ODOMETER AND TRIP METER
Trip meter reset knob
This meter displays the odometer and two trip meters. To
change the mode indication, push the trip meter reset
knob briefly. Each time you push the knob, the mode
changes in order from the odometer to trip meter A to trip
meter B, then back to the odometer.
The odometer records the total distance the vehicle has
been driven. The twin trip meter records two different
distances independently.
For example, you can use one meter to calculate the fuel
economy and the other to measure the distance on each trip.
To set the A trip meter to zero, display the A meter reading,
push the knob and hold it. The same applies for the B trip
meter.
The data of trip meters will be cancelled if the electrical power
source is disconnected.
SERVICE REMINDER INDICATORS AND WARNING BUZZERS
IF THIS INDICATOR
OR BUZZER COMES
ON ... DO THIS.
(a)
If parking brake is off,
stop immediately and
contact Lexus dealer.
(b) Fasten seat belt.

(indicator and buzzer)
(c) Fasten front
passenger’s seat belt.
(on the center console)
(d) Take vehicle to Lexus
dealer immediately.
or
13E050

GAUGES, METERS AND SERVICE REMINDER INDICATORS
49
(e) Stop and check.
(f) Stop and check.
(g) Add engine oil.
(h) Take vehicle to Lexus
dealer.
(i) Take vehicle to Lexus dealer.
(j) Close all doors.
(k) Replace bulb.
(l) Take vehicle to Lexus dealer.
(m) Add washer fluid. (n) Take vehicle to
Lexus dealer.
(o) Low fuel level Fill up tank. warning light
(p) Key reminder buzzer Remove key.
or
w59

GAUGES, METERS AND SERVICE REMINDER INDICATORS
50
(a) Brake System Warning Light
This light comes on in the following cases when the ignition key
is in the “ON” position.
 When the parking brake is applied...
This light comes on for a few seconds when the ignition key is
turned to the “ON” position even after the parking brake is
released.
 When the brake fluid level is low...
CAUTION
It is dangerous to continue driving normally when the
brake fluid level is low.
Have your vehicle checked at your Lexus dealer in the
following cases.
The light does not come on even if the parking brake is
applied when the ignition key is in the “ON” position.
 The light does not come on even if the ignition key is turned
on with the parking brake released.
A warning light turning on briefly during operation does not
indicate a problem.
CAUTION
If either of the following conditions occurs, immediately
stop your vehicle at a safe place and contact your Lexus
dealer.
 The light does not turn off even after the parking
brake is released while the engine is running.
In this case, the brakes may not work properly and
your stopping distance will become longer. Depress
the brake pedal firmly and bring the vehicle to an
immediate stop.
 The brake system warning light remains on together
with the “ABS” warning light.
In this case, not only the antilock brake system will
fail but also the vehicle will become extremely
unstable during braking.
(b) Driver’s Seat Belt Reminder Light and
Buzzer
This light and buzzer remind you to buckle up the driver’s seat
belt.
Once the ignition key is turned to “ON” or “START”, the
reminder light and buzzer come on if the driver’s seat belt is not
fastened. Unless the driver fastens the belt, the light stays on
and the buzzer stops after about 4 to 8 seconds.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
51
(c) Front Passenger’s Seat Belt ReminderLight
This light reminds you to buckle up the front passenger’s seat
belt.
Once the ignition key is tur ned to the “ON” position, the
reminder light flashes if a front passenger sits in the front
passenger seat and does not fasten the seat belt. Unless the
front passenger fastens the belt, the light keeps flashing.
If luggage load is placed on the front passenger seat,
depending on its weight and how it is placed on the seat,
builtin sensors in the seat cushion may detect the pressure,
causing the reminder light to come on.
(d) SRS Warning Light
This light comes on when the ignition key is turned to the
“ON” position. It goes off after about 6 seconds. This
means the SRS airbags and seat belt pretensioners are
operating properly.
This warning light system monitors the airbag sensor
assembly, front airbag sensors, side and curtain shield airbag
sensor assemblies, curtain shield airbag sensor assemblies,
driver’s seat position sensor, driver’s seat belt buckle switch,
front seat belt pretensioner assemblies, inflators, warning light,
interconnecting wiring and power sources. If any of the following conditions occurs, this indicates a
malfunction
somewhere in the parts monitored by the warning
light system. Contact your Lexus dealer as soon as possible
to service the vehicle.
 The light does not come on as described above.
 The light stays on or flashes.
 The light comes on or starts flashing while driving.
If the light stays on, it indicates that the driver and front
passenger airbags fail. If the light flashes, the side and curtain
shield airbags and/or seat belt pretensioners fail.
(e) Discharge Warning Light
This light warns that the battery is being discharged.
If it comes on while you are driving, stop the vehicle, turn off the
engine, and check for the cause. Look first at the engine drive
belt.
 If it is loose or broken, the generator will not charge the
battery properly.
 If the belt is O.K., there is a problem somewhere in the
charging system.
The engine ignition will continue to operate, however, until the
battery is discharged. Turn off the air conditioning, blower,
radio, etc., and drive directly to the nearest Lexus dealer or
repair shop.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
52
NOTICE
Do not continue driving if the engine drive belt is broken
or loose.
(f) Low Engine Oil Pressure Warning Light
This light warns that the engine oil pressure is too low.
If it flickers or stays on while you are driving, pull off the road
to a safe place and stop the engine immediately. Call a Lexus
dealer or qualified repair shop for assistance.
The light may occasionally flicker when the engine is idling or
it may come on briefly after a hard stop. There is no cause for
concern if it then goes out when the engine is accelerated
slightly.
The light may come on when the oil level is extremely low. It
is not designed to indicate low oil level, and the oil level must
be checked using the oil level dipstick.
NOTICE
Do not drive the vehicle with the warning light on even
for one block. It may ruin the engine.
(g) Low Engine Oil Level Warning Light
This light warns that the engine oil level is too low. Add oil as
soon as possible. (For instructions, see “Checking the engine
oil level” on page 302.)
While driving on steep inclines or rough roads which causes
the vehicle to substantially sway or on curves, this light may
come on due to the movement of engine oil in the engine.
NOTICE
Continued engine operation with low engine oil will
damage the engine.
(h) Malfunction Indicator Lamp
This lamp comes on when the ignition key is turned to the
“ON” position and goes off after the engine starts. This
means that the warning light system is operating properly.
If the lamp remains on, or the lamp comes on while
driving, first check the followings.
 Empty fuel tank
If the fuel tank is empty, refuel immediately.
 Loose fuel tank cap
If the fuel tank cap is loose, securely tighten it.
These cases are temporary malfunctions. The malfunction
indicator lamp will go off after taking several driving trips.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
53
If the lamp will not go off even after the several trips, contact
your Lexus dealer as soon as possible.
If the fuel tank is not empty or the fuel tank cap is not
loose...

