turn signal Lexus ES300h 2015 Specifications / Owner's Manual Quick Guide (OM33B53U)

3
ES300h_QG_OM33B53U_(U)
Moon Roof............................................................................................................................... 105
Multi-information Display .................................................................................................... 35
Navigation System
*
Register home .................................................................................................................. .............. 58
Destination input - Search by address ..................................................................................59
Destination input - Search points of interest by name......................................................61
Destination input - Search points of interest by category............................................. 62
Destination input - Search points of interest by telephone number .........................63
Outside Rear View Mirrors.................................................................................................. 27
Portable Audio Device Ports ............................................................................................... 93
Power (Ignition) Switch ....................................................................................................... .. 28
Power Windows.................................................................................................................. .... 104
Rear Sunshade/Rear Door Sunshades ............................................................................ 94
Remote Touch (with navigation system) ........................................................................... 54
Seat Heaters and Ventilators............................................................................................... 93
Smart Access System with Push-button Start ................................................................. 19
Theft Deterrent System......................................................................................................... 22
Tire Pressure Warning System ............................................................................................ 53
Trunk .......................................................................................................................... .................107
Trunk Storage Extension ....................................................................................................... 9 5
Turn Signal Lever .............................................................................................................. ....... 34
Voice Command System
Basic operation ................................................................................................................ .............. 88
Command list ................................................................................................................... ...............89
Windshield Wipers and Washer.......................................................................................... 40
XM Satellite Radio ............................................................................................................. .. 102
*: These features may be operated by Voice Command (See P.88)

5
ES300h_QG_OM33B53U_(U)
OverviewInstrument Panel
Windshield wiper and washer switch P.40
Multi-information display P.35
Headlight switch Turn signal lever
Fog light switch
*
P.37
P.34
Inside lock buttons P.103
Trunk opener P.107
Hood lock release lever*
Driving position memory switches P.25
See P.8
See P.7
Window lock switch P.104
Power window switches P.104
Door lock switch P.103
Tire pressure warning reset switch
P.53
Fuel filler door opener P.106

34
ES300h_QG_OM33B53U_(U)
Tu r n S i g n a l L e v e r
Right turn
Lane change to the right (move the
lever partway and release it)
The right hand signals will flash 3 times.
Lane change to the left (move the lever
partway and release it)
The left hand signals will flash 3 times.
Left turn1
2
3
4
■Customization
The number of times the turn signals flash during a lane change can be changed.

51
ES300h_QG_OM33B53U_(U)
BSM (Blind Spot Monitor) (if equipped)
BSM main switch
Pressing the switch turns the system on or off. When the switch is set to on, the switch’s
indicator illuminates. Common switch for Blind Spot Monitor function and Rear Cross
Tr a f f i c A l e r t f u n c t i o n .
Outside rear view mirror indicator
Blind Spot Monitor function:
When a vehicle is detected in the blind sp ot, the outside rear view mirror indicator
comes on while the turn signal lever is no t operated and the outside rear view mirror
indicator flashes while the turn signal lever is operated.
Rear Cross Traffic Alert function:
When a vehicle approaching from the right or left rear of the vehicle is detected, the
outside rear view mirror indicators flash.
Rear Cross Traffic Alert function buzzer (Rear Cross Traffic Alert function only)
When a vehicle approaching from the right or left rear of the vehicle is detected, a
buzzer sounds from behind the rear seat.
The Blind Spot Monitor is a system that has 2 functions;
● The Blind Spot Monitor function
Assists the driver in making th e decision when changing lanes
● The Rear Cross Traffic Alert function
Assists the driver when backing up
These functions use same sensors.
1
2
3

What to do if...
111
ES300h_QG_OM33B53U_(U)
See the OWNER’S MANUAL
Turn signal indicatorCruise control “SET” indicator
Headlight indicator (U.S.A.)“LDA” (Lane Departure Alert)
indicator (if equipped)
Tail light indicator (Canada)Intuitive parking assist
indicator (if equipped)
Headlight high beam indicator
(Flashes)
Slip indicator
Automatic High Beam
indicator (if equipped)VSC OFF indicator
Fog light indicator(Flashes faster)
“PCS” warning light
(if equipped)
“READY” indicator BSM outside rear view mirror
indicators (if equipped)
EV indicator “AIR BAG ON/OFF”
indicator
Cruise control indicator
Radar cruise control
indicator (if equipped)
For further information, refer to the OWNER’S MANUAL.
