trunk Lexus ES300h 2018 Owner's Manual Quick Guide (OM33D51U)

3
ES300h_QG_OM33D51U_(U)
Moon Roof.............................................................................................................................................. 91
Multi-information Display ..............................................................................................................33
Navigation System
*
Register home .................................................................................................................. ...............54
Destination search ............................................................................................................. ...........55
Outside Rear View Mirrors ........................................................................................................... 25
Portable Audio Device Ports ....................................................................................................... 80
Power (Ignition) Switch ................................................................................................................... 26
Power Windows ............................................................................................................................... ...90
Rear Sunshade/Rear Door Sunshades ..................................................................................... 81
Remote Touch (with navigation system) ................................................................................. 50
Seat Heaters and Ventilators ....................................................................................................... 80
Smart Access System with Push-button Start ....................................................................... 19
Theft Deterrent System ...................................................................................................................20
Tire Pressure Warning System ....................................................................................................49
Trunk .........................................................................................................................................................93
Turn Signal Lever ............................................................................................................................... .32
Voice Command System Basic operation................................................................................................................ ............... 75
Command list ................................................................................................................... ............... 76
Windshield Wipers and Washer ..................................................................................................38
XM Satellite Radio ............................................................................................................................ 88
*: These features may be operated by Voice Command (See P.75)

5
ES300h_QG_OM33D51U_(U)
OverviewInstrument Panel
Windshield wiper and washer switch P.38
Multi-information display P.33
Headlight switch Turn signal lever
Fog light switch
*
P.35
P.32
Inside lock button P.89
Trunk opener P.93
Hood lock release lever*
Driving position memory switches∗ P.23
See P.8
See P.7 Window lock switch
P.90
Power window switches P.90
Door lock switch P.89
Tire pressure warning reset
switch
P.49
Fuel filler door opener P.92
Tilt and telescopic steering
lock release lever
∗*

6
ES300h_QG_OM33D51U_(U)
∗: If equipped
*: Refer to “OWNER’S MANUAL”.
Remote Touch screen∗
Navigation system∗
Lexus Display Audio system
∗
P.50
P.54
P.63
Clock*
Trunk opener main switch
P.93
Audio system P.59, 68
Air conditioning system P.72
Emergency flasher switch*
See P.9 Power (ignition) switch
P.26
Parking brake*
Tilt and telescopic st
eering control switch∗*
Floor mats P.11

13
ES300h_QG_OM33D51U_(U)
■Charging the hybrid ba ttery (traction battery)
As the gasoline engine charges the hybrid battery (traction battery), the battery does not
need to be charged from an outside source. However, if the vehicle is left parked for a long
time the hybrid battery (tractio n battery) will slowly discharge. For this reason, be sure to
drive the vehicle at least once every few months for at least 30 minutes or 10 miles (16 km).
If the hybrid battery (traction battery) become s fully discharged and you are unable to start
the hybrid system, contact your Lexus dealer.
■ Regenerative braking
In the following situations, kinetic energy is converted to electric energy and deceleration
force can be obtained in conjunction with the recharging of the hybrid battery (traction bat-
tery).
● The accelerator pedal is released while driving with the shift lever in D or S.
● The brake pedal is depressed while driv ing with the shift lever in D or S.
■Sounds and vibrations specific to a hybrid vehicle
There may be no engine sound or vibration even though the vehicle is able to move with the
“READY” indicator is illuminated. For safety, apply the parking brake and make sure to shift
the shift lever to P when parked.
The following sounds or vibrat ions may occur when the hybrid system is operating and are
not a malfunction:
● Motor sounds may be heard from the engine compartment.
● Sounds may be heard from the hybrid battery (traction battery) behind the rear seats
when the hybrid syst em starts or stops.
● Relay operating sounds such as a snap or so ft clank will be emitted from the hybrid bat-
tery (traction battery), behind the rear seats, when the hybrid system is started or
stopped.
● Sounds from the hybrid system may be heard when the trunk lid is open.
● Sounds may be heard from the transmission when the gasoline engine starts or stops,
when driving at low speeds, or during idling.
● Engine sounds may be heard when accelerating sharply.
● Sounds may be heard due to regenerative braking when the brake pedal is depressed or
as the accelerator pedal is released.
● Vibration may be felt when the gasoline engi ne starts or stops.
● Cooling fan sounds may be heard from th e air intake vent on rear left seat.
■Running out of fuel
When the vehicle has run out of fuel and the hybrid system cannot be started, refuel the
vehicle with at least enough gasoline to make the low fuel level warning light go off. If there is
only a small amount of fuel, the hybrid system may not be able to start. (The standard amount
of fuel is about 3.0 gal. [11.3 L, 2.5 Imp.gal.], when the vehicle is on a level surface. This value
may vary when the vehicle is on a slope. Ad d extra fuel when the vehicle is inclined.)

