- AUTOMATIC TRANSMISSION / TRANSAUTOMATIC TRANSAXLE ASSY (U151E/U151F)
40-59
83 Author: Date:
U151E, U151F A/T REPAIR MANUAL (RM1021U)
119. INSPECT UNDERDRIVE 1 WAY CLUTCH ASSY
(a) Install the underdrive clutch assy to the 1-way clutch.
(b) Rotate the underdrive clutch assy to check the rotating
direction for the lock or free operation.
120. INSTALL UNDERDRIVE 1 WAY CLUTCH ASSY
(a) Install the outer race retainer to the 1-way clutch.
NOTICE:
Fix the outer race retainer to the external tooth of the one
way clutch surely.
(b) Install the 1-way clutch to the transaxle case.
NOTICE:
Make sure that the mark on the 1-way clutch outer race is
visible.
(c) Using a screwdriver, install the snap ring to the transaxle
case.
NOTICE:
The snap ring should be fixed certainly in the groove of the
transaxle case as the gap exists except in the lock of teeth.
Page 132 of 969
D03580
D09691
Parking Lock Pawl
Spring
Pawl Pin
D26386
D03579
Underdrive
Planetary
Gear Assy
40-60
- AUTOMATIC TRANSMISSION / TRANSAUTOMATIC TRANSAXLE ASSY (U151E/U151F)
84 Author: Date:
U151E, U151F A/T REPAIR MANUAL (RM1021U)
121. INSTALL UNDERDRIVE CLUTCH ASSY
(a) Coat the bearing and bearing race with petroleum jelly,
install them onto the underdrive clutch.
Bearing and bearing race diameter: mm (in.)
InsideOutside
Bearing37.73 (1.4854)58.0 (2.2835)
Race29.9 (1.1772)55.5 (2.185)
(b) Install the underdrive clutch assy to the transaxle case.
NOTICE:
Installing the underdrive clutch drum sub-assy, be sure
not to damage the oil seal ring.
122. INSTALL PARKING LOCK PAWL
(a) Install the pawl pin and spring to the parking lock pawl.
(b) Temporarily install the parking lock pawl, shaft and spring
to the transaxle case, as shown in the illustration.
123. INSTALL UNDERDRIVE PLANETARY GEAR ASSY
(a) Install the underdrive planetary gear assy to the transaxle
case.
NOTICE:
Engage all the discs of underdrive clutch and hub splines
of the underdrive planetary gear assy firmly and assemble
them securely.
Page 133 of 969
D09693
D03576Pawl Shaft Clamp
D03875
E
D25511
Dimension (1)
Dimension (2)
D08087
Thrust Bearing Race No.1
- AUTOMATIC TRANSMISSION / TRANSAUTOMATIC TRANSAXLE ASSY (U151E/U151F)
40-61
85 Author: Date:
U151E, U151F A/T REPAIR MANUAL (RM1021U)
(b) Install the parking lock pawl shaft.
(c) Install the pawl shaft clamp with the bolt.
Torque: 9.8 NVm (100 kgfVcm, 87 in.Vlbf)
(d) Using a straight edge and vernier calipers as shown in the
illustration, measure the gap between the top of the differ-
ential drive pinion in the underdrive planetary gear and
contact surface of the transaxle case and housing (Di-
mension E).
NOTICE:
Note down the dimension E as it is necessary for the follow-
ing process.
(e) As shown in the illustration, measure the 2 places of the
transaxle housing, calculate the dimension F using the
formula.
NOTICE:
Note down the dimension F as it is necessary for the follow-
ing process.
HINT:
Dimension F = Dimension (1) - Dimension (2)
124. INSTALL MULTIPLE DISC CLUTCH CLUTCH HUB
(a) Install the thrust bearing race No.1 to the transaxle case
while checking its direction.
Bearing race diameter: mm (in.)
