3897-2. Steps to take in an emergency
7
When trouble arises
open.
■Key linked functions
1
Closes the windows and the moon roof
(turn and hold)
2
Opens the windows and the moon roof
(turn and hold)
These settings must be customized at your
Lexus dealer.
1Ensure that the shift lever is in P and
depress the brake pedal.
2
Touch the Lexus emblem side of the
electronic key to the power switch.
When the electronic key is detected, a
buzzer sounds and the power switch will
turn to ON mode.
When the smart access system with push-
button start is deactivated in customization
setting, the power switch will turn to
ACCESSORY mode.
3Firmly depress the brake pedal and
check that is shown on the
multi-information display.
4
Press the power switch shortly and
firmly.
In the event that the hybrid system still
cannot be started, contact your Lexus
dealer.
■Stopping the hybrid system
Set the parking brake, shift the shift lever to
P and press the power switch as you nor-
mally do when stopping the hybrid system.
■Electronic key battery
As the above procedure is a temporary
measure, it is recommended that the elec-
tronic key battery be replaced immediately
when the battery is depleted. (P.346)
WARNING
■When using the mechanical key and
operating the power windows or
moon roof
Operate the power window after check-
ing to make sure that there is no possibil-
ity of any passenger having any of their
body parts caught in the window or
moon roof.
Also, do not allow ch ildren to operate the
mechanical key. It is possible for children
and other passengers to get caught in
the power window or moon roof.
Starting the hybrid system

3927-2. Steps to take in an emergency
6Open and close any of the doors of
your vehicle with the power switch
off.
7 Maintain the engine speed of the
second vehicle and start the hybrid
system of your vehicle by turning
the power switch to ON mode.
8 Make sure the “READY” indicator
comes on. If the indicator does not
come on, contact your Lexus
dealer.
9 Once the vehicle’s hybrid system
has started, remove the jumper
cables in the exact reverse order
from which they were connected.
10 Close the exclusive jump starting
terminal cover, and reinstall the fuse
box cover to its original position.
Once the hybrid system starts, have the
vehicle inspected at your Lexus dealer as
soon as possible.
■Starting the hybrid system when the 12-
volt battery is discharged
The hybrid system cannot be started by
push-starting.
■To prevent 12-volt battery discharge
●Turn off the headlights and the audio sys-
tem while the hybrid system is stopped.
●Turn off any unnecessary electrical com-
ponents when the vehicle is running at a
low speed for an extended period, such
as in heavy traffic.
■When the 12-volt battery is removed or
discharged
●Information stored in the ECU is cleared.
When the 12-volt battery is depleted,
have the vehicle inspected at your Lexus
dealer.
●Some systems may require initialization.
(  P.429)
■When removing the 12-volt battery ter-
minals
When the 12-volt battery terminals are
removed, the information stored in the
ECU is cleared. Before removing the 12-
volt battery terminals, contact your Lexus
dealer.
■Charging the 12-volt battery
The electricity stored in the 12-volt battery
will discharge gradually even when the
vehicle is not in use, due to natural dis-
charge and the draining effects of certain
electrical appliances. If the vehicle is left for
a long time, the 12-volt battery may dis-
charge, and the hybrid system may be
unable to start. (The 12-volt battery
recharges automatically while the hybrid
system is operating.)
■When recharging or replacing the 12-
volt battery
●In some cases, it may not be possible to
unlock the doors using the smart access
system with push-button start when the
12-volt battery is discharged. Use the
wireless remote control or the mechani-
cal key to lock or unlock the doors.
●The hybrid system may not start on the
first attempt after the 12-volt battery has
recharged but will start normally after the
second attempt. This is not a malfunction.
●The power switch mode is memorized by
the vehicle. When the 12-volt battery is
reconnected, the system will return to the
mode it was in before the 12-volt battery
was discharged. Before disconnecting
the 12-volt battery, turn the power switch
off.
If you are unsure what mode the power
switch was in before the 12-volt battery
discharged, be especially careful when
reconnecting the 12-volt battery.
■When replacing the 12-volt battery
●Use a 12-volt battery that conforms to
European regulations.
●Use a 12-volt battery that the case size is
same as the previous one (LN2), 20 hour
rate capacity (20HR) is equivalent
(60Ah) or greater, and performance rat-
ing (CCA) is equivalent (345A) or
greater.

