lights Lexus ES300 2002 Owner's Manuals (in English)

For detailed information, refer to the description given in each section\
.
PICTORIAL INDEX
viiiPage
1
Tachometer 47
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2 Traction control system off indicator light 234 . . . .
3 Vehicle skid control system/traction control
system warning light 55
. . . . . . . . . . . . . . . . . . . . . . . . .
4 Headlight indicator light 26
. . . . . . . . . . . . . . . . . . . . . .
5 Headlight high beam indicator light 31
. . . . . . . . . . .
6 Turn signal indicator light 31
. . . . . . . . . . . . . . . . . . . .
7 Fog light indicator light 32
. . . . . . . . . . . . . . . . . . . . . . .
8 Cruise control indicator light 230
. . . . . . . . . . . . . . . .
9 Slip indicator light 234, 236
. . . . . . . . . . . . . . . . . . . . . .
10 Automatic headlight leveling system
warning light 55 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
11 Low fuel level warning light 55
. . . . . . . . . . . . . . . . . . .
12 Automatic transmission indicator lights 223 . . . . . .
13 Engine coolant temperature gauge 46
. . . . . . . . . . . . Page
14 Odometer and trip meter
48
. . . . . . . . . . . . . . . . . . . . .
15 Trip meter reset knob 48
. . . . . . . . . . . . . . . . . . . . . . . .
16 Fuel gauge 46
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
17 Low washer fluid warning light 55
. . . . . . . . . . . . . . . .
18 Low engine oil level warning light 52
. . . . . . . . . . . . .
19 Multiinformation display 57
. . . . . . . . . . . . . . . . . . . . .
20 Rear light failure warning light 55
. . . . . . . . . . . . . . . .
21 Low engine oil pressure warning light 52
. . . . . . . . .
22 Brake system warning light 50
. . . . . . . . . . . . . . . . . . .
23 Antilock brake system warning light 53
. . . . . . . . . .
24 Driver’s seat belt reminder light 50
. . . . . . . . . . . . . . .
25 Discharge warning light 51
. . . . . . . . . . . . . . . . . . . . . .
26 SRS warning light 51
. . . . . . . . . . . . . . . . . . . . . . . . . . . .
27 Open door warning light 55
. . . . . . . . . . . . . . . . . . . . . .
28 Malfunction indicator lamp 52
. . . . . . . . . . . . . . . . . . .

For detailed information, refer to the description given in each section\
.
PICTORIAL INDEX
xPage
1
Tachometer 47
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2 Traction control system off indicator light 234 . . . .
3 Vehicle skid control system/traction control
system warning light 55
. . . . . . . . . . . . . . . . . . . . . . . . .
4 Tail light indicator light 28
. . . . . . . . . . . . . . . . . . . . . . .
5 Headlight high beam indicator light 31
. . . . . . . . . . .
6 Turn signal indicator light 31
. . . . . . . . . . . . . . . . . . . .
7 Fog light indicator light 32
. . . . . . . . . . . . . . . . . . . . . . .
8 Cruise control indicator light 230
. . . . . . . . . . . . . . . .
9 Slip indicator light 234, 236
. . . . . . . . . . . . . . . . . . . . . .
10 Automatic headlight leveling system
warning light 55 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
11 Low fuel level warning light 55
. . . . . . . . . . . . . . . . . . .
12 Automatic transmission indicator lights 223 . . . . . .
13 Engine coolant temperature gauge 46
. . . . . . . . . . . . Page
14 Odometer and trip meter
48
. . . . . . . . . . . . . . . . . . . . .
15 Trip meter reset knob 48
. . . . . . . . . . . . . . . . . . . . . . . .
16 Fuel gauge 46
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
17 Low washer fluid warning light 55
. . . . . . . . . . . . . . . .
18 Low engine oil level warning light 52
. . . . . . . . . . . . .
19 Multiinformation display 57
. . . . . . . . . . . . . . . . . . . . .
20 Rear light failure warning light 55
. . . . . . . . . . . . . . . .
21 Low engine oil pressure warning light 52
. . . . . . . . .
22 Brake system warning light 50
. . . . . . . . . . . . . . . . . . .
23 Antilock brake system warning light 53
. . . . . . . . . .
24 Driver’s seat belt reminder light 50
. . . . . . . . . . . . . . .
25 Discharge warning light 51
. . . . . . . . . . . . . . . . . . . . . .
26 SRS warning light 51
. . . . . . . . . . . . . . . . . . . . . . . . . . . .
27 Open door warning light 55
. . . . . . . . . . . . . . . . . . . . . .
28 Malfunction indicator lamp 52
. . . . . . . . . . . . . . . . . . .

