PICTORIAL INDEX
ix
Page
1Door lock switch and power window
switches 28, 51. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2Driving position memory switches 178. . . . . . . . . . .
3Power rear view mirror control switches 183. . . . . .
4Side vents 205. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5Instrument panel light control dial 68. . . . . . . . . . . . . .
6Headlight, turn signal and
fog light switches 34, 37, 40, 41. . . . . . . . . . . . . . . . . . .
7Multi-information display control switches 66. . . . .
8Ignition switch 268. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
9Wiper and washer switches 41. . . . . . . . . . . . . . . . . . . .
10Seat heater switches 56. . . . . . . . . . . . . . . . . . . . . . . . . .
11Emergency flasher switch 54. . . . . . . . . . . . . . . . . . . . .
12Clock 74. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
13Car audio 211, 235. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
14Front passenger's seat belt reminder light 57. . . . . .
15AIRBAG OFFº indicator light 152. . . . . . . . . . . . . . . .
16AIRBAG ONº indicator light 152. . . . . . . . . . . . . . . . . Page
17Security indicator light 16, 30. . . . . . . . . . . . . . . . . . . .
18Glove box 77. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
19Automatic air conditioning controls 192. . . . . . . . . .
20Rear window and outside rear view mirror
defogger switch 49. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
21Ashtray 75. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
22Automatic transmission selector lever 272. . . . . . . .
23Rear electric sunshade switch 88. . . . . . . . . . . . . . . . .
24Electronic modulated suspension
control switch 282. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
25Traction control system off switch 284. . . . . . . . . . .
26Cruise control switch 279. . . . . . . . . . . . . . . . . . . . . . .
27Power adjustable pedals switch 181. . . . . . . . . . . . . .
28Parking brake pedal 269. . . . . . . . . . . . . . . . . . . . . . . . .
29Auxiliary box 85. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
30Hood lock release lever 92. . . . . . . . . . . . . . . . . . . . . . .
31Trunk lid opener 93. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
32Fuel filler door opener 96. . . . . . . . . . . . . . . . . . . . . . . . .

KEYS AND DOORS
20When you push the UNLOCKº button, the driver's door
is unlocked. Pushing that button once again within 3
seconds from the first push, all other doors are also
unlocked.*
NOTE:
* The 2-step unlocking function can be changed.
Ask your Lexus dealer for details.
At this time, two beeps sound and the turn signal lights flash
twice.* Together with the activation of unlocking, the interior
light comes on for 15 seconds if the interior light switch is in
DOORº position.** However, this function does not work
when the ignition key is in the ACCº or ONº position. For
further information, see Illuminated entry systemº on page 73.
You have 30 seconds to open a door after using the wireless
remote unlock feature.*** If a door is not opened by then, all
the doors will be automatically locked again.
Even if the LOCKº or UNLOCKº button is kept pressed in, the
locking or unlocking operation is not repeated. Release the
button and then push again.
NOTE:
* The turn signal lights can be set not to flash and the beep
volume can be changed.
** The duration of lighting can be changed.
*** The time before automatic re-locking can be changed.
Ask your Lexus dealer for details.

1Off2Louder
When you push any button on the key, the vehicle sounds one
beep when the doors are locked by remote control, and sounds
two beeps when the doors are unlocked.
You can adjust the beep loudness with the knob under the
instrument panel. Turning the knob clockwise increases the
volume and turning it counterclockwise until it stops turns the
buzzer off.

Finish
SECTION 1 ± 4
70
INSTRUMENTS AND CONTROLS
Interior equipment
Vanity mirrors71 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Interior light72 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Personal lights73 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Illuminated entry system73 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Clock74 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cigarette lighter and ashtray75 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Power outlet76 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Glove box77 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear console box77 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Garage door opener78 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cup holders82 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Overhead console box83 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Auxiliary boxes85 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Trunk storage extension86 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Floor mat86 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Grocery bag hook87 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Coat hooks88 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear electric sunshade88 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tie-down hooks89 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Finish
INTERIOR EQUIPMENT
74All of the lights will come on when any of the doors are
opened.* After all the doors are closed, the lights remain
on for about 15 seconds before fading out.**
NOTE:
* The operating condition can be changed.
** The duration of lighting can be changed and only the foot
lights can be set not to come on.
Ask your Lexus dealer for details.
However, in the following cases, the lights go out immediately:
All the doors are closed and the ignition key is in the ACCº
or ONº position. (The foot lights come on when the ignition
switch is in the ONº position. See the following Foot
lightsº.)
All the doors are locked.
When any of the door is unlocked, all of the lights will come on
and remain on for about 15 seconds before fading out.
Foot lights
The foot lights also come on when the ignition switch is in the
ONº position with the selector lever in the Pº position. When
the selector lever is moved out of the Pº position, the foot lights
will be dimmed.*
NOTE:
* The foot lights can be set to turn off when the selector lever
is moved out of the Pº position.
Ask your Lexus dealer for details.
When the instrument panel light control dial is turned fully
down, the foot lights will turn off.
CLOCK
The digital clock indicates the time with the ignition key at
the ACCº or ONº position. To reset the hour, press the
Hº button. To reset the minutes, press the Mº button.
To adjust the time to the nearest hour, press the :00º
button.
For example, if the :00º button is pressed when the time is
between 9:30 Ð 9:59 or between 10:01 Ð 10:29, the time will
change to 10:00.
With the tail lights on, the brightness of the time indication will
be reduced.
If the electrical power source has been disconnected from the
clock, the time display will automatically be set to 1:00 (one
o'clock).

