is in the safe and legal operation of a vehicle, and use of any handheld devices, other equipment or vehicle systems which take the
driver’s eyes, attention and focus away from the safe operation of a vehicle or that are not permissible by law should never be used during operation
of the vehicle.
Safety Features: No system, no matter how advanced, can compensate for all driver error and/or driving conditions. Always drive responsibly.
Airbags: For maximum protection, always wear your seat belt. Please refer
to your vehicle’s Owner’s Manual for additional important safety information
regarding airbags, including additional cautions and warnings.
Android Auto
™: Android Auto is a trademark of Google, Inc. Android™ is a
registered trademark of Google, Inc.
Apple CarPlay
®: Apple CarPlay® a registered trademark of Apple Inc.
Distracted driving can result in a loss of vehicle control.
Apps: All information contained herein was based upon the latest available
information at the time of appstore registration. Descriptions are believed to
be correct, and Kia makes every effort to ensure accuracy, however, accuracy
cannot be guaranteed. From time to time, Kia may need to update or make
changes to the vehicle features and other vehicle information reported in this
app. Kia, by the publication and dissemination of this material, does not create
any warranties, either express or implied, to any Kia products. Contact your
local Kia dealer for the most current information.
Bluetooth
® Wireless Technology: The Bluetooth® word mark and logos
are registered trademarks owned by Bluetooth SIG Inc., and any use of
such marks by Kia is pursuant to license. A Bluetooth
® enabled cell phone is
required to use Bluetooth® wireless technology.
Driver Assist Features: Smart Cruise Control (SCC), Blind-Spot Collision
Warning (BCW ) with Lane Change Assist, Rear Cross Traffic Alert (RCTA),
Lane Keeping Assist/Lane Departure Warning, Rear-Camera Display:
These features are not substitutes for safe driving, and may not detect all
objects surrounding vehicle. Always drive safely and use caution.
Electronic Stability Control (ESC)/ Traction Control System ( TCS)/Hill-start
Assist Control (HAC): No system, no matter how advanced, can compensate
for all driver error and/or driving conditions. Always drive responsibly.
Engine Start/Stop Button with Smart Key: Always come to a complete stop
before turning the engine on or off. However, if you have an emergency while
the vehicle is in motion and must turn the engine off, you can turn the engine
off to the ACC position by pressing the Start /Stop button for more than 3
seconds or 3 times in succession. If the vehicle is still moving, you can restart
the engine by pressing the Start /Stop button with the shift lever in Neutral (N).
With the engine off, hydraulic power assist for steering and braking will be
disabled and the vehicle will be more dif ficult to control.
Google Play
™ Store is a trademark of Google, Inc. © 2017 Google Inc. All
rights reserved. Google and the Google Logo are registered trademarks of
Google Inc.
Head-Up Display (HUD): Failure to pay attention to travel conditions and
vehicle operation could result in loss of vehicle control. Always drive safely
and use caution.
HomeLink
®: Homelink® is a registered trademark of Gentex Corporation
iPod®/iPhone® are registered trademarks of Apple Inc. iPod® mobile
digital device sold separately.
Navigation: Distracted driving can result in a loss of vehicle control. When
operating a vehicle, never use a vehicle system that takes your focus away
from safe vehicle operation. Navigation is for information purposes only, and
Kia does not make any warranties about the accuracy of the information.
Occupant Detection System (ODS): Kia vehicles use a number of different
ODS types that vary by model. Children age 12 and under should always be
seated in the RE AR seats.
Parking Assist System: The Parking Assist System is not a substitute for
proper and safe backing-up procedures. The Parking Assist System may not
detect every object behind the vehicle. Always drive safely and use caution
when backing up. Rear-Camera Display: The Rear-Camera Display are not substitutes for
proper and safe backing-up procedures. The Rear-Camera Display may not
display every object behind the vehicle. Always drive safely and use caution
when backing up.
Roadside Assist:
24-hour Enhanced Roadside Assistance is a service plan
provided by Kia Motors America, Inc. Certain limitations apply. Coverage
details are available in the Kia Warranty and Consumer Information Manual.
For access to Enhanced Roadside Assistance, a connected mobile phone via
Bluetooth
® within the cellular service coverage area is required.
Seat adjustments: Reclining the passenger seats can reduce the
effectiveness of the safety restraint system and may lead to additional injury
in an accident.
Seat belts: For maximum protection, always wear your seatbelt.
Seat warmers: Use extreme caution when using the seat warmers to avoid
burns. Refer to the Owner’s Manual for more information.
Siri
®: Siri® is a registered trademark of Apple, Inc.
SiriusXM®: SiriusXM Satellite Radio, SiriusXM Traf fic and SiriusXM Travel
Link each require a subscription sold separately, or as a package, by SiriusXM
Radio Inc. If you decide to continue your service at the end of your
trial subscription, the plan you choose will automatically renew and bill
at then-current rates until you call 1-866-635-2349 to cancel. See SiriusXM Customer Agreement for complete terms at siriusxm.com.
Other fees and taxes will apply. All fees and programming are subject to
change. Not all vehicles or devices are capable of receiving all services
offered by SiriusXM. Data displays and individual product availability vary by
vehicle hardware. Current information and features may not be available in all
locations, or on all receivers. Weather Forecast, Current Conditions may not be
available in all locations. Images above are for representative purposes only
and are not real products. For actual features and images of real products,
consult the vehicle manufacturer. SiriusXM is not responsible for any errors
or inaccuracies in the data services or their use in the vehicle. Travel Link
Stocks displays current price and daily delta of around 7,000 actively reported
securities traded on the NYSE
®, NASDAQ® and AME X®. The service is delayed
approximately 20 minutes. SiriusXM satellite service is available only to those
at least 18 years of age in the 48 contiguous USA, DC, and Puerto Rico (with
coverage limitations). SiriusXM Internet Radio service is available throughout
our satellite service area and in AK and HI. © 2017 SiriusXM Radio Inc. Sirius,
XM and all related marks and logos are trademarks of SiriusXM Radio Inc.
Smart Power Liftgate*: Driving with the Liftgate open may be unlawful and
can draw dangerous exhaust fumes into your vehicle; if you choose to do so,
keep air vents and all windows open for proper ventilation.
Steering-wheel-mounted controls: Driving while distracted is dangerous
and should be avoided. Remain attentive to driving and be cautious when
using steering-wheel-mounted controls while driving.
Sunvisors: Sunvisor may not shield all direct light. Do not operate the vehicle
if sunvisor is impairing your visibility.
Tire Pressure Monitoring System (TPMS): Even with Tire Pressure
Monitoring System, check tire pressure on regular basis.
UVO: Distracted driving can result in a loss of vehicle control. Never use a
handheld device or vehicle system that takes your focus away from safe
vehicle operation.
UVO link / UVO eco app: App uses your smartphone data service. Normal
cellular service rates will apply.
UVO with Premium Navigation: Distracted driving can result in a loss of
vehicle control. Never use a handheld device or vehicle system that takes
your focus away from safe vehicle operation. Navigation is for information
purposes only, and Kia does not make any warranties about the accuracy of
the information.
LEGAL DISCLAIMERS

