cruise control Lexus ES300h 2016 Owner's Manual (OM33B71U)

3
ES300h_OM_OM33B71U_(U)
1
9 8
7
6 4 3
2
10
5
4-1. Before drivingDriving the vehicle ......................154
Cargo and luggage.................... 160
Vehicle load limits ........................163
Trailer towing .................................164
Dinghy towing ...............................165
4-2. Driving procedures Power (ignition) switch ..............166
EV drive mode ............................... 171
Hybrid transmission .................... 173
Turn signal lever ............................ 176
Parking brake ................................ 177
4-3. Operating the lights and wipers
Headlight switch .......................... 178
Automatic High Beam................ 181
Fog light switch ............................ 185
Windshield wipers and washer ................................. 186
4-4. Refueling Opening the fuel tank cap ...... 190 4-5. Using the driving support
systems
Lexus Safety System+ ................194
PCS (Pre-Collision System) .......... 201
LDA (Lane Departure Alert with steering co ntrol) ..............213
Dynamic radar cruise control............................ 222
Cruise control ............................. 234
Intuitive parking assist ...............237
Lexus parking assist monitor.........................................246
Driving mode select switch ............................................262
BSM (Blind Spot Monitor)..... 264 •Blind Spot Monitor function ..................................... 267
• Rear Cross Traffic Alert
function .................................... 269
Driving assist systems ............... 272
4-6. Driving tips Hybrid vehicle driving tips ......278
Winter driving tips ..................... 280
4Driving

ES300h_OM_OM33B71U_(U)
9
The installation of a mobile two-way radio system in your vehicle could affect electronic
systems such as:
●Multiport fuel injection system/sequential multiport fuel injection system
●Dynamic radar cruise control system
●Cruise control system
●Anti-lock brake system
●SRS airbag system
●Seat belt pretensioner system
Be sure to check with your Lexus dealer fo r precautionary measures or special instruc-
tions regarding insta llation of a mobile two-way radio system.
High voltage parts and cables on the hybrid vehicles emit approximately the same
amount of electromagnetic waves as the conventional gasoline powered vehicles or
home electronic appliances despite of their electromagnetic shielding.
Unwanted noise may occur in the rece ption of the mobile two-way radio.
Installation of a mobile two-way radio system

22Pictorial index
ES300h_OM_OM33B71U_(U)
Audio remote control switches*1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 293
Ta l k s w i t c h
*1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 356
LDA (Lane Departure Alert with steering control) switch
*2 . . . . . . P. 213
Meter control switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 92
Vehicle-to-vehicle distance button
*2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 222
Cruise control switch
Cruise control*2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 234
Dynamic radar cruise control*2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 222
Telephone switches*1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 356
1
2
3
4
5
6
7

84
ES300h_OM_OM33B71U_(U)2. Instrument cluster
The indicators inform the driver of the operating state of the vehicle’s various sys-
tems.
Indicators
Turn signal indicator
(
 P. 1 76 )
(if equipped)
“LDA” (Lane Departure
Alert with steering control)
indicator ( P. 2 1 3 )
(U.S.A.)
Headlight indicator
( P. 1 7 8 )
(if equipped)
Intuitive parking assist
indicator ( P. 2 3 7 )
(Canada)
Tail light indicator
( P. 1 7 8 ) *1, 2Slip indicator light
( P. 2 7 3 )
Headlight high beam
indicator ( P. 1 7 9 )
*1VSC OFF indicator
( P. 2 74 )
(if equipped)
Automatic High Beam
indicator ( P. 1 8 1 ) *1, 3
(if equipped)
PCS warning light
( P. 2 0 4 )
Fog light indicator
(  P. 1 8 5 )
*4, 5
(if equipped)
BSM outside rear view
mirror indicators
( P. 2 6 4 )
“READY” indicator
( P. 166)*1, 6
“A I R B A G O N / O F F ”
indicator ( P. 4 6 )
EV indicator ( P. 6 9 )
Cruise control indicator
(  P. 230, 234)
(U.S.A.)
Parking brake indicator
( P. 1 7 7 )
(if equipped)
Radar cruise control
indicator ( P. 222)
(Canada)
Parking brake indicator
( P. 1 7 7 )
Cruise control “SET”
indicator ( P. 2 3 4 )*7Low outside temperature
indicator ( P. 9 1 )

