4248-2. Customization
*1:Except for Canada
*2: If equipped
■PCS (Pre-Collision System) (P.178)
■LTA (Lane Tracing Assist) ( P.185)
■RSA (Road Sign Assist)* ( P.194)
Welcome lightingOnOffO
AFS (Adaptive Front-lighting
System)
*2OnOffO
FunctionDefault settingCustomized set-
ting
PCS (Pre-Collision System)OnOffO
Adjust alert timingMiddleEarlyOLate
FunctionDefault settingCustomized set-ting
Lane centering functionOnOffO
Steering assist functionOnOffO
Alert typeSteering wheel vibrationBuzzerO
Alert sensitivityHighStandardO
Vehicle sway warning functionOnOffO
Vehicle sway warning sensitivityStandardHighOLow
FunctionDefault settingCustomized set- ting
RSA (Road Sign Assist)OnOffO
Excess speed notification
methodDisplay onlyNo notificationODisplay and buzzer
FunctionDefault settingCustomized set-tingABC
ABC
ABC
ABC

4258-2. Customization
8
Vehicle specifications
*:If equipped
■BSM (Blind Spot Monitor)* ( P.206)
*:If equipped
■PKSA (Parking Support Alert) ( P.214)
■Intuitive parking assist* ( P.215)
*:If equipped
Excess speed notification level1 mph (2 km/h)3 mph (5 km/h)O5 mph (10 km/h)
Other notifications method
(No-entry notification)Display onlyNo notificationODisplay and buzzer
FunctionDefault settingCustomized set-
ting
BSM (Blind Spot Monitor)OnOffO
Outside rear view mirror indi-
cator brightnessBrightDimO
Alert timing for presence of
approaching vehicle (sensitiv-
ity)
Intermediate
Early
O
Late
Only when vehicle detected in blind spot
FunctionDefault settingCustomized set- ting
Buzzer volumeLevel2Level1OLevel3
FunctionDefault settingCustomized set-ting
Intuitive parking assistOnOffO
FunctionDefault settingCustomized set-tingABC
ABC
ABC
ABC

4288-2. Customization
*:If equipped
■Vehicle customization
●When the smart access system with
push-button start is off, the entry unlock
function cannot be customized.
●When the doors remain closed after
unlocking the doors and the timer acti-
vated automatic door lock function acti-
vates, signals will be generated in
accordance with the operation buzzer
volume and operational signal (Emer-
gency flashers) function settings.
●Some settings can be changed using a
switch or the Center Display. If a setting is
changed using a switch, the changed set-
ting will not be reflected on the Center
Display until the power switch is turned
off and then to ON mode.
■Clock settings screen
If the clock adjustment screen is displayed
continuously when attempting to change
the clock settings, the system may be mal-
functioning. Have the vehicle inspected by
your Lexus dealer.
Time elapsed before the outer
foot lights turn off15 seconds
Off
OO7.5 seconds
30 seconds
Operation of the outer foot
lights when you approach the
vehicle with the electronic key
on your person
OnOffO
Operation of the outer foot
lights when the doors are
unlocked
OnOffO
Operation of the outer foot
lights when a door is openedOnOffO
Fading out of the outer foot
lights when they turn offLongShortO
FunctionDefault settingCustomized set-
tingABC

445What to do if... (Troubleshooting)
In this case, the hybrid system can be
started in a temporary way. ( P.389)
Is the 12-volt battery discharged?
( P.390)
 Is the power switch in ON mode?
If you cannot release the shift lever
by depressing the brake pedal with
the power switch in ON mode
( P.151)
 It is locked automatically to prevent
theft of the vehicle. ( P.143)
 Is the window lock switch pressed?
The power window except for the one at
the driver’s seat cannot be operated if the
window lock switch is pressed. ( P.129)
 The auto power off function will be
operated if the vehicle is left in
ACCESSORY or ON mode
(hybrid system is not operating) for
a period of time. ( P.146) 
The seat belt reminder light is flash-
ing
Are the driver and the passengers wearing
the seat belts? ( P.367)
 The parking brake indicator is on
Is the parking brake released? ( P.155)
Depending on the situation, other
types of warning buzzer may also
sound. ( P.364, 374)
 Did anyone inside the vehicle open
a door during setting the alarm?
The sensor detects it and the alarm sounds.
( P.69)
To stop the alarm, turn the power
switch to ON mode, or start the hybrid
system.
 Is the message displayed on the
multi-information display?
Check the message on the multi-informa-
tion display. ( P.374)
 When a warning light turns on or a
warning message is displayed, refer
to P.364, 374.
The shift lever cannot be shifted
from P even if you depress the
brake pedal
The steering wheel cannot be
turned after the hybrid system is
stopped
The windows do not open or
close by operating the power
window switches
The power switch is turned off
automatically
A warning buzzer sounds during
driving
An alarm is activated and the
horn sounds
A warning buzzer sounds when
leaving the vehicle
A warning light turns on or a
warning message is displayed