InsideOutside
Bearing race39.5 (1.555)45.8 (1.803)
Page 134 of 969
D26710
Thrust Needle
Roller BearingMultiple Disc
Clutch Clutch
Hub
D26711
Thrust Needle
Roller BearingMultiple Disc
Clutch Clutch
Hub
D03820
Thrust Needle
Roller Bearing
D03574
Forward Clutch Assy
40-62
- AUTOMATIC TRANSMISSION / TRANSAUTOMATIC TRANSAXLE ASSY (U151E/U151F)
86 Author: Date:
U151E, U151F A/T REPAIR MANUAL (RM1021U)
(b) Coat the thrust needle roller bearing and race with yellow
petrolatum, install them onto the multiple disc clutch hub.
Thrust bearing and race diameter: mm (in.)
InsideOutside
Thrust Bearing36.4 (1.433)52.2 (2.055)
(c) Coat the needle roller bearing with ATF.
(d) Install the needle roller bearing to the multiple clutch hub.
Bearing diameter: mm (in.)
InsideOutside
Bearing23.6 (0.929)44 (1.732)
(e) Install the multiple clutch hub to the transaxle case.
125. INSTALL FORWARD CLUTCH ASSY
(a) Coat the thrust needle roller bearing with ATF.
(b) Install the thrust needle roller bearing to the forward
clutch.
Thrust bearing diameter: mm (in.)
InsideOutside
Thrust Bearing33.58 (1.3220)51.9 (2.043)
NOTICE:
Install the thrust bearing properly so that the no colored
race or blue ink jet race will be visible.
(c) Install the forward clutch to the forward clutch assy.
NOTICE:
Align the splines of all discs in the forward clutch with
those of multiple clutch hub to assemble them se-
curely.
Be careful not to damage the bush inside of the for-
ward clutch hub during installing.
Page 135 of 969
D03573
D26450
Differential
Gear Assy
D25506
Thrust Bearing
Underdrive
Race No.2Underdrive Planetary
Gear Assy
Forward Clutch
Assy
Differential Gear Assy
Forward Clutch
Assy
D25505
Thrust
Needle
Roller Bearing
Differential Gear Assy
Underdrive Planetary
Gear Assy
- AUTOMATIC TRANSMISSION / TRANSAUTOMATIC TRANSAXLE ASSY (U151E/U151F)
40-63
87 Author: Date:
U151E, U151F A/T REPAIR MANUAL (RM1021U)
126. INSTALL OVERDRIVE BRAKE GASKET
(a) Install the 2 new overdrive brake gaskets.
127. INSTALL DIFFERENTIAL GEAR ASSEMBLY
(a) Install the differential gear assy to the transaxle case.
128. INSTALL THRUST BEARING UNDERDRIVE RACE
NO.2
(a) Install the thrust bearing underdrive race No.2 to the un-
derdrive planetary gear assy.
129. INSTALL THRUST NEEDLE ROLLER BEARING
(a) Coat the thrust needle roller bearing with ATF.
(b) Calculate the end play value using the following formula
and values of Dimension E and F that ware measured
when installing cylindrical roller bearing and underdrive
planetary gear. Select an appropriate underdrive plane-
tary gear thrust bearing race No. 2 which satisfies the spe-
cified end play value, and install it.
End play: 0.498 - 0.993 mm (0.01961 - 0.03909 in.)
HINT:
End play = Dimension F - Dimension E - thrust bearing thick-
ness 2.5 mm (0.0984 in.) - underdrive thrust bearing race No.
2 thickness.
Race thickness: mm (in.)
F - EThickness
Less than 7.72 (0.3039)3.5 (0.138)
7.72 (0.3039)3.8 (0.150)
Page 136 of 969
D03569
D03629
O-ring
D03630Seal Bend Width 1.2 mm (0.047 in.) FIPG
40-64
- AUTOMATIC TRANSMISSION / TRANSAUTOMATIC TRANSAXLE ASSY (U151E/U151F)
88 Author: Date:
U151E, U151F A/T REPAIR MANUAL (RM1021U)
Bearing and bearing race diameter: mm (in.)
