Page 80 of 688
801-2. Hybrid system
CT200h_OM_OM76102E_(EE)
Sounds and vibrations specific to a hybrid vehicle
There may be no engine sound or vibration even though the vehicle is able to
move with the “READY” indicator is illuminated. For safety, apply the parking
brake and make sure to shift the shift position to P when parked.
The following sounds or vibrations may occur when the hybrid system is operat-
ing and are not a malfunction:
Motor sounds may be heard from the engine compartment.
Sounds may be heard from the hybrid battery (traction battery) behind the rear
seats when the hybrid system starts or stops.
Relay operating sounds such as a snap or soft clank will be emitted from the
hybrid battery (traction battery), behind the rear seats, when the hybrid system
is started or stopped.
Sounds may be heard from the transmission when the gasoline engine starts or
stops, when driving at low speeds, or during idling.
Engine sounds may be heard when accelerating sharply.
Sounds may be heard due to regenerative braking when the brake pedal is
depressed or as the accelerator pedal is released.
Operating sounds or motor sounds that occur when the brake pedal is operated.
Vibration may be felt when the gasoline engine starts or stops.
Cooling fan sounds may be heard from the air intake vent on the side of rear
right seatback.
Maintenance, repair, recycling, and disposal
Contact any authorized Lexus dealer or repairer, or another duly qualified and
equipped professional regarding maintenance, repair, recycling and disposal. Do
not dispose of the vehicle yourself.
Customization Settings
Settings (e.g. on/off operation of the EV indicator) can be changed.
(Customizable features: P. 650)
Page 203 of 688
203
4 4-2. Driving procedures
Driving
CT200h_OM_OM76102E_(EE)
Hybrid transmission
Shift lever
Operate the shift lever gently and ensure correct shifting operation.
Release the shift lever after each shifting operation to allow it to return to the
position.
When shifting from P to N, D or R, from D to R, or from R to D, ensure that
the brake pedal is being depressed and the vehicle is stationary.
Shift position indicator
The current shift position is illuminated.
When any shift position other than D or B is selected, the arrow toward B and
B position indicator disappear from the shift position indicator.
When selecting the shift position, make sure that the shift position has
been changed to the desired position by checking the shift position indi-
cator provided on the instrument cluster.
Shifting the shift lever
1
When shifting to the D or R positions, move the shift lever along
the shift gate.
To shift to the N position, slide the shift lever to the left (left-hand
drive vehicle) or right (right-hand drive vehicle) and hold it. The
shift position will change to N.
To shift to the B position, pull the shift lever down. Shifting to B is
only possible when shift position D is selected.
2
Page 567 of 688
5638-2. Steps to take in an emergency
CT200h_OM_OM76102E_(EE)
8
When trouble arises
The following may indicate a problem with your hybrid transmission.
Contact any authorized Lexus dealer or repairer, or another duly qualified
and equipped professional before towing.
The hybrid warning message shows on and the vehicle does not move.
The vehicle makes an abnormal sound.
Do not tow with a sling-type truck
to prevent body damage.
Situations needs to contact dealers before towing
Towing with a sling-type truck
Towing with a wheel-lift type truck
From the frontFrom the rear
Release the parking brake. Use a towing dolly under the front
wheels.
