manual radio set Lexus CT200h 2013 Owner's Manual (in English)

2985-3. Using the radio
CT200h_OM_OM76102E_(EE)
Manually operation
Search for the desired stations by turning the “TUNE•SEL” knob or
pressing “”or “” on the “SEEK•TRACK” button.
Press and hold the button (from the “1” button to the “6” button) the
station is to be set to until you hear a beep.
Automatically operation
Press and hold the “AST” button until you hear a beep.
Up to 6 stations are set in order of reception quality. When the set-
ting is complete, 2 beeps will be heard.
This feature allows your radio to receive station and program information
(classical, news, etc.) from radio stations which broadcast this informa-
tion.
Listening to stations of the same network
Press the “AF” button.
“AF-ON”, “REG-OFF” modes:
A station among those of the same network with strong reception is
selected.
“AF-ON”, “REG-ON” modes:
A station among those of the same network with strong reception and
broadcasting the same program is selected.
Each time the “AF” button is pressed, the mode changes in the following
order:
“AF-ON”, “REG-OFF” “AF-ON”, “REG-ON” “AF-OFF”, “REG-
OFF”.
Setting station presets
RDS (Radio Data System)
1
2

3765-13. Using the audio system (Lexus Display Audio System)
CT200h_OM_OM76102E_(EE)
Audio menu screen operation
To display the audio menu screen, move the controller to the left while on
an audio top screen.
FM or AM radio
Seek a station of the nearest
frequency (stops when a sta-
tion is found) (manual mode)
Change FM radio settings
(P. 373)
Change DAB settings (P.
373)
DAB
Adjust the playback offset
time on time shift mode
Cancel time shift operation
Select an ensemble (manual
mode)
Select a service (manual
mode)
Change FM radio settings
(P. 373)
Change DAB settings (P.
373)
You can change the settings and control functions for each audio source.
Audio menu screen
1
2
3
1
2
3
4
5
6

379
5 5-14. Using the radio (Lexus Display Audio System)
Audio system
CT200h_OM_OM76102E_(EE)
Radio operation
Pressing the “RADIO” button displays the radio top screen from any
screen of the selected source.
Menu screen
P. 3 7 6
Move the controller to the right to display the right menu screen.
Change the radio top screen to
the preset selection screen.
Change the radio top screen to
the station list selection screen.
(FM and DAB)
Change the radio top screen to
the manual selection screen.
Change the radio top screen to
the time shift operation screen.
(DAB) (P. 380)
Tune in to the desired station using one of the following methods.
Seek tuning
Manual screen: Press or press and hold “” or “” button.
Preset or station list screen: Press and hold “” or “” button.
Seek turning can also be operated on the menu screen. (P. 376)
The radio will begin seeking up or down for a station of the nearest fre-
quency and will stop when a station is found.
Select “AM”, “FM” or “DAB” on the “Source” screen to begin listening
to the radio.
Radio top screen
Changing the top screen mode
1
2
3
4
Selecting a station

3805-14. Using the radio (Lexus Display Audio System)
CT200h_OM_OM76102E_(EE)
Manual tuning (manual screen)
Turn the “TUNE•SCROLL” knob or turn the controller.
Station list (preset or station list screen)
Select the desired station by pressing “<” or “>”, turn the
“TUNE•SCROLL” knob or controller.
Radio stations can be preset.
Search for desired stations.
Turn the controller to select one of the stations and then press the
controller until you hear a beep while on the preset selection screen.
The broadcast you are currently listening to can be re-listened to at any
time.
Move the controller to the right and then select “Time shift”.
Turn the “TUNE•SCROLL” knob to set the desired offset.
An offset playback time can also be set on the menu screen. (P. 3 7 6 )
To cancel the time shift operation while in time shift mode, move the control-
ler to the left and select “Time shift off”. If the time shift display is left show-
ing “-0’ 00”” for 6 seconds without any operation, the time shift operation will
be canceled.
Reception sensitivity
Maintaining perfect radio reception at all times is difficult due to the continu-
ally changing position of the antenna, differences in signal strength and sur-
rounding objects, such as trains, transmitters, etc.
The radio antenna is mounted inside the rear window. To maintain clear radio
reception, do not attach metallic window tinting or other metallic objects to the
antenna wire mounted inside the rear window.
Traffic announcement operation
When traffic announcement is set to on, “TP” will appear on the screen and the
radio will begin seeking a TP station. If the radio seeks out a TP station, the pro-
gram name will appear on the screen. If a traffic announcement station is
received, the radio will be switched to the traffic information program automati-
cally. When the program ends, the initial operation will resume.
Setting station presets (preset screen)
Time shift operation (DAB)
1
2
1
2

669Alphabetical index
CT200h_OM_OM76102E_(EE)
Audio system
(with navigation system)
*
Audio system (with Lexus
Display Audio System) ...........354
Antenna ................................380
Audio input ...........................362
AUX port ..............................362
Bluetooth
® audio ..................405
CD player .............................381
iPod.......................................387
MP3/WMA disc ...................381
Optimal use...........................371
Portable music player ...........396
Radio ....................................379
Setup menu ...........................363
Steering wheel audio
switches ..............................361
USB memory ........................391Audio system (without Lexus
Display Audio System) .......... 290
Audio input .......................... 320
AUX port ............................. 320
Bluetooth
® audio ................. 342
CD player............................. 301
iPod ...................................... 309
MP3/WMA disc................... 301
Optimal use .......................... 295
Portable music player .......... 320
Radio.................................... 297
Steering wheel audio
switches ............................. 326
USB memory ....................... 315
Automatic air conditioning system
Air conditioning filter .......... 527
Automatic air conditioning
system........................ 442, 452
Automatic headlight leveling
system .................................... 214
Automatic light control
system .................................... 214
AUX port .......................... 293, 362
Auxiliary boxes ........................ 468
*: Refer to the “NAVIGATION SYSTEM OWNER’S MANUAL”.