InsideOutside
Bearing57.2 (2.252)84.96 (3.345)
Bearing race56.4 (2.22)83 (3.268)
130. INSTALL OIL PUMP ASSY
(a) Install the oil pump to the transaxle case with the 7 bolts.
Torque: 22.0 NVm (226 kgfVcm, 16 ftVlbf)
(b) Coat the O-ring of oil pump with ATF.
NOTICE:
Confirm the input shaft rotates smoothly with the manual
operation after assembling the oil pump.
131. INSTALL TRANSAXLE HOUSING
(a) Remove any parking material and be careful not to get oil
on the contacting surface of the transaxle case or trans-
axle housing.
(b) Apply FIPG to the transaxle case.
FIPG:
Part No. 08826-00090, THREE BOND 1281 or equiva-
lent
Page 137 of 969
D25608
C
C
CAB2WD:
4WD:
B
D
C CC
CB
B
A
A
D08091
D03631
D26468
SST
- AUTOMATIC TRANSMISSION / TRANSAUTOMATIC TRANSAXLE ASSY (U151E/U151F)
40-65
89 Author: Date:
U151E, U151F A/T REPAIR MANUAL (RM1021U)
(c) Install the transaxle housing and 16 bolts to the transaxle
case.
Torque:
Bolt A: 25 NVm (255 kgfVcm, 18 ftVlbf)
Bolt B: 33 NVm (337 kgfVcm, 24 ftVlbf)
Bolt C: 29 NVm (295 kgfVcm, 21 ftVlbf)
Bolt D: 22 NVm (226 kgfVcm, 16.0 ftVlbf)
HINT:
Apply seal packing or equivalent to the bolt A and D.
Seal packing:
THREE BOND 2403 or equivalent
Bolt length:
Bolt A: 50 mm (1.969 in.)
Bolt B: 50 mm (1.969 in.)
Bolt C: 42 mm (1.654 in.)
Bolt D: 72 mm (2.835 in.)
NOTICE:
Because the bolt A is a seal bolt, apply the seal packing to
new bolts and tighten them within 10 minutes after applica-
tion.
132. INSPECT INPUT SHAFT ENDPLAY
(a) Using a dial indicator, measure the input shaft end play.
End play: 0.262 - 1.249 mm (0.0100 - 0.0494 in.)
133. FIX AUTOMATIC TRANSAXLE ASSY
(a) Fix the transaxle assy.
134. INSTALL MANUAL VALVE LEVER SHAFT OIL SEAL
(a) Coat a new oil seal with MP grease.
(b) Install the oil seal to the transaxle case.
SST 09950- 60010 (09951- 00230), 09950- 70010
(09951-07100)
Oil seal drive in depth: 0 0.5 mm (0 0.0197 in.)
Page 138 of 969
D26382
Parking Lock Rod Sub-assy
D03565
Spacer
D03564
D26765
D03559
40-66
- AUTOMATIC TRANSMISSION / TRANSAUTOMATIC TRANSAXLE ASSY (U151E/U151F)
90 Author: Date:
U151E, U151F A/T REPAIR MANUAL (RM1021U)
135. INSTALL PARKING LOCK ROD SUB-ASSY
(a) Install the parking lock rod to the manual valve lever.
136. INSTALL MANUAL VALVE LEVER SUB-ASSY
(a) Install a new spacer and manual valve lever shaft to the
transaxle case.
NOTICE:
Do not damage on the oil seal during assembling the shaft
to the transaxle case.
(b) Using a pin punch and hammer, drive in a new pin.
(c) Turn the spacer and the lever shaft to align the small hole
for locating the staking position in the spacer with the
staking position mark on the lever shaft.
(d) Using a pin punch, stake the spacer through the small
hole.
(e) Check that the spacer does not turn.
137. INSTALL MANUAL VALVE LEVER SHAFT RETAINER
SPRING
(a) Using needle-nose pliers, install the retainer spring.
