290
2-4. Using other driving systems
CT200h_EE (OM76041E)
Hill-start assist control
Hill-start assist control can be operated when
The shift position is in a position other than P.
The parking brake is not applied.
The accelerator pedal is not depressed.
Hill-start assist control
While hill-start assist control is operating, the brakes remain automati-
cally applied after the driver releases the brake pedal. The stop lights and
the high mounted stoplight turn on.
Hill-start assist control operates for about 2 seconds after the brake pedal
is released.
If the slip indicator does not flash and the buzzer does not sound when
the brake pedal is further depressed, slightly reduce the pressure on the
brake pedal (do not allow the vehicle to roll backward) and then firmly
depress it again. If the system still does not operate, check if the operat-
ing conditions explained above have been met.
Hill-start assist control helps to prevent the vehicle from rolling back-
wards when starting on an incline or slippery slope.
To engage hill-start assist
control, further depress the
brake pedal when the vehicle
is stopped completely.
A buzzer will sound once to
indicate the system is acti-
vated. The slip indicator will
also start flashing.

484
4-3. Do-it-yourself maintenance
CT200h_EE (OM76041E)
CAUTION
When raising your vehicle
Make sure to observe the following precautions to reduce the possibility of
death or serious injury:
When using a floor jack, follow the instructions of the manual provided
with the jack.
Do not use the jack that was supplied with your vehicle.
Do not put any part of your body underneath the vehicle when it is sup-
ported only by the floor jack.
Always use floor jack and/or automotive jack stands on a solid, flat, level
surface.
Do not start the hybrid system while the vehicle is supported by the floor
jack.
Stop the vehicle on level, firm ground, firmly set the parking brake and
shift the shift position to P.
Make sure to set the floor jack properly at the jack point.
Raising the vehicle with an improperly positioned floor jack will damage
the vehicle and may cause the vehicle to fall off the floor jack.
Do not raise the vehicle while someone is in the vehicle.
When raising the vehicle, do not place any object on top of or underneath
the floor jack.
Lift up the vehicle using a floor jack
such as the one shown in the illustra-
tion.

529
4-3. Do-it-yourself maintenance
4
Maintenance and care
CT200h_EE (OM76041E)
2PANEL10 A
Audio system, Lexus parking
assist-sensor switch, windshield
wiper de-icer switch, navigation
system, fuel filler door opener,
glove box light, headlight cleaner
switch, emergency flasher switch,
manual headlight leveling dial, air
conditioning system, outside rear
view mirrors, driving mode select
switches, P position switch, instru-
ment panel light control dial, shift
position indicators, seat heater
switches, heated steering wheel
switch, pre-crash braking off
switch
3IGN10 A
Electronically controlled brake
system, smart entry & start system,
multiport fuel injection system/
sequential multiport fuel injection
system, stop/tail lights, SRS air-
bags
4MET7.5 AGauges and meters
FuseAmpereCircuit

5When trouble arises
549
CT200h_EE (OM76041E)
5-1. Essential information
Emergency flashers .......... 550
If your vehicle needs to be
towed.............................. 551
If you think something is
wrong ............................. 5575-2. Steps to take in an
emergency
If a warning light turns on
or a warning buzzer
sounds ............................ 558
If a warning message is
displayed ........................ 565
If you have a flat tire
(vehicles with a spare
tire) ................................ 586
If you have a flat tire
(vehicles without a spare
tire) ................................ 600
If the hybrid system will not
start ................................ 614
If you lose your keys ....... 616
If the electronic key does
not operate properly....... 617
If the 12-volt battery is
discharged ...................... 620
If your vehicle overheats . 627
If the vehicle becomes
stuck............................... 632
If your vehicle has to be
stopped in an
emergency...................... 634

5
573
5-2. Steps to take in an emergency
When trouble arises
CT200h_EE (OM76041E)
Warning messageDetailsCorrection procedure
Indicates that the hybrid
system has overheatedStop and check.
(P. 627)
(Flashes)
Indicates that the trac-
tion battery is low
When stopping the
vehicle for a long
period of time, shift the
shift position to P. The
battery cannot be
charged with the shift
position in N.
(Flashes)
Indicates that the trac-
tion battery power has
dropped because a long
period of time has
elapsed after shifting
the shift position to N
Restart the hybrid sys-
tem when starting the
vehicle.
(Flashes)
Indicates that the
driver’s door was
opened with the shift
position in any position
other than P
Shift the shift position
to P.

