display Lexus CT200h 2016 Owner's Manual (in English)

596
CT200h_OM_OM76197U_(U)9-2. Customization
■Instrument cluster (
P. 84, 88)
*: If equipped
■Automatic air conditioning system ( P. 410, 418)
■Powe r w i n d ow s ( P. 1 3 7 )
FunctionDefault
settingCustomized setting
Display of the tachometer
and Hybrid System Indicator AutoHybrid system
indicator (always) –OOO
Tachometer
(always)
Eco lampEco drive sup-
portOn (always)–OOOOff
Sport lampOnOff–OOO
Brightness of Eco lamp and
sport lampStandardBright–OOO
EV indicatorAutoOff–OOO
LanguageEnglishFrench–OOOSpanish
Units
(except for Canada)miles (MPG)
km (km/L)
–OOOkm
(L/100km)
Units
(For Canada)km
(L/100km)km (km/L)–OOOmiles (MPG)
Sensitivity of the ambient
light sensor used for dim-
ming the meter light etc.
*
Standard-2 to 2–––O
Sensitivity of the ambient
light sensor used for bright-
ening the meter light etc.
*
Standard-2 to 2–––O
1234
FunctionDefault settingCustomized setting
A/C Auto switch operationOffOnO–OO
Heating/cooling operation
minimized in Eco drive
mode
OnOff–––O
1234

CT200h_OM_OM76197U_(U)
5979-2. Customization
9
Vehicle specifications
*: This function cannot be customized unless power window operation using the wire-less remote control is enabled.
■Intuitive parking assist* ( P. 202)
*: If equipped
■Seat belt reminder ( P. 5 3 1 )
FunctionDefault
settingCustomized setting
Mechanical key linked oper-
ation (close) Off On – – – O
Mechanical key
linked operation (open)Off On–––O
Wireless remote control
linked operation (open) OffOn
(Open only) –––O
Buzzer sounds if operated
using wireless remote con-
trol
*
OnOff–––O
1234
FunctionDefault
settingCustomized setting
Alert Volume
(Alert volume can be
adjusted)31 to 5O––O
Display
(Automatic display off the
LEXUS Park Assist graphic
can be enabled/disabled)
OnOffO––O
Distance
(Distance mode can be
selected)
LongShortO––O
1234
FunctionDefault settingCustomized setting
Vehicle speed linked seat
belt reminder buzzerOnOff–––O
1234

598
CT200h_OM_OM76197U_(U)9-2. Customization
■Reverse warning buzzer (
P. 1 6 4 )
■Vehicle customization
●When the Speed linked door locking function and the Shift position linked door locking
function are both on, the door lock operates as follows.
• When shifting the shift position to any position other than P, all the doors will be locked.
• If the vehicle is started with all the doors locked, the Speed linked door locking func-
tion would not operate.
• If the vehicle is started with any door unlocked, the Speed linked door locking func- tion will operate.
●When the smart access system with push-butto n start is off, Smart door unlocking can-
not be customized.
●When the doors remain closed after unloc king the doors and the automatic door lock
function is activated, the signals will be generated in accordance with the operation sig-
nal (buzzer) and the operation signal (emergency flashers) settings.
■In the following situations, customize mo de in which the settings can be changed
through the “DISP” switch will automatically be turned off.
●A warning message appears after the cu stomize mode screen is displayed.
●The power switch is turned off.
●The vehicle begins to move while the customize mode screen is displayed.
FunctionDefault
settingCustomized setting
Signal (buzzer) when the
shift position is in RIntermittentSingle–––O
WA R N I N G
■Cautions during customization
As the hybrid system needs to be operating during customization, ensure that the vehi-
cle is parked in a place with adequate vent ilation. In a closed area such as a garage,
exhaust gases including harmful carbon mo noxide (CO) may collect and enter the
vehicle. This may lead to death or a serious health hazard.
NOTICE
■During customization
To prevent 12-volt battery discharge, ensure that the hybrid system is operating while
customizing features.
1234

614What to do if... (Troubleshooting)
CT200h_OM_OM76197U_(U)
●The seat belt reminder light is flashing
Are the driver and the front passenger wearing the seat belts? ( P. 5 3 1 )
●The parking brake indicator is on
Is the parking brake released? ( P. 1 6 8 )
Depending on the situation, other type s of warning buzzer may also sound.
( P. 5 2 9 , 5 3 6 )
●Did anyone inside the vehicle open a door during setting the alarm?
The sensor detects it and the alarm sounds. ( P. 76 )
To stop the alarm, turn the power switch to ON mode or start the hybrid system.
●Is the electronic key left inside the vehicle or the moon roof opened?
Check the message on the multi-information display. ( P. 5 3 6 )
●When a warning light turns on or a warning message is displayed, refer to
P. 5 2 9 , 5 3 6 . A warning buzzer sounds during driving
An alarm is activated and the horn sounds
A warning buzzer sounds when leaving the vehicle
A warning light turns on or a warning message is displayed

