For detailed information, refer to the description given in each Section.
PICTORIAL INDEX
xi
Page
1Tachometer 53. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2Traction control system off indicator light 284. . . .
3Vehicle stability control system/traction control
system warning light 64. . . . . . . . . . . . . . . . . . . . . . . . . .
4Engine oil replacement reminder light 61. . . . . . . . . .
5Headlight indicator light 34. . . . . . . . . . . . . . . . . . . . . . .
6Headlight high beam indicator light 40. . . . . . . . . . . .
7Turn signal indicator light 40. . . . . . . . . . . . . . . . . . . . .
8Fog light indicator light 41. . . . . . . . . . . . . . . . . . . . . . . .
9Cruise control indicator light 279. . . . . . . . . . . . . . . .
10Slip indicator light 283, 286. . . . . . . . . . . . . . . . . . . . . .
11Automatic headlight leveling system
warning light 64. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
12Low fuel level warning light 64. . . . . . . . . . . . . . . . . . . .
13Automatic transmission indicator lights 272. . . . . .
14Engine coolant temperature gauge 51. . . . . . . . . . . . . Page
15Odometer and trip meter 54. . . . . . . . . . . . . . . . . . . . . .
16Trip meter reset knob 54. . . . . . . . . . . . . . . . . . . . . . . . .
17Fuel gauge 50. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
18Low washer fluid warning light 64. . . . . . . . . . . . . . . . .
19Low engine oil level warning light 60. . . . . . . . . . . . . .
20Multi-information display 66. . . . . . . . . . . . . . . . . . . . . .
21Rear light failure warning light 64. . . . . . . . . . . . . . . . .
22Low engine oil pressure warning light 59. . . . . . . . . .
23Brake system warning light 56. . . . . . . . . . . . . . . . . . . .
24Anti-lock brake system warning light 62. . . . . . . . . . .
25Driver's seat belt reminder light 57. . . . . . . . . . . . . . . .
26Discharge warning light 58. . . . . . . . . . . . . . . . . . . . . . .
27SRS warning light 57. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
28Open door warning light 63. . . . . . . . . . . . . . . . . . . . . . .
29Malfunction indicator lamp 61. . . . . . . . . . . . . . . . . . . .

For detailed information, refer to the description given in each Section.
PICTORIAL INDEX
xiii
Page
1Tachometer 53. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2Traction control system off indicator light 284. . . .
3Vehicle stability control system/traction control
system warning light 64. . . . . . . . . . . . . . . . . . . . . . . . . .
4Tail light indicator light 37. . . . . . . . . . . . . . . . . . . . . . . .
5Headlight high beam indicator light 40. . . . . . . . . . . .
6Turn signal indicator light 40. . . . . . . . . . . . . . . . . . . . .
7Fog light indicator light 41. . . . . . . . . . . . . . . . . . . . . . . .
8Cruise control indicator light 279. . . . . . . . . . . . . . . .
9Slip indicator light 283, 286. . . . . . . . . . . . . . . . . . . . . .
10Automatic headlight leveling system
warning light 64. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
11Low fuel level warning light 64. . . . . . . . . . . . . . . . . . . .
12Automatic transmission indicator lights 272. . . . . .
13Engine coolant temperature gauge 51. . . . . . . . . . . . . Page
14Odometer and trip meter 54. . . . . . . . . . . . . . . . . . . . . .
15Trip meter reset knob 54. . . . . . . . . . . . . . . . . . . . . . . . .
16Fuel gauge 50. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
17Low washer fluid warning light 64. . . . . . . . . . . . . . . . .
18Low engine oil level warning light 60. . . . . . . . . . . . . .
19Multi-information display 66. . . . . . . . . . . . . . . . . . . . . .
20Rear light failure warning light 64. . . . . . . . . . . . . . . . .
21Low engine oil pressure warning light 59. . . . . . . . . .
22Brake system warning light 56. . . . . . . . . . . . . . . . . . . .
23Anti-lock brake system warning light 62. . . . . . . . . . .
24Driver's seat belt reminder light 57. . . . . . . . . . . . . . . .
25Discharge warning light 58. . . . . . . . . . . . . . . . . . . . . . .
26SRS warning light 57. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
27Open door warning light 63. . . . . . . . . . . . . . . . . . . . . . .
28Malfunction indicator lamp 61. . . . . . . . . . . . . . . . . . . .

MAINTENANCE
347 Accelerator pedal
Check the pedal for smooth operation and uneven pedal effort
or catching.
Brake pedal
Check the pedal for smooth operation and the proper
clearance and freeplay. Check the brake booster function.
Brakes
At a safe place, check that the brakes do not pull to one side
when applied.
Parking brake
Check that the pedal has the proper travel and that, on a safe
incline, your vehicle is held securely with only the parking brake
applied.
Automatic transmission Parkº mechanism
On a safe incline, check that your vehicle is held securely with
the selector lever in Pº position and all brakes released.
Vehicle exterior
Items listed below should be performed from time to time,
unless otherwise specified.
Wheel nuts
When checking the tires, make sure to check the nuts for
looseness. Tighten them if necessary.Fluid leaks
Check underneath for leaking fuel, oil, water or other fluid after
the vehicle has been parked for a while. If you smell fuel fumes
or notice any leak, have the cause found and corrected
immediately.
Doors and engine hood
Check that all doors, including trunk lid, operate smoothly and
all latches lock securely. Make sure the engine hood
secondary latch secures the hood when the primary latch is
released.
Tire inflation pressure
Check the tire inflation pressure with a gauge every
two weeks, or at least once a month and adjust as
shown on the tire and loading information label. See
page 389 for additional information.
Tire surface
Check the tires carefully for cuts, damage or
excessive wear. See page 402 for additional
information.
Tire rotation
Rotate the tires according to the maintenance
schedule. (For scheduled maintenance information,
please refer to the Owner's Manual
Supplement/Scheduled Maintenanceº.) See page 401
for additional information.

