CD player Lexus ES300h 2015 Specifications / Owner's Manual (OM33B99U)

TABLE OF CONTENTS4
ES350_300h_OM_OM33B99U_(U)5-1. Basic Operations
Lexus Display Audio System ......................................... 350
Steering wheel audio switches .......................................357
USB/AUX ports ......................... 359
5-2. Setup Setup menu .................................... 361
General settings......................... 362
Voice settings .............................. 366
Display settings ............................367
5-3. Using the audio system Selecting the audio source .......................................... 369
Optimal use of the audio system .......................................... 370
Audio settings ..............................372
Audio menu screen operation .....................................375
5-4. Using the radio Radio operation.......................... 378
5-5. Playing an audio CD and MP3/WMA/AAC discs
CD player operation ................ 387 5-6. Using an external device
Listening to an iPod................... 395
Using USB memory device .......................................... 399
Using the AUX port ................. 404
5-7. Connecting Bluetooth
®
Steps for using Bluetooth®
devices ........................................ 405
Registering a Bluetooth
®
device ..........................................408
Selecting a Bluetooth
®
device ........................................... 410
Connecting a Bluetooth
®
audio player ................................. 411
Connecting a Bluetooth
®
phone ............................................. 412
Displaying a Bluetooth
®
device details .............................. 414
Detailed Bluetooth
®
settings ..........................................415
5-8. Bluetooth
® Audio
Listening to Bluetooth
®
Audio ............................................. 417
5-9. Bluetooth
® Phone
Using a Bluetooth
®
Phone.............................................419
Making a call.................................. 421
Receiving a call ............................424
Speaking on the phone ........... 425
Using a Bluetooth
®
phone message ....................... 428
Using the steering wheel switches ........................................431
Bluetooth
® phone
settings ........................................ 432
5Lexus Display Audio system

451-1. For safe use
ES350_300h_OM_OM33B99U_(U)
1
For safety and security
■If the SRS airbags deploy (inflate)
●Bruising and slight abrasions may result from contact with a deploying (inflating)
SRS airbag.
●A loud noise and white powder will be emitted.
●Parts of the airbag module (steering wheel hub, airbag cover and inflator) as well as
the seats, parts of the front and rear pillars, and roof side rails may be hot for several
minutes. The airbag it self may also be hot.
●The windshield may crack.
●For Lexus Enform Safety Connect subscriber s, if the SRS airbags deploy or in the
event of a severe rear-end collision, the system is designed to send an emergency
call to the response center, notifying them of the vehicle’s location (without needing
to push the “SOS” button) and an agent wi ll attempt to speak with the occupants to
ascertain the level of emergency and assistance required. If the occupants are
unable to communicate, the agent automatically treats the call as an emergency
and helps to dispatch the necessary emergency services. ( P. 5 1 3 )
CAUTION
■Modification and disposal of SRS airbag system components
Do not dispose of your vehicle or perfor m any of the following modifications with-
out consulting your Lexus dealer. The SRS airbags may malfunction or deploy
(inflate) accidentally, causing death or serious injury.
●Installation, removal, disassembl y and repair of the SRS airbags
●Repairs, modifications, removal or replacement of the steering wheel, instrument
panel, dashboard, glove box, seats or seat upholstery, front, side and rear pillars
or roof side rails
●Repairs or modifications of the front fend er, front bumper, or side of the occupant
compartment
●Installation of a grille guard (bull bars, kangaroo bar, etc.), snow plows or winches
●Modifications to the vehicle’s suspension system
●Installation of electronic devices such as mobile two-way radios and CD players
●Modifications to your vehicle for a person with a physical disability

134
ES350_300h_OM_OM33B99U_(U)
3-2. Opening, closing and locking the doors and trunk
■Conditions affecting operation
The smart access system with push-button start uses weak radio waves. In the follow-
ing situations, the communication between the electronic key and the vehicle may be
affected, preventing the smar t access system with push-button start, wireless remote
control and engine immobilizer system from operating prop-
erly. (Ways of coping: P. 6 7 7 )
●When the electronic ke y battery is depleted
●Near a TV tower, electric power plant, gas station, radio station, large display, air-
port or other facility that generates strong radio waves or electrical noise
●When carrying a portable radio, cellular phone, cordless phone or other wireless
communication device
●When the electronic key is in contact with, or is covered by the following metallic
objects
• Cards to which aluminum foil is attached
• Cigarette boxes that have aluminum foil inside
• Metallic wallets or bags
•Coins
• Hand warmers made of metal
• Media such as CDs and DVDs
●When other wireless keys (that emit radio waves) are being used nearby
●When carrying the electronic key togeth er with the following devices that emit
radio waves
• Another vehicle’s electronic key or a wireless key that emits radio waves
• Personal computers or person al digital assistants (PDAs)
• Digital audio players
• Portable game systems
●If window tint with a metallic content or metallic objects are attached to the rear
window

349
ES350_300h_OM_OM33B99U_(U)
Lexus Display Audiosystem
5
5-4. Using the radio
Radio operation .......................... 378
5-5. Playing an audio CD and MP3/WMA/AAC discs
CD player operation.................387
5-6. Using an external device Listening to an iPod ...................395
Using USB memory device ...........................................399
Using the AUX port................. 404
5-7. Connecting Bluetooth
®
Steps for using Bluetooth®
devices ........................................ 405
Registering a Bluetooth
®
device .......................................... 408
Selecting a Bluetooth
®
device ............................................ 410
Connecting a Bluetooth
®
audio player ..................................411
Connecting a Bluetooth
®
phone ............................................ 412
Displaying a Bluetooth
®
device details ............................. 414
Detailed Bluetooth
®
settings.......................................... 415 5-8. Bluetooth
® Audio
Listening to Bluetooth
®
Audio ............................................. 417
5-9. Bluetooth
® Phone
Using a Bluetooth
®
Phone ............................................ 419
Making a call ..................................421
Receiving a call ........................... 424
Speaking on the phone............ 425
Using a Bluetooth
®
phone message........................ 428
Using the steering wheel switches........................................ 431
Bluetooth
® phone
settings ........................................ 432
5-10. Phonebook Contact settings ......................... 434
Messaging setting......................438
5-11. Bluetooth
®
What to do if... (Troubleshooting).................... 439
Bluetooth
®................................... 443
5-12. Other function “Information” screen ................. 449
USB photo ......................................451
Weather information ................ 453
Voice command system .......... 455
Mobile Assistant......................... 459
LEXUS Enform Remote ...........461

