roof Lexus CT200h 2011 Owner's Manual (in English)

TABLE OF CONTENTSIndex
2
CT200h_EE (OM76041E)
1-1. Hybrid system
Hybrid system features......... 34
Hybrid system precautions ... 39
Energy monitor/consumption
screen ................................. 45
Hybrid vehicle driving tips .. 51
1-2. Key information
Keys ..................................... 53
1-3. Opening, closing and locking
the doors
Smart entry & start system ... 59
Push-button start system ...... 75
Wireless remote control ....... 80
Side doors............................. 85
Back door ............................. 891-4. Adjustable components (seats,
mirrors, steering wheel)
Front seats ............................ 94
Rear seats ............................. 96
Driving position memory ..... 98
Head restraints.................... 101
Seat belts ............................ 104
Steering wheel .................... 111
Inside rear view mirror ....... 112
Outside rear view mirrors .. 114
1-5. Opening and closing the win-
dows and moon roof
Power windows .................. 119
Moon roof .......................... 123
1-6. Refueling
Opening the fuel tank cap .. 127
1Before driving
For vehicles with a navigation system, refer to the “Navigation System
Owner’s Manual” for information regarding the equipment listed below.
• Navigation system
• Air conditioning
• Windshield wiper de-icer
• Lexus parking assist monitor• Audio/video system
• Rear window and outside rear
view mirror defogging
• Climate control

8
CT200h_EE (OM76041E)
Moon roof P. 123
Front fog lights
P. 237
Hood P. 481
Windshield wipers
P. 239
Outside rear view
mirrors
P. 114
Headlight cleaner P. 247
Pictorial indexExterior
Headlights
Front position lights
Turn signal lights P. 232
P. 232
P. 213
Turn signal lights
P. 213

11
CT200h_EE (OM76041E)
Anti-glare inside rear view mirror
P. 112
Sun visors P. 448
SRS curtain shield airbags P. 148
Interior lights
Personal lights P. 439
P. 439
Moon roof switches
Intrusion sensor cancel switch

P. 123
P. 140
Vanity mirrors
P. 449
Interior light P. 439
A
: If equipped

19
CT200h_EE (OM76041E)
Anti-glare inside rear view mirror
P. 112
Sun visors P. 448
SRS curtain shield airbags P. 148
Interior lights
Personal lights P. 439
P. 439
Moon roof switches
Intrusion sensor cancel switch

P. 123
P. 140
Vanity mirrors
P. 449
: If equipped
Interior light P. 439
A

1Before driving
33
CT200h_EE (OM76041E)
1-4. Adjustable components (seats,
mirrors, steering wheel)
Front seats .......................... 94
Rear seats ........................... 96
Driving position memory ... 98
Head restraints ................. 101
Seat belts .......................... 104
Steering wheel.................. 111
Inside rear view mirror..... 112
Outside rear view mirrors 114
1-5. Opening and closing the
windows and moon roof
Power windows ................ 119
Moon roof ........................ 123
1-6. Refueling
Opening the fuel tank cap 1271-7. Theft deterrent system
Immobilizer system ......... 131
Double locking system .... 136
Alarm ............................... 138
1-8. Safety information
Correct driving posture .... 146
SRS airbags...................... 148
Airbag manual on-off
system ............................ 160
Child restraint systems..... 163
Installing child restraints . 173

52
1-1. Hybrid system
CT200h_EE (OM76041E)
Air conditioning
Use the air conditioning only when necessary. Doing so can help
control excessive gasoline consumption.
In summer: In high temperatures, use the recirculated air mode.
Doing so will help to reduce the burden on the air conditioner and
reduce fuel consumption as well.
In winter: Because the gasoline engine will not automatically cut
out until the gasoline engine and the interior of the vehicle are
warm, it will consume fuel. Also, fuel consumption can be
improved by avoiding overuse of the heater.
Checking tire inflation pressure
Make sure to check the tire inflation pressure frequently. Improper
tire inflation pressure can cause poor fuel consumption.
Also, as snow tires can cause large amounts of friction, their use on
dry roads can lead to poor fuel consumption. Use a tire that is
appropriate for the season.
Luggage
Carrying heavy luggage can lead to poor fuel consumption. Avoid
carrying unnecessary luggage. Installing a large roof rack can also
cause poor fuel consumption.
Warming up before driving
Since the gasoline engine starts up and cuts out automatically when
cold, warming up the engine is unnecessary. Moreover, frequently
driving short distances will cause the engine to repeatedly warm up,
which can lead to poor fuel consumption.

55
1-2. Key information
1
Before driving
CT200h_EE (OM76041E)
Card key
The mechanical key that is stored inside the card key should be used
only if a problem arises, such as when the card key does not operate
properly.
If it is difficult to take out the mechanical key, push down the lock
release button using a pen tip etc. If it is still difficult to pull it out, use a
coin etc.
The card key is not waterproof.
To store the mechanical key in the
card key, insert it while pressing the
lock release button.
If the battery cover is not installed
and the battery falls out or if the bat-
tery was removed because the key
got wet, reinstall the battery with
the positive terminal facing the
Lexus emblem.

119
1
Before driving
CT200h_EE (OM76041E)
1-5. Opening and closing the windows and moon roof
Power windows
The power windows can be opened and closed using the switches.
Operating the switch moves the windows as follows:
Closing
One-touch closing
*
Opening
One-touch opening
*
*
: Pushing the switch in the
opposite direction will
stop window travel part-
way.

120
1-5. Opening and closing the windows and moon roof
CT200h_EE (OM76041E)
Window lock switch
Press the switch down to lock
the passenger window.
Use this switch to prevent chil-
dren from accidentally opening
or closing a passenger window.
The power windows can be operated when
The “POWER” switch is in ON mode.
Operating the power windows after turning the hybrid system off
The power windows can be operated for approximately 43 seconds even
after the “POWER” switch is turned to ACCESSORY mode or turned off.
They cannot, however, be operated once either front door is opened.
Jam protection function
If an object becomes caught between the window and the window frame,
window travel is stopped and the window is opened slightly.

121
1-5. Opening and closing the windows and moon roof
1
Before driving
CT200h_EE (OM76041E)
When the power window does not close normally
If the jam protection function is operating abnormally and a window cannot
be closed, perform the following operations using the power window switch
on the relevant door.
After stopping the vehicle, the window can be closed by holding the
power window switch in the one-touch closing position while the
“POWER” switch is turned to ON mode.
If the window still cannot be closed even by carrying out the operation
explained above, initialize the function by performing the following pro-
cedure.
Hold the power window switch in the one-touch closing position.
Continue holding the switch for a further 6 seconds after the win-
dow has closed.
Hold the power window switch in the one-touch opening position.
Continue holding the switch for a further 2 seconds after the win-
dow has opened completely.
Hold the power window switch in the one-touch closing position
once again. Continue holding the switch for a further 2 seconds
after the window has closed.
If you release the switch while the window is moving, start again from the
beginning.
If the window continues to close but then re-open slightly even after per-
forming the above procedure correctly, have the vehicle inspected by any
authorized Lexus dealer or repairer, or another duly qualified and equipped
professional.
STEP1
STEP2
STEP3
