fog light Lexus CT200h 2011 (in English) User Guide

312
CT200h_EE (OM76041E)
3-1. Using the air conditioning system and defogger
Automatic air conditioning system
Air outlets and fan speed are automatically adjusted according to the
temperature setting.
Vehicles with a navigation system
Refer to the “Navigation System Owner’s Manual”.
Vehicles without a navigation system
The illustration below is for left-hand drive vehicles.
The button positions and shapes may differ slightly for right-
hand drive vehicles.
Automatic mode but-
“OFF” but-
Fan speed control but-
Air outlet selector buttonOutside/recirculated air mode but-Cooling and dehumidifica-
tion Dual mode but- Driver’s side temperature control buttons
Fan speed dis- Driver’s side tempera-
ture
Windshield
defogger but-Passenger’s side temperature control but-
Air outlet dis-Passenger’s side tempera-
ture
Pollen removal
mode button

473
4-1. Maintenance and care
4
Maintenance and care
CT200h_EE (OM76041E)
NOTICE
Cleaning detergents
Do not use the following types of detergent, as they may discolor the vehi-
cle interior or cause streaks or damage to painted surfaces:
• Non-seat portions: Organic substances such as benzene or gasoline,
alkaline or acidic solutions, dye, and bleach
• Seats: Alkaline or acidic solutions, such as thinner, benzene, and
alcohol
Do not use polish wax or polish cleaner. The instrument panel’s or other
interior part’s painted surface may be damaged.
Preventing damage to leather surfaces
Observe the following precautions to avoid damage to and deterioration of
leather surfaces:
Remove any dust or dirt from leather surfaces immediately.
Do not expose the vehicle to direct sunlight for extended periods of time.
Park the vehicle in the shade, especially during summer.
Do not place items made of vinyl, plastic, or containing wax on the uphol-
stery, as they may stick to the leather surface if the vehicle interior heats
up significantly.
Water on the floor
Do not wash the vehicle floor with water.
Vehicle systems such as the audio system may be damaged if water comes
into contact with electrical components such as the audio system above or
under the floor of the vehicle. Water may also cause the body to rust.
Cleaning the inside of the rear window
Do not use glass cleaner to clean the rear window, as this may cause dam-
age to the rear window defogger heater wires or antenna. Use a cloth
dampened with lukewarm water to gently wipe the window clean. Wipe
the window in strokes running parallel to the heater wires or antenna.
Be careful not to scratch or damage the heater wires or antenna.

528
4-3. Do-it-yourself maintenance
CT200h_EE (OM76041E)Left side instrument panel
FuseAmpereCircuit
1TA I L10 A
Rear fog light, manual headlight
leveling dial, headlights (high
beam), stop/tail lights, license
plate lights, front position lights

531
4-3. Do-it-yourself maintenance
4
Maintenance and care
CT200h_EE (OM76041E)
13DOOR RL25 APower windows
14DOOR RR25 APower windows
15D FR DOOR25 APower windows, outside rear view
mirrors
16P FR DOOR25 APower windows, outside rear view
mirrors
17STOP10 A
Emergency brake signal, stop/tail
lights, electronically controlled
brake system, pre-crash safety sys-
tem
18RR FOG7.5 ARear fog light, stop/tail lights
19FUEL OPEN7.5 AFuel filler door opener
20OBD7.5 AOn-board diagnosis system
21PWR SEAT30 APower seat
22FR FOG15 AFront fog lights
23DBL LOCK25 ADouble locking system
24PSB30 APre-crash seat belts
25STRG HTR10 AHeated steering wheel
26DOOR NO.125 APower door lock system
27SEAT HTR FL10 ASeat heaters
28SEAT HTR FR10 ASeat heaters
FuseAmpereCircuit

