DRIVING TIPS
327
Tires
Ensure that your vehicle's tires are properly inflated.
Adjust the tire pressure to the recommended cold tire
pressure indicated below:
Tire pressure, kPa (kgf/cm
2 or bar, psi)
Front 220 (2.2, 32)
Rear 220 (2.2, 32)
 The trailer tires should be inflated to the pressure
recommended by the trailer manufacturer in respect
to the total trailer weight.
Trailer lights
Trailer lights must comply with federal,
state/provincial and local regulations. See your local
recreational vehicle dealer or rental agency for the
correct type of wiring and relays for your trailer.
Check for correct operation of the turn signals and
stop lights each time you hitch up. Direct splicing may
damage your vehicle's electrical system and cause a
malfunction of your lights.
Break±in schedule
 Lexus recommends that you do not tow a trailer with
a new vehicle or a vehicle with any new power train
component (engine, transmission, differential, wheel
bearing, etc.) for the first 800 km (500 miles) of
driving.
Maintenance
If you tow a trailer, your vehicle will require more
frequent maintenance due to the additional load. For
this information, please refer to the scheduled
maintenance information in the ªOwner's Manual
Supplement/ Maintenance Scheduleº.
 Retighten all fixing bolts of the towing ball and bracket
after approximately 1000 km (600 miles) of trailer
driving.
Pre±towing safety check
 Check that your vehicle remains level when a loaded
or unloaded trailer is hitched. Do not drive if the
vehicle has an abnormal nose±up or nose±down
condition, and check for improper tongue load,
overload, worn suspension or other possible causes.
 Make sure the trailer cargo is securely loaded so that
it cannot shift.
 Check that your rear view mirrors conform to any
federal, state/provincial or local regulation. If they do
not, install required rear view mirrors appropriate for
towing purposes.

DRIVING TIPS
329
wheels will be closer than the vehicle wheels to the
inside of the turn. Therefore, compensate for this by
making a larger than normal turning radius with your
vehicle.

Crosswinds and rough roads will adversely affect
handling of your vehicle and trailer, causing sway.
Pay attention to the rear from time to time to prepare
yourself for being passed by large trucks or buses,
which may cause your vehicle and trailer to sway. If
swaying happens, firmly grip the steering wheel and
reduce speed immediately but gradually. Never
increase speed. If it is necessary to reduce speed,
brake slowly. Steer straight ahead. If you make no
extreme correction with the steering or brakes, your
vehicle and trailer will stabilize.
 Be careful when passing other vehicles. Passing
requires considerable distance. After passing a
vehicle, do not forget the l ength of your trailer and be
sure you have plenty of room before changing lanes.
 In order to maintain efficient engine braking and
electrical charging performance, do not use
overdrive.
 Because of the added load of the trailer, your vehicle's
engine may overheat on hot days (at temperatures
over 30C [85F]) when going up a long or steep
grade with a trailer. If the engine coolant temperature
gauge indicates overheating, immediately turn off the
air conditioning (if in use), pull your vehicle off the
road and stop in a safe spot. See ªIf your vehicle
overheatsº on page 342 of this manual.
 Always place wheel blocks under both the vehicle
and trailer wheels when parking. Apply the parking
brake firmly. Put the transmission in ªPº. Avoid

CHASSIS
413
SPECIFICATIONS
± AUTOMATIC TRANSAXLEFluid capacity Drain and refill
Fluid type
3.5 L (3.7 qt., 3.1 lmp. qt.)
Automatic transmission fluid Type T±IV*
*Change automatic transmission fluid only as
necessary. Generally, it is necessary to change
automatic transmission fluid only if your vehicle is driven
under one of the Special Operating Conditions listed in
your ªOwner's Manual Supplement/Maintenance
Scheduleº. When changing the automatic transmission
fluid, use only Toyota Genuine ATF Type T±IV (ATF
JWS3309 or NWS6500) to aid in assuring optimum
transaxle performance.NOTICE
Using automatic transmission fluid other than Toyota Genuine ATF Type T±IV may causedeterioration in shift quality, locking up of yourtransmission accompanied by vibration, andultimately damage the automatic transmission ofyour vehicle.