PICTORIAL INDEX
xii
EXTERIOR VIEW
Page
1 Rear window defogger 37
. . . . . . . . . .
2 Trunk lid 83
. . . . . . . . . . . . . . . . . . . . . . .
3 Tire and wheel 315
. . . . . . . . . . . . . . . .
4 Moon roof 88
. . . . . . . . . . . . . . . . . . . . .
5 Outside rear view mirror 99
. . . . . . . .
6 Fuel filler door 85
. . . . . . . . . . . . . . . . .
7 Door 20
. . . . . . . . . . . . . . . . . . . . . . . . . .
8 Headlights 26, 28, 338
. . . . . . . . . . . . . .
9 Hood 82
. . . . . . . . . . . . . . . . . . . . . . . . . .
10 Wiper and washer 32, 336
. . . . . . . . . .
For detailed information, refer to the
description given in each section.

Automatic light control
Parking, tail, license plate,
side marker and instrument
panel lights turn on.
Headlights turn on at full
intensity.
Daytime running light
system off
Parking, tail, license plate,
side marker and instrument
panel lights turn on.
Headlights also turn on.
BE004
BE004
Parking, tail, license plate,
side marker and instrument
panel lights turn on.
Headlights turn on at full
intensity.
Automatic light control
Parking, tail, license plate,
side marker and instrument
panel lights turn on.
Headlights also turn on.
Automatic light control
QUICK REFERENCE
4
4. HEADLIGHT AND TURN SIGNAL SWITCH
HEADLIGHT SWITCH (U.S.A.)
With the ignition OFF
With the engine started and parking brake
released
 HEADLIGHT SWITCH (Canada)
With the ignition OFF
With the engine started and parking brake
released

KEYS AND DOORS
14
Locking/Unlocking the doors
When you push the “LOCK” button on the key briefly, all
the doors can be locked from outside the vehicle.
At this time, one beep sounds and the turn signal lights flash
once.* However, when you push the “LOCK” button with any
door not closed securely, the buzzer sounds for 10 seconds.**
To stop the buzzer, close all the doors securely or push the
“UNLOCK” button. If the key is in the ignition switch, locking
cannot be done.
Make sure all the doors are locked when you leave the vehicle.
Push the “LOCK” button once again.
NOTE:
* The turn signal lights can be set not to flash and beep
volume can be changed.
** The buzzer can be set not to sound if a door is not closed
securely.
Ask your Lexus dealer for details.
NOTICE
Do not push the “LOCK” button any longer than 2 to 3
seconds. Pushing the button longer activates an alarm.
For details, see page 16.
When you push the “UNLOCK” button, the driver’s door
is unlocked. Pushing that button once again within 3
seconds from the first push, all other doors are also
unlocked.*
NOTE:
* The 2step unlocking function can be changed.
Ask your Lexus dealer for details.
At this time, two beeps sound and the turn signal lights flash
twice.* Together with the activation of unlocking, the interior
light comes on for 15 seconds if the interior light switch is in
“DOOR” position.** However, this function does not work
when the ignition key is in the “ACC” or “ON” position. For\
further information, see “Illuminated entry system” on page 64.
You have 30 seconds to open a door after using the wireless
remote unlock feature.*** If a door is not opened by then, all
the doors will be automatically locked again.
Even if the “LOCK” or “UNLOCK” button is kept pressed in, the
locking or unlocking operation is not repeated. Release the
button and then push again. NOTE:
* The turn signal lights can be set not to flash and beep
volume can be changed.
** The duration of lighting can be changed
*** The time before automatic relocking can be changed.
Ask your Lexus dealer for details.

SWITCHES
26
HEADLIGHT SWITCH(U.S.A.)
“AUTO” position
The headlights and all other lights automatically turn on
depending on the darkness of the surroundings when the
ignition key is in the “ON” position.*
NOTE:
* The operating condition or sensitivity can be changed.
Ask your Lexus dealer for details.
To turn on the lights manually, twist the knob on the end
of the lever.
First clickstop: Only the parking, tail, license plate, side
marker and instrument panel lights turn on.
Second clickstop: Headlights also turn on.
When the headlights are on, the headlight indicator lights up in
the instrument cluster. Twist the knob to the second clickstop to turn on the
headlight if they are needed immediately when entering a
dark tunnel, parking structure, etc.
When the headlight switch is turned to the first or second
clickstop, the brightness of the instrument cluster will be
reduced slightly unless the instrument panel light control dial
is turned fully up.
“DRL OFF” position
The daytime running light (DRL) system does not work
when the knob is set in this position.
For details, see the following “Daytime Running Light (DRL)
System”.