447Alphabetical index
Alphabetical index
A
A/C ................................................................... 265Air conditioning filter ................................. 341
Automatic air conditioning system ... 265
ABS (Anti-lock Brake System)...............247 Function .......................................................... 247
Warning light ...............................................366
ACA (Active Cornering Assist) ............247
Active Cornering Assist (ACA) ............247
Adaptive Front-lighting System (AFS) .. 161
AFS (Adaptive Front-lighting System) .. 161
Airbags ............................................................... 28 Airbag operating conditions................... 30
Airbag precautions for your child ........ 33
Correct driving posture .............................23
Curtain shield airbag operating condi-tions .................................................................... 31
Curtain shield airbag precautions ....... 33
Front passenger occupant classification system ..............................................................37
General airbag precautions ................... 33
Locations of airbags.................................... 28
Modification and disposal of airbags . 35
Side airbag operating conditions ........... 31
Side airbag precautions ............................ 33
Side and curtain shield airbags operating conditions........................................................ 31
Side and curtain shield airbags precau- tions .................................................................. 33
SRS airbags ..................................................... 28
SRS warning light ......................................365
Air conditioning filter ...................................341
Air conditioning system ............................ 265 Air conditioning filter ................................. 341
Automatic air conditioning system ... 265
Alarm ................................................................... 69 Alarm .................................................................. 69
Warning buzzer ......................................... 364
Anchor brackets ...................................... 43, 51
Antennas (smart access system with push- button start) ................................................... 110 Anti-lock Brake System (ABS)...............247
Function .......................................................... 247
Warning light .............................................. 366
Approach warning...................................... 202
Armrest............................................................ 293
Assist grips ..................................................... 293
Audio system-linked display ........................81
Auto Glide Control ......................................213
Automatic headlight leveling system ... 160
Automatic High Beam ................................162
Automatic light control system................159
Auxiliary box.................................................. 282
Average fuel economy................................. 80
Average vehicle speed ................................ 80
B
Back-up lights Replacing light bulbs ................................. 351
Battery (12-volt battery) ........................... 326 Battery checking ........................................326
If the 12-volt battery is discharged ... 390
Preparing and checking before winter..........................................................................253
Warning light .............................................. 365
Battery (traction batter y) ............................ 63
Blind Spot Monitor (BSM)....................... 206
Brake Brake hold .......................................................157
Fluid.................................................................. 404
Parking brake ............................................... 155
Regenerative braking ...................................61
Warning light ...............................................364
Brake assist .....................................................247
Break-in tips.....................................................135
Brightness control Instrument panel light control................. 78
BSM (Blind Spot Monitor)....................... 206
C
Care ...................................................... 306, 309 Aluminum wheels ..................................... 306

