Pressure Monitoring Telltale Light”
will turn off. The vehicle may need to
be driven for up to 20 minutes above
24 km/h in order for the TPMS to
receive this information.
Check TPMS WarningWhen a system fault is detected, a chime
will sound and the “Tire Pressure Moni-
toring Telltale Light” will flash on and
off for 75 seconds and then remain on
solid. In addition, the EVIC will display
a "CHECK TPM SYSTEM" message for
a minimum of five seconds and then
display dashes (- -) in place of the pres-
sure value to indicate which sensor is
not being received.If the ignition key is cycled, this se-
quence will repeat, providing the sys-
tem fault still exists. If the system
fault no longer exists, the “Tire Pres-
sure Monitoring Telltale Light” will
no longer flash, and the "CHECK
TPM SYSTEM" message will no lon-
ger display, and a pressure value willdisplay in place of the dashes. A sys-
tem fault can occur due to any of the
following:
1. Jamming due to electronic devices
or driving next to facilities emitting
the same Radio Frequencies as the
TPM sensors.
2. Installing some form of aftermar-
ket window tinting that affects radio
wave signals.
3. Lots of snow or ice around the
wheels or wheel housings.
4. Using tire chains on the vehicle.
5. Using wheels/tires not equipped
with TPM sensors.
The EVIC will also display a
"CHECK TPM SYSTEM" message
for a minimum of five seconds when a
system fault related to an incorrect
sensor location fault is detected. In
this case, the "CHECK TPM SYS-
TEM" message is then followed with a
graphic display with pressure values
still shown. This indicates that thepressure values are still being received
from the TPM sensors but they may
not be located in the correct vehicle
position. The system still needs to be
serviced as long as the "CHECK TPM
SYSTEM" message is displayed.
FUEL REQUIREMENTS
All engines are designed to meet all
emissions regulations and provide ex-
cellent fuel economy and performance
when using high quality unleaded
gasoline with a minimum research oc-
tane rating of 91.
Light spark knock at low engine
speeds is not harmful to your engine.
However, continued heavy spark
knock at high speeds can cause dam-
age and immediate service is required.
Poor quality gasoline can cause prob-
lems such as hard starting, stalling,
and hesitations. If you experience
these symptoms, try another brand of
gasoline before considering service for
the vehicle.
164

 If frequent engine coolant (anti-freeze) additions are required, or if
the level in the coolant recovery
bottle does not drop when the en-
gine cools, the cooling system
should be pressure tested for leaks.
Maintain engine coolant (antifreeze)
concentration at 50% engine coolant
(antifreeze) (minimum) and dis-
tilled water for proper corrosion pro-
tection of your engine, which con-
tains aluminum components. Make sure that the radiator and coolant recovery bottle overflow
hoses are not kinked or obstructed.
 Keep the front of the radiator clean. If your vehicle is equipped with air
conditioning, keep the front of the
condenser clean.
Do not change the thermostat for
Summer or Winter operation. If re-
placement is ever necessary, install
ONLY the correct type thermostat.
Other designs may result in unsatis-
factory cooling performance, poor
gas mileage, and increased emissions.
BRAKE SYSTEMIn order to assure brake system perfor-
mance, all brake system components
should be inspected periodically. Refer
to the “Maintenance Schedule” for the
proper maintenance intervals.WARNING!
Riding the brakes can lead to brake
failure and possibly a collision.
Driving with your foot resting or
riding on the brake pedal can result
in abnormally high brake tempera-
tures, excessive lining wear, and
possible brake damage. You would
not have your full braking capacity
in an emergency.CAUTION!
Car maintenance should be done at
a LANCIA Dealership. For routine
and minor maintenance operations
you wish to carry out yourself, we
do recommend you have the proper
equipment, genuine LANCIA spare
parts and the necessary fluids; do
not however carry out these opera-
tions if you have no experience. Master Cylinder – Brake Fluid
Level Check
Check the fluid level in the master cyl-
inder immediately if the brake system
warning light indicates system failure.
