headlight switch Lexus ES300h 2015 Do-it-yourself maintenance / (OM33B99U) User Guide

242
ES350_300h_OM_OM33B99U_(U)
4-3. Operating the lights and wipers
■Temporarily lowering sensor sensitivity
The sensitivity of the sensor can be temporarily lowered.Turn the “START STOP ENGINE” <“POWER”> switch off while the following
conditions are met.
• The headlight switch is in or .
• The headlight switch lever is in high beam position.
• Automatic High Beam switch is on.
Tu r n t h e “ S T A R T S T O P E N G I N E ” < “ POWER”> switch to IGNITION ON
mode.
Within 5 seconds after , repeat pulling the headlight switch lever to the origi-
nal position then pushing it to the high beam position quickly 9 times, then leave
the lever in high beam position.
Automatic High Beam (headlights) may turn on even the vehicle is stopped.
1
2
32

244
ES350_300h_OM_OM33B99U_(U)
4-3. Operating the lights and wipers
Fog light switch
(U.S.A.) or (Canada)
Turns the fog lights off
Turns the fog lights on
■Fog lights can be used when
The headlights are on in low beam.
The fog lights secure excellent visibility in difficult driving conditions,
such as in rain and fog.
1
2

367
ES350_300h_OM_OM33B99U_(U)
5-2. Setup
5
Lexus Display Audio system
Display settings
Go to “Display”: “MENU” button  “Display”
Turn off screen.
Adjust screen quality.
Adjust screen quality of the rear
view monitor camera.
Change to day mode.
This setting turns the screen off. To turn it on, press any button such as the
“AUDIO” button or “MENU” button.
If a screen off image has been set, the set image will be displayed.
When the headlights are turned on, the screen dims.
However, the screen can be switched to day mode by selecting “Day
Mode”.
The screen will stay in day mode when the headlights are turned on until “Day
Mode” is selected again.
Settings are available for adjusting the contrast and brightness of the
screen.
The display can also be turned off.
Screen for display settings
1
2
3
4
Screen off
Day mode

6758-2. Steps to take in an emergency
ES350_300h_OM_OM33B99U_(U)
8
When trouble arises
One of the following may be the cause of the problem:
●One or both of the 12-volt battery terminals may be disconnected.
●The 12-volt battery may be discharged. ( P. 6 8 4 )
Contact your Lexus dealer if the problem cannot be repaired, or if repair proce-
dures are unknown.
When the hybrid system does not start, the following steps can be used as
an interim measure to start the hybr id system if the “POWER” switch is
functioning normally:
Set the parking brake.
Shift the shift lever to P.
Turn the “POWER” switch to ACCESSORY mode.
Press and hold the “POWER” swit ch for about 15 seconds while
depressing the brake pedal firmly.
Even if the hybrid system can be star ted using the above steps, the system
may be malfunctioning. Have the vehicle inspected by your Lexus dealer.
The interior lights and headlights do not turn on, or the horn does
not sound.
Emergency start function
1
2
3
4

6818-2. Steps to take in an emergency
ES350_300h_OM_OM33B99U_(U)
8
When trouble arises
Connect a positive jumper cable clamp to the positive (+) battery
terminal on your vehicle.
Connect the clamp on the other end of the positive cable to the pos-
itive (+) battery terminal on the second vehicle.
Connect a negative cable clamp to the negative (-) battery terminal
on the second vehicle.
Connect the clamp at the other end of the negative cable to a solid,
stationary, unpainted metallic point away from the 12-volt battery
and any moving parts, as shown in the illustration.
Start the engine of the second ve hicle. Increase the engine speed
slightly and maintain at that le vel for approximately 5 minutes to
recharge the 12-volt battery of your vehicle.
Open and close any of th e doors of your vehicle with the “START STOP
ENGINE” switch off.
Maintain the engine speed of the seco nd vehicle and start the engine of
your vehicle by turning the “START STOP ENGINE” switch to IGNI-
TION ON mode.
Once the vehicle’s engine has started , remove the jumper cables in the
exact reverse order from wh ich they were connected.
Once the engine starts, have the vehi cle inspected at your Lexus dealer as
soon as possible.
■Starting the engine when the 12-volt battery is discharged
The engine cannot be started by push-starting.
■To prevent 12-volt battery discharge
●Turn off the headlights and the audio system while the engine is off.
●Turn off any unnecessary electrical compon ents when the vehicle is running at a
low speed for an extended period, such as in heavy traffic.
1
2
3
4
3
4
5
6

