Lexus ES300 2003 Owner's Manuals (in English)

STARTING AND DRIVING
247
CAUTION
Do not use tires other than the manufacturer’s
designated tires, and never mix tires or wheels of the
sizes different from the originals.
 Do not mix summer and all season tires on your
vehicle as this can cause dangerous handling
characteristics, resulting in loss of control.

STARTING AND DRIVING
248

SECTION 3 – 2
249
STARTING AND DRIVING
Driving tips
Break−in period250
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . .
Operation in foreign countries 250
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tips for driving in various conditions 251
. . . . . . . . . . . . . . . . . . . . . . . .
Winter driving tips 252
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . .
Dinghy towing 254
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . .
Trailer towing 254
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . .
How to save fuel and make your vehicle
last longer 260
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . .

DRIVING TIPS
250
BREAKIN PERIOD
Drive gently and avoid high speeds.
You need not follow a break−in schedule with your new Lexus.
But following a few simple tips for the first 1600 km (1000 miles)
can add to the future economy and long life of your vehicle:
 Avoid full throttle acceleration when starting and driving.
 Avoid racing the engine.
 Try to avoid hard stops during the first 300 km (200 miles).
 Do not drive for a long time at any single speed, either fast
or slow.
 Do not tow a trailer during the first 800 km (500 miles).
OPERATION IN FOREIGN
COUNTRIES
If you plan to drive your Lexus in another country ...
First, comply with the vehicle registration laws.
Second, confirm the availability of the correct fuel (unleaded
and minimum octane rating).

DRIVING TIPS
251
TIPS FOR DRIVING IN VARIOUSCONDITIONS
Always slow down in gusty crosswinds. This will allow you
much better control.
 Drive slowly onto curbs and, if possible, at a right angle.
Avoid driving onto high, sharp −edged objects and other
road hazards. Failure to do so can lead to severe tire
damage resulting in tire bursts.
Drive slowly when passing over bumps or travelling on a
bumpy road. Otherwise, the impact could cause severe
damage to the tires and/or wheels.
 When parking on a hill, turn the front wheels until they touch
the curb so that the vehicle will not roll. Apply the parking
brake, and place the transmission in “P”. If necessary, block
the wheels.
 Washing your vehicle or driving through deep water may get
the brakes wet. To see whether they are wet, check that
there is no traffic near you and then press the pedal lightly.
If you do not feel a normal braking force, the brakes are
probably wet. To dry them, drive the vehicle cautiously while
lightly pressing the brake pedal with the parking brake
applied. If they still do not work safely , pull to the side of the
road and call a Lexus dealer for assistance.
CAUTION
 Before driving off, make sure the parking brake is
fully released and that the parking brake reminder
light is off.
 Do not leave your vehicle unattended while the
engine is running.
 Do not rest your foot on the brake pedal while driving.
It can cause dangerous overheating, needless wear,
and poor fuel economy.
 To drive down a long or steep hill, reduce your speed
and downshift. Remember, if you ride the brakes
excessively, they may overheat and not work
properly. See page 230.
 Be careful when accelerating, upshifting,
downshifting or braking on a slippery surface. The
abrupt change in engine speed, such as sudden
acceleration or engine braking, could cause the
vehicle to spin or skid.
 Do not drive in excess of the speed limit. Even if the
legal speed limit permits it, do not drive over 140 km/h
(85 mph) unless your vehicle has highspeed
capability tires. Driving over 140 km/h (85 mph) may
result in tire failure, loss of control and possible
injury. Be sure to consult a tire dealer to determine
whether the tires on your vehicle are highspeed
capability tires or not before driving at such speeds.

DRIVING TIPS
252
Do not continue normal driving when the brakes are
wet. If they are wet, your vehicle will require a longer
stopping distance, and it may pull to one side when
the brakes are applied. Also, the parking brake will
not hold the vehicle securely.WINTER DRIVING TIPS
Make sure you have a proper freeze protection of engine
coolant.
Your coolant must contain ethylene −glycol type coolant for a
proper corrosion protection of aluminum components. Use
“Toyota Genuine Long Life Coolant” or equivalent. See
“Checking the engine coolant level” on page 315 for
instructions.
NOTICE
Do not use alcohol type antifreeze or plain water alone.
When it is extremely cold, we recommend to use 60% solution
for your Lexus, to provide protection down to about −50C
(−58 F). Do not use more than 70% solution for better coolant
performance.
Check the condition of the battery and cables.
Cold temperatures reduce the capacity of any battery, so it
must be in top shape to pr ovide enough power for winter
starting. Page 341 tells you how to visually inspect the battery.
Your Lexus dealer and most service stations will be pleased to
check the battery charge level.

