maintenance reset Lexus CT200h 2013 Owner's Manual (in English)

5127-3. Do-it-yourself maintenance
CT200h_OM_OM76102E_(EE)
How to initialize the tire pressure warning system
Park the vehicle in a safe place and turn the power switch off.
Initialization cannot be performed while the vehicle is moving.
Adjust the tire inflation pressure to the specified cold tire inflation
pressure level. (P. 645)
Make sure to adjust the tire pressure to the specified cold tire inflation pres-
sure level. The tire pressure warning system will operate based on this pres-
sure level.
Turn the power switch to ON mode.
Press and hold the tire pressure
warning reset switch until the
tire pressure warning light
blinks slowly 3 times.
Wait for a few minutes with the power switch in ON mode and then
turn the power switch off.
Registering ID codes
The tire pressure warning valve and transmitter is equipped with a
unique ID code. When replacing a tire pressure warning valve and
transmitter, it is necessary to register the ID code. Have the ID code
registered by any authorized Lexus dealer or repairer, or another duly
qualified and equipped professional.
1
2
3
4
5

5157-3. Do-it-yourself maintenance
CT200h_OM_OM76102E_(EE)
7
Maintenance and care
The initialization operation
Make sure to carry out initialization after adjusting the tire inflation pressure.
Also, make sure the tires are cold before carrying out initialization or tire infla-
tion pressure adjustment.
If you have accidentally turned the power switch off during initialization, it is
not necessary to press the reset switch again as initialization will restart auto-
matically when the power switch has been turned to ON mode for the next time.
If you accidentally press the reset switch when initialization is not necessary,
adjust the tire inflation pressure to the specified level when the tires are cold,
and conduct initialization again.
Warning performance of the tire pressure warning system
The warning of the tire pressure warning system will change in accordance with
the conditions under which it was initialized. For this reason, the system may
give a warning even if the tire pressure does not reach a low enough level, or if
the pressure is higher than the pressure that was adjusted to when the system was
initialized.
When initialization of the tire pressure warning system has failed
Initialization can be completed in a few minutes. However, in the following
cases, the settings have not been recorded and the system will not operate prop-
erly. If repeated attempts to record tire inflation pressure settings are unsuccess-
ful, have the vehicle inspected by any authorized Lexus dealer or repairer, or
another duly qualified and equipped professional.
When operating the tire pressure warning reset switch, the tire pressure warning
light does not blink 3 times.
After carrying out the initialization procedure, the tire pressure warning light
blinks for 1 minute then stays on after driving for 20 minutes.

5217-3. Do-it-yourself maintenance
CT200h_OM_OM76102E_(EE)
7
Maintenance and care
WA R N I N G
When inspecting or replacing tires
Observe the following precautions to prevent accidents.
Failure to do so may cause damage to parts of the drive train as well as danger-
ous handling characteristics, which may lead to an accident resulting in death
or serious injury.
Do not mix tires of different makes, models or tread patterns.
Also, do not mix tires of remarkably different treadwear.
Do not use tire sizes other than those recommended by Lexus.
Do not mix differently constructed tires (radial, bias-belted or bias-ply tires).
Do not mix summer, all season and snow tires.
Do not use tires that have been used on another vehicle.
Do not use tires if you do not know how they were used previously.
Vehicles with a compact spare tire: Do not tow if your vehicle has a compact
spare tire installed.
Vehicles with an emergency tire puncture repair kit: Do not tow anything if a
tire that has been repaired using the emergency tire puncture repair kit is
installed. The load on the tire may cause unexpected damage to the tire.
When initializing the tire pressure warning system
Do not operate the tire pressure warning reset switch without first adjusting the
tire inflation pressure to the specified level. Otherwise, the tire pressure warn-
ing light may not come on even if the tire inflation pressure is low, or it may
come on when the tire inflation pressure is actually normal.

681Alphabetical index
CT200h_OM_OM76102E_(EE)
Headlight cleaner switch ......223
Heated steering wheel...........459
Ignition switch ......................196
Intrusion sensor cancel
switch ...................................96
Lexus parking assist-sensor
switch .................................245
Light switches.......................211
Meter control switches .........114
Moon roof switches ..............181
Outside rear view mirror
switches ..............................174
Power switch ........................196
Power window switch ..........178
Pre-crash braking off switch.276
Rear window wiper and
washer switch .....................222
Rear window and outside
rear view mirror defoggers
switch .........................447, 454
Seat heater switches..............459
Talk switch ...........326, 418, 439
Telephone switches ......326, 418
Tire pressure warning
reset switch.........................512
TRC OFF switch ..................270
Vehicle-to-vehicle distance
button .................................231
Window lock switch .............178
Windshield wipers and
washer switch .....................218Tachometer ............................... 105
Tail lights
Light switch ......................... 211
Replacing light bulbs ........... 556
Talk switch ............... 326, 418, 439
Telephone switch.............. 326, 418
Theft deterrent system
Alarm ..................................... 93
Double locking system .......... 92
Immobilizer system ............... 87
Intrusion sensor...................... 96
Tilt sensor .............................. 96
Tilt sensor ................................... 96
Tire inflation pressure
Maintenance data ................. 645
Warning light ....................... 571
Tire pressure warning system
Function ............................... 511
Initializing............................ 511
Installing tire pressure warning
valves and transmitters ...... 511
Registering ID codes ........... 512
Tire pressure warning reset
switch ................................ 512
Warning light ....................... 571T