617Alphabetical index
CT200h_OM_OM76197U_(U)
Audio system (with Lexus Display Audio system) .................... 320 Antenna ..................................................344
Audio input............................................326
AUX port...............................................326
Bluetooth
® audio ............................. 369
CD player .............................................. 347
iPod .......................................................... 353
MP3/WMA disc ............................... 347
Optimal use ......................................... 335
Portable music player ..................... 360
Radio ......................................................... 341
Setup menu .......................................... 328
Steering wheel audio switches ...............................................325
USB memory ...................................... 356
Audio system (without Lexus Display Audio system) .................... 252 Antenna .................................................. 262
Audio input........................................... 255
AUX port.............................................. 255
Bluetooth
® audio ............................... 310
CD player/changer..........................265
iPod ........................................................... 272
MP3/WMA disc ...............................265
Optimal use .......................................... 257
Portable music player ..................... 255
Radio ........................................................259
Steering wheel audio switches ...............................................254
USB memory .......................................278 Automatic air conditioning system
Air conditioning filter .......................502
Automatic air conditioning system ......................................... 410, 418
Automatic headlight leveling system ........................................................171
Automatic light control system ..........171
AUX port ..................................... 255, 326
Auxiliary boxes ..................................... 435
Back door ................................................... 110
Back-up lights Replacing light bulbs ........................ 518
Wattage ................................................. 579
Battery (12-volt battery) If the 12-volt battery is discharged......................................... 562
Preparing and checking before winter.................................................... 246
Warning light ....................................... 529
Battery (traction battery) ......................69
Bluetooth
®................................... 316, 390
Audio system ............................ 310, 369
Hands-free system (for cellular phone) ............. 284, 371
Bottle holders ........................................ 430
Brake Fluid .......................................................... 577
Parking brake ....................................... 168
Regenerative braking ..........................67
Warning light ....................................... 529
B
*: Refer to the “NAVIGATION SYSTEM OWNER’S MANUAL”.

619Alphabetical index
CT200h_OM_OM76197U_(U)
Cooling system ..................................... 482Hybrid system overheating ......... 566
Consumption screen ...............................91
Cruise control Cruise control....................................... 186
Dynamic radar cruise control ................................................... 189
Cup holders ............................................ 430
Curtain shield airbags ........................... 38
Customizable features ........................ 591
Daytime running light system ............170
Defogger Outside rear view mirrors....................................... 414, 420
Rear window ............................. 414, 420
Windshield ................................. 414, 420
Dimension ............................................... 572
Dinghy towing......................................... 155
Display Drive information ................................. 88
Dynamic radar cruise control ................................................... 189
Energy monitor ........................................91
Multi-information display ................. 88
Warning messages.......................... 536
Do-it-yourself maintenance ............. 473 Doors
Automatic door locking and unlocking system............................. 108
Back door................................................. 110
Door glasses .......................................... 137
Door lock................................................ 105
Open door warning buzzer ........530
Open door warning light ..............530
Outside rear view mirrors ..............135
Rear door child-protectors ........... 108
Side doors .............................................. 105
Drive information .................................... 88
Driver’s seat belt reminder light ........................................................... 531
Driver’s seat position memory.......... 124
Driving Break-in tips ...........................................145
Correct posture .................................... 30
Driving mode select switch .......... 234
Hybrid vehicle driving tips ............ 244
Procedures ............................................. 144
Winter drive tips ................................ 246
Driving position memory .................... 124 Memory recall function .................... 125
Dynamic radar cruise control Function ................................................... 189
Warning message...............................541
D