DRIVING TIPS
253
Make sure the engine oil viscosity is suitable for the cold
weather.
See page 314 for recommended viscosity. Leaving a heavy
summer oil in your vehicle during winter months may cause
harder starting. If you are not sure about which oil to use, call
your Lexus dealer
− they will be pleased to help.
Check the electronic ignition system for loose
connections or obvious damage.
Keep the door locks from freezing.
Squirt lock de −icer or glycerine into the locks to keep them from
freezing.
Use a washer fluid containing an antifreeze solution.
This product is available at your Lexus dealer and most auto
parts stores. Follow the manufacturer’s directions for how
much to mix with water.
NOTICE
Do not use engine antifreeze or any other substitute
because it may damage your vehicle’s paint.
Do not use your parking brake when there is a possibility
it could freeze.
When parking, put the transmission into “P” and block the rear
wheels. Do not use the parking brake, or snow or water
accumulated in and around the parking brake mechanism may
freeze the parking brake, making it hard to release. Keep ice
and snow from accumulating under the fenders.
Ice and snow built up under your fenders can make steering
difficult. During bad winter driving, stop and check under the
fenders occasionally.
Depending on where you are driving, we recommend you
carry some emergency equipment.
Some of the things you might put in the vehicle are tire chains,
window scraper, bag of sand or salt, flares, small shovel,
jumper cables, etc.

DRIVING TIPS
254
DINGHY TOWING
Your vehicle is not designed to be dinghy towed (with four
wheels on the ground) behind a motorhome.
NOTICE
Do not tow your vehicle with four wheels on the ground.
This may cause serious damage to your vehicle.
TRAILER TOWING
Your vehicle is designed primarily as a passenger−carrying
vehicle. Towing a trailer w ill have an adverse effect on
handling, performance, braking, durability and driving
economy (fuel consumption etc.). Y our safety and satisfaction
depend on the proper use of correct equipment and cautious
driving habits. For your safety and the safety of others, you
must not overload your vehicle or trailer. Lexus warranties do
not apply to damage or malfunction caused by towing a trailer
for commercial purposes. Ask your local Lexus dealer for
further details before towing.
We recommend you to use a weight carrying hitch when towing
a trailer.
NOTICE
When towing a trailer, be sure to consult your Lexus
dealer for further information on additional
requirements such as a towing kit etc.

DRIVING TIPS
255
Weight limits
Before towing, make sure the total trailer weight, gross
vehicle weight, gross axle weight and trailer tongue load
are all within the limits.
The total trailer weight and tongue load can be measured with
platform scales found at a highway weighing station, building
supply company, trucking company, junk yard, etc.
Certification label
CAUTION
 The total trailer weight (trailer weight plus its cargo
load) must not exceed 907 kg (2000 lb.). Exceeding
this weight is dangerous.
Trailer hitch assemblies have different weight
capacities established by the hitch manufacturer.
Even though the vehicle may be physically capable of
towing a higher weight, the operator must determine
the maximum weight rating of the particular hitch
assembly and never exceed the maximum weight
rating specified for the trailer hitch. Exceeding the
maximum weight rating set by the trailer hitch
manufacturer can cause an accident resulting in
serious personal injuries.
 The gross vehicle weight must not exceed the Gross
Vehicle Weight Rating (GVWR) indicated on the
Certification Label. The gross vehicle weight is the
sum weight of the unloaded vehicle, driver,
passengers, luggage, hitch and trailer tongue load.
It also includes the weight of any special equipment
installed on your vehicle.
 The load on either the front or rear axle resulting from
distribution of the gross vehicle weight on both axles
must not exceed the Gross Axle Weight Rating
(GAWR) listed on the Certification Label.

Tongue load
Total trailer weight x 100 = 9 to 11%
DRIVING TIPS
256
32L002

Total trailer weight Tongue load
 The trailer cargo load should be distributed so that
the tongue load is 9 to 11% of the total trailer weight,
not exceeding the maximum of 90 kg (200 lb.).
 Never load the trailer with more weight in the back
than in the front. About 60% of the trailer load should
be in the front half of the trailer and the remaining 40%
in the rear.
Hitches
If you wish to install a trailer hitch, your Lexus dealer should
be consulted.
 Use only a hitch which is recommended by Lexus dealer
and conforms to the total trailer weight requirement.
 Follow the directions supplied by the hitch manufacturer.
Lubricate the hitch ball with a light coat of grease.
 Lexus recommends removing the trailer hitch whenever
you are not towing a trailer to reduce the possibility of
additional damage caused by the hitch if your vehicle is
struck from behind. After re moving the hitch, seal any
mounting holes in the vehicle body to prevent entry of
pollutants such as exhaust fumes, dirt, water, etc.
NOTICE
 Install the trailer hitch using only the position
recommended by your Lexus dealer. Do not install
the trailer hitch on the bumper; this may cause body
damage.
 Do not use axlemounted hitches as they can cause
damage to the axle housing, wheel bearings, wheels
or tires.
