display KIA STINGER 2021 Owner's Manual

479
Features of your vehicle
Trip computer mode
This mode displays driving information
like the tripmeter, fuel economy, and
so on.
❈ For more details, refer to “Trip
Computer” in this chapter.
Turn By Turn Mode (if equipped)
This mode displays the state of the
navigation.
Assist mode (if equipped)
SCC/LKA/DAW
This mode displays the state of the
Smart Cruise Control (SCC), Lane
Keeping Assist (LKA) and Driver
Attention Warning (DAW).
❈ For more details, refer to each sys-
tem information in chapter 5.
OCK047465NOYG046123NOCK047115N

Features of your vehicle
80 4
Tire Pressure
This mode displays information relat-
ed to Tire Pressure.
❈ For more details, refer to "Tire
Pressure Monitoring System
(TPMS)" in chapter 6.
Service mode
When Service Required is set, the
remaining distance/time before serv-
ice is required appears on the LCD
screen.
From the point at which the remain-
ing distance to drive amounts to 900
mi. (1,500 km) or the remaining time
amounts to 3 days, the Service
Required message automatically
displays and remains on the LCD
screen for a number of seconds
every time the engine start/stop but-
ton is ON.When Service Required is set, a
Service Required Alarm message
pops up when an aggregated
amount of miles/time driven reaches
a certain point.
With Service Required mode, press
OK button for more than 1 second.
The values will return to initial setting
values.
❈See User Settings
Mode in this chapter for further infor-
mation about Service Required
Setting.
❈Service Required Setting
If the Battery Cable is disconnected,
Fuse Switch is turned OFF, the
Service Required Setting values (an
amount of miles/time driven) may
change. In this situation, re-enter
Service Required settings.
OCK047117N
OCK067025L

Features of your vehicle
82 4
If the estimated distance is below 1
mi. (1 km), the trip computer will
display “---” as distance to empty.
✽ ✽
NOTICE
• If the vehicle is not on level ground
or the battery power has been
interrupted, the distance to empty
function may not operate correct-
ly.
• The distance to empty may differ
from the actual driving distance as
it is an estimate of the available
driving distance.
• The trip computer may not regis-
ter additional fuel if less than 1.6
gallons (6 liters) of fuel are added
to the vehicle.
• The fuel economy and distance to
empty may vary significantly
based on driving conditions, driv-
ing habits, and condition of the
vehicle.
User Settings Mode
Description
On this mode, you can change set-
ting of the doors, lamps, and so on.
Shift to P to edit settings
This warning message appears if
you try to adjust the User Settings
while driving.
For your safety, change the User
Settings after parking the vehicle,
applying the parking brake by press-
ing the parking “P” button.OCK049140L
WARNING
Do not adjust the User Setting
while driving. You may lose your
steering control which could
cause an accident and severe
bodily injury.
OCK047142L

483
Features of your vehicle
Head-Up Display (HUD) (if equipped)
Enable Head-Up Display : If this
item is checked, Head-Up Display
will be activated.
Display Height : Adjust the height
of the HUD image on the wind-
shield glass.
Rotation : Adjust the degree of the
HUD rotation.
Brightness : Adjust the intensity of
the HUD brightness.
Content Selection : If below items
are checked, the items will be acti-
vated.
- Tu r n b y Tu r n
- Traffic Signs
- Driving Assist Info
- Lane Safety Info
- Blind-Spot Safety Info
Speed size :
Small/Medium/Large
Speed color :
White/Orange/GreenDriver Assistance
SCC Reaction (if equipped)
- Choose the sensitivity (slow, nor-
mal, fast) of the smart cruise con-
trol.
❈For more details, refer to “Smart
Cruise Control with Stop & Go” in
chapter 5.
Driver Attention Warning (if
equipped) : Choose the alert stage
(Off/Normal/Early stage) of the
Driver Attention Warning.
Lane Safety (if equipped) :
- Active LKA : To activate the active
LKA mode.
- Standard LKA : To activate the
standard LKA mode.
- Lane Departure Warning : To acti-
vate the lane departure warning
function.
❈For more details, refer to “Lane
Keeping Assist (LKA) system” in
chapter 5. Forward Collision-Avoidance
Assist (FCA, if equipped) :
- To activate or deactivate the FCA
system.
❈For more details, refer to “Forward
Collision-Avoidance Assist (FCA)
system” in chapter 5.
Forward Collision Warning
(FCW, if equipped)
- Choose the sensitivity of the for-
ward collision warning.
(Late/Normal/Early)
❈For more details, refer to “Forward
Collision-Avoidance Assist (FCA)
system” in chapter 5.
Blind-Spot Collision Warning (if
equipped)
- If this item is checked, Blind-Spot
Collision Warning function will be
activated.
❈For more details, refer to “Blind-Spot
Collision Warning (BCW) system” in
chapter 5.