Check the fluid level in the master cyl-
inder when performing underhood ser-
vices.Clean the top of the master cylinder
area before removing the cap. If nec-
essary, add fluid to bring the fluid
level up to the requirements described
on the brake fluid reservoir.
Overfilling of fluid is not recom-
mended because it may cause leaking
in the system.
Fluid level can be expected to fall as
the brake pads wear. Brake fluid level
should be checked when pads are re-
placed. However, low fluid level may
be caused by a leak and a checkup
may be needed.
Use only manufacturer's recom-
mended brake fluid. Refer to “Fluids,
Lubricants, and Genuine Parts” in
“Maintaining Your Vehicle” for fur-
ther information.
201

Thousands Of Kilometers 24 48 72 96 120 144 168 192Months 12 24 36 48 60 72 84 96
Check windshield/rear window wiper blade position/wear.
Check cleanliness of hood and tailgate locks and cleanliness
and lubrication of linkages.
Visually inspect condition of: exterior bodywork, underbody
protection, pipes and hoses (exhaust - fuel system - brakes),
rubber elements (boots, sleeves, bushes, etc.).
Check conditions and wear of front disc brake pads.
Check conditions and wear of rear disc brake pads.
Check and, if necessary, top up fluid levels (brakes, windshield
washer, battery, engine coolant, etc.).
Visually inspect the condition of accessory drive belt/s.
Check the handbrake lever stroke and adjust it, if necessary.
Check exhaust gas emissions.
Check engine management system operation (via diagnostic
socket).
Change the automatic transmission fluid and filter. (*)
Replace spark plugs.
Replace air filter cartridge.
Change engine oil and replace oil filter.**
Change brake fluid (or every 24 months).
Replace pollen filter.
(*) Change the automatic transmis-
sion fluid and filter(s) at 96 kkm or
48 months if using your vehicle for
any of the following: city driving, short (less than 7-8 km) and repeated
journeys, or frequent trailer or cara-
van towing.
** The engine oil and the oil filter
must be changed when the instrument
panel warning light comes on or in
any case every 12 months.
223

Periodic Checks
Every1,000 km or before long jour-
neys, check and, if necessary, restore:
 engine coolant;
 brake fluid;
 Power Steering Fluid;
 windshield washer fluid level;
 power steering fluid;
tire inflation pressure and condition; operation of lighting system (head- lights, direction indicators, hazard
warning lights, etc.);
 operation of windshield washer/ wiper system and positioning/wear
of windshield/rear window wiper
blades.
Every 3,000 km, check and top up, if
required, the engine oil level. Heavy-Duty Use Of The Car
If the car is used mainly under one of
the following conditions:
 towing a trailer or caravan;
 dusty roads;

short, repeated journeys (less than
7-8 km) at sub-zero outside
temperatures; engine often idling or driving long
distances at low speeds or long pe-
riods of idleness.
You should perform the following in-
spections more frequently than shown
on the Scheduled Servicing Plan:
 check front disc brake pad condi- tions and wear;
 check cleanliness of hood and trunk locks, cleanliness and lubrication of
linkage;  visually inspect conditions of: en-
gine, transmission, pipes and hoses
(exhaust - fuel system - brakes) and
rubber elements (boots - sleeves -
bushes - etc.);
 check battery charge and battery fluid level (electrolyte);
 visually inspect condition of the accessory drive belts;
 check and, if necessary, change engine oil and replace oil filter;
 check and, if necessary, replace pol- len filter;
 check and, if necessary, replace air cleaner.