6868-2. Steps to take in an emergency
ES350_300h_OM_OM33B99U_(U)
■Starting the hybrid system when the 12-volt battery is discharged
The hybrid system cannot be started by push-starting.
■To prevent 12-volt battery discharge
●Turn off the headlights and the audio system while the hybrid system is off.
●Turn off any unnecessary electrical components when the vehicle is running at a
low speed for an extended period, such as in heavy traffic.
■Charging the 12-volt battery
The electricity stored in the 12-volt battery will discharge gradually even when the
vehicle is not in use, due to natural discharge and the draining effects of certain elec-
trical appliances. If the vehicle is left for a long time, the 12-volt battery may dis-
charge, and the hybrid system may be unable to start. (The 12-volt battery recharges
automatically while the hybrid system is operating.)
■When recharging or replacing the 12-volt battery
●Make sure that the key is not inside the vehicle when recharging or replacing the
12-volt battery. The key may be locked in the vehicle if the alarm is activated.
(  P. 8 9 )
●In some cases, it may not be possible to unlock the doors using the smart access
system with push-button start when the 12-volt battery is discharged. Use the wire-
less remote control or the mechanical key to lock or unlock the doors.
●The hybrid system may not start on the fir st attempt after the 12-volt battery has
recharged but will start normally after the second attempt. This is not a malfunction.
●The “POWER” switch mode is memorized by the vehicle. When the 12-volt battery
is reconnected, the system will return to the mode it was in before the 12-volt bat-
tery was discharged. Before disconnectin g the 12-volt battery, turn the “POWER”
switch off.
If you are unsure what mode the “POWER” switch was in before the 12-volt battery
discharged, be especially careful when reconnecting the 12-volt battery.

767Alphabetical index
ES350_300h_OM_OM33B99U_(U)
Armrest door ......................................... 498
Assist grip ................................................500
Audio input.............................................. 359
Audio system
*.......................................350
Audio input........................................... 359
AUX port.............................................. 359
Bluetooth
® audio ................................417
CD player ..............................................387
iPod .......................................................... 395
MP3/WMA disc ...............................387
Optimal use ..........................................370
Portable music player ..................... 404
Radio ........................................................378
Setup menu ............................................ 361
Steering wheel audio switches ...............................................357
USB memory ...................................... 399
Automatic air conditioning system .................................................... 464
Automatic headlight leveling system .................................................... 236
Automatic High Beam ....................... 237
Automatic light control system .................................................... 233
Automatic transmission ..................... 222 If the shift lever cannot be shifted from P ............676
AUX port
*.............................................. 359
Auxiliary box .......................................... 487 Back-up lights
Replacing light bulbs ...................... 609
Wattage ................................................... 714
Battery (12-volt battery) ......... 557, 562 If the 12-volt battery is discharged .......................680, 684
Preparing and checking before winter...................................................... 341
Warning light ....................................... 627
Battery (traction battery) ...................... 77
Bluetooth
®*
Audio system .......................................405
Hands-free system (for cellular phone) .........................419
Brake Fluid ..........................................................556
Parking brake ........................................ 231
Warning light ...........................626, 628
Brake assist ............................................... 313
Break-in tips .............................................190
Brightness control Instrument panel light control ........ 99
BSM (Blind Spot Monitor) ............... 328
B
*: For vehicles with a navigation system, refer to the
“NAVIGATION SYSTEM OWNER’S MANUAL”.

772Alphabetical index
ES350_300h_OM_OM33B99U_(U)
Hands-free system (for cellular phone)
*..........................419
Head restraints ........................................165
Headlights Discharge headlights precautions ........................................... 611
Light switch ........................................... 233
Replacing light bulbs............................... 600, 601, 610
Wattage ....................................................714
Heaters Air conditioning system ..................................................464
Heated steering wheel ....................478
Seat heaters ..........................................478
Outside rear view mirrors .............470
High-voltage components ................... 77
Hill-start assist control ..........................319
Hood ............................................................541 Warning message .............................. 641
Hooks Cargo hooks ....................................... 488
Coat hooks .......................................... 499
Grocery bag hooks......................... 488
Retaining hooks (floor mat) ............. 28
Horn ........................................................... 232
Hybrid battery (traction battery) ................................... 77
Hybrid battery (traction battery) air vents ................ 78 Hybrid system............................................ 73
Emergency shut off system ............. 78
Energy monitor/consumption screen ......................................................112
EV drive mode ..................................... 219
High voltage components ................ 77
Hybrid System Indicator ................. 100
Hybrid system precautions .............. 77
Hybrid vehicle driving tips ............338
If the hybrid system will not start ............................................... 674
Overheating...........................................691
“Power” (ignition) switch ................. 212
Starting the hybrid system............... 212
Vehicle proximity notification system ......................................................74
Hybrid System Indicator .................... 100
Hybrid transmission .............................226 If the shift lever cannot be shifted from P ................................... 676
H