448Alphabetical index
Exterior ...........................................................306
Interior .............................................................309
Seat belts........................................................309
Cargo capacity................................................ 141
Cargo hooks ................................................. 283
Center Display ............................................. 258
Chains .............................................................. 254
Child-protectors............................................102
Child restraint system................................... 42 Fixed with a LATCH system .................. 49
Fixed with a seat belt................................... 46
Front passenger occupant classification system ..............................................................37
Points to remember .....................................42
Riding with children ......................................42
Types of child restraint system installation method ........................................................... 43
Using an anchor bracket ............................ 51
Child safety ....................................................... 42 12-volt battery precautions ....... 327, 393
Airbag precautions...................................... 33
Child restraint system................................. 43
Heated steering wheel and seat heater
precautions................................................ 273
How your child should wear the seat belt ............................................................................ 25
Moon roof precautions ............................. 131
Power window lock switch..................... 129
Power window precautions ................... 129
Rear door child-protectors ....................102
Removed electronic key battery precau- tions ............................................................... 347
Seat belt extender precautions ............. 25
Seat belt precautions ...................................42
Trunk precautions ...................................... 103
Cleaning.............................................. 306, 309 Aluminum wheels ......................................306
Exterior ...........................................................306
Interior .............................................................309
Radar sensor......................................172, 208
Seat belts........................................................309
Clock ........................................................ 76, 284 Coat hooks..................................................... 295
Compass ......................................................... 302
Condenser ..................................................... 324
Console box ....................................................281
Console box light ..........................................281
Cooling system............................................. 323
Engine overheating.................................. 395
Hybrid system overheating ................. 396
Cornering lights .............................................. 161 Replacing light bulbs ................................. 351
Cruise control Dynamic radar cruise control with full-
speed range ............................................... 196
Cup holder .......................................................281
Current fuel consumption .......................... 80
Curtain shield airbags .................................. 28
Customizable features ............................... 418
D
Daytime running light system ...................159
Defogger Outside rear view mirrors.....................266
Rear window ................................................266
Windshield ....................................................266
Dimension ......................................................400
Dinghy towing................................................. 142
Display BSM (Blind Spot Monitor)................... 206
Dynamic radar cruise control with full-
speed range ............................................... 196
Energy monitor ............................................. 88
Head-up display............................................84
Intuitive parking assist ............................... 215
LTA (Lane-Tracing Assist) .................... 190
Multi-information display .......................... 79
Parking Support Brake function (rear
pedestrians)............................................... 244
RCD (Rear Camera Detection) ........ 225
RCTA................................................................. 221
Warning message ..................................... 374
Distance until next engine oil change .... 78
Do-it-yourself maintenance ......................313

Alphabetical index449
Door courtesy lights ....................................277
Door lockDoors .................................................................. 99
Smart access system with push-button start ................................................................... 110
Wireless remote control........................... 97
Doors ................................................................... 99 Automatic door lock ing and unlocking
system ............................................................102
Door glasses ..................................................128
Door lock.......................................................... 99
Open door warning bu zzer .......100, 102
Outside rear view mirrors ......................125
Rear door child-protectors ....................102
Drive distance .................................................. 80
Drive info 1/Drive info 2 .............................. 80
Driver’s seat position memory .................. 118 Driving position memory .......................... 118
Memory recall function ............................. 119
Drive-start control ........................................135
Driving................................................................134 Break-in tips ...................................................135
Correct driving posture .............................23
Driving Mode Select switch ................... 212
Hybrid vehicle driving tips ......................251
Procedures ..................................................... 134
Winter drive tips......................................... 253
Driving information display ........................ 80
Driving Mode Select switch...................... 212
Driving range ................................................... 80
Driving support system information display ...............................................................................81
Dynamic radar cruise control with full- speed range..................................................196Warning message..................................... 204
E
ECB (Electronically Controlled Brake Sys- tem) .................................................................247
Eco drive mode .............................................. 212
EDR (Event data recorder) ........................... 8
Elapsed time ..................................................... 80 Electric motor (traction motor) ................ 60
Electric Power Steering (EPS)
Function .......................................................... 247
Warning light .............................................. 366
Electronically Controlled Brake System (ECB) .............................................................247
Electronic key .................................................. 96 Battery-saving function................................ 111
If the electronic key does not operate properly ...................................................... 388
Replacing the battery ...............................346
Emergency, in case of If a warning buzzer sounds...................364
If a warning light turns on.......................364
If a warning message is displayed ..... 374
If the 12-volt battery is discharged ... 390
If the electronic key does not operate properly ...................................................... 388
If the fuel filler do or cannot be opened
..........................................................................387
If the hybrid system will not start ....... 385
If the vehicle is trapped in rising water ..........................................................................357
If you have a flat tire ..................................378
If you lose your keys .................................387
If you think something is wrong..........362
If your vehicle becomes stuck ............ 398
If your vehicle has to be stopped in an emergency ................................................ 356
If your vehicle needs to be towed .... 359
If your vehicle overheats ....................... 395
Emergency flashers .................................... 356
Energy monitor ............................................... 88
Engine ACCESSORY mode............................... 146
Compartment................................................321
Hood ................................................................. 319
How to start the hybrid system.............143
Identification number ................................ 401
If the hybrid system will not start ....... 385
If your vehicle has to be stopped in an emergency ................................................ 356