534
4-3. Do-it-yourself maintenance
CT200h_EE (OM76041E)
Light bulbs
You may replace the following bulbs by yourself. The difficulty level
of replacement varies depending on the bulb. If necessary bulb
replacement seems difficult to perform, contact any authorized Lexus
dealer or repairer, or another duly qualified and equipped professional.
For more information about replacing other light bulbs, contact any
authorized Lexus dealer or repairer, or another duly qualified and
equipped professional.
Preparing for light bulb replacement
Check the wattage of the light bulb to be replaced. (P. 652)
Removing the engine compartment covers
P. 486
Front bulb locations
Halogen headlights
Front turn signalHeadlight low
Headlight high Front fog light

535
4-3. Do-it-yourself maintenance
4
Maintenance and care
CT200h_EE (OM76041E)
LED headlights
Rear bulb locations
Headlight high
Front turn signal Front fog light
Rear turn signal
Rear fog light
(left-hand drive
vehicles) or back-upRear fog light (right-hand
drive vehicles) or back-up
License
plate

539
4-3. Do-it-yourself maintenance
4
Maintenance and care
CT200h_EE (OM76041E)Front fog lights (if equipped)
Remove 2 screws, a bolt and a
clip, and pull down the engine
under cover.
Pull the cover down slowly,
being careful not to dislodge
any fixed components.
Unplug the connector while
pressing the lock release.
Turn the bulb base counter-
clockwise.
STEP1
STEP2
STEP3

544
4-3. Do-it-yourself maintenance
CT200h_EE (OM76041E)Back-up light/rear fog light
Open the back door and remove
the cover.
Use a flathead screwdriver
wrapped in a cloth.
Turn the bulb base counter-
clockwise.
Remove the light bulb.
The illustrations show the removal of a back-up light from a right-
hand drive vehicle.
STEP1
STEP2
STEP3

652
6-1. Specifications
CT200h_EE (OM76041E)
Light bulbs
A: H11 halogen bulbs
B: H9 halogen bulbs
C: Wedge base bulbs (clear)
D: Wedge base bulbs (amber)
E: Double end bulbs
*: If equipped
Light BulbsWTy p e
Exterior
Headlights
Low beam (halogen bulbs)
*
High beam
55
65A
B
Front fog lights*55A
Front turn signal lights21D
Rear turn signal lights21D
Back-up lights16C
Rear fog light21C
License plate lights5C
Interior
Front interior/personal lights5C
Rear interior light8E
Vanity lights8C
Luggage compartment light5E

682
Alphabetical index
CT200h_EE (OM76041E)
Child safety
Airbag precautions................155
Back door precautions ............91
Child restraint system ...........163
Child-protectors ......................86
How your child should wear
the seat belt.........................107
Installing child restraints ......173
Moon roof precautions .........126
Power window lock switch...120
Power window precautions...122
Removed electronic key battery
precautions .........................519
Seat belt precautions .............109
Seat heater precautions .........456
12-volt battery precautions ...500
Child-protectors...........................86
Cleaning
Exterior .................................466
Interior ..................................471
Seat belts...............................472
Clock
*.......................................450
Condenser ..................................494
Console box ...............................443
Cooling system
Engine overheating ...............627
Hybrid system overheating ...627
Cruise control
Cruise control .......................248
Dynamic radar cruise control .....
252
Cup holders ...............................444Curtain shield airbags ............... 148
Customizable features .............. 655
Daytime running light system .. 235
Defogger
Rear window ........................ 323
Side mirrors ......................... 323
Dimensions ............................... 638
Display
Dynamic radar cruise
control ............................... 252
Multi-information display.... 226
Trip information .................. 228
Warning message................. 565
Do-it-yourself maintenance ...... 477
Door lock
Back door............................... 89
Side doors .............................. 85
Smart entry & start system .... 59
Wireless remote control ......... 80
Doors
Back door............................... 89
Door glasses......................... 119
Door lock ................... 59, 80, 85
Rear door child protector ....... 86
Side doors .............................. 85
Driver’s seat belt reminder light562
Driver’s seat position memory ... 98
Driving
Break-in tips ........................ 185
Correct posture .................... 146
Procedures ........................... 184
Winter driving tips ............... 304
Driving position memory ........... 98
D
