fog light Lexus ES300h 2014 Instrument cluster / (OM33A60U) User Guide

ES350_300h_OM_OM33A60U_(U)
2734-5. Using the driving support systems
4
Driving
NOTICE
■To prevent damage to or incorrect operation of the LDA system
●Do not modify the headlights or attach stickers to the surface of the lights.
●Do not modify the suspension or replace it with non-genuine parts.
●Do not install or place anything on the h ood or the grille. Also, do not install a
grille guard (bull bars, kangaroo bar etc.).
●If your windshield needs repairs, contact your Lexus dealer.
■Camera sensor ( P. 2 6 7 )
Observe the following to ensure that the LDA system functions correctly.
●Keep the windshield clean at all times.
Performance could be affected if the windshield is dirty, or if raindrops, conden-
sation or ice are adhering to the windshield.
●Do not spill liquid onto the camera sensor.
●Do not attach window tinting to the windshield.
●Do not install an antenna in front of the camera lens.
●If the windshield is fogged up, use the windshield defogger to remove fog from
the windshield.
When it is cold, using the heater with ai r blowing to the feet may allow the upper
part of the windshield to fog up. This will have a negative effect on the images.
●Do not attach a sticker or other items to the
windshield near the camera sensor.

664
ES350_300h_OM_OM33A60U_(U)
6-1. Maintenance and care
NOTICE
■Cleaning detergents
●Do not use the following types of detergent, as they may discolor the vehicle inte-
rior or cause streaks or damage to painted surfaces:
• Non-seat portions: Organic substances such as benzene or gasoline, alkalineor acidic solutions, dye, and bleach
• Seats: Alkaline or acidic solutions, such as thinner, benzene, and alcohol
●Do not use polish wax or polish cleaner. The instrument panel’s or other interior
part’s painted surf ace may be damaged.
■Preventing damage to leather surfaces
Observe the following precautions to avoid damage to and deterioration of
leather surfaces:
●Remove any dust or dirt from leather surfaces immediately.
●Do not expose the vehicle to direct sunlight for extended periods of time. Park
the vehicle in the shade, especially during summer.
●Do not place items made of vinyl, plastic, or containing wax on the upholstery, as
they may stick to the leather surface if the vehicle interior heats up significantly.
■Water on the floor
Do not wash the vehicle floor with water.
Vehicle systems such as the audio syst em may be damaged if water comes into
contact with electrical components such as the audio system above or under the
floor of the vehicle. Water may also cause the body to rust.
■When cleaning the inside of the windshield (vehicles with LDA [Lane Departure
Alert] and Automatic High Beam)
Be careful not to touch the camera sensor ( P. 273).
If the camera is accidentally scratched or hit, LDA and Automatic High Beam sys-
tem may not operate properly or may cause a malfunction.
■Cleaning the inside of the rear window
●Do not use glass cleaner to clean the rear window, as this may cause damage to
the rear window defogger heater wires or antenna. Use a cloth dampened with
lukewarm water to gently wipe the window clean. Wipe the window in strokes
running parallel to the heater wires or antenna.
●Be careful not to scratch or damage the heater wires or antenna.

733
ES350_300h_OM_OM33A60U_(U)
6-3. Do-it-yourself maintenance
6
Maintenance and care
Light bulbs
Check the wattage of the light bulb to be replaced. (P. 846)
■Front
You may replace the following bulbs by yourself. The difficulty level of
replacement varies depending on the bulb. If necessary bulb replace-
ment seems difficult to perform, contact your Lexus dealer.
For more information about replacin g other light bulbs, contact your
Lexus dealer.
Preparing for light bulb replacement
Bulb locations
Front side marker light
Front turn signal light
Headlight low beam (halogen
bulb) Headlight high beam
Halogen fog light (if
equipped)1
2
3
4
5

ES350_300h_OM_OM33A60U_(U)
7376-3. Do-it-yourself maintenance
6
Maintenance and care
■Halogen fog lights (if equipped)Remove the bolt and partly
remove the under cover, and
unplug the connector while
pushing the lock release.
Turn the bulb base counter-
clockwise.
Set the new light bulb.
Align the 3 tabs on the light bulb
with the mounting, and insert. Turn
it clockwise to set.
1
2
3

