STARTING AND DRIVING
283
TRACTION CONTROL SYSTEM
The traction control system automatically helps prevent
the spinning of front wheels when the vehicle is started or
accelerated on slippery road surfaces.
When the ignition key is turned to ONº, the system
automatically turns on.
CAUTION
Under certain slippery road conditions, full traction of
the vehicle and power against front wheels cannot be
maintained, even though the traction control system is
in operation. Do not drive the vehicle under any speed
or maneuvering conditions which may cause the
vehicle to lose traction control. In situations where the
road surface is covered with ice or snow, your vehicle
should be fitted with snow tires or tire chains. Always
drive at an appropriate and cautious speed for the
present road conditions.
Normal driving mode

Slip indicator light
Leave the system on during the ordinary driving so that it
can operate when needed.
You may hear a sound in the engine compartment for a few
seconds when the engine is started or just after the vehicle
begins to move. This means that the traction control system
is in the self-check mode, but does not indicate a malfunction.
When the traction control system is operating, the following
conditions occur:
The system controls the spinning of the front wheels. At this
time, the slip indicator light blinks.
You may feel vibration or noise in your vehicle, caused by
operation of the brakes. This indicates the system is
functioning properly.

STARTING AND DRIVING
284The slip indicator light comes on for a few seconds when the
ignition key is turned to ONº. If the indicator light does not
come on when the ignition is turned on, contact your Lexus
dealer.
Traction control off mode
If your wheels get stuck in a ditch when you are driving on
a severe off road and sand, turn off the traction control
system. This system that controls engine performance
interferes with the process of freeing your wheels.
To turn off: Push TRAC OFFº switch.
The TRAC OFFº indicator light will come on.
The vehicle stability control system is always activated, even
if the traction control system is turned off.To turn on: Push TRAC OFFº switch once again.
The TRAC OFFº indicator light will go off.
TRAC OFFº indicator light comes on for a few seconds when
the ignition key is turned to ONº. It will come on again when
you push the TRAC OFFº switch to turn off the system.
In the following cases, contact your Lexus dealer:
The indicator light does not come on when the ignition key
is turned to ONº.
The indicator light remains on after the ignition is turned on.
The indicator light comes on with the normal driving mode
while driving.

STARTING AND DRIVING
285
VSCº warning light

U.S.A.

Canada
This light warns that there is a problem somewhere in the
traction control system or the vehicle stability control system.
The light will come on when the ignition key is turned to ONº
and will go off after a few seconds.
If the light comes on while driving, the system does not work.
However, as conventional braking operates when applied,
there is no problem to continue your driving.
In the following cases, contact your Lexus dealer:
The warning light does not come on after the ignition key is
turned to ONº.
The warning light remains on after the ignition key is turned
to ONº.
The warning light comes on while driving.
The TRAC OFFº indicator light will come on when the VSCº
warning light comes on even if the TRAC OFFº switch is not
pushed.

STARTING AND DRIVING
286
VEHICLE STABILITY CONTROL
SYSTEM
The vehicle stability control system helps provide
integrated control of the systems such as anti-lock brake
system, traction control, engine control, etc. This system
automatically controls the brakes and engine to help
prevent the vehicle from skidding when cornering on a
slippery road surface or operating steering wheel
abruptly.
The system will activate when your vehicle speed reaches or
exceeds 15 km/h (9 mph), and will deactivate when the vehicle
speed reduced to below 15 km/h (9 mph).
You may hear a sound in the engine compartment for a few
seconds when the engine is started or just after the vehicle
begins to move. This means that the system is in the
self-check mode but does not indicate a malfunction.
CAUTION
Do not rely excessively on the vehicle stability
control system. Even if the vehicle skid control
system is operating, you must always drive carefully
and attentively to avoid serious injury. Reckless
driving will result in an unexpected accident. If the
slip indicator light blinks, sounding an alarm, special
care should be taken while driving.
Only use tires of specified size. The size,
manufacture, brand and tread pattern for all 4 tires
should be the same. If you use the tires other than
specified, or different type or size, the vehicle
stability control system may not function correctly.
When replacing the tires or wheels, contact your
Lexus dealer.
In situations where the road surface is covered with
ice or snow, your vehicle should be fitted with snow
tires or tire chains.