Alphabetical index451
Replacing light bulbs..................................351
Headlights aim .............................................. 350
Head restraints ................................................ 121
Head-up display.............................................. 84 Driving information display area........... 84
Driving support system display area .. 86
HUD (Head-up display) switch............85
Hybrid System Indicator ........................... 87
Navigation system-linked display ........ 84
Pop-up display............................................... 86
Settings .............................................................. 85
Heated steering wheel .............................. 273
Heaters Air conditioning system.......................... 265
Heated steering wheel............................ 273
Outside rear view mirrors .................... 266
Seat heaters .................................................. 273
High mounted stoplight Replacing light bulbs..................................351
High-voltage components ......................... 63
Hill-start assist control ................................247
Hood ...................................................................319 Open .................................................................319
Hooks Cargo hooks................................................ 283
Coat hooks ................................................... 295
Grocery bag hooks ................................. 283
Retaining hooks (floor mat)......................22
Horn .................................................................... 124
HUD (Head-up display) switch................ 85
Hybrid battery (traction battery) Location............................................................. 63
Specification ................................................. 402
Warning message........................................ 66
Hybrid battery (traction battery) air vents ............................................................................. 65
Hybrid system .................................................. 60 Emergency shut off system ..................... 66
Energy monitor/consumption screen88
EV drive mode ............................................ 148
High voltage components ....................... 63
Hybrid system precautions ..................... 63 Hybrid vehicle driving tips ..................... 251
If the hybrid system will not start ....... 385
Overheating ................................................ 396
Power (ignition) switch .............................143
Regenerative braking ...................................61
Starting the hybrid system .......................143
Vehicle proximity noti
fication system. 62
Hybrid System Indicator.......................77, 87
Hybrid transmission..................................... 150 Paddle shift switches ....................... 152, 153
S mode ............................................................. 153
I
I/M test ..............................................................316
IdentificationEngine............................................................... 401
Vehicle ........................................................... 400
Ignition switch (power switch) .................143
Auto power off function........................... 146
Changing the power switch modes . 146
If your vehicle has to be stopped in an emergency ................................................ 356
Starting the hybrid system .......................143
Immobilizer system.........................................67
Indicators ............................................................73
Initialization Items to initialize ......................................... 429
Maintenance.......................................312, 323
Power windows ........................................... 128
Tire pressure warning system .............334
Inside rear view mirror ................................ 124
Instrument panel light control ................... 78
Interior lights...................................................277
Intuitive parking assist........................ 214, 215 Function ........................................................... 215
Warning message ....................................... 217
J
JackPositioning a floor jack ............................. 319
Vehicle-equipped jack ........................... 379