Features of your vehicle
86
4
• Steering Easy Access (if
equipped)
- On (checked) : The steeringwheel will automatically move to
the top of Steering column when
leaving the vehicle and move to
the last saved position when
entering the vehicle for the driver
to enter or exit the vehicle com-
fortably.
- Off (unchecked) : The steering easy access function will be
deactivated.
❈ For more details, refer to “Driver
Position Memory System” in chap-
ter 3.
Welcome Mirror/Light (if equipped) : - If this item is checked, the wel-come Mirror/light function will be
activated.
Wiper/Light Display (if equipped) : If this item is checked, the
Wiper/Light Display will be activat-
ed.
Gear Position Pop-up (if equipped) : If this item is checked, the gear
position pop-up display will be acti-
vated. Icy road warning (if equipped) : If
this item is checked, the Icy road
warning display will be activated.
Lateral seat support enhancement (if equipped)
- If this item checked, it increaseslateral seat bolster support.
Service interval
Service Interval If this item checked, it displays an
alert when a specified service
interval is reached.
Adjust Interval To set the service interval reminder
time and distance.
Reset To reset the service interval
reminder time and distance.
✽ ✽ NOTICE
To use the service interval menu,
consult an authorized Kia dealer.
Other features
Fuel Economy Auto Reset
- Off : The average fuel economywill not reset automatically when-
ever refueling.
- After Ignition : The average fuel economy will reset automatically
whenever it has passed 4 hours
after turning OFF the engine.
- After Refueling : The average fuel economy will reset automatically
when refueling.
❈ For more details, refer to “Trip
Computer” in this chapter.
Fuel Economy Unit - Choose the fuel economy unit.(US gallon, UK gallon)
Temperature Unit - Choose the temperature unit.(°C,°F)

489
Features of your vehicle
Door, Hood, Liftgate Open
It means that a door, hood, or lift-
gate is open.
The hood warning message will
appear on the LCD display when
hood is open.
The warning chime will operate
when the vehicle is being driven at
or above 2 mph (3 km/h) with the
hood open.
Sunroof Open (if equipped)
This warning message illuminates
if you turn off the engine and then
open the driver's door when the
sunroof is open.
Icy Road Warning Light
(if equipped)
This warning pop-up message and
light are to warn the driver the road
may be icy.
When the Outside Temperature is
below approximately 39°F (4°C),
- The warning light (including
Outside Temperature) blinks 5
times and then illuminates.
- The warning pop-up message dis-
plays, and the warning chime
sounds once at the same time only
once for each ignition cycle.
OCK047124LOCK047123L
OCK047152N

Features of your vehicle
90 4
✽
✽
NOTICE
If the icy road warning light appears
while driving, you should drive
more attentively and refraining
from speeding, rapid acceleration,
sudden braking or sharp turning.
Check headlight LED
This warning message illuminates if
LED headlamp malfunctions.
Check headlight cooling fan
This warning message illuminates if
LED headlamp cooling fan malfunc-
tions.
Check shift lever
(if SBW equipped)
If there is a problem with the SBW
(Shift-By-Wire) system, this warning
message is displayed.
Low Washer Fluid
This warning message illuminates
on the service reminder mode if
the washer fluid level in the reser-
voir is nearly empty.
It means that you should refill the
washer fluid.
Turn on FUSE SWITCH
This warning message illuminates
if the fuse switch under the steer-
ing wheel is OFF.
It means that you should turn the
fuse switch on.
❈For more details, refer to “Fuses”
in chapter 7.