224

About Your Brakes. . . . . . . . . . .150
ABS (Anti-Lock Brake System) . . .151
Adding Engine Coolant (Antifreeze) . . . . . . . . . . . . . .199
Adding Fuel . . . . . . . . . . . . . . .167
Adding Washer Fluid . . . . . . . . .196
Additives, Fuel . . . . . . . . . . . . . .166
Airbag . . . . . . . . . . . . . . . . . . . .31
Airbag Deployment . . . . . . . . . . .36
Airbag Light . . . . . . .34, 37, 49, 112
Airbag Maintenance . . . . . . . . . . .37
Airbag, Side . . . . . . . . . . .32, 34, 35
Airbag, Window (Side Curtain) . . . .34
Air Cleaner, Engine (Engine Air Cleaner Filter) . . . . . . . . . .192
Air Conditioner Maintenance . . . .194
Air Conditioning Filter . . . . .136, 194
Air Conditioning, Operating Tips . . . . . . . . . . . .135
Air Conditioning Refrigerant . . . .194
Air Conditioning System . . .129, 194
Air Pressure, Tires . . . . . . . . . . .157
Alarm (Security Alarm) . . . . . . . . .15
Alarm System (Security Alarm) . . . . . . . . . . . . . .15, 116
Alterations/Modifications, Vehicle . . .7
Antifreeze (Engine Coolant) . . . . . . . . . . . .198, 216
Disposal . . . . . . . . . . . . . . .200 Anti-Lock Brake System (ABS)
. . .151
Anti-Lock Warning Light . . . . . .151
Anti-Theft Security Alarm (Theft Alarm) . . . . . . . . . . . . .15
Ashtray . . . . . . . . . . . . . . . . . .103
Auto Down Power Windows . . . . . .20
Automatic Door Locks . . . . . . . . .19
Automatic Headlights . . . . . . . . . .94
Automatic Oil Change Indicator . . . . . . . . . . . .114, 121
Automatic Temperature Control (ATC) . . . . . . . . . . . .129
Automatic Transaxle . . . . . . .12, 140
Automatic Transmission . . . .141, 202
Adding Fluid . . . . . . . . . . . .203
Fluid and Filter Changes . . . .203
Fluid Level Check . . . . . . . . .203
Fluid Type . . . . . . . . . . . . . .202
Gear Ranges . . . . . . . . . . . . .143
Autostick . . . . . . . . . . . . . . . . .147
Auto Unlock, Doors . . . . . . . . . . .19
Battery . . . . . . . . . . . . . . . . . . .193
Keyless Transmitter
Replacement (RKE) . . . . . . . . .18
Location . . . . . . . . . . . . . . .193
Belts, Seat . . . . . . . . . . . . . . .24, 48
Body Mechanism Lubrication . . . .195
Brake Assist System . . . . . . . . . .154 Brake, Parking
. . . . . . . . . . . . . .150
Brakes . . . . . . . . . . . . . . . . . . .201
Brake System . . . . . . . . . . . . . . .201
Anti-Lock (ABS) . . . . . . . . . .151
Fluid Check . . . . . . . . . . . . .201
Master Cylinder . . . . . . . . . .201
Parking . . . . . . . . . . . . . . . .150
Warning Light . . . . . . . . . . .112
Brake/Transmission Interlock . . . .142
Break-In Recommendations, New Vehicle . . . . . . . . . . . . . . .47
Bulb Replacement . . . . . . . .212, 213
Bulbs, Light . . . . . . . . . . . . .50, 212
Calibration, Compass . . . . . . . . .123
Capacities, Antifreeze (Engine Coolant) . . . . . . . . . . .16
Capacities, Fluid . . . . . . . . . . . .216
Caps, Filler Fuel . . . . . . . . . . . . . . . . . .167
Oil (Engine) . . . . . . . . . . . . .189
Power Steering . . . . . . . . . . .153
Radiator (Coolant Pressure) . .199
Carbon Monoxide Warning . . . . . .48
Car Washes . . . . . . . . . . . . . . . .204
Cellular Phone . . . . . . . . . . .67, 129
