emergency towing Lexus CT200h 2011 Owner's Manual (in English)

251
2-4. Using other driving systems
2
When driving
CT200h_EE (OM76041E)
Automatic cruise control cancellation
Cruise control will stop maintaining the vehicle speed in any of the follow-
ing situations.
Actual vehicle speed falls more than approximately 16 km/h (10 mph)
below the preset vehicle speed.
At this time, the memorized set speed is not retained.
Actual vehicle speed is below approximately 40km/h (25 mph).
VSC is activated.
CAUTION
To avoid operating the cruise control by mistake
Switch the cruise control off using the “ON-OFF” button when not in use.
Situations unsuitable for cruise control
Do not use cruise control in any of the following situations.
Doing so may result in loss of control and could cause an accident resulting
in death or serious injury.
In heavy traffic
On roads with sharp bends
On winding roads
On slippery roads, such as those covered with rain, ice or snow
On steep hills
Vehicle speed may exceed the set speed when driving down a steep hill.
When emergency towing

267
2-4. Using other driving systems
2
When driving
CT200h_EE (OM76041E)
CAUTION
Situations unsuitable for dynamic radar cruise control
Do not use dynamic radar cruise control in any of the following situations.
Doing so may result in inappropriate speed control and could cause an acci-
dent resulting in death or serious injury.
In heavy traffic
On roads with sharp bends
On winding roads
On slippery roads, such as those covered with rain, ice and snow
On steep downhills, or where there are sudden changes between sharp up
and down gradients
Vehicle speed may exceed the set speed when driving down a steep hill.
At entrances to expressways
When weather conditions are bad enough that they may prevent the sen-
sors from functioning correctly (fog, snow, sandstorm, heavy rain, etc.)
When an approach warning buzzer is heard often
When emergency towing
When the sensor may not be correctly detecting the vehicle ahead
Apply the brakes as necessary when any of the following types of vehicles
are in front of you.
As the sensor may not be able to correctly detect these types of vehicles, the
approach warning (P. 259) will not be activated, and a fatal or serious
accident may result.
Vehicles that cut in suddenly
Vehicles traveling at low speeds
Vehicles that are not moving
Vehicles with small rear ends (trailers with no load on board etc.)
Motorcycles traveling in the same lane

552
5-1. Essential information
CT200h_EE (OM76041E)
Emergency towing
If a tow truck is not available in
an emergency, your vehicle
may be temporarily towed
using a cable or chain secured
to the emergency towing eye-
let(s). This should only be
attempted on hard surfaced
roads for short distances at
under 30 km/h (18 mph).
A driver must be in the vehicle
to steer and operate the brakes.
The vehicle’s wheels, drive
train, axles, steering and brakes
must be in good condition.

5
555
5-1. Essential information
When trouble arises
CT200h_EE (OM76041E)
Using a flat bed truck
If your Lexus is transported by
a flat bed truck, it should be
tied down at the locations
shown in the illustration.
If you use chains or cables to tie
down your vehicle, the angles
shaded in black must be 45.
Do not overly tighten the tie
downs or the vehicle may be
damaged.
Before emergency towing
Turn the “POWER” switch to ON mode.
Do not turn the “POWER” switch to ACCESSORY mode.
Shift the shift position to N.
Release the parking brake.
Emergency towing eyelet location
P. 586, 600
STEP1
STEP2
STEP3