91
ES300h_OM_OM33B71U_(U)2. Instrument cluster
2
Instrument cluster
Multi-information display
The multi-information display presents the driver with a variety of vehicle data.
Displays the following information
when an icon is selected. (
P. 9 2 )
Drive information
Select to display various drive data.
(  P. 9 2 )
Navigation system-linked dis-
play (if equipped)
Select to display the following na vigation system-linked information.
• Route guidance
• Compass display (north-up display/heading-up display)
Audio system-linked display
Select to enable selection of an audio source or track on the display using the
meter control switches.
Driving assist information
Select to display the cruise control or dynamic radar cruise control/LDA (Lane
Departure Alert with steering control) information, when the system is used.
(  P. 213, 222, 234)
Warning message display
Select to display warning me ssages and measures to be taken if a malfunction is
detected. ( P. 5 0 5 )
Settings display
Select to change the meter display settings. ( P. 5 5 7 )
Display contents

153
ES300h_OM_OM33B71U_(U)
4Driving
4-1. Before drivingDriving the vehicle ...................... 154
Cargo and luggage .................... 160
Vehicle load limits ....................... 163
Trailer towing ................................. 164
Dinghy towing............................... 165
4-2. Driving procedures Power (ignition) switch.............. 166
EV drive mode ............................... 171
Hybrid transmission ....................173
Turn signal lever ............................ 176
Parking brake .................................177 4-3. Operating the lights
and wipers
Headlight switch...........................178
Automatic High Beam ................181
Fog light switch ............................ 185
Windshield wipers and washer.................................. 186
4-4. Refueling Opening the fuel tank cap ...... 190
4-5. Using the driving support systems
Lexus Safety System+ ............... 194
PCS (Pre-Collision System)........... 201
LDA (Lane Departure Alert with steering control) ............. 213
Dynamic radar cruise control ............................ 222
Cruise control ............................. 234
Intuitive parking assist .............. 237
Lexus parking assist monitor ........................................ 246
Driving mode select switch ........................................... 262
BSM (Blind Spot Monitor) ..... 264 • Blind Spot Monitor
function .....................................267
• Rear Cross Traffic Alert function .................................... 269
Driving assist systems................272
4-6. Driving tips Hybrid vehicle driving tips...... 278
Winter driving tips .....................280

ES300h_OM_OM33B71U_(U)
1754-2. Driving procedures
4
Driving
■S mode
●When the shift range is 4 or lower, holding the shift lever toward “+” sets the shift range
to 6.
●To prevent excessive engine speed, a function was adopted that automatically selects a
higher shift range before the engine speed becomes too high.
■When driving with cruise control or dynamic radar cruise control activated
Even when performing the following actions with the intent of enabling engine braking,
the engine brake will not operate in the S mo de, even when downshifting to 5 or 4.
(  P. 2 3 4 )
■Downshifting restrictions warning buzzer
To help ensure safety and driving performa nce, downshifting operation may sometimes
be restricted. In some circumstances, downshifting may not be possible even when the
shift lever is operated. (A buzzer will sound twice.)
■If the S indicator does not come on ev en after shifting the shift lever to S
This may indicate a malfunct ion in the hybrid transmission system. Have the vehicle
inspected by your Lexus dealer immediately.
(In this situation, the transmission will operat e in the same manner as when the shift lever
is in D.)
■If the shift lever cannot be shifted from P
 P. 5 2 0
■AI-SHIFT
AI-SHIFT automatically select s the suitable gear according to driver performance and
driving conditions.
AI-SHIFT automatically operates when the shift lever is in D. (Shifting the shift lever to S
cancels the function.)
WA R N I N G
■When driving on slippery road surfaces
Do not accelerate or shift gears suddenly.
Sudden changes in engine braking may cause th e vehicle to spin or skid, resulting in an
accident.
NOTICE
■Hybrid battery (traction battery) charge
If the shift lever is in N, the hybrid batter y (traction battery) will not be charged even
when the engine is running. Therefore, if the ve hicle is left with the shift lever in N for a
long period of time, the hybrid battery (tr action battery) will discharge, and this may
result in the vehicle not being able to start.