Checking Your Vehicle For Safety . . . . . . . . . . . . . . . . . . .47
Checks, Safety . . . . . . . . . . . . . . .47
226

Child Restraint. . .39, 41, 42, 44, 45
Child Restraint Tether Anchors . . . . . . . . . . . . . . .43, 44
Cigar Lighter . . . . . . . . . . . . . . .103
Clean Air Gasoline . . . . . . . . . . .165
Cleaning Wheels . . . . . . . . . . . . . . . .205
Windshield Wiper Blades . . . .196
Climate Control . . . . . . . . . . . . .129
Clock . . . . . . . . . . . . . . . . . . . .127
Compass . . . . . . . . . . . . . . . . . .122
Compass Calibration . . . . . . . . . .123
Compass Variance . . . . . . . . . . .123
Computer, Trip/Travel . . . . . .16, 122
Console . . . . . . . . . . . . . . . . . .104
Console, Floor . . . . . . . . . . . . . .104
Convertible . . . . . . . . . . . . . . . . .55
Convertible Top . . . . . . . . . . . . . .55
Coolant Pressure Cap (Radiator Cap) . . . . . . . . . . . . . . . . . . .199
Cooling System . . . . . . . . . . . . .198
Adding Coolant (Antifreeze) . .199
Coolant Capacity . . . . . . . . . .216
Coolant Level . . . . . . . .198, 200
Disposal of Used Coolant . . . .200
Drain, Flush, and Refill . . . . .198
Inspection . . . . . . . . . . . . . .200
Points to Remember . . . . . . .200
Pressure Cap . . . . . . . . . . . .199 Radiator Cap
. . . . . . . . . . . .199
Selection of Coolant
(Antifreeze) . . . . . . . . .198, 216
Corrosion Protection . . . . . . . . . .204
Crankcase Ventilation Module . . . .16
Cruise Light . . . . . . . . . . . . . . .115
Cupholders . . . . . . . . . . . .103, 206
Customer Programmable Features . . . . . . . . . . . . . . . .126
Data Recorder, Event . . . . . . . . . .38
Deck Lid, Power Release . . . . . . . .21
Defroster, Rear Window . . . . . . . .105
Defroster, Windshield . . . . . .49, 132
Delay (Intermittent) Wipers . . . . . .98
Diagnostic System, Onboard . . . . .190
Diesel Fuel . . . . . . . . . . . . . . . .216
Dimmer Switch, Headlight . . . . . . .96
Dipsticks Automatic Transmission . . . . .203
Oil (Engine) . . . . . . . . . . . . .191
Power Steering . . . . . . . . . . .153
Disabled Vehicle Towing . . . . . . .184
Disposal Antifreeze (Engine Coolant) . .200
Door Locks . . . . . . . . . . . . . . . . .18
Door Locks, Automatic . . . . . . . . .19
Driver's Seat Back Tilt . . . . . . . . .91Driving
Through Flowing, Rising, or
Shallow Standing Water . . . . .148
Electrical Power Outlets . . . . . . .102
Electric Rear Window Defrost . . . .105
Electric Remote Mirrors . . . . . . . . .66
Electronic Speed Control (Cruise Control) . . . . . . . . . . .100
Electronic Stability Control (ESC) . . . . . . . . . . . .154
Electronic Vehicle Information Center (EVIC) . . . . . . . . . . . .119
Emergency, In Case of Jump Starting . . . . . . . . . . . .179
Towing . . . . . . . . . . . . . . . .184
Engine . . . . . . . . . . . . . . . . . . .189
Air Cleaner . . . . . . . . . . . . .192
Break-In Recommendations . . .47
Checking Oil Level . . . . . . . .191
Coolant (Antifreeze) . . . .198, 216
Cooling . . . . . . . . . . . . . . . .198
Exhaust Gas Caution . . . . . . . .48
Fails to Start . . . . . . . . . . . .140
Flooded, Starting . . . . . . . . .140
Fuel Requirements . . . . .164, 216
Jump Starting . . . . . . . . . . . .179