INTRODUCTION
357
NOTICE
Remember that battery and ignition cables carry high
currents or voltages. Be careful of accidentally
causing a short circuit.
Before closing the engine hood, check to see that you
have not forgotten any tools, rags, etc.
Do not drive with the air cleaner removed, or
excessive engine wear could result. Also backfiring
could cause a fire in the engine compartment.
Do not overfill automatic transmission fluid, or the
transmission could be damaged.
Be careful not to scratch the glass surface with the
wiper frame.

INTRODUCTION
358
PARTS AND TOOLS
Here is a list of parts and tools you will need to perform
do-it-yourself maintenance. Remember all Lexus parts are
designed in metric sizes, so your tools must be metric.
Checking the engine oil level
Parts (if level is low):
Toyota Genuine Motor Oilº or equivalent
See page 374 for details about engine oil selection.
Tools:
Rag or paper towel
Funnel (only for adding oil)
Checking the engine coolant level
Parts (if level is low):
Toyota Super Long Life Coolantº or similar high quality
ethylene glycol based non-silicate, non-amine, non-nitrite,
and non-borate coolant with long-life hybrid organic acid
technology
Toyota Super Long Life Coolantº is pre-mixed with 50%
coolant and 50% deionized water. This coolant provides
protection down to about -35C (-31F).
Tools:
Funnel (only for adding coolant)
Checking brake fluid
Parts (if level is low):
FMVSS No. 116 DOT 3 or SAE J1703 brake fluid
Tools:
Funnel (only for adding fluid)
Checking power steering fluid
Parts (if level is low):
Automatic transmission fluid DEXRON
II or III
Tools:
Rag or paper towel
Funnel (only for adding fluid)
Checking battery condition
Tools:
Warm water
Baking soda
Grease
Conventional wrench (for terminal clamp bolts)
Checking and replacing the blade type fuses
Parts (if replacement is necessary):
Fuse with same amperage rating as original

CHASSIS
381
SPECIFICATIONS
Ð AUTOMATIC TRANSAXLE
Fluid capacity
Drain and refill
3.5 L (3.7 qt., 3.1 lmp. qt.)
Fluid typeToyota Genuine ATF Type T-IV*
*: Change automatic transmission fluid only as necessary.
Generally, it is necessary to change automatic transmission
fluid only if your vehicle is driven under one of the Special
Operating Conditions listed in your Owner's Manual
Supplement/Scheduled Maintenanceº. When changing the
automatic transmission fluid, use only Toyota Genuine ATF
Type T-IVº (ATF JWS3309 or NWS6500) to aid in assuring
optimum transaxle performance.

CHASSIS
382
NOTICE
Using automatic transmission fluid other than Toyota
Genuine ATF Type T-IVº may cause deterioration in
shift quality, locking up of your transmission
accompanied by vibration, and ultimately damage the
automatic transmission of your vehicle.
Please contact your Lexus dealer for further details.

CHASSIS
383 Ð BRAKES
Pedal clearance
Fixed type
Adjustable type (in frontmost position)
70 mm (2.8 in.) Min. *1
59 mm (2.3 in.) Min. *1
Pedal free play
Fixed type
Adjustable type (in frontmost position)1 Ð 6 mm (0.04 Ð 0.24 in.)
1 Ð 8 mm (0.04 Ð 0.31 in.)
Brake pad wear limit1.0 mm (0.04 in.)
Parking brake lining wear limit1.0 mm (0.04 in.)
Parking brake adjustment3 Ð 6 clicks *2
Fluid typeSAE J1703 or FMVSS No. 116 DOT 3
*1: Minimum pedal clearance when depressed with the force of 490 N (50 kgf, 110 lbf) with the engine running
*2: Parking brake adjustment when depressed with the force of 294 N (30 kgf, 66 lbf)
Ð STEERING
Wheel free play
Less than 30 mm (1.2 in.)
Power steering fluid typeAutomatic transmission fluid DEXRONII or III

CHASSIS
387
CHECKING POWER STEERING
FLUID
Check the fluid level through the reservoir. If necessary,
add automatic transmission fluid DEXRONII or III.
If the vehicle has been driven around 80 km/h (50 mph) for 20
minutes (a little more in frigid temperatures), the fluid is hot
(60C Ð 80C or 140F Ð 175F). You may also check the
level when the fluid is cold (about room temperature, 10C Ð
30C or 50F Ð 85F) if the engine has not been run for about
five hours.

1If cold O.K.2If cold add3If hot O.K.
4If hot add
Clean all dirt off the reservoir and look at the fluid level. If the
fluid is cold, the level should be in the COLDº range. Similarly,
if it is hot, the fluid level should be in the HOTº range. If the
level is at the low side of the appropriate range, add automatic
transmission fluid DEXRON
II or III to bring the level within
the range.
To remove the reservoir cap, turn it counterclockwise and lift
up. To reinstall it, turn it clockwise. After replacing the reservoir
cap, visually check the steering box case, vane pump and hose
connections for leaks or damage.
CAUTION
The reservoir may be hot so be careful not to burn
yourself.