359
ES350_300h_OM_OM33B99U_(U)
5-1. Basic Operations
5
Lexus Display Audio system
USB/AUX ports
Push the knob to release the lock,
and lift the armrest to open fully.
Open the cover.
Connect an iPod, USB memory device or portable audio player to the
USB/AUX port as indicated below. Select “iPod”, “USB”, “AUX” or “A/V”
on the audio source selection screen and the device can be operated via
Lexus Display Audio system.
Connecting using the USB/AUX port
1
2

3605-1. Basic Operations
ES350_300h_OM_OM33B99U_(U)
■iPod
Open the cover and connect an iPod using an iPod cable.
Turn on the power of the iPod if it is not turned on.
■USB memory
Open the cover and connect the USB memory device.
Turn on the power of the USB memory device if it is not turned on.
■Portable audio player
Open the cover and connect the portable audio player.
Turn on the power of the portable audio player if it is not turned on.
CAUTION
■While driving
Do not connect a device or operate the device controls.

387
ES350_300h_OM_OM33B99U_(U)
5-5. Playing an audio CD and MP3/WMA/AAC discs
5
Lexus Display Audio system
CD player operation
Pressing the “MEDIA” button displays the CD top screen from any screen
of the selected source.
■Menu screen
 P. 3 7 5
■Selecting a track/file
Press the “ ” or “ ” button or turn the “TUNE•SCROLL” knob to select
the desired track/file number.
To fast-forward or rewind, press and hold the “ ” or “ ” button.
■Selecting the track by the list (CD)
Move the controller to the right and then select the desired track.
■Selecting a folder (MP3/WMA/AAC disc)
Move the controller to the right and then select “Folders”.
Select the desired folder. Then se lect a file to begin using the
selected folder.
■Selecting a file by the selected folder (MP3/WMA/AAC disc)
Move the controller to the right and then select “Files”.
Select the desired file.
Insert a disc, press the “MEDIA ” button or select “DISC” on the
“Source” screen with a disc inserted to begin listening to a CD.
CD top screen
1
2
1
2

3885-5. Playing an audio CD and MP3/WMA/AAC discs
ES350_300h_OM_OM33B99U_(U)
■Error messages
If the following error messages appear on the screen, refer to the table and take the
appropriate measures. If the problem is not rectified, take the vehicle to your Lexus
dealer.
■Discs that can be used
Discs with the marks shown below can be used.
Playback may not be possible depending on recording format or disc features, or
due to scratches, di rt or deterioration.
CDs with copy-protection features may not play correctly.
■CD player protection feature
To protect the internal components, playba ck is automatically stopped when a prob-
lem is detected.
■If a disc is left inside the CD player or in the ejected position for extended periods
Disc may be damaged and may not play properly.
■Lens cleaners
Do not use lens cleaners. Doing so may damage the CD player.
MessageCauseCorrection procedures
“Check disc”
• The disc is dirty or damaged.
• The disc is inserted upside down.
• The disc is not playable with the player.•Clean the disc.
•Insert the disc cor-rectly.
• Confirm the disc is playable with the
player.
“DISC Error”There is a malfunction
within the system.Eject the disc.
“No music files found.”No playable data is
included on the disc.Eject the disc.

3945-5. Playing an audio CD and MP3/WMA/AAC discs
ES350_300h_OM_OM33B99U_(U)
NOTICE
■Discs and adapters that cannot be used
Do not use the following types of discs.
Also, do not use 3 in. (8 cm) disc adapters, DualDiscs or printable discs.
Doing so may damage the player and/or disc insert/eject function.
●Discs that have a diameter that is not 4.7 in. (12 cm).
●Low-quality or deformed discs.
●Discs with a transparent or translucent recording area.
●Discs that have tape, stickers or CD-R labels attached to them, or that have had
the label peeled off.
■Player precautions
Failure to follow the precautions below may result in damage to the discs or the
player itself.
●Do not insert anything other th an discs into the disc slot.
●Do not apply oil to the player.
●Store discs away from direct sunlight.
●Never try to disassemble any part of the player.

404
ES350_300h_OM_OM33B99U_(U)
5-6. Using an external device
Using the AUX port
P. 359
Pressing the “MEDIA” button displays the top screen from any screen of
the selected source.
■Menu screen
 P. 3 7 5
■Operating portable players connected to the audio system
Volume can be adjusted using the vehicl e’s audio controls. All other adjustments
must be made on the portable player itself.
■When using a portable player connected to the power outlet
Noise may occur during playback. Use the power source of the portable player.
To use the AUX port, connect a portable player, press the “MEDIA”
button or select “AUX” or “A/V” on the “Source” screen.
Connecting a portable player
Top screen
NOTICE
■To prevent damage to the portable player or its terminal
●Do not leave portable player in the vehicle. The temperature inside the vehicle
may become high.
●Do not push down on or apply unnecessary pressure to the portable player while
it is connected.
●Do not insert foreign objects into the port.
