fuse box Lexus ES330 2004 Pictorial Index / LEXUS 2004 ES330 OWNER'S MANUAL (OM33633U)

61E080
INTRODUCTION
355
ENGINE COMPARTMENT OVERVIEW
1Power steering fluid
reservoir
2Engine oil filler cap
3Brake fluid reservoir
4Fuse box
5Battery
6Radiator
7Condenser
8Electric cooling fans
9Engine oil level
dipstick
10Washer fluid tank
11Engine coolant
reservoir

ELECTRICAL COMPONENTS
419
No.FUSEAMPERECIRCUIT
44AM15Starting system
45FOG15Front fog lights
46SUN-
SHADE15Rear sunshade
47GAUGE210
Auto anti- glare inside rear
view mirror, compass, back- up
lights, automatic light control
system, automatic headlight
leveling system, cruise control
system, seat belt reminder
lights
48PANEL10
Glove box light, console box
light, clock, outside
temperature gauge,
multi- information display,
instrument cluster lights,
instrument panel lights
49TAIL10Tail lights, parking lights,
license plate lights
50PWR NO.420Rear passenger's power
window (left side)
No.FUSEAMPERECIRCUIT
51PWR NO.220Front passenger's door lock
system, front passenger's
power window
52OBD7.5On- board diagnosis system
53SEAT
HTR20Seat heaters

ELECTRICAL COMPONENTS
427
CHECKING AND REPLACING THE
BLADE TYPE FUSES

Engine compartment 1 Pull-out tool 2 Spare fuses

Driver's side instrument panel
1. Turn the ignition switch off and remove the auxiliary
box.
Determine which fuse may be causing the problem. The
auxiliary box shows the name of the circuit for each fuse.

ELECTRICAL COMPONENTS
428
2. Make sure the inoperative component is turned off. Pull
the suspected fuse straight out with the pull-out tool and
check it. If it has blown, push a new fuse into the clips.
Good
Blown
a. Look carefully at the fuse. If the thin wire is broken, the fuse
has blown. If you are not sure or if it is too dark to see, try
replacing the suspected fuse with one of the same value that
you know is good.
b. Only install a fuse with the amperage rating designated on
the fuse box lid.
If you do not have a spare fuse, in an emergency you can pull
out the RAD NO.1º, RAD NO.2º or POWER POINTº fuse,
which may be dispensable for normal driving, and use it if its
amperage rating is the same.
If you cannot use one of the same amperage, use one lower
than, but as close as possible to, the amperage. If the
amperage is lower than that specified, the fuse might blow out
again but this does not indicate anything wrong. Be sure to get
the correct fuse as soon as possible and return the substitute
to its original clips.
