4-3. Do-it-yourself maintenance
4
Maintenance and care
CT200h_OM_OM76067E_(EE)Rear turn signal lights
Open the back door and remove
the covers and bolts, and
remove the lamp assembly by
pulling it directly backward
from the rear of the vehicle.
Use a flathead screwdriver
wrapped in a cloth.
Turn the bulb base counter-
clockwise.
Remove the light bulb.
STEP1
STEP2
STEP3

558
4-3. Do-it-yourself maintenance
CT200h_OM_OM76067E_(EE)Lights other than the above
If any of the lights listed below has burnt out, have it replaced by
any authorized Lexus dealer or repairer, or another duly quali-
fied and equipped professional.
Headlight low beams (LED type)
Front position lights and daytime running lights
Side turn signal lights
Stop/tail lights
High mounted stoplight
Outer foot light
After replacing the bulbs
After lifting up the air cleaner duct or
removing the power control unit cover,
return the duct or the cover to their origi-
nal positions with the clips.
Push up center portion
Insert
Press

559
4-3. Do-it-yourself maintenance
4
Maintenance and care
CT200h_OM_OM76067E_(EE)
LED lights
The headlight low beams (LED type), front position lights, daytime running
lights, side turn signal lights, stop/tail lights and high mounted stoplight
consist of a number of LEDs. If any of the LEDs burn out, take your vehicle
to any authorized Lexus dealer or repairer, or another duly qualified and
equipped professional to have the light replaced.
Condensation build-up on the inside of the lens
Contact any authorized Lexus dealer or repairer, or another duly qualified
and equipped professional for more information in the following situations.
Temporary condensation build-up on the inside of the headlight lens does
not indicate a malfunction.
Large drops of water have built up on the inside of the lens.
Water has built up inside the headlight.
When replacing light bulbs
P. 5 4 4
CAUTION
Replacing light bulbs
Turn off the lights. Do not attempt to replace the bulb immediately after
turning off the lights.
The bulbs become very hot and may cause burns.
Do not touch the glass portion of the light bulb with bare hands. Hold the
bulb by the plastic or metal portion.
If the bulb is scratched or dropped, it may blow out or crack.
Fully install light bulbs and any parts used to secure them. Failure to do so
may result in heat damage, fire, or water entering the headlight unit. This
may damage the headlights or cause condensation to build up on the lens.
To prevent damage or fire
Make sure bulbs are fully seated and locked.

562
CT200h_OM_OM76067E_(EE)
5-1. Essential information
Emergency flashers
Emergency flashers
If the emergency flashers are used for a long time while the hybrid system is
not operating (while the “READY” indicator is not illuminated), the 12-volt
battery may discharge.
The emergency flashers are used to warn other drivers when the vehi-
cle has to be stopped in the road due to a breakdown, etc.
Press the switch.
All the turn signal lights will
flash. To turn them off, press
the switch once again.

664
6-1. Specifications
CT200h_OM_OM76067E_(EE)
Light bulbs
A: H11 halogen bulbs
B: H9 halogen bulbs
C: Wedge base bulbs (clear)
D: Wedge base bulbs (amber)
E: Double end bulbs
*: If equipped
Light BulbsWTy p e
Exterior
Headlights
Low beam (halogen bulbs)
*
High beam
55
65A
B
Front fog lights*55A
Front turn signal lights21D
Rear turn signal lights21D
Back-up lights16C
Rear fog light21C
License plate lights5C
Interior
Front interior/personal lights5C
Rear interior light8E
Vanity lights8C
Luggage compartment light5E

686
6-2. Customization
CT200h_OM_OM76067E_(EE)
Vehicle customization
When “SPEED SENSITIVE AUTO LOCK” and “SHIFT-LINKED
AUTOMATIC LOCK” are both on, the door lock operates as follows.
• When shifting the shift position to any position other than P, all the
doors will be locked.
• If the vehicle is started with all the doors locked, “SPEED SENSI-
TIVE AUTO LOCK” would not operate.
• If the vehicle is started with any door unlocked, “SPEED SENSITIVE
AUTO LOCK” will operate.
When “ENTRY AND START SYSTEM” is off, “SELECT DOORS TO
UNLOCK” cannot be customized.
When the doors remain closed after unlocking the doors and “AUTO.
RELOCK TIME ADJUSTMENT” activates, the signals will be gener-
ated in accordance with the “LOCK/ FEEDBACK VOLUME” and the
“LOCK/UNLOCK ANSWER BACK” settings.
In the following situations, customize mode in which the settings can be
changed through the “DISP” switch will automatically be turned off.
A warning message appears after the customize mode screen is dis-
played.
The “POWER” switch is turned off.
The vehicle begins to move while the customize mode screen is dis-