Oil . . . . . . . . . . . . . . .191, 216
227

Oil Change
Interval. . . . . . . . .114, 121, 191
Oil Filler Cap . . . . . . . . . . . .189
Oil Filter . . . . . . . . . . . . . . .192
Oil Selection . . . . . . . . . . . . .216
Oil Synthetic . . . . . . . . . . . .192
Overheating . . . . . . . . . . . . .172
Starting . . . . . . . . . . . . . . . .140
Temperature Gauge . . . . . . . .111
Enhanced Accident Response Feature . . . . . . . . . . . . . . . . . .36
Entry System, Illuminated . . . . . . .16
Ethanol . . . . . . . . . . . . . . . . . .165
Event Data Recorder . . . . . . . . . . .38
Exhaust Gas Caution . . . . . . . . . .48
Exhaust System . . . . . . . . . .48, 196
Exterior Lights . . . . . . . . . . . . . .50
Filler Location Fuel . . . . . . .111, 167
Filters Air Cleaner . . . . . . . . . . . . .192
Air Conditioning . . . . . .136, 194
Automatic Transmission . . . . .203
Engine Oil . . . . . . . . . .192, 216
Engine Oil Disposal . . . . . . . .192
Flashers . . . . . . . . . . . . . . . . . .172
Hazard Warning . . . . . . . . . .172
Turn Signal . . . . . . . .50, 96, 214
Flash-To-Pass . . . . . . . . . . . . . . .96 Flooded Engine Starting
. . . . . . .140
Fluid Capacities . . . . . . . . . . . . .216
Fluid Leaks . . . . . . . . . . . . . . . . .50
Fluid Level Checks Automatic Transmission . . . . .203
Brake . . . . . . . . . . . . . . . . .201
Cooling System . . . . . . . . . . .198
Engine Oil . . . . . . . . . . . . . .191
Power Steering . . . . . . . . . . .153
Fluids, Lubricants and Genuine Parts . . . . . . . . . . . . .216
Fog Lights . . . . . . . . . .95, 115, 214
Fog Light Service . . . . . . . . . . . .214
Freeing A Stuck Vehicle . . . . . . . .182
Fuel . . . . . . . . . . . . . . . . . . . . .164
Adding . . . . . . . . . . . . . . . .167
Additives . . . . . . . . . . . . . . .166
Diesel . . . . . . . . . . . . . . . . .216
Ethanol . . . . . . . . . . . . . . . .165
Filler Cap (Gas Cap) . . .111, 167
Filler Door (Gas Cap) . . . . . .111
Gasoline . . . . . . . . . . . . . . .164
Gauge . . . . . . . . . . . . . . . . .111
Light . . . . . . . . . . . . . . . . . .111
Octane Rating . . . . . . . .164, 216
Requirements . . . . . . . .164, 216
Specifications . . . . . . . . . . . .216
Tank Capacity . . . . . . . . . . .216
Fueling . . . . . . . . . . . . . . . . . . .167 Fuel System Caution
. . . . . . . . . .168
Fuses . . . . . . . . . . . . . . . . . . . .208
Gas Cap (Fuel Filler Cap) . . . . . .167
Gasoline, Clean Air . . . . . . . . . . .165
Gasoline (Fuel) . . . . . . . . . . . . .164
Gauges Coolant Temperature . . . . . . .111
Fuel . . . . . . . . . . . . . . . . . .111
Odometer . . . . . . . . . . . . . . .113
Tachometer . . . . . . . . . . . . .113
Gear Ranges . . . . . . . . . . . . . . .143
Gear Select Lever Override . . . . .183
General Information . . . . . . . . . . .14
General Maintenance . . . . . . . . .190
Glass Cleaning . . . . . . . . . . . . . .205
Hands-Free Phone (Uconnect™) . .67
Hazard Driving Through Flowing, Rising,
or Shallow Standing Water . . .148
Hazard Warning Flasher . . . . . . .172
Headlights . . . . . . . . . . . . . .94, 213
Automatic . . . . . . . . . . . . . . .94
Bulb Replacement . . . . . . . . .213