556
5-1. Essential information
CT200h_EE (OM76041E)
CAUTION
Caution while towing
Use extreme caution when towing the vehicle.
Avoid sudden starts or erratic driving maneuvers which place excessive
stress on the emergency towing eyelets and the cables or chains. Always
be cautious of the surroundings and other vehicles while towing.
Do not turn the “POWER” switch off.
This may lead to an accident as the front wheels will be locked by the
parking lock.
If the hybrid system is off, the power assist for the brakes and steering will
not function, making steering and braking more difficult.
Installing towing eyelets to the vehicle
Make sure that towing eyelets are installed securely.
If not securely installed, towing eyelets may come loose during towing. This
may lead to accidents that cause serious injury or even death.
NOTICE
To prevent damaging the vehicle
When raising the vehicle, ensure adequate ground clearance for towing at
the opposite end of the raised vehicle. Without adequate clearance, the vehi-
cle could be damaged while being towed.
To prevent causing serious damage to the hybrid transmission when towing
using a wheel-lift type truck
Never tow this vehicle from the front with the rear wheels on the ground.
To prevent body damage when towing with a sling-type truck
Do not tow with a sling-type truck, either from the front or rear.
To prevent causing serious damage to the hybrid transmission in emergency
towing
Never tow a vehicle from the rear with four wheels on the ground. This may
cause serious damage to the hybrid transmission.

586
5-2. Steps to take in an emergency
CT200h_EE (OM76041E)
If you have a flat tire (vehicles with a spare tire)
Remove the flat tire and replace it with the spare tire provided.
Before jacking up the vehicle
Stop the vehicle on a hard, flat surface.
Set the parking brake.
Shift the shift position to P.
Stop the hybrid system.
Turn on the emergency flashers.
Location of the spare tire, jack and tools
Center auxil-
iary
Jack Spare Jack han- Wheel
nut
Towing eye-

5
593
5-2. Steps to take in an emergency
When trouble arises
CT200h_EE (OM76041E)
Stowing the flat tire
Vehicles with a 16 or 17 inch
wheel: Before stowing the flat
tire, remove the center wheel
ornament by pushing from the
reverse side.
Place the flat tire on the deck
board, and pass the belt through
the lower-right cargo hook and
then through the hole in the
center of the tire.
Pass the belt through the lower-
left cargo hook.
Pass the belt through the buckle
and secure the tire firmly.
Check that the belt is securely
held by the buckle.
The belt cannot be fastened
securely if the buckle is facing
the wrong direction.
STEP1
STEP2
STEP3
STEP4

5
599
5-2. Steps to take in an emergency
When trouble arises
CT200h_EE (OM76041E)
CAUTION
After using the tools and jack
Before driving, make sure all the tools and jack are securely in place in their
storage location to reduce the possibility of personal injury during a colli-
sion or sudden braking.
When stowing the flat tire
Make sure the rear seatbacks are in their original position.
Secure it using a tire tie-down belt. Otherwise, the flat tire may fly out in
case of sudden braking or an accident, resulting in death or serious injury.
NOTICE
Do not drive the vehicle with a flat tire.
Do not continue driving with a flat tire.
Driving even a short distance with a flat tire can damage the tire and the
wheel beyond repair.
Be careful when driving over bumps with the compact spare tire installed on
the vehicle.
The vehicle becomes lower when driving with the compact spare tire com-
pared to when driving with standard tires. Be careful when driving over
uneven road surfaces.
Driving with tire chains and the compact spare tire
Do not fit tire chains to the compact spare tire.
Tire chains may damage the vehicle body and adversely affect driving per-
formance.

600
5-2. Steps to take in an emergency
CT200h_EE (OM76041E)
If you have a flat tire (vehicles without a spare tire)
Your vehicle is equipped with an emergency tire puncture repair kit.
A puncture caused by a nail or screw passing through the tire tread can
be repaired temporarily with the emergency tire puncture repair kit.
Before repairing the vehicle
Stop the vehicle in a safe place on a hard, flat surface.
Set the parking brake.
Shift the shift position to P.
Stop the hybrid system.
Turn on the emergency flashers.
Location of the emergency tire puncture repair kit, jack and
tools
Center auxil-
iary
Jack*Towing eye-
Wheel
nut
Jack han-
Emergency tire
puncture repair

5
633
5-2. Steps to take in an emergency
When trouble arises
CT200h_EE (OM76041E)
NOTICE
To avoid damage to the hybrid transmission and other components
Avoid spinning the wheels and depressing the accelerator pedal more than
necessary.
If the vehicle remains stuck even after these procedures are performed, the
vehicle may require towing to be freed.
