SECTION 3 – 1
217
STARTING AND DRIVING
Starting and driving
Threeway catalytic converter218
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Engine exhaust caution 219
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Before starting the engine 220
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Ignition switch with steering lock 220
. . . . . . . . . . . . . . . . . . . . . . . . . . .
Parking brake 221
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . .
How to start the engine 222
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Automatic transmission 223
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cruise control 230
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . .
Electronic modulated suspension 233
. . . . . . . . . . . . . . . . . . . . . . . . . .
Traction control system 233
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Vehicle skid control system 236
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Brake system 237
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . .
Brake pad wear limit indicators 241
. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Types of tires 242
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . .

STARTING AND DRIVING
233
ELECTRONIC MODULATEDSUSPENSION
This electronic modulated suspension adjusts the
damping effect on the shock absorbers with the control
switch. Select one of the 4 modes which is suited to the
driving conditions with the control switch to provide good
riding comfort and stability.
1 For sporty type driving such as on winding mountain
roads and high speed driving
2For moderate high speed driving
3For ordinary driving such as in the city traffic
4For driving on a bumpy road
5Soft
6Firm
TRACTION CONTROL SYSTEM
The traction control system automatically helps prevent
the spinning of front wheels when the vehicle is started or
accelerated on slippery road surfaces.
When the ignition key is turned to “ON”, the system
automatically turns on.
CAUTION
Under certain slippery road conditions, full traction of
the vehicle and power against front wheels cannot be
maintained, even though the traction control system is
in operation. Do not drive the vehicle under any speed
or maneuvering conditions which may cause the
vehicle to lose traction control. In situations where the
road surface is covered with ice or snow, your vehicle
should be fitted with snow tires or tire chains. Always
drive at an appropriate and cautious speed for the
present road conditions.

STARTING AND DRIVING
236
VEHICLE SKID CONTROL SYSTEM
The vehicle skid control system helps provide integrated
control of the systems such as antilock brake system,
traction control, engine control, etc. This system
automatically controls the brakes and engine to help
prevent the vehicle from skidding when cornering on a
slippery road surface or operating steering wheel
abruptly.
The system will activate when your vehicle speed reaches or
exceeds 15 km/h (9 mph), and will deactivate when the vehicle
speed reduced to below 15 km/h (9 mph).
You may hear a sound in the engine compartment for a few
seconds when the engine is started or just after the vehicle is
started. This means that the s ystem is in the selfcheck mode
but does not indicate a malfunction.
CAUTION
 Do not rely excessively on the vehicle skid control
system. Even if the vehicle skid control system is
operating, you must always drive carefully and
attentively to avoid serious injury. Reckless driving
will result in an unexpected accident. If the slip
indicator light blinks, sounding an alarm, special
care should be taken while driving.
Only use tires of specified size. The size,
manufacture, brand and tread pattern for all 4 tires
should be the same. If you use the tires other than
specified, or different type or size, the vehicle skid
control system may not function correctly. When
replacing the tires or wheels, contact your Lexus
dealer.
 In situations where the road surface is covered with
ice or snow, your vehicle should be fitted with snow
tires or tire chains.
Slip indicator light
If the vehicle is going to skid during driving, the slip indicator
light blinks and an alarm sounds intermittently. Special care
should be taken while driving.
The slip indicator light comes on for a few seconds when the
ignition key is turned to “ON”. If the indicator light does not
come on when the ignition is turned on, contact your Lexus
dealer.

STARTING AND DRIVING
242
TYPES OF TIRES
Determine what kind of tires your vehicle is originally equipped
with.
1. Summer tires
Summer tires are highspeed capability tires best suited to
highway driving under dry conditions.
Since summer tires do not have the same traction performance
as snow tires, summer tire s are inadequate for driving on
snowcovered or icy roads. For driving on snowcovered or
icy roads, we recommend using snow tires. If installing snow
tires, be sure to replace all four tires.
2. All season tires
All season tires are designed to provide better traction in snow
and to be adequate for driving in most winter conditions, as well
as for use all year round.
All season tires, however, do not have adequate traction
performance compared with snow tires in heavy or loose snow.
Also, all season tires fall short in acceleration and handling
performance compared with summer tires in highway driving.
CAUTION
Do not use tires other than the manufacturer’s
designated tires, and never mix tires or wheels of the
sizes different from the originals.
 Do not mix summer and all season tires on your
vehicle as this can cause dangerous handling
characteristics, resulting in loss of control.

