Lexus ES300h 2015 Specifications / Owner's Manual (OM33B99U)

ES350_300h_OM_OM33B99U_(U)
4816-2. Using the interior lights
6
Interior features
■Illuminated entry system
The lights automatically turn on/off according to “START STOP ENGINE”
<“POWER”> switch mode, the presence of the electronic key, whether the doors are
locked/unlocked, and whether the doors are opened/closed.
■To prevent 12-volt battery discharge
If the following lights remain on when the “START STOP ENGINE” <“POWER”>
switch is turned off the lights will go off automatically after 20 minutes:
●Outer foot lights
●Personal/interior light
●Door courtesy lights
●Ornament lights (if equipped)
●Footwell lights
■Customization
Setting (e.g. the time elapsed before lights turn off) can be changed.
(Customizable features: P. 7 3 0 )

482
ES350_300h_OM_OM33B99U_(U)
6-3. Using the storage features
List of storage features
Cup holders (P. 4 8 6 )
Glove box ( P. 4 8 4 )Console box (
P. 485)
Auxiliary box ( P. 4 8 7 )1
2
3
4

ES350_300h_OM_OM33B99U_(U)
4836-3. Using the storage features
6
Interior features
CAUTION
■Items that should not be left in the storage spaces
Do not leave glasses, lighters or spray cans in the storage spaces, as this may cause
the following when cabin temperature becomes high:
●Glasses may be deformed by heat or cracked if they come into contact with
other stored items.
●Lighters or spray cans may explode. If they come into contact with other stored
items, the lighter may catch fire or the spray can may release gas, causing a fire
hazard.
■When driving or when the storage compartments are not in use
Keep the lids closed.
In the event of sudden braking or sudden swerving, an accident may occur due to
an occupant being struck by an open lid or the items stored inside.

484
ES350_300h_OM_OM33B99U_(U)
6-3. Using the storage features
Open (press the button)
Unlock with the mechanical key
Lock with the mechanical key
■Glove box light
The glove box light turns on when the tail lights are on.
■Trunk opener main switch
The trunk opener main switch is located in the glove box. ( P. 1 5 0 )
■Removing the insert
The insert inside the glove box can be removed. ( P. 5 8 2 )
Glove box
1
2
3

ES350_300h_OM_OM33B99U_(U)
4856-3. Using the storage features
6
Interior features
Push the knob to release the lock,
and lift the armrest to open fully.
■Tray in the console box
■Console box light
The console box light turns on when the tail lights are on.
Console box
The tray slides forward/backward and can be
removed.
CAUTION
When using the console box with half-open, do not apply too much load on the
armrest. Doing so may damage the armrest and may cause you to injure yourself.

486
ES350_300h_OM_OM33B99U_(U)
6-3. Using the storage features
■Driver’s sideTo open, move the cup holder
lid until it locks.
To close, press and release the
cup holder lid.
■Front passenger’s side
To open, press down and release
the cup holder lid.
■Rear
To open, pull down the armrest
and press in and release the rear
cup holder on the armrest.
Cup holders
1
2

ES350_300h_OM_OM33B99U_(U)
4876-3. Using the storage features
6
Interior features
Press in the button.
CAUTION
■Items unsuitable for the cup holders
Do not place anything other than cups or beverage cans in the cup holders.
Other items may be thrown out of the holders in the event of an accident or sudden
braking, causing injury. If possible, cover hot drinks to prevent burns.
■Items unsuitable for the cup holder (front passenger’s side)
Do not place anything larger than a 32 oz cup in the cup holder.
Doing so may prevent the switches from being operated properly or block the
driver’s view of the switches, which may cause an accident.
NOTICE
■To prevent damage to the rear cup holder
Stow the cup holder before stowing the armrest.
Auxiliary box

488
ES350_300h_OM_OM33B99U_(U)
6-3. Using the storage features
Tr u n k f e a t u r e s
Raise the hooks when needed.
The cargo hooks are provided for
securing loose items.
Pull the lever upwards when lift-
ing the luggage mat up.
Cargo hooks
Grocery bag hooks
Luggage mat
1

ES350_300h_OM_OM33B99U_(U)
4896-3. Using the storage features
6
Interior features
The lever can be hooked on the
edge of the trunk.2
CAUTION
■When the cargo hooks are not in use
To avoid injury, always return the cargo hooks to their stowed positions.
NOTICE
■When closing the trunk
Do not leave the luggage mat lever hooked on the edge of the trunk.
The luggage mat may get damaged.

490
ES350_300h_OM_OM33B99U_(U)
6-4. Other interior features
Sun visors and vanity mirrors
To set the visor in the forward
position, flip it down.
To set the visor in the side posi-
tion, flip down, unhook, and swing
it to the side.
To use the side extender, place
the visor in the side position, then
slide it backward.
Slide the cover to open.
The light turns on when the cover is
opened.
Sun visors
1
2
3
Va n i t y m i r r o r s
NOTICE
■To prevent 12-volt battery discharge
Do not leave the vanity lights on for exte nded periods while the engine is not run-
ning .