© 2017 Kia Motors America, Inc. All rights reserved. Part Number: US180-PS-004

CRUISE
CANCEL
RESOKSET
Sales Consultant:
Sales Manager:
Customer: Date:
Date:
Date:
STINGER CUSTOMER DELIVERY CHECKLIST
Smart Cruise Control (SCC) with
Stop & Go* – page 22
Demonstrate operation
Key Feature Walkthrough
During Delivery Aux/USB/iPod® Port, Power Outlets & USB Charger – page 30
Blind-Spot Collision Warning (BCW )*
– page 13
Clock Setup – page 30
Electric Parking Brake (EPB) / Auto Hold* - pages 33-34
Engine S tar t / S top Button – page 18
Head-Up Display (HUD)* – page 10
Sunroof Operation – page 42
Parking Assist System – page 16
Passenger Air Bag Off Indicator –
page 47
Front Seat Headrest Adjustment* –
page 37
Seat Warmers/ Ventilated Seats –
page 35
Smart Key – page 40
Sunvisor – page 44
Tire Pressure Monitoring System
( TPMS) – page 6
Explain first service process and schedule first service appointment
Tour Parts & Service departments, introduce staff and explain value of
Kia Parts and Service
Review recommended maintenance schedule and maintenance
requirements to validate warranty
Review business hours and Customer 360° Care
Review the Kia 10-year/100,000-mile warranty program
Ensure 100% satisfaction with sales and delivery process and no
problems with the vehicle
Confirm time and best contact number for initial dealer follow-up
Bluetooth® Wireless
Technology – pages 24-25 Demonstrate operation
Auto-Dimming Rearview Mirror
with HomeLink® – page 4 3
Windshield Wipers &
Washers – page 21
FRONT
MIST
OFF
AUTO LOHIAUTO
CRUISE
CANCEL
RESOKSET
MODE MODE

P
R
N D
+
-
AUTOSYNCOFF CLIMATE
A/C
REAR
FRONT
STINGER CUSTOMER DELIVERY CHECKLIST
Confirm “Good Battery” with Kia GR8-1299 battery tester
Verify all tire pressures are to spec (see driver’s door label) LF LR RF RR
Verify proper operation of Smart Key* lock /unlock
Ensure floormats are snapped into place (if applicable)
Verify vehicle is clean (interior and exterior), in good condition, free of chips and scratches
Ensure all key documents are in the vehicle (Owner’s Manual, Warranty and Consumer Information booklet, Tire Warranty booklet,
Features & Functions Guide and any supplemental audio/video/navigation user’s guides)
Automatic Transmission / Sport Shift Mode*
– page 32
Automatic Climate Control – page 31 Demonstrate Air Flow Modes, Defog and Defrosting Windshield
Fan Speed.
UVO – pag e s 2 7-2 8 For further system operation, refer to the Car Multimedia
System User’s Manual.
UVO / Android Auto™ / Apple CarPlay® Setup*
– page 27
UVO with Premium Navigation System – page 29 For further system operation, refer to the Car Multimedia
System User’s Manual.
UVO / Android Auto™ / Apple CarPlay® Setup*
– page 27
Before Delivery
Key Feature Walkthrough
Owner’s Name: ____________________________________ VIN:
_______________________ Mileage: _ _________________ Dealership Name:
______________________
Sales Consultant:
_________________________________ Date:
__________
RADIO
MEDIA SEEK
PASSENGERPASSENGER
AIR BAGOFFTRACK APPS/
PHONE SETUPUVORADIO
MEDIA SEEK
PASSENGERPASSENGER
AIR BAGOFFTRACK MAP
N AVSETUPMAP