Finish
INTERIOR EQUIPMENT
77
GLOVE BOX
1Unlock2Open3Lock
To open the glove box door, pull the lever. To lock the
glove box door, insert the master key and turn it
clockwise.
With the tail lights on, the glove box light will come on when the
glove box door is open.
The trunk lid opener main switch is installed inside the glove
box. See page 89 for further information.
CAUTION
To reduce the chance of injury in case of an accident or
a sudden stop, always keep the glove box door closed
while driving.
REAR CONSOLE BOX
Upper tray
Console box

EXTERIOR EQUIPMENT
97
2. To remove the fuel tank cap, turn the cap
counterclockwise by 90 degrees (to the pressure point
1), and then turn it an additional 30 degrees (to point2). Pause slightly before removing it.
It is not unusual to hear a slight swoosh when the cap is
opened.
3. The removed cap can be stored on the back side of the
fuel filler door.
Position the cap so that the hooks point to the left and right, and
set it in the receptacle on the back side of the door.

EXTERIOR EQUIPMENT
98When installing the cap, turn the cap clockwise until you
hear a click. When you hear the click, the cap is fully
closed.
If the cap is not tightened securely, the malfunction indicator
lamp comes on. Make sure the cap is tightened securely.
The indicator lamp goes off after driving several times. If the
indicator lamp does not go off, contact your Lexus dealer as
soon as possible.
CAUTION
Make sure the cap is installed securely to prevent fuel
spillage in the event of an accident.
Use only a genuine Lexus fuel tank cap for
replacement. It is designed to regulate fuel tank
pressure.
NOTICE
To prevent damage to the cap, apply force only in the
turning direction to the cap. Do not pull or pry it.

IN CASE OF AN EMERGENCY
325
3. Block the wheel diagonally opposite the flat tire
to keep the vehicle from rolling when it is jacked
up.
When blocking the wheel, place a wheel block in front
of one of the front wheels or behind one of the rear
wheels.4. Loosen all the wheel nuts.
Always loosen the wheel nuts before raising the
vehicle.
Turn the wheel nuts counterclockwise to loosen them.
To get maximum leverage, fit the wrench to the nut
so that the handle is on the right side, as shown
above. Grab the wrench near the end of the handle
and pull up on the handle. Be careful that the wrench
does not slip off the nut.
Do not remove the nuts yet Ð just unscrew them
about one-half turn.
CAUTION
Never use oil or grease on the bolts or nuts.
The nuts may loose and the wheels may fall off,
which could cause a serious accident.

IN CASE OF AN EMERGENCY
326
5. Position the jack at the jack points as shown.
Rotate the load rest 90 from storage position to
lifting position.
Make sure the jack is positioned on a level and solid
surface.6. After making sure no one is in the vehicle, raise
it high enough so that the spare tire can be
installed.
Allow for the fact that you need more ground
clearance when putting on the spare tire than when
removing the flat tire.
To raise the vehicle, insert the jack handle into the
jack (it is a loose fit) and turn it clockwise. As the
jack touches the vehicle and begins to lift,
double-check that it is properly positioned.
CAUTION
Never get under the vehicle when the vehicle
is supported by the jack alone.

IN CASE OF AN EMERGENCY
328
8. Reinstall all the wheel nuts finger tight.
Align the holes in the wheel with the bolts. Then lift
up the wheel and get at least the top bolt started
through its hole. Wiggle the tire and press it back
over the other bolts.
Reinstall the wheel nuts and tighten them as much
as you can by hand. Press the tire back and see
if you can tighten them more.
CAUTION
Never use oil or grease on the bolts or nuts.
Doing so may lead to overtightening the nuts
and damaging the bolts. The nuts may loose
and the wheels may fall off, which could cause
a serious accident. If there is oil or grease on
any bolt or nut, clean it.
9. Lower the vehicle completely and tighten the
wheel nuts.
Turn the jack handle counterclockwise to lower the
vehicle.
Use only the wheel nut wrench to tighten the nuts.
Do not use other tools or any additional leverage other
than your hands, such as a hammer, pipe or your foot.
Make sure the wrench is securely engaged over the
nut.
Tighten each nut a little at a time in the order shown.
Repeat the process until all the nuts are tight.