194
ES300h_OM_OM33B71U_(U)4-5. Using the driving support systems
Lexus Safety System+
◆PCS (Pre-Collision System)

P. 2 0 1
◆LDA (Lane Departure Alert with steering control)
P. 2 1 3
◆Dynamic radar cruise control
P. 222
◆AHB (Automatic High Beam)
P. 1 8 1
: If equipped
The Lexus Safety System+ consists of the following drive assist systems and
contributes to a safe and comfo rtable driving experience:
WA R N I N G
■Lexus Safety System+
The Lexus Safety System+ is designed to operate under the assumption that the driver
will drive safely, and is designed to help reduce the impact to the occupants and the
vehicle in the case of a collision or assist the driver in normal driving conditions.
As there is a limit to the degree of recognition accuracy and control performance that
this system can provide, do not overly rely on this system. The driver is always responsi-
ble for paying attention to the vehicl e’s surroundings and driving safely.

222
ES300h_OM_OM33B71U_(U)4-5. Using the driving support systems
Dynamic radar cruise control
In vehicle-to-vehicle distance control mode, the vehicle automatically acceler-
ates and decelerates to match the speed changes of the preceding vehicle even
if the accelerator pedal is not depressed.
In constant speed control mode, the
vehicle runs at a fixed speed.
Use the dynamic radar cruise control on freeways and highways.
●Vehicle-to-vehicle distance control mode ( P. 225)
●Constant speed control mode ( P. 2 3 0 )
Display
Set speed
Indicators
Vehicle-to-vehicle distance but-
ton
Cruise control switch
: If equipped
Summary of functions
1
2
3
4
5

ES300h_OM_OM33B71U_(U)
2234-5. Using the driving support systems
4
Driving
WA R N I N G
■Before using dynamic radar cruise control
Driving safely is the sole responsibility of the driver. Do not rely solely on the system,
and drive safely by always paying ca reful attention to your surroundings.
The dynamic radar cruise control provides driving assistance to reduce the driver’s
burden. However, there are limitatio ns to the assistance provided.
Even when the system is functioning normal ly, the condition of the preceding vehicle as
detected by the system may differ from the condition observed by the driver. There-
fore, the driver must always remain alert, assess the danger of each situation and drive
safely. Relying on this system or assuming the system ensures safety while driving can
lead to an accident, resultin g in death or serious injury.
■Cautions regarding the driving assist systems
Observe the following precautions, as there are limitations to the assistance provided
by the system.
Failure to do so may cause an accident resulting in death or serious injury.
●Assisting the driver to measure following distance
The dynamic radar cruise control is only in tended to help the driver in determining
the following distance between the driver’s own vehicle and a designated vehicle
traveling ahead. It is not a mechanism that al lows careless or inattentive driving, and it
is not a system that can assist the driver in low-visibility conditions. It is still necessary
for driver to pay close attention to the vehicle’s surroundings.
●Assisting the driver to judge proper following distance
The dynamic radar cruise control determines whether the following distance
between the driver’s own vehicle and a designated vehicle traveling ahead is appro-
priate or not. It is not capable of making an y other type of judgement. Therefore, it is
absolutely necessary for the driver to remain vigilant and to determine whether or not
there is a possibility of danger in any given situation.
●Assisting the driver to operate the vehicle
The dynamic radar cruise control has limited capability to prevent or avoid a collision
with a vehicle traveling ahead. Therefore, if there is ever any danger, the driver must
take immediate and direct control of the vehicle and act appropriately in order to
ensure the safety of all involved.
■To avoid inadvertent dynamic radar cruise control activation
Switch the dynamic radar cruise control off using the “ON/OFF” button when not in
use.