620Alphabetical index
CT200h_OM_OM76197U_(U)
ECO lamp .................................................. 86
EDR (Event data recorder) ................... 12
Electric motorLocation .....................................................65
Specification .........................................573
Electric Power Steering (EPS) Function ..................................................235
Warning light ...................................... 530
Electronic key If the electronic key does not operate properly............................ 560
Replacing the battery ...................... 504
Emergency flashers ............................. 522
Emergency, in case of If a warning buzzer sounds...........529
If a warning light turns on...............529
If a warning message is displayed............................................ 536
If the 12-volt battery is discharged .........................................562
If the electronic key does not operate properly............................ 560
If the hybrid system will not start ............................................... 558
If you have a flat tire ......................... 549
If you lose your keys ................102, 104
If you think something is wrong .................................................. 528
If your vehicle becomes stuck ..................................................... 570
If your vehicle has to be stopped in an emergency ..........523
If your vehicle needs to be towed....................................................524
If your vehicle overheats ............... 566 Energy monitor .......................................... 91
Engine
Accessory mode ................................. 157
Compartment ..................................... 478
Engine switch ........................................156
Hood........................................................ 475
How to start the hybrid system ....................................................156
Identification number....................... 573
If your vehicle has to be stopped in an emergency.......... 523
Ignition switch (power switch) ..................................156
Overheating.........................................566
Power switch .........................................156
Engine compartment cover..............479
Engine coolant Capacity................................................. 575
Checking ............................................... 482
Preparing and checking before winter .................................... 246
Engine oil Capacity................................................. 574
Checking ............................................... 479
Oil pressure warning light ............ 529
Engine oil maintenance data ........... 468
Engine switch ........................................... 156 Auto power off function .................. 158
Changing the power switch modes .................................................... 157
If your vehicle has to be stopped in an emergency.......... 523
Starting the hybrid system...............156
EPS (Electronic Power Steering) Function .................................................. 235
Warning light .......................................530
E

623Alphabetical index
CT200h_OM_OM76197U_(U)
JackPositioning a floor jack .................... 477
Vehicle-equipped jack .................. 550
Jack handle .............................................550
Jam protection function Moon roof ................................................ 141
Power windows ................................... 138
Keyless entry Smart access system with push-button start ............................... 114
Wireless remote control .................100
Keys............................................................. 100 Electronic key .......................................100
Engine switch ........................................ 156
If the electronic key does not operate properly............................ 560
If you lose your keys ................102, 104
Key number plate ...............................100
Keyless entry .........................................100
Mechanical key ....................................100
Power switch......................................... 156
Replacing the battery ...................... 504
Warning buzzer .................................... 115
Wireless remote control key ........100
Knee airbags ............................................. 38 Language (multi-information
display) .................................................. 596
LATCH anchors .......................................56
Lever Auxiliary catch lever ......................... 475
Hood lock release lever................. 475
Shift lever ................................................. 162
Turn signal lever ................................... 167
Wiper lever............................................. 174
Lexus Display Audio controller ................91, 206, 412
Lexus parking assist monitor Display..................................................... 220
Function .................................................... 219
Precautions ........................................... 226
License plate lights Light switch.............................................169
Replacing light bulbs .........................519
Light Fog light switch ..................................... 172
Headlight switch ..................................169
Illuminated entry system................. 428
Interior lights ........................................ 428
Interior light list .....................................427
Luggage compartment light ............. 111
Personal lights ......................................427
Replacing light bulbs ...................... 509
Turn signal lever ................................... 167
Vanity lights .......................................... 439
Wattage ................................................. 579
Light bulbs Replacing .............................................. 509
Wattage ................................................. 579
Luggage cover ...................................... 436
J
K
L

624Alphabetical index
CT200h_OM_OM76197U_(U)
MaintenanceDo-it-yourself maintenance...................................... 473
General maintenance .................... 469
Maintenance data .............................. 572
Maintenance requirements........... 467
Malfunction indicator lamp .............. 529
Meter Indicators.................................................. 80
Instrument panel light control .................................................... 85
Meters.........................................................84
Multi-information display ................. 88
Warning lights .....................................529
Warning messages.......................... 536
Micro dust and pollen filter ............................................... 414, 420
Microphone ................................. 286, 372
Mirrors Inside rear view mirror ......................132
Outside rear view mirror defoggers ................................ 414, 420
Outside rear view mirrors .............. 135
Vanity mirrors ......................................439
Moon roof Jam protection function ..................... 141
Operation ............................................... 140
Warning message .............................542
MP3 disc....................................... 265, 347 Multi-information display
Drive information..................................88
Dynamic radar cruise control................................................... 189
Energy monitor........................................ 91
Language...............................................596
Warning messages ..........................536
Navigation system
*
Noise from under vehicle ...................... 10
Odometer .................................................. 85
Oil Engine oil ............................................... 574
Opener Back door................................................... 111
Fuel filler door....................................... 183
Hood........................................................ 475
Outside rear view mirrors .................. 135 Adjusting and folding ........................135
Outside rear view mirror defoggers............................................. 414
Outside temperature display ............. 84
Overhead console .............................. 435
Overheating........................................... 566
M
N
O