18
ES300h_QG_OM33D51U_(U)
Keys
■Electronic key
Smart access system with push-button start
(→ P.19, 26)
Wireless remote control ( →P.18)
■Mechanical key
To take out the mechanical key, push the
release button and take the key out.
After using the mechani cal key, store it in
the electronic key. Carry the mechanical
key together with the electronic key. If
the electronic key battery is depleted or
the entry function does not operate
properly, you will ne ed the mechanical
key.
■ Wireless remote control
Locks the doors
Unlocks the doors
Opens the windows and moon roof
*
Opens the trunk
Sounds the alarm
*: This setting must be customized at your
Lexus dealer.
1
2
3
4
5

19
ES300h_QG_OM33D51U_(U)
Smart Access System with Push-button Start
■Entering and exiting the vehicle
Grip the driver’s door handle to unlock
the door. Grip the passenger’s door
handle to unlock all the doors.
*
Make sure to touch the sensor on the
back of the handle.
The doors cannot be unlocked for
3 seconds after the doors are locked.
*: The door unlock settings can be
changed.
Touch the lock sensor (the indentation
on the upper part of the door handle)
to lock all the doors. Check that the door is securely
locked.
■ Opening the trunk
Press the button.
If the vehicle is equipped with power
trunk opener and closer, the trunk lid
automatically opens fully.
The following operations can be performed simply by carrying the electronic key on your
person, for example in your pocket. The driver should always carry the electronic key.
For details on starting the hybrid system, see page 26.
1
2
For details on what to do when the electronic key does not operate properly, see page 97.

20
ES300h_QG_OM33D51U_(U)
Theft Deterrent System
■Immobilizer system
The indicator light flashes after the power
switch has been turned off to indicate that
the system is operating.
The indicator light stops flashing after the
power switch has been turned to ACCES-
SORY or ON mode to indicate that the sys-
tem has been canceled.
■ Alarm
The alarm uses light and sound to give an alert when an intrusion is detected.
To set the alarm:
Close the doors, trunk and hood, and lock all th e doors. The system will be set automatically
after 30 seconds. The indicator light changes from being on to flashing when the system is set.
To deactivate or stop the alarm:
● Unlock the doors or open the trunk using the entry function or wireless remote control.
● Turn the power switch to ACCESSORY or ON mode, or start the hybrid system. (The
alarm will be deactivated or stopped after a few seconds.)

93
ES300h_QG_OM33D51U_(U)
Trunk
■Opening the trunk
● From inside the vehicle
Press the opener switch.If the vehicle is equipped with a power
trunk opener and closer, the trunk lid
automatically opens fully
Turn the main switch in the glove box off to
disable the trunk opener. On
Off
The trunk lid cannot be opened even with
the wireless remote control or the trunk
release button.
● From outside the vehicle
• Smart access system wi th push-button start
While carrying the electronic key, press the
button on the trunk lid.When all the doors are unlocked with
the power door lock system, the trunk
can be opened without carrying the
electronic key.
If the vehicle is equipped with power
trunk opener and closer, the trunk lid
automatically opens fully.
• Wireless remote control Press and hold the switchIf the vehicle is equipped with a power
trunk opener and closer, the trunk lid
automatically opens fully.
1
2

94
ES300h_QG_OM33D51U_(U)
■Trunk easy closer (vehicles with power trunk opener and closer)
In the event that the trunk lid is left slightly open, the trunk easy closer will automatically
close it to the fully closed position.
■ Trunk closer switch (vehicles with power trunk opener and closer)
Pressing the switch closes the trunk lid
automatically. (A buzzer sounds.)
Pressing the switch while the trunk lid is
closing opens the trunk lid again.

What to do if...
97
ES300h_QG_OM33D51U_(U)
If the electronic key does not operate properly
■Unlocking and locking the doors
Use the mechanical key ( →P.18) in order to
perform the following operations:
Locks all the doors
Closes the windows and moon roof
*
(turn and hold)
Unlocks the door
Turning the key rear ward unlocks the
driver’s door. Turning the key once
again within 5 seconds unlocks the
other doors.
Opens the windows and moon roof
*
(turn and hold)
*: This setting must be customized at your
Lexus dealer.
■ Unlocking the trunk
Turn the mechanical key clockwise to open.
An alarm will sound if the alarm is set.
(→ P.20)
1
2
3
4