Cleaning . . . . . . . . . . . . . . .205
Delay . . . . . . . . . . . . . . . . . .95
High Beam . . . . . . . . . . . . . .119
228

Lights On Reminder. . . . . . . .94
Low Fuel . . . . . . . . . . . . . . .111
Malfunction Indicator
(Check Engine) . . . . . . . . . . .118
Map Reading . . . . . . . . . . . . .96
Oil Pressure . . . . . . . . . . . . .112
Park . . . . . . . . . . . . . . . . . . .94
Passing . . . . . . . . . . . . . . . . .96
Seat Belt Reminder . . . . . . . .112
Service . . . . . . . . . . . . . . . .213
Theft Alarm (Security
Alarm) . . . . . . . . . . . . . . . .116
Tire Pressure Monitoring
(TPMS) . . . . . . . . . . . .117, 161
Traction Control . . . . . . . . . .156
Turn
Signal . . . . .50, 94, 96, 115, 214
Voltage . . . . . . . . . . . . . . . .111
Warning (Instrument Cluster
Description) . . . . . . . . . . . . .111
Locks . . . . . . . . . . . . . . . . . . . . .18
Automatic Door . . . . . . . . . . .19
Auto Unlock . . . . . . . . . . . . . .19
Door . . . . . . . . . . . . . . . . . . .18
Power Door . . . . . . . . . . . . . .19
Lower Anchors and Tether for CHildren (LATCH) . . . . . . .43, 44 Low Tire Pressure System
. . . . . .161
Lubrication, Body . . . . . . . . . . .195
Maintenance Free Battery . . . . . .193
Maintenance, General . . . . . . . . .190
Maintenance Procedures . . . . . . .190
Maintenance Schedule . . . . . . . . .222
Malfunction Indicator Light (Check Engine) . . . . . . . . . . .118
Map/Reading Lights . . . . . . . . . . .96
Master Cylinder (Brakes) . . . . . . .201
Memory Feature (Memory Seat) . . .91
Methanol . . . . . . . . . . . . . . . . .165
Methanol Fuel . . . . . . . . . . . . . .165
Mini-Trip Computer . . . . . . . . . .122
Mirrors . . . . . . . . . . . . . . . . . . . .65
Electric Powered . . . . . . . . . . .66
Electric Remote . . . . . . . . . . .66
Outside . . . . . . . . . . . . . . . . .66
Vanity . . . . . . . . . . . . . . . . . .67
Modifications/Alterations, Vehicle . . .7
Monitor, Tire Pressure System . . .161
Multi-Function Control Lever . . . . .94
New Vehicle Break-In Period . . . . .47Occupant Restraints
. . . . .22, 34, 36
Occupant Restraints (Sedan) . . . . . . . . . . . . . . .32, 34
Octane Rating, Gasoline (Fuel) . . . . . . . . . . . . . .164, 216
Odometer . . . . . . . . . . . . . . . . .113
Trip . . . . . . . . . . . . . . .113, 115
Oil Change Indicator . . . . . .114, 121
Oil Change Indicator, Reset . . . . . . . . . . . . . . .114, 121
Oil, Engine . . . . . . . . . . . .191, 216
Capacity . . . . . . . . . . . . . . .216
Change Interval . . .114, 121, 191
Checking . . . . . . . . . . . . . . .191
Dipstick . . . . . . . . . . . . . . . .191
Disposal . . . . . . . . . . . . . . .192
Filter . . . . . . . . . . . . . .192, 216
Filter Disposal . . . . . . . . . . .192
Recommendation . . . . . . . . .216
Synthetic . . . . . . . . . . . . . . .192
Viscosity . . . . . . . . . . . . . . .216
Oil Filter, Change . . . . . . . . . . . .192
Oil Filter, Selection . . . . . . . . . . .192
Oil Pressure Light . . . . . . . . . . .112
Onboard Diagnostic System . . . . .190
Operating Precautions . . . . . . . . .190
Operator Manual (Owner's Manual) . . . . . . . . . . . .6
230

Outside Rearview Mirrors. . . . . . .66