738
ES350_300h_OM_OM33A60U_(U)
6-3. Do-it-yourself maintenance
Set the connector.
After installing the connector,
shake the bulb base gently to check
that it is not loose, turn the fog lights
on once and visually confirm that
no light is leaking through the
mounting.
4

ES350_300h_OM_OM33A60U_(U)
7456-3. Do-it-yourself maintenance
6
Maintenance and care
■Replacing the following bulbs
If any of the lights listed below has burnt out, have it replaced by your
Lexus dealer.
●Headlight low beams (discharge bulbs)
●Parking lights/daytime running lights
●Side turn signal lights
●LED fog lights (if equipped)
●Stop/tail lights
●Tail lights
●Rear side marker lights
●High mounted stoplight
●License plate lights
●Outer foot lights
■Discharge headlights (if equipped)
If voltage to the discharge bulbs is insufficient, the bulbs may not come on, or may go
out temporarily. The discharge bulbs will come on when normal power is restored.
■LED lights
The parking lights/daytime runni ng lights, side turn signal lights, LED fog lights (if
equipped), stop/tail lights, tail lights, rear side marker lights, high mounted stoplight,
license plate lights and outer foot lights co nsist of a number of LEDs. If any of the
LEDs burn out, take your vehicle to your Lexus dealer to have the light replaced.
■Condensation build-up on the inside of the lens
Temporary condensation build-up on the insi de of the headlight lens does not indi-
cate a malfunction. Contact your Lexus dealer for more information in the following
situations:
●Large drops of water have built up on the inside of the lens.
●Water has built up inside the headlight.
■When replacing light bulbs
 P. 7 3 2

846
ES350_300h_OM_OM33A60U_(U)
8-1. Specifications
A: HB3 halogen bulbsB: H11 halogen bulbs
C: D4S discharge bulbs D: H16 halogen bulbs E: Wedge base bulbs (amber)F: Wedge base bulbs (clear)
*:If equipped
Light bulbs
Light BulbsBulb No.WTy p e
Exterior
Headlights High beam
Low beam (halogen bulbs)
Low beam (discharge bulbs)
9005
605535A B
C
Fog lights*19D
Front turn signal lights7444NA28 /8E
Front side marker lightsW5W5F
Rear turn signal lightsWY21W21E
Back-up lightsW16W16F
Outer foot lightsW5W5F
Interior
Door courtesy lights5F
Vanity lights5F
Interior light8F
Pe r s o n a l l i g h t s8F
Tr u n k l i g h t5F

901Alphabetical index
ES350_300h_OM_OM33A60U_(U)
Cup holders ............................................. 618
Curtain shield airbags ........................... 39
Customizable features ....................... 862
Daytime running light system .......... 230
Defogger
*
Front windshield ................................ 369
Outside rear view mirrors .............378
Rear window ........................................378
Dimension ............................................... 832
Dinghy towing........................................200
Display Dynamic radar cruise control...... 252
LDA (Lane Departure Alert) .......269
Multi-information display ................100
Trip information ..................................... 101
Warning message .............................769
Display Audio system ......................... 338 Display settings ...................................343
Setup menu ...........................................345
Do-it-yourself maintenance ............. 673
Door courtesy lights Location ..................................................... 611
Wattage ................................................. 846
Doors Automatic door locking and unlocking system.................... 144
Door glasses ..........................................174
Door lock .................................................142
Open door warning buzzer.......... 129
Open door warning light............... 762
Outside rear view mirrors ................ 171
Rear door child-protector.............. 143 Driver’s seat position memory.......... 156
Driving position memory................. 157
Memory recall function ....................159
Power easy access system .............156
Driving Break-in tips .......................................... 186
Correct driving posture .................... 30
Driving mode select switch ......... 300
Hybrid vehicle driving tips .............327
Procedures .............................................184
Winter drive tips ................................330
Dynamic radar cruise control Function .................................................. 252
Warning message................... 771, 778
Eco drive mode..................................... 300
Eco Driving Indicator ........................... 107
EDR (Event data recorder).....................11
Electric motor (traction motor).......... 72
Electric Power Steering (EPS) Function ..................................................303
Warning light ......................................... 761
Warning message..............................772
Electronic key .......................................... 122 Battery-saving function ......................131
If the electronic key does not operate properly ............................. 810
Replacing the battery ........................ 719
D
E
*: For vehicles with a navigation system, refer to the “Navigation System Owner’s Manual”.

