seat memory Lexus ES300 1999 Owner's Manuals (in English)

PE004±3
PICTORIAL INDEX
xvii
SEAT AND STEERING WHEEL
Page
1 Tilt steering adjustment lever 118 . . . . . . . . . . . . . . .
2 Driving position memory
switch 188 . . . . . . . . . . . . . .
3 Seat position, seat
cushion angle and height control switch 112 . . . . . . . . . . . . . .
4 Seatback angle control
switch 113 . . . . . . . . . . . . . .
5 Lumbar support control
switch 115 . . . . . . . . . . . . . .
For detailed information, refer to the description givenin each section.

SECTION 1 ± 6
108
INSTRUMENTS AND CONTROLS
Comfort adjustment
Front seats108
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Trunk storage extension 11 5
. . . . . . . . . . . . . . . . . . . . . . .
Head restraints 11 6
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tilt steering wheell1 18
. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Outside rear view mirrors 11 9
. . . . . . . . . . . . . . . . . . . . . .
Inside rear view mirror 123
. . . . . . . . . . . . . . . . . . . . . . . . .
Seat belts 125
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Supplemental restraint system (SRS) 136
. . . . . . . . . . . .
Child restraint 161
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Driving position memory system 188
. . . . . . . . . . . . . . . .
FRONT SEATS
Front seat precautions

COMFORT ADJUSTMENT
188
16E034±1

1Bolt 2Anchor bracket 3Spacer
3. Insert a 15 mm (0.6 in.) spacer, and tighten down the
anchor bracket for your child restraint system with a bolt.
Torque the bolt to 16.5 ± 24.7 N´m (1.68 ±2.52 kgf´m,
12.2 ± 18.2 ft´lbf.).
To comply with Canadian Motor Vehicle Safety
Standards, this model sold in Canada is provided with a
bracket set in the glovebox, designed for use with any of
the 3 anchor locations shown in the illustration.
DRIVING POSITION MEMORY SYSTEM
The micro computer can memorize the position of the
driver's seat. Two different driving position profiles can
be entered into the computer's memory.
Recording a driving position in the computer's memory
can only be done when the ignition key is in the ºONº
position and the selector lever is in the ºPº position.
Setting a driving position
16E047

COMFORT ADJUSTMENT
189
1. Adjust the driver's seat to the desired position.
2. While
pushing the ºSETº button, push button º1º
or º2º until the signal beeps.
The beep sound means that the positions are recorded
in the computer's memory. By repeating these two steps and pressing the
remaining button, the driving position for another driver
can be recorded.
To set a new memorized position, select the desired
position and perform step 2. The previous memory will
be erased and the new position will be set.
To make only slight changes to an already memorized
position, the easiest way is to first activate the
memorized position, then make the desired changes
and perform step 2 above.

COMFORT ADJUSTMENT
191
Conditions for memorized position activation

Ignition key ºONº and selector lever in ºPº position
All parts of the memorized positions can be activated.
However, if the brake pedal is being depressed, the
seat position will not change.
 Key not in ignition switch and within 30 seconds of
opening driver's door.
The memorized position can be activated.
If any driving position memory switch is pushed while
one of the memorized driving position profiles is being
activated, the operation will stop.
To activate the system, push the desired button (º1º or
º2º) again.
The driving position memory control system cannot be
operated while the vehicle is moving.
If the vehicle's battery is disconnected, the computer's
memory will be erased and the memorized positions will
have to be set again.

COMFORT ADJUSTMENT
192
CAUTION
Do not start the vehicle while the adjustments are
being made.
 Take care not to select the wrong button, or the seat
could strike the rear passenger or hit your body
against the steering wheel. If this happens, you can
stop the movement by pressing another driving
position memory switch, or depressing the brake
pedal.