DRIVING TIPS
251
Tires
Ensure that your vehicle’s tires are properly inflated. Adjust
the tire pressure to the recommended cold tire pressure
indicated below:
Tire pressure, kPa (kgf/cm
2 or bar, psi)
Front 200 (2.0, 29)
Rear 200 (2.0, 29)
 The trailer tires should be inflated to the pressure
recommended by the trailer manufacturer in respect to the
total trailer weight.
Trailer lights
 Trailer lights must comply with federal, state/provincial and
local regulations. See your local rec reational vehicle dealer
or rental agency for the correct type of wiring and relays for
your trailer. Check for correct operation of the turn signals
and stop lights each time you hitch up. Direct splicing may
damage your vehicle’s electrical system and cause a
malfunction of your lights.
Breakin schedule
 Lexus recommends that you do not tow a trailer with a new
vehicle or a vehicle with any new power train component
(engine, transmission, differential, wheel bearing, etc.) for
the first 800 km (500 miles) of driving.
Maintenance
 If you tow a trailer, your vehicle will require more frequent
maintenance due to the additional load. For this
information, please refer to the scheduled maintenance
information in the “Owner’s Manual Supplement/
Scheduled Maintenance”.
 Retighten all fixing bolts of the towing ball and bracket after
approximately 1000 km (600 miles) of trailer driving.
Pretowing safety check
Check that your vehicle remains level when a loaded or
unloaded trailer is hitched. Do not drive if the vehicle has
an abnormal noseup or nosedown condition, and check
for improper tongue load, overload, worn suspension or
other possible causes.
 Make sure the trailer cargo is securely loaded so that it
cannot shift.
 Check that your rear view mirrors conform to any federal,
state/provincial or local regulations. If they do not, install
required rear view mirrors appropriate for towing purposes.

CHASSIS
318Warning: The traction grade assigned to this tire is based on
braking (straight ahead) traction tests and does not include
cornering (turning) traction.
Temperature A, B, C The temperature grades are A (the
highest), B, and C, representing the tire’s resistance to the
generation
of heat and its ability to dissipate heat when tested
under controlled conditions on a specified indoor laboratory
test wheel. Sustained high temperature can cause the
material of the tire to degenerate and reduce tire life, and
excessive temperature can lead to sudden tire failure. The
grade C corresponds to a level of performance which all
passenger car tires must meet under the Federal Motor
Vehicle Safety Standard No. 109. Grades B and A represent
higher levels of performance on the laboratory test wheel than
the minimum required by law.
Warning: The temperature grade for this tire established for a
tire that is properly inflated and not overloaded. Excessive
speed, underinflation, or excessive loading, either separately
or in combination, can cause heat buildup and possible tire
failure.
Tire selection
When replacing a tire, use only the same size and
construction as originally installed and with the same or
greater load capacity.
Using any other size or type of tire may seriously affect
handling, ride, speedometer/odometer calibration, ground
clearance, and clearance between the body and tires or snow
chains.
Do not mix radial, belted, or conventional tires on your
vehicle.
Do not use tires or wheels other than the manufacturer’s
recommended size.
It can cause dangerous handling characteristics, resulting in
loss of control. If you need to change from conventional tires
to radial tires or vice versa, replace them as a set.

CHASSIS
319
INSTALLING SNOW TIRES ANDCHAINS
When to use snow tires or chains
Snow tires or chains are recommended when driving on
snow or ice.
On wet or dry roads, conventional or radial tires provide better
traction than snow or studded tires.
Snow tire selection
If you need snow tires, select the same size, construction
and load capacity as the original tires on your Lexus.
Do not use tires other than stated above. Since your vehicle
has radial tires as original equipment, make sure your snow
tires also have radial construction. Do not install studded tires
without first checking local regulations for possible restrictions.
Snow tire installation
Snow tires should be installed on all wheels.
Installing snow tires on the front wheels only can lead to an
excessive difference in road grip capability between the front
and rear tires which could cause loss of vehicle control.
CAUTION
Snow tires should be inflated to the same pressure as
the original tires.
 Never drive over 120 km/h (75 mph) with any type of
snow tires.
Tire chain selection
Regulations regarding the use of tire chains vary
according to location or type of road. Always check the
local regulations before installing chains.
Use SAE Class “S” type radial tire chains, with the exception
of radial cable chains or Vbar type chains.
Chain installation
Install the chains on the front tires as tightly as possible.
Do not use tire chains on the rear tires. Retighten chains
after driving 0.5 1.0 km (1/4 1/2 mile).
When installing chains on your tires, carefully follow the
instructions of the chain manufacturer.