903Alphabetical index
ES350_300h_OM_OM33A60U_(U)
Enhanced VSC ..................................... 302
EPS (Electronic Po wer Steering)
Function ................................................. 303
Warning light .........................................761
Warning message ............................. 772
Event data recorder (EDR) .................... 11
Flat tire ...................................................... 792
Floor mats ................................................... 28
Fluid Automatic transaxle..........................842
Brake ....................................................... 843
Hybrid transaxle .................................842
Washer ...................................................697
Fog lights Replacing light bulbs ........................ 737
Switch...................................................... 238
Wattage ................................................. 846
Footwell light ............................................. 611
Front passenger occupant classification system ............................ 50
Front personal lights..............................612
Front seats Adjustment ............................................. 154
Cleaning .................................................662
Correct driving posture ....................30
Driving position memory ................ 156
Head restraints ..................................... 162
Power easy access system ............ 156
Seat heaters ......................................... 628
Seat position memory....................... 156
Seat ventilators ................................... 628 Front side marker lights
Light switch........................................... 228
Replacing light bulbs ......................... 741
Welcome light illumination control.................................................... 125
Wattage .................................................846
Front turn signal lights Replacing light bulbs ....................... 739
Turn signal lever ................................. 225
Wattage .................................................846
Fuel Capacity.................................................836
Fuel gauge ............................................... 95
Fuel pump shut off system ............ 758
Information............................................ 847
Refueling ................................................ 243
Type..........................................................836
Warning light ....................................... 762
Warning messages ..........................780
Fuel filler door.........................................243 Refueling ................................................ 243
When the fuel filler door cannot be opened ......................... 246
Fuel pump shut off system ................ 758
Fuses............................................................ 721
Garage door opener...........................637
Gauges........................................................ 95
Glove box ................................................. 616
Glove box light........................................ 616
Grocery bag hooks............................. 620
F
G

906Alphabetical index
ES350_300h_OM_OM33A60U_(U)
Language (multi-information display) ............ 863
LATCH anchors ...................................... 62
LDA (Lane Departure Alert) .......... 267
Lever Auxiliary catch lever ......................... 677
Hood lock release lever ................. 677
Internal trunk release lever............. 150
Shift lever ....................................... 218, 221
Turn signal lever ................................. 225
Wiper lever ...........................................239
Lexus Display Audio system ............ 338 Display settings ...................................343
Setup menu ...........................................345
Lexus Enform
*
License plate lights Light switch ...........................................228
Replacing light bulbs ........................745
Welcome light illumination control ......................... 125
Light bulbs Replacing ............................................... 733
Wattage ................................................. 846 Lights
Fog light switch ................................... 238
Headlight switch ................................ 228
Illuminated entry system...................613
Interior light............................................. 612
Interior lights list..................................... 611
Personal lights ....................................... 612
Replacing light bulbs ....................... 733
Trunk light................................................149
Turn signal lever ................................. 225
Vanity lights .......................................... 622
Wattage .................................................846
Welcome light illumination control.................................................... 125
Lock steering column......................... 204
Low profile tire .......................................706
Luggage security system .................... 148
Maintenance Do-it-yourself maintenance ......... 673
General maintenance .................... 668
Maintenance data.............................. 832
Maintenance requirements ..........665
Malfunction indicator lamp ...............760
Master warning light ............................ 762
Meter............................................................ 95 Indicators .................................................. 93
Instrument panel light control ........ 96
Multi-information display................ 100
Warning lights.......................................... 91
Micro dust and pollen filter ................ 371
L
M