774Alphabetical index
ES350_300h_OM_OM33B99U_(U)
Language (multi-information display) .............. 731
LATCH anchors ...................................... 63
LDA (Lane Departure Alert) .......... 273
Lever Auxiliary catch lever .......................... 541
Hood lock release lever .................. 541
Internal trunk release lever............. 152
Shift lever .................................... 222, 226
Turn signal lever ................................ 230
Wiper lever ...........................................245
Lexus Display Audio system ............350 Display settings ...................................367
Setup menu ............................................ 361
Lexus Enform
*
Lexus Enform Remote*......................461
Lexus Enform Safety Connect......... 513
License plate lights Light switch ........................................... 233
Replacing light bulbs ......................... 610
Welcome light illumination control .......................... 127
Light bulbs Replacing .............................................. 598
Wattage ....................................................714 Lights
Fog light switch ................................... 244
Headlight switch ................................ 233
Illuminated entry system...................481
Interior light.......................................... 480
Interior lights list.................................. 479
Personal lights .................................... 480
Replacing light bulbs ...................... 598
Trunk light................................................. 151
Turn signal lever ................................. 230
Vanity lights ..........................................490
Wattage ................................................... 714
Welcome light illumination control.................................................... 127
Lock steering column............... 208, 215
Low profile tire ...................................... 570
Luggage security system ....................150
Maintenance Do-it-yourself maintenance ......... 537
General maintenance ..................... 532
Maintenance data..............................700
Maintenance requirements .......... 529
Malfunction indicator lamp ............... 627
Master warning light ............................629
Meter............................................................. 97 Indicators .................................................. 95
Instrument panel light control ........ 99
Multi-information display.................102
Warning lights........................................ 93
Micro dust and pollen filter ................ 471
L
M

778Alphabetical index
ES350_300h_OM_OM33B99U_(U)
SeatsAdjustment ............................................. 157
Adjustment precautions .................. 158
Child seats/child restraint system installation.............................. 62
Cleaning .................................................526
Driving position memory ................ 159
Head restraints ..................................... 165
Power easy access system ............ 159
Properly sitting in the seat ................30
Seat heaters ..........................................478
Seat position memory....................... 159
Seat ventilators ....................................478
Sensor Automatic headlight system .........235
Humidity sensor ................................. 476
Inside rear view mirror ......................173
Intuitive parking assist ....................... 281
LDA (Lane Departure Alert) ....... 279
Radar sensor ..................267, 322, 331
Rain-sensing windshield wipers ................................................... 247
Service reminder indicators ............... 92
Shift lever Automatic transmission .................. 222
Hybrid transmission.......................... 226
If the shift lever cannot be shifted from P ............676
Shift lever light ....................................... 479
Shift lock system.................................... 676
Side airbags ............................................... 39 Side marker lights
Light switch........................................... 233
Replacing light bulbs ............606, 610
Welcome light illumination control.................................................... 127
Side mirrors Adjusting and folding ........................ 174
Blind Spot Monitor ........................... 328
Linked mirror function when reversing.................................. 175
Mirror position memory ..................159
Side turn signal lights Replacing light bulbs ........................ 610
Turn signal lever ................................. 230
Smart access system with push-button start Antenna location.................................. 129
Entry functions ...................................... 127
Starting the engine ............................205
Starting the hybrid system............... 212
Warning message.............................640
Snow tires ................................................ 345
Spare tire ................................................. 659 Inflation pressure.................................. 713
Storage location ................................ 660
Spark plug ............................................... 708
Specifications......................................... 700
Speedometer ............................................. 97
“START STOP ENGINE” switch ..................................................... 205