There is a problem somewhere in the engine, emission
control system, electronic throttle control system, automatic
transmission electrical system or warning light system itself.
Contact your Lexus dealer as soon as possible to service the
vehicle.
If the engine speed does not increase with the accelerator
pedal depressed down, there may be a problem somewhere
in your electronic throttle control system.
At this time, vibration may occur. However, if you depress the
accelerator pedal more firmly and slowly, you can drive your
vehicle at low speeds. Have your vehicle checked by your
Lexus dealer as soon as possible.
Even if the abnormality of the electronic throttle control system
is corrected during low speed driving, the system may not be
recovered until the engine is stopped and the ignition key is
turned to “ACC” or “LOCK” position.
CAUTION
Be especially careful to prevent erroneous pedal
operation.
Emissions Inspection and Maintenance (I/M) programs
Your vehicle may not pass a state emission inspection if the
malfunction indicator lamp remains on. Contact your Lexus
dealer to check your vehicle’s emission control system and
OBD (OnBoard Diagnostics) system before taking your
vehicle for the inspection.
For details, see “Emissions Inspection and Maintenance (I/M)
programs” on page 285.
(i) “ABS” Warning Light
Vehicles without vehicle skid control system—
The light comes on with the ignition key turned to the “ON”
position. If the antilock brake system works properly, the light
turns off after a few seconds. Thereafter, if the system
malfunctions, the light comes on again.
When the “ABS” warning light is on (and the brake system
warning light is off), the antilock brake system does not
operate, but the brake system still operates conventionally.
When the “ABS” warning light is on (and the brake system
warning light is off), the antilock brake system does not
operate so that the wheels could lock up during a sudden
braking or braking on slippery road surfaces.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
54If either of the following conditions occurs, this indicates
a malfunction somewhere in the parts monitored by the
warning light. Contact your Lexus dealer as soon as
possible to service the vehicle.