Slip indicator light
If the vehicle is going to skid during driving, the slip indicator
light blinks and an alarm sounds intermittently. Special care
should be taken while driving.
The slip indicator light comes on for a few seconds when the
ignition key is turned to ONº. If the indicator light does not
come on when the ignition is turned on, contact your Lexus
dealer.

STARTING AND DRIVING
287
VSCº warning light

U.S.A.

Canada
This light warns that there is a problem somewhere in the
vehicle stability control system or the traction control system.
The light will come on when the ignition key is turned to ONº
and will go off after a few seconds.
If the light comes on while driving, the system does not work.
However, as conventional braking operates when applied,
there is no problem to continue your driving.
In the following cases, contact your Lexus dealer:
The warning light does not come on after the ignition key is
turned to ONº.
The warning light remains on after the ignition key is turned
to ONº.
The warning light comes on while driving.
The TRAC OFFº indicator light will come on when the VSCº
warning light comes on even if the TRAC OFFº switch is not
pushed.

STARTING AND DRIVING
290ABSº warning light

1U.S.A.2Canada
Vehicles without vehicle stability control system Ð
The light comes on when the ignition key is turned to the ONº
position. If the anti-lock brake system works properly, the light
turns off after a few seconds. Thereafter, if either of the
systems malfunctions, the light comes on again.
When the ABSº warning light is on (and the brake system
warning light is off), the anti-lock brake system does not
operate, but the brake system still operates conventionally.
When the ABSº warning light is on (and the brake system
warning light is off), the anti-lock brake system does not
operate so that the wheels could lock up during a sudden
braking or braking on slippery road surfaces.If either of the following conditions occurs, this indicates
a malfunction somewhere in the parts monitored by the
warning light. Contact your Lexus dealer as soon as
possible to service the vehicle.
The light does not come on when the ignition key is turned
to the ONº position, or remains on.
The light comes on while you are driving.
A warning light turning on briefly during operation does not
indicate a problem.
CAUTION
If the ABSº warning light remains on together with the
brake system warning light, immediately stop your
vehicle at a safe place and contact your Lexus dealer.
In this case, not only the anti-lock brake system will fail
but also the vehicle will become extremely unstable
during braking.
Vehicles with vehicle stability control system Ð
The light comes on when the ignition key is turned to the ONº
position. If the anti-lock brake system and the brake assist
system work properly, the light turns off after a few seconds.
Thereafter, if either of the systems malfunctions, the light
comes on again.

STARTING AND DRIVING
291 When the ABSº warning light is on (and the brake system
warning light is off), the anti-lock brake system, the brake
assist system, the traction control system and the vehicle
stability control system do not operate, but the brake system
still operates conventionally.
When the ABSº warning light is on (and the brake system
warning light is off), the anti-lock brake system does not
operate so that the wheels could lock up during a sudden
braking or braking on slippery road surfaces.
If either of the following conditions occurs, this indicates
a malfunction somewhere in the components monitored
by the warning light. Contact your Lexus dealer as soon
as possible to service the vehicle.
The light does not come on when the ignition key is turned
to the ONº position, or remains on.
The light comes on while you are driving.
A warning light turning on briefly during operation does not
indicate a problem.
CAUTION
If the ABSº warning light remains on together with the
brake system warning light, immediately stop your
vehicle at a safe place and contact your Lexus dealer.
In this case, not only the anti-lock brake system will fail
but also the vehicle will become extremely unstable
during braking.
Drum-in-disc type parking brake system
Your vehicle has a drum-in-disc type parking brake system.
This type of brake system needs bedding-down of the brake
shoes periodically or whenever the parking brake shoes and/or
drums are replaced.
Have your Lexus dealer perform the bedding-down.
Brake assist system (vehicles with vehicle
stability control system)
When you slam the brakes on, the brake assist system
judges as an emergency stop and provides more powerful
braking for a driver who cannot hold down the brake pedal
firmly.
When you slam the brakes on, more powerful braking will be
applied. At this time, you may hear a sound in the engine
compartment and feel the vibrations of the brake pedal. This
does not indicate a malfunction.
The brake assist system becomes operative after the vehicle
has accelerated to a speed in excess of approximately 10 km/h
(6 mph). It stops operating when the vehicle decelerates to a
speed below approximately 5 km/h (3 mph).
For an explanation of this system's warning light, see ABS
warning lightº on page 62.