SWITCHES
27
The automatic light control sensor is on top of the driver’s side
instrument panel.
Do not place anything on the instrument panel, and/or do not
affix anything on the windshield to block this sensor.
When the headlights are on, they automatically turn off about
30 seconds after any door or trunk lid is opened and closed
with the ignition key turned to the “ACC” or “LOCK” position\
.*
To turn them on again, turn the ignition key to the “ON” position,
or twist the knob on the end of lever to the “AUTO” position and
then twist the knob until the first or second clickstop.
If you are going to park for over one week, make sure the knob
is in the “AUTO” position.
NOTE:
* The time before turning off the lights can be changed.
Ask your Lexus dealer for details. Daytime Running Light (DRL) System
When the knob is set in the “AUTO” position, the headlights
turn on at
reduced intensity when the parking brake is released
with the engine started. They will not go off until the ignition
switch is turned off.
The headlights will automatically adjust to full intensity and/or
turn on the other lights dependi ng on the darkness of the
surroundings.
To turn on the other exterior lights and instrument panel lights,
twist the knob to the first clickstop.
Twist the knob to the second clickstop to turn on the headlights
to full intensity for driving at night.
To cancel the DRL system, twist the knob to the “DRL OFF”
position.
NOTICE
To prevent the battery from being discharged, do not
leave the lights on longer than necessary when the
engine is not running.

SWITCHES
28
Automatic headlight leveling system
(vehicles with discharge headlight only)
Vehicle position changes according to loading condition,
passengers getting on and off, vehicle acceleration and
deceleration, etc. However, as the headlight beam level is
always maintained automatically by the system at the proper
level, your headlights do not dazzle other road users.
If this system fails, the warning light in the instrument cluster
comes on. If this occurs, have your vehicle checked by your
Lexus dealer.
If you replace the rear suspension and/or the vehicle height
changes, contact your Lexus dealer to check the automatic
headlight leveling system and headlight beam level.
HEADLIGHT SWITCH(Canada)
To turn the lights on, twist the knob on the end of the lever.
FIRST CLICKST OP: Only the parking, tail, license plate, side
marker and instrument panel lights turn on.
SECOND CLICKSTOP: Headlights also turn on.
THIRD CLICKSTOP (“AUTO”): The headlights and all other
lights automatically turn on depending on the darkness of the
surroundings.*
NOTE:
* The operating condition or sensitivity can be changed.
Ask your Lexus dealer for details.
When the tail lights are on, the tail light indicator lights up in the
instrument cluster.

SWITCHES
29
Manually
twist the knob to the second clickstop to turn on
the headlights if they are needed immediately when
entering a dark tunnel, parking structure, etc.
When the headlight switch is turned to the first or second
clickstop, the brightness of the instrument cluster will be
reduced slightly unless the instrument panel light control dial
is turned fully up.
The automatic light control sensor is on top of the driver’s side
instrument panel.
Do not place anything on the instrument panel, and/or do not
affix anything on the windshield to block this sensor.
When the headlights come on, the lights automatically turn off
about 30 seconds after the driver’s door is opened and closed
with the ignition key turned to the “ACC” or “LOCK” position\
.*
To turn them on again, turn the ignition key to the “ON” position,
or turn the headlight switch off and then twist the knob until the
first or second clickstop.
If you are going to park for over one week, make sure the
headlight switch is off.
NOTE:
* The time before turning off the lights can be changed.
Ask your Lexus dealer for details.

SWITCHES
30Daytime Running Light System
The headlights turn on at reduced intensity when the parking
brake is released with the engine started, even with the light
switch in the “OFF” position. They will not go off until the
ignition switch is turned off.
To turn on the other exterior lights and instrument panel lights,
twist the knob to the first clickstop.
Twist
the knob to the second clickstop to turn on the headlights
to full intensity for driving at night.
When setting the knob to the third clickstop (“AUTO”), the
headlights will automatically adjust to full intensity and/or turn
on the other lights depending on the darkness of the
surroundings. Likewise, as the surroundings become brighter,
the headlights will turn to reduced intensity, ultimately turning
off the other lights.
NOTICE
To prevent the battery from being discharged, do not
leave the lights on longer than necessary when the
engine is not running.
Automatic headlight leveling system
(vehicles with discharge headlight only)
Vehicle position changes according to loading condition,
passengers getting on and off, vehicle acceleration and
deceleration, etc. However, as the headlight beam level is
always maintained automatically by the system at the proper
level, your headlights do not dazzle other road users.
If this system fails, the warning light in the instrument cluster
comes on. If this occurs, have your vehicle checked by your
Lexus dealer.
If you replace the rear suspension and/or the vehicle height
changes, contact your Lexus dealer to check the automatic
headlight leveling system and headlight beam level.