NOTICE:
Hang the spring on the shaft certainly.
Page 139 of 969
D03561
D03560
B
A
D03904
O-ring
B-3 Accumulator Piston
D25512
AT F
- AUTOMATIC TRANSMISSION / TRANSAUTOMATIC TRANSAXLE ASSY (U151E/U151F)
40-67
91 Author: Date:
U151E, U151F A/T REPAIR MANUAL (RM1021U)
138. INSTALL PARKING LOCK PAWL BRACKET
(a) Install the parking lock pawl bracket with the 2 bolts.
Torque: 20 NVm (205 kgfVcm, 15 ftVlbf)
Bolt length: 25 mm (0.984 in.)
NOTICE:
Be sure the parking rod is placed between the parking pawl
and the guide of the parking bracket when the parking
bracket is assembled.
139. INSTALL MANUAL DETENT SPRING SUB-ASSY
(a) Install the manual detent spring with the 2 bolts.
NOTICE:
Make sure to install the manual detent spring and cover in
this order.
HINT:
Tighten them in the order, A and B.
Torque:
Bolt A: 20 NVm (205 kgfVcm, 15 ftVlbf)
Bolt B: 12 NVm (120 kgfVcm, 9 ftVlbf)
Bolt length:
Bolt A: 27 mm (1.063 in.)
Bolt B: 16 mm (0.630 in.)
140. INSTALL B-3 ACCUMULATOR PISTON
(a) Coat a new O-ring with ATF, install it to the B-3 accumula-
tor piston.
NOTICE:
Install the O-ring to the accumulator piston and the accu-
mulator sleeve not to have a twist and a protrusion. More-
over, apply enough ATF prior to assembling. Be sure to the
installed position.
(b) Coat the piston with ATF, install it to the transaxle case.
NOTICE:
Install the springs to each accumulator piston with check-
ing of the identification color or each spring.
Accumulator spring:
Free length
Outer diameter mm (in.)Color
Inner 62.00 (2.4409) /
15.50 (0.610)Purple
Outer 74.23 (2.9224) /
21.70 (0.854)Purple
Page 140 of 969
D26402
O-ring
O-ring Reverse clutch Accumulator Piston
C92978
AT F
D03902
O-ring
C-3 Accumulator Piston
C83146
D03555
40-68
- AUTOMATIC TRANSMISSION / TRANSAUTOMATIC TRANSAXLE ASSY (U151E/U151F)
92 Author: Date:
U151E, U151F A/T REPAIR MANUAL (RM1021U)
141. I N S TA L L REVERSE CLUTCH ACCUMULATOR
PISTON
(a) Coat the 2 new O-rings with ATF, install them to the re-
verse accumulator piston.
NOTICE:
Install the O-ring to the accumulator piston and the accu-
mulator sleeve not to have a twist and a protrusion. More-
over, apply enough ATF prior to assembling. Be sure to the
installed position.
(b) Coat the piston with ATF, install it to the transaxle case.
NOTICE:
Install the springs to each accumulator piston with check-
ing of the identification color or each spring.
Accumulator spring:
Free length
Outer diameter mm (in.)Color
60.96 (2.3999) /
14.10 (0.555)Yellow
142. INSTALL C-3 ACCUMULATOR PISTON
(a) Coat a new O-ring with ATF, install it to the C-3 accumu-
lator piston.
NOTICE:
Install the O-ring to the accumulator piston and the accu-
mulator sleeve not to have a twist and a protrusion. More-
over, apply enough ATF prior to assembling. Be sure to the
installed position.
(b) Coat the piston with ATF, install it to the transaxle case.
NOTICE:
Install the springs to each accumulator piston with check-
ing of the identification color or each spring.
Accumulator spring:
Free length
Outer diameter mm (in.)Color
72.20 (2.8425) /
19.0 (0.748)Colorless
(c) Install the spring from the C-3 accumulator piston.
NOTICE:
Install the springs to each accumulator piston with check-
ing of the identification color or each spring.