SECTION 4
314
IN CASE OF AN EMERGENCY
If your engine stalls while driving315 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
If your vehicle will not start315 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
If you cannot increase the engine speed320 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
If your vehicle overheats321 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
If you have a flat tire322 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
If your vehicle becomes stuck330 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
If your vehicle needs to be towed332 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
If you cannot shift automatic transmission selector lever341 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
If you lose your keys or lock yourself out342 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

IN CASE OF AN EMERGENCY
315
IF YOUR ENGINE STALLS WHILE
DRIVING
If your engine stalls while driving...
1. Reduce your speed gradually, keeping a straight line. Move
cautiously off the road to a safe place.
2. Turn on your emergency flashers.
3. Turn the ignition key to ACCº or LOCKº, and try starting the
engine again.
If the engine will not start, see If your vehicle will not startº.
CAUTION
If the engine is not running, the power assist for the
brakes and steering will not work, so steering and
braking will be much harder than usual.
IF YOUR VEHICLE WILL NOT
START
(a) Simple checks
Before making these checks, make sure you have followed the
correct starting procedure instructions in How to start the
engineº on page 270 and that you have sufficient fuel. Since
your vehicle is equipped with the engine immobilizer system,
also check whether the other keys will start the engine. If they
work, your key may be broken. Have the key checked at your
Lexus dealer. If none of your keys work, there may be a
malfunction in the immobilizer system. Call your Lexus dealer.
See Keysº on page 10.
If the engine is not turning over or is turning over too
slowly Ð
1. Check that the battery terminals are tight and clean.
2. If the battery terminals are O.K., switch on the interior light.
3. If the light is out, dim or goes out when the starter is cranked,
the battery is discharged. You may try jump starting. See (c)
Jump startingº for further instruction.
If the light is O.K., but the engine still will not start, it needs
adjustment or repair. Call a Lexus dealer, Roadside
Assistance or Customer Service Assistance. (See
Forewordº.)

IN CASE OF AN EMERGENCY
316
NOTICE
Do not pull- or push-start the vehicle. It may damage
the vehicle or cause a collision when the engine starts.
Also the three-way catalytic converter may overheat
and become a fire hazard.
If the engine turns over at its normal speed but will not
start Ð
1. Turn the ignition key to ACCº or LOCKº and try starting the
engine again.
2. If the engine will not start, the engine may be flooded
because of repeated cranking. See (b) Starting a flooded
engineº for further instructions.
3. If the engine still will not start, it needs adjustment or repair.
Call a Lexus dealer, Roadside Assistance or Customer Service
Assistance. (See Forewordº.)(b) Starting a flooded engine
If the engine will not start, your engine may be flooded
because of repeated cranking.
If this happens, turn the key to STARTº with the accelerator
pedal fully depressed. Continue this operation for 30 seconds
and then stop cranking. Then try starting the engine with your
foot off the accelerator pedal.
If the engine does not start after 30 seconds of cranking,
release the key, wait a few minutes and try again.
If the engine still will not start, it needs adjustment or repair.
Call a Lexus dealer, Roadside Assistance or Customer Service
Assistance. (See Forewordº.)
NOTICE
Do not crank for more than 30 seconds at a time. This
may overheat the starter and wiring systems.