Alphabetical index449
Door courtesy lights ....................................277
Door lockDoors .................................................................. 101
Smart access system with push-button start ....................................................................112
Wireless remote control........................... 99
Doors ................................................................... 101 Automatic door lock ing and unlocking
system ........................................................... 104
Door glasses ................................................. 130
Door lock.......................................................... 101
Open door warning buzzer ....... 102, 104
Outside rear view mirrors ...................... 127
Rear door child-protectors ................... 104
Drive distance .................................................. 82
Drive info 1/Drive info 2 .............................. 82
Driver’s seat position memory .................120 Driving position memory .........................120
Memory recall function ..............................121
Drive-start control ........................................ 137
Driving................................................................136 Break-in tips ................................................... 137
Correct driving posture .............................23
Driving Mode Select switch ................... 213
Hybrid vehicle driving tips .................... 252
Procedures .....................................................136
Winter drive tips......................................... 254
Driving information display ........................ 82
Driving Mode Select switch......................213
Driving range ................................................... 82
Driving support system information display ............................................................................. 83
Dynamic radar cruise control with full- speed range................................................. 198Warning message.....................................206
E
ECB (Electronically Controlled Brake Sys- tem) ................................................................ 248
Eco drive mode ..............................................213
EDR (Event data recorder) ........................... 8
Elapsed time ..................................................... 82 Electric motor (traction motor) .................. 61
Electric Power Steering (EPS)
Function ..........................................................248
Warning light .............................................. 366
Electronically Controlled Brake System (ECB) ............................................................ 248
Electronic key .................................................. 98 Battery-saving function.............................. 113
If the electronic key does not operate properly ...................................................... 388
Replacing the battery ...............................346
Emergency, in case of If a warning buzzer sounds...................364
If a warning light turns on.......................364
If a warning message is displayed ..... 374
If the 12-volt battery is discharged ... 390
If the electronic key does not operate properly ...................................................... 388
If the fuel filler do or cannot be opened
..........................................................................387
If the hybrid system will not start ....... 385
If the vehicle is trapped in rising water ..........................................................................357
If you have a flat tire ..................................378
If you lose your keys .................................387
If you think something is wrong..........362
If your vehicle becomes stuck ............ 398
If your vehicle has to be stopped in an emergency ................................................ 356
If your vehicle needs to be towed .... 359
If your vehicle overheats ....................... 395
Emergency flashers .................................... 356
Energy monitor ............................................... 90
Engine ACCESSORY mode............................... 148
Compartment................................................321
Hood ................................................................. 319
How to start the hybrid system............ 145
Identification number ................................ 401
If the hybrid system will not start ....... 385
If your vehicle has to be stopped in an emergency ................................................ 356

456Alphabetical index
Starting the hybrid system.......................145
Snow tires ....................................................... 254
Spare tire Storage location ......................................... 379
Spark plug ...................................................... 403
Specifications ................................................400
Speedometer ................................................... 78
Sport mode ......................................................213
Steering lock Column lock release..................................145
Steering lock system warning message...........................................................................145
Steering wheel ................................................125 Adjustment......................................................125
Heated steering wheel............................ 273
Meter control switches .............................. 82
Power easy access system .....................120
Steering wheel position memory ........120
Stop lights Replacing light bulbs..................................351
Storage feature ............................................280
Stuck If the vehicle becomes stuck................398
Suggestion function....................................... 84
Sunshade Roof ....................................................................133
Sun visors ........................................................ 284
Switches “ODO TRIP” switch ....................................80
“SOS” button .................................................. 54
Automatic High Beam system..............164
Brake Hold switch ..................................... 159
BSM (Blind spot monitor) switch......208
Door lock switches .................................... 103
Driving Mode Select switch ................... 213
Driving position memory switches .....120
Dynamic radar cruise control with full-speed range switch .................................199
Emergency flashers switch ...................356
EV drive mode switch ............................. 150
Garage door opener switches .......... 296
Heated steering wheel switch............. 273 HUD (Head-up display) switch ............ 87
Ignition switch ............................................... 145
Instrument panel light control switches
............................................................................ 80
Intuitive parking assist switch ................. 217
Light switches ................................................. 161
LTA (Lane-Tracing Assist) switch ......192
Meter control switches .............................. 82
Moon roof switches....................................132
Outside rear view mi rror switches ..... 127
Paddle shift switches .......................154, 155
Parking brake switch..................................157
PCS OFF switch ......................................... 182
PKSB (Parking Support Brake) switch ..........................................................................230
Power door lock switch .......................... 103
Power switch................................................. 145
Power window switches ......................... 130
RCD (Rear Camera Detection) switch .......................................................................... 226
RCTA switch ................................................ 222
Rear sunshades switch............................293
Rear window and outside rear view mir-
ror defoggers switch ............................265
Seat heater switches................................. 273
Seat ventilator switches .......................... 273
Tilt and telescopic steering control switch ........................................................................... 125
Tire pressure warning reset switch...334
Trunk closer switch ....................................108
Trunk opener main switch.......................... 111
Trunk opener switch ................................. 107
Vehicle-to-vehicle distance switch.... 199
VSC OFF switch ....................................... 249
Window lock switch.................................... 131
Windshield wiper and washer switch166
Windshield wiper de-icer switch.......269
T
Tachometer....................................................... 78
Tail lights............................................................. 161 Light switch ...................................................... 161