The light does not come on when the ignition key is turned
to the “ON” position, or remains on.
 The light comes on while you are driving.
A warning light turning on briefly during operation does not
indicate a problem.
CAUTION
If the “ABS” warning light remains on together with the
brake system warning light, immediately stop your
vehicle at a safe place and contact your Lexus dealer.
In this case, not only the antilock brake system will fail
but also the vehicle will become extremely unstable
during braking.
Vehicles with vehicle skid control system—
The light comes on with the ignition key turned to the “ON”
position. If the antilock brake system and the brake assist
system work properly, the light turns off after a few seconds.
Thereafter, if the system malfunctions, the light comes on
again. When the “ABS” warning light is on (and the brake system
warning light is off), the antilock brake system, the brake
assist
system, the traction control system and the vehicle skid
control system do not operate, but the brake system still
operates conventionally.
When the “ABS” warning light is on (and the brake system
warning light is off), the antilock brake system does not
operate so that the wheels could lock up during a sudden
braking or braking on slippery road surfaces.
If either of the following conditions occurs, this indicates
a malfunction somewhere in the parts monitored by the
warning light. Contact your Lexus dealer as soon as
possible to service the vehicle.
 The light does not come on when the ignition key is turned
to the “ON” position, or remains on.
 The light comes on while you are driving.
A warning light turning on briefly during operation does not
indicate a problem.CAUTION
If the “ABS” warning light remains on together with the
brake system warning light, immediately stop your
vehicle at a safe place and contact your Lexus dealer.
In this case, not only the antilock brake system will fail
but also the vehicle will become extremely unstable
during braking.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
55
(j) Open Door Warning Light
This light remains on until all the doors are completely closed.
(k) Rear Light Failure Warning Light
If this light comes on when the headlight switch is turned on (at
the first or second clickstop), it indicates that one or more of the
tail lights are burned out.
If it comes on when the brake pedal is depressed, one or more
stop lights are burned out.
Have defective bulbs replaced as soon as possible.
(l) Vehicle Skid Control System/Traction Control System Warning Light
This light warns that there is a problem somewhere in the
vehicle skid control system or traction control system.
The light will come on when the ignition key is turned to “ON”
and will go off after a few seconds.
If the light comes on while driving, the system does not work.
However, as conventional braking operates when applied,
there is no problem to continue your driving.
In the following cases, contact your Lexus dealer:
The warning light does not come on after the ignition key is
turned to “ON”.
 The warning light remains on after the ignition key is turned
to “ON”.
 The warning light comes on while driving. The “TRAC OFF” indicator light will come on when the “VSC”
warning light comes on even if the “TRAC OFF” switch is not
pushed.
(m) Low Washer Fluid Warning Light
This light comes on when the fluid level in the tank becomes
nearly empty. Fill the tank as soon as possible.
(n) Automatic Headlight Leveling System
Warning Light (vehicles with discharge
headlight only)
This light warns that when there is a problem somewhere
in the automatic headlight leveling system.
If it comes on, have your vehicle checked by your Lexus dealer.
(o) Low Fuel Level Warning Light
This light comes on when the fuel level in the tank becomes
nearly empty. Fill the tank as soon as possible.
On inclines or curves, due to the movement of fuel in the tank,
the low fuel level warning light may come on earlier than usual.
(p) Key Reminder Buzzer
This buzzer reminds you to remove the key when you open the
driver’s door with the ignition key in the “ACC” or “LOCK”
position.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
56
How to check all the service reminder
indicators
(except the low fuel level warning light and low washer
fluid warning light):
1. Apply the parking brake.
2. Open the door.
The following service reminder indicator should come on. It
goes off when you close the door completely.
3. Turn the ignition key to “ON”.
The following service reminder indicators should come on.
or

or

w069
The following service reminder indicators go off after a few
seconds.
or
w069
The following service reminder indicator goes off after 6
seconds.
If any service reminder indicator or warning buzzer does not
function as described above, have it checked by your Lexus
dealer as soon as possible.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
57
MULTIINFORMATION DISPLAY
13E068
The following information is displayed in the instrument
cluster when you push the “MODE” button with the
ignition switch turned on.
Each time you push the “MODE” button, the display
toggles through this information.
(1) Instantaneous fuel consumption
(2) Average fuel consumption
(3) Driving range
(4) Average vehicle speed
(5) Driving time
The displayed values in the multiinformation display indicate
general driving conditions. Accuracy varies with driving habits
and road conditions.
When the ignition switch is on, the last previously used mode
displayed just before the ignition switch is off will appear.
If the electrical power source has been disconnected from the
multiinformation display , the display will automatically be set
to the initial mode.
When the instrument panel lights are turned on, the brightness
of the display will be reduced.
CAUTION
Do not adjust the display while the vehicle is moving.
Be sure to adjust the display only when the vehicle is
stopped.