452Alphabetical index
Jack handle .................................................... 379
Jam protection functionMoon roof ........................................................ 131
Power trunk opener and closer ...........107
Power windows............................................128
K
Keyless entrySmart access system with push-button start ................................................................... 110
Wireless remote control........................... 97
Keys...................................................................... 96 Battery-saving function ............................... 111
Electronic key ................................................. 96
If the electronic key does not operate properly...................................................... 388
If you lose your keys................................. 387
Key number plate ......................................... 96
Keyless entry ............................... 99, 105, 110
Mechanical key.............................................. 96
Power switch ................................................. 143
Replacing the battery............................... 346
Warning buzzer ............................................ 110
Wireless remote control........................... 97
Knee airbags .................................................... 28
L
Lane Tracing Assist (LTA) ........................ 185 Operation....................................................... 185
Warning messages ....................................193
Language (multi-information display) ... 82
LATCH anchors ............................................. 49
Lever Auxiliary catch lever ...................................319
Hood lock release lever...........................319
Internal trunk release lever .....................107
Shift lever......................................................... 150
Turn signal lever ...........................................154
Wiper lever.....................................................164
Lexus climate concierge .......................... 263
Lexus Enform Safety Connect.................. 54 Lexus Safety System + 2.0 ........................ 172
Automatic High Beam ..............................162
Dynamic radar cruise control with full-
speed range ............................................... 196
LTA (Lane Tracing Assist) ..................... 185
PCS (Pre-Collision System) ................. 178
RSA (Road Sign Assist)........................... 194
License plate lights........................................159 Light switch .................................................... 159
Replacing light bulbs ................................. 351
Light bulbs Replacing ........................................................ 351
Wattage ......................................................... 406
Lights Automatic High Beam system ..............162
Front interior lights .................................... 278
Front personal lights.................................278
Headlight switch.......................................... 159
Interior lights list .......................................... 277
Interior lights ................................................. 277
Rear interior lights .....................................278
Rear personal lights .................................. 278
Trunk light ....................................................... 107
Turn signal lever .......................................... 154
Vanity lights ..................................................284
Wattage ......................................................... 406
Welcome light illumination control ... 160
Lock steering column ..................................143
Low profile tire.............................................. 329
LTA (Lane Tracing Assist) ........................ 185 Operation ....................................................... 185
Warning messages.................................... 193
Luggage mat ................................................. 283
M
Maintenance
Do-it-yourself maintenance ...................317
General maintenance .............................. 313
Maintenance data ..................................... 400
Maintenance requirements ....................312
Malfunction indicator la mp ..................... 365
Master warning light .................................... 371

Alphabetical index453
Menu icons.........................................................79
MeterClock .................................................................. 76
Hybrid System Indicator ............................ 77
Indicators ...........................................................73
Instrument panel light control ................ 78
Meter control switches ..............................80
Meters ................................................................ 76
Multi-information display .......................... 79
Settings .............................................................. 82
Warning lights ............................................. 364
Warning message..................................... 374
Mirrors Inside rear view mirror.............................. 124
Outside rear view mirror defoggers266
Outside rear view mirrors ......................125
Vanity mirrors.............................................. 284
Moon roof Door lock linked moon roof operation............................................................................ 131
Jam protection function............................. 131
Operation....................................................... 130
Multi-information display .............................79
Audio system-linked display.....................81
Drive information 1/Drive information 2............................................................................80
Driving information display......................80
Driving support system information dis- play .....................................................................81
Dynamic radar cruise control with full- speed range ................................................196
Energy monitor..............................................88
LTA (Lane-Tracing Assist) .................... 190
Menu icons ...................................................... 79
Meter control switches ..............................80
Navigation system-linked display ..........81
Pop-up display............................................... 79
Settings .............................................................. 82
Suggestion function..................................... 82
Tire pressure ..................................................331
Warning message..................................... 374N
Navigation system-linked display..... 81, 84
Noise from under vehicle ...............................6
O
Odometer ......................................................... 78
Odometer and trip meter display “ODO TRIP” switch .................................... 78
Display items ................................................... 78
Pop-up display ............................................... 78
“ODO TRIP” switch ...................................... 78
Oil Engine oil........................................................402
Opener Fuel filler door ............................................... 170
Hood ................................................................. 319
Trunk ................................................................. 105
Outer foot lights Replacing light bulbs ................................. 351
Outside door handle lig hts.......................277
Outside rear view mirrors .........................125 Adjustment ..................................................... 125
BSM (Blind Spot Monitor)................... 206
Folding...............................................................126
Linked mirror functi on when reversing
............................................................................ 127
Mirror position memory ............................ 118
Outside rear view mirror defoggers266
RCTA function .............................................. 221
Outside temperature.....................................76
Overheating .................................................. 395
P
Paddle shift switches ..........................152, 153
Panic mode ........................................................97
Parking assist sensors (intuitive parking assist) ...............................................................215
Parking brake................................................. 155 Operation ....................................................... 155
Parking brake engaged warning buzzer