5
627
5-2. Steps to take in an emergency
When trouble arises
CT200h_EE (OM76041E)
If your vehicle overheats
Correction procedures
If the high coolant temperature warning light comes on or
flashes
Stop the vehicle in a safe place and turn off the air condi-
tioning system.
Check to see if steam is coming out from the engine area.
If you see steam:
Stop the hybrid system. Carefully lift the hood after the
steam subsides and then restart the hybrid system.
If you do not see steam:
Leave the hybrid system operating and carefully lift the
hood.
Check to see if the cooling fans are operating.
If the fans are operating:
Wait until the high coolant temperature warning light goes
off and then stop the hybrid system.
If the fans are not operating:
Stop the hybrid system immediately and call any authorized
Lexus dealer or repairer, or another duly qualified and
equipped professional.
The following may indicate that your vehicle is overheating:
The high coolant temperature warning light comes on or
flashes:
The engine may be overheating.
“HYBRID SYSTEM OVERHEAT” is shown on the multi-
information display:
STEP1
STEP2
STEP3

632
5-2. Steps to take in an emergency
CT200h_EE (OM76041E)
If the vehicle becomes stuck
CAUTION
When attempting to free a stuck vehicle
If you choose to push the vehicle back and forth to free it, make sure the sur-
rounding area is clear to avoid striking other vehicles, objects or people. The
vehicle may also lunge forward or lunge back suddenly as it becomes free.
Use extreme caution.
When changing the shift position
Be careful not to change the shift position with the accelerator pedal
depressed.
Changing the shift position to any positions other than P or N may cause the
vehicle to accelerate abruptly, causing an accident and resulting in death or
serious injury.
Carry out the following procedures if the tires spin or the vehicle
becomes stuck in mud, dirt or snow:
Set the parking brake and shift the shift position to P.
Stop the hybrid system.
Remove the mud, snow or sand from around the stuck
tire.
Place wood, stones or some other material under the tires
to help provide traction.
Restart the hybrid system.
Shift the shift position to D or R, release the parkingSTEP1
STEP2
STEP3
STEP4
STEP5

683
Alphabetical index
CT200h_EE (OM76041E)
Electric power steering ..............285
Electronic key
If the electronic key does not
operate properly .................617
Replacing battery ..................515
Emergency, in case of
If a warning buzzer sounds ...558
If a warning light turns on ....558
If a warning message is
displayed ............................565
If the electronic key does not
operate properly .................617
If the hybrid system will not
start .....................................614
If the 12-volt battery is
discharged ..........................620
If you have a flat tire ...586, 600
If you lose your keys ............616
If you think something is
wrong .................................557
If your vehicle becomes stuck ....
632
If your vehicle has to be stopped
in an emergency .................634
If your vehicle needs to be
towed ..................................551
If your vehicle overheats ......627
Emergency brake signal ............286
Emergency flashers ...................550Engine
Accessory mode................... 197
Compartment ....................... 485
Hood .................................... 481
How to start the hybrid
system................................ 196
Identification number .......... 639
If the hybrid system will not
start .................................... 614
Ignition switch ..................... 196
Overheating ......................... 627
“POWER” switch ................ 196
Engine compartment cover....... 486
Engine coolant
Capacity ............................... 645
Checking .............................. 491
Preparing and checking
before winter ..................... 304
Engine/power control unit coolant
Capacity ............................... 645
Checking .............................. 491
Preparing and checking
before winter ..................... 304E
