ENGINE CODES - BODYWORK VERSIONS
2.0 TB
2.4
2.4 CAE
2.4 JTD 20VCAE
3.2 V6 CAE
(*) EURO 4 version (for specific markets)
(**) Version for specific marketsEngine code
841E000
841D000
841D000
841P000
841N000 (**)
841L000Bodywork version
841AXA1B 03D
841AXA1B 03E (**)
841AXA1B 03F (*)
841AXB1B 00C
841AXB1B 00D (*)
841AXB11 04C
841AXB11 04D (*)
841AXN11 10
841AXH11 06B (**)
841AXM11 09 (**)
841AXF11 07

344
2.0 TB
841E000
Front,
transversally-mounted
Otto
5 in line
4 - Hydraulic
tappets
82 x 75.65
1,998
8.5 : 1
136
185
5,500
308
31.4
2,200
Unleaded
petrol 95 R.O.N. 2.4
841D000
Front,
transversally-mounted
Otto
5 in line
4 - Hydraulic
tappets
83 x 90.4
2,446
10.3 : 1
125
170
6,000
226
23.0
3,500
Unleaded
petrol 95 R.O.N. 2.4 CAE
841D000
Front,
transversally-mounted
Otto
5 in line
4 - Hydraulic
tappets
83 x 90.4
2,446
10.3 : 1
125
170
6,000
226
23.0
3,500
Unleaded
petrol 95 R.O.N.
ENGINE
GENERAL FEATURES
Engine code
Location
Cycle
Number and layout of cylinders
Number of valves per
cylinder
Diameter x stroke mm
Total capacity cc
Compression ratio
Maximum power (EEC): kW
HP
corresponding ratio rpm
Maximum torque (EEC): Nm
Kgm
corresponding ratio rpm
Fuel

345
3.2 V6 CAE
841L000
Front,
transversally-mounted
Otto
6 V, 60°
4 - Hydraulic
tappets
93 x 78
3,179
10 : 1
169
230
6,200
289
29
4,800
Unleaded
petrol 95 R.O.N. 2.4 JTD 20VCAE
841H000
Front,
transversally-mounted
Diesel
5 in line
4 - Hydraulic
tappets
82 x 90.4
2,387
17 : 1
136
185
4,000
330
34
1,750
Diesel fuel for
motor vehicles
GENERAL FEATURES
Engine code
Location
Cycle
Number and layout of cylinders
Number of valves per
cylinder
Diameter x stroke mm
Total capacity cc
Compression ratio
Maximum power (EEC): kW
HP
corresponding ratio rpm
Maximum torque (EEC): Nm
Kgm
corresponding ratio rpm
Fuel

CAPACITIES
Prescribed fuels
Recommended product
Unleaded petrol with a RON
not lower than 95
Diesel fuel for motor
vehicles (Specification EN590)
50-50 mixture of distilled water
andPARAFLU UP
SELENIA RACING
SELENIA WR
TUTELA CAR
TECHNYX
TUTELA CAR GI/V
TUTELA CAR GI/E
TUTELA TOP 4
Mixture of water and TUTELA
PROFESSIONAL SC 35
362
2.4
75
10
–
–
8.6
5.50
–
1.70
–
1.05
approx 1.5
4.5 2.0 TB
75
10
–
–
8.6
5.50
–
1.70
–
1.05
approx 1.5
4.52.4 CAE
75
10
–
–
8.6
5.50
–
–
7.25
1.05
approx 1.5
4.5
Fuel tank: litres– including a reserve of litres
Fuel tank: litres
– including a reserve of litres
Engine cooling system litres
Engine oil (amount for periodical change – sump and filter) litres
Engine oil (amount for periodical
change – sump and filter) litres
Manual gearbox/differential kg
Electronic automatic gearbox litres
Hydraulic power steering litres
Hydraulic brake circuit
with ABS litres
Windscreen headlight washer
reservoir litres

3.2 V6
CAE
75
10
–
–
12.2
5.90
–
–
1.05
approx 1.5
4.5
363
Prescribed fuels
Recommended product
Unleaded petrol with a RON
not lower than 95
Diesel fuel for motor vehicles
(Specification EN590)
50-50 mixture of
distilled water and PARAFLU UP
SELENIA RACING
SELENIA WR
TUTELA CAR GI/V
TUTELA CAR GI/E
TUTELA TOP 4
Mixture of water and TUTELA
PROFESSIONAL SC 35 2.4 JTD
20VCAE
–
–
75
10
8.6
–
5.0
–
1.05
approx 1.5
4.5
Fuel tank: litres
– including a reserve of litres
Fuel tank: litres
– including a reserve of litres
Engine cooling system litres
Engine oil (amount for periodical
change – sump and filter) litres
Engine oil (amount for periodical
change – sump and filter) litres
Electronic automatic gearbox litres
Hydraulic power steering litres
Hydraulic brake circuit
with ABS litres
Windscreen headlight washer
reservoir litres

364
FLUIDS AND LUBRICANTS
PRODUCTS WHICH MAY BE USED AND THEIR SPECIFICATIONS
Use
Lubricants for
petrol engines
Lubricants for
diesel engines
For regular operation of JTD versions fitted with DPF, use genuine lubricant only. In the event of an emergency, lacking the genuine
lubricant, top up just once with max. 0.5 l and go to Lancia Dealership as soon as possible
Should non-genuine products be used, lubricants with minimum ACEA A3 properties for petrol engines and ACEA B4 for Diesel en-
gines are tolerated; in this event top engine performance is not guaranteed.
Using low-quality products, not compliant with ACEA A3 and ACEA B4 properties and specifications could cause engine damages not
covered by warranty.
For very cold temperatures, consult Lancia Dealership for the proper Seleniaproduct to use.Original fluids and
lubricants
SELENIA RACING
Contractual Technical
Reference N° F007.A00
SELENIA WR
Contractual Technical
Reference N° F515.D06Change Fluid and lubricant specifications
for correct car operation
Synthetic-based oils, grade SAE 10W-60,
FIAT 9.55535-H3qualification.
Synthetic-based oils, grade SAE 5W-40,
FIAT 9.55535-M2qualification.According
to Service
Schedule
According
to Service
Schedule