CHASSIS
320
CAUTION
Do not exceed 50 km/h (30 mph) or the chain
manufacturer’s recommended speed limit,
whichever is lower.
 Drive carefully avoiding bumps, holes, and sharp
turns, which may cause the vehicle to bounce.
 Avoid sharp turns or lockedwheel braking, as use of
chains may adversely affect vehicle handling.
 When driving with chains installed, be sure to drive
carefully. Slow down before entering the curves to
avoid losing control of the vehicle. Otherwise an
accident may occur.
REPLACING WHEELS
When to replace your wheels
If you have wheel damage such as bending, cracks or
heavy corrosion, the wheel should be replaced.
If you fail to replace damaged wheels, a tire may slip off a wheel
or cause loss of handling control.
Replacement with used wheels is not recommended as they
may have been subjected to rough treatment or high mileage
and could fail without warning. Also, bent wheels which have
been straightened may have hidden structural damage and
therefore should not be used. Never use an inner tube in a
leaking wheel which is designed for a tubeless tire.
Wheel selection
When replacing wheels, care should be taken to ensure
that they are equivalent to those removed in load capacity,
diameter, rim width, and offset.
Correct replacement wheels are available at your Lexus
dealer.
A wheel of a different size or type may adversely affect
handling, wheel and bearing life, brake cooling,
speedometer/odometer calibration, stopping ability, headlight
aim, bumper height, vehicle ground clearance, and tire or snow
chain clearance to the body and chassis.

ELECTRICAL COMPONENTS
335
CHECKING THE CARTRIDGE TYPEFUSES
Engine compartment
Driver’s side instrument panel If the headlights or other electrical components do not
work and the blade type fuses are O.K., check the
cartridge
type fuses. If any of the cartridge type fuses are
blown, they must be replaced.
If there is an overload in the circuits from the battery, the fuses
are designed to blow before the entire wiring harness is
damaged.
CAUTION
Always use a genuine Lexus fuse or equivalent for
replacement. Never install an ordinary wire even for
a temporary fix. This may cause extensive damage and
possibly a fire.
NOTICE
Before replacing the fuses, have the cause of electrical
overload determined and repaired by your Lexus dealer.

GAS STATION INFORMATION
Fuel selection:
Select premium unleaded gasoline with an Octane Rating
of 91 (Research Octane Number 96) or higher for optimum
engine performance. However, if such premium type
cannot be obtained, you may temporarily use unleaded
gasoline with an Octane Rating as low as 87 (Research
Octane Number 91).
 Fuel tank capacity:
70 L (18.5 gal., 15.4 lmp. gal.)
 Engine oil:
API grade SJ “EnergyConserving”, SL
“EnergyConserving” or ILSAC multigrade engine oil
Recommended oil viscosity SAE 5W30 if normal
temperatures are below 38 C (100 F)
Oil capacity: L (qt., lmp. qt.)
Drain and refill With filter 4.7 (5.0, 4.1)
Without filter 4.5 (4.8, 4.0)
See page 304 for detailed information.
Engine coolant:
Capacity: 9.2 L (9.7 qt., 8.2 lmp. qt.)
Coolant type “Toyota Long Life Coolant” or equivalent
With ethyleneglycol type coolant for a proper corrosion
protection of aluminum components
Do not use alcohol type antifreeze or plain water alone.
For checking the engine coolant, see page 306 .
 Automatic transaxle:
Fluid type Automatic transmission fluid Type TIV
See page 310 for detailed information.
 Tire information:
See pages 315 through 321 for detailed information.
 Tire pressure:
Tire size: P215/60R16 94V
Tire pressure:
Front 200 kPa (2.0 kgf/cm
2 or bar, 29 psi)
Rear 200 kPa (2.0 kgf/cm2 or bar, 29 psi)
For sustained high speeds above 160 km/h (99 mph), in
countries where such speeds are permitted by law, add 40
kPa (0.4 kgf/cm
2 or bar, 6 psi) to the front tires and rear tires,
but never exceed the maximum cold tire pressure molded
on the tire sidewall.