491
Features of your vehicle
Check headlights (if equipped)
This warning message illuminates if
there is a malfunction (burned-out
bulb or circuit malfunction) with the
head lights (high and low beam). In
this case, have the vehicle inspected
by an authorized Kia dealer.
✽ ✽
NOTICE
• When replacing the bulb, use the
same wattage bulb.
For more information, refer to
“BULB WATTAGE” in chapter 8.
• If the different wattage bulb is
equipped with the vehicle, this
warning message is not displayed.
Low Fuel
This warning message illuminates
if the fuel tank is nearly empty.
- When the low fuel level warning
light is illuminated, add fuel as
soon as possible.
Device in Wireless Charger
(if equipped)
If a smart phone is still left in the
wireless charging pad unattended,
even when the Engine Start/Stop
Button is in the ACC or OFF position,
a warning message will appear on
the instrument panel.
❈For more details, refer to “Smart
Phone Wireless Charger” in this
chapter.

Features of your vehicle
98 4
Low Tire Pressure
Warning Light
This warning light illuminates:
Once you set the Engine Start/Stop
Button to the ON position.
- It illuminates for approximately 3
seconds and then goes off.
When one or more of your tires are
significantly underinflated (The
location of the underinflated tires
are displayed on the LCD display).
❈For more details, refer to “Tire
Pressure Monitoring System
(TPMS)” in chapter 6.
The TPMS cannot alert you to
severe and sudden tire damage
caused by external factors.
If you notice any vehicle instability,
immediately take your foot off the
accelerator pedal, apply the brakes
gradually with light force, and slow-
ly move to a safe position off the
road.This warning light remains on after
blinking for approximately 60 seconds
or repeats blinking on and off at the
intervals of approximately 3 seconds:
When there is a malfunction with
the TPMS.
In this case, have the vehicle
inspected by an authorized Kia
dealer.
❈For more details, refer to “Tire
Pressure Monitoring System
(TPMS)” in chapter 6.
LED Headlamp Warning
Light (if equipped)
This warning light illuminates:
Once you set the Engine Start/Stop
Button to the ON position.
- It illuminates for approximately 3
seconds and then goes off.
When there is a malfunction with
the LED headlamp.
In this case, have the vehicle inspect-
ed by an authorized Kia dealer.
This warning light blinks:
When there is a malfunction with a
LED headlamp related part.
In this case, have the vehicle inspect-
ed by an authorized Kia dealer.
✽ ✽
NOTICE
Continuous driving with the LED
Headlamp Warning Light on or
blinking can reduce LED headlamp
(low beam) life.
WARNING - Low tire
pressure
Significantly low tire pressure
makes the vehicle unstable
and can contribute to loss of
vehicle control and increased
braking distances.
Continued driving on low pres-
sure tires will cause the tires to
overheat and fail.

4105
Features of your vehicle
Description
The Head Up Display is a transpar-
ent display which projects some
information of the instrument cluster
and navigation on the windshield
glass. The Head Up Display image on the
windshield glass may not be visible
when:
- Sitting posture prevents visibility.
- Wearing polarized sunglasses.
- There is an object on the cover of
the head up display.
- Driving on a wet road.
- Lighting is turned on inside the
vehicle.
- Any light comes from the outside.
- Wearing inadequate glasses for
your eyesight.
If the Head Up Display image is not
shown well, adjust the height, rota-
tion or illumination of the Head Up
Display in the LCD window.
❈For more details, refer to “LCD
window” in this chapter.
When the Head Up Display needs
inspection or repair, consult an
authorized Kia dealer.
Do not place any accessories on
the dashboard or attach any
objects on the windshield glass.
✽ ✽
NOTICE
Installing window tint or any other
type of metallic coating on the wind-
shield can prevent the driver from
seeing the Head Up Display images.
✽ ✽
NOTICE
When replacing the front wind-
shield glass of vehicles equipped
with the head up display, replace it
with a windshield glass designed for
the Head Up Display operation.
Otherwise, duplicated images may
be displayed on the windshield glass.
HEAD UP DISPLAY (HUD) (IF EQUIPPED)
OCK048467N
WARNING - Head Up
Display
The Head Up Display is a sup-
plemental system. Do not solely
rely on the system, always drive
safely, and pay attention to the
driving conditions on the road.