Overheating, Engine . . . . . . . . . .172
Owner's Manual (Operator Manual) . . . . . . . . . . .6
Paint Care . . . . . . . . . . . . . . . . .204
Parking Brake . . . . . . . . . . . . . .150
Passenger Seat Back Tilt (Easy Entry System) . . . . . . . . .91
Passing Light . . . . . . . . . . . . . . .96
Personal Settings . . . . . . . . . . . .126
Pets . . . . . . . . . . . . . . . . . . . . . .47
Phone, Cellular . . . . . . . . . . . . . .67
Phone, Hands-Free (Uconnect™) . .67
Power Deck Lid Release . . . . . . . . . .21
Door Locks . . . . . . . . . . . . . .19
Mirrors . . . . . . . . . . . . . . . . .66
Outlet (Auxiliary Electrical
Outlet) . . . . . . . . . . . . . . . .102
Seats . . . . . . . . . . . . . . . . . . .88
Steering . . . . . . . . . . . .152, 153
Windows . . . . . . . . . . . . . . . .19
Pregnant Women and Seat Belts . . .31
Pretensioners Seat Belts . . . . . . . . . . . . . . . .28
Programmable Electronic Features . . . . . . . . . . . . . . . .126 Radial Ply Tires
. . . . . . . . . . . . .158
Radiator Cap (Coolant Pressure Cap) . . . . . . . . . . . . . . . . . . .199
Radio Operation . . . . . . . . . . . . .129
Radio Remote Controls . . . . . . . .128
Radio (Sound Systems) . . . . . . . .127
Rear Cupholder . . . . . . . . . . . . .104
Rear Window Defroster . . . . . . . .105
Rear Window Features . . . . . . . .105
Recorder, Event Data . . . . . . . . . .38
Recreational Towing . . . . . . . . . .169
Refrigerant . . . . . . . . . . . . . . . .194
Release, Hood . . . . . . . . . . . . . . .93
Reminder, Lights On . . . . . . . . . . .94
Reminder, Seat Belt . . . . . . . . . . .30
Remote Control Door Locks . . . . . . . . . . . . . .16
Security Alarm . . . . . . . . . . . .15
Remote Keyless Entry (Sedan) . . . .16
Remote Sound System (Radio) Controls . . . . . . . . . . . . . . . .128
Remote Trunk Release . . . . . . . . . .21
Replacement Bulbs . . . . . . . . . . .212
Replacement Keys . . . . . . . . . . . .14
Replacement Parts . . . . . . . . . . .190
Replacement Tires . . . . . . . . . . .160
Resetting Oil Change Indicator . . . . . . . . . . . .114, 121 Restraint, Head
. . . . . . . . . . . . . .91
Restraints, Child . . . . . . . . . . . . .39
Restraints, Occupant . . . . . . . . . . .22
Rotation, Tires . . . . . . . . . . . . . .161
Safety Checks Inside Vehicle . . . . .48
Safety Checks Outside Vehicle . . . .50
Safety, Exhaust Gas . . . . . . . . . . .48
Safety Tips . . . . . . . . . . . . . . . . .47
Schedule, Maintenance . . . . . . . .222
Seat Belt Maintenance . . . . . . . . .206
Seat Belt Reminder . . . . . . . . . . . .30
Seat Belts . . . . . . . . . . . . .22, 24, 48
And Pregnant Women . . . . . . .31
Child Restraint . . . .39, 41, 42, 45
Front Seat . . . . . . . . . . . .24, 25
Inspection . . . . . . . . . . . . . . .48
Operating Instructions . . . . . . .25
Pretensioners . . . . . . . . . . . . .28
Rear Seat . . . . . . . . . . . . . . . .24
Reminder . . . . . . . . . . . . . . .112
Untwisting Procedure . . . . . . .26
Seats . . . . . . . . . . . . . . . . . . . . .88
Adjustment . . . . . . . . . . . . . .88
Easy Entry . . . . . . . . . . . . . . .91
Height Adjustment . . . . . . . . .88
Memory . . . . . . . . . . . . . . . . .91
231
