ELECTRICAL COMPONENTS
391
— FUSES
1Engine compartment
64E165
2Driver’s side instrument panel

ELECTRICAL COMPONENTS
398
NOTICE
Make sure the engine and all accessories are turned
off before performing maintenance.
 When checking the battery, remove the ground cable
first and reinstall it last.
 Be careful not to cause a short circuit with tools.
 Take care no solution gets into the battery when
washing it.
If the battery is disconnected or run down
The moonroof may not operate automatically and the jam
protection function will not function correctly after you
reconnect, replace or recharge the battery. In any of these
cases, you should normalize the moonroof. To normalize the
moonroof, see page 98.
Checking battery condition
Checking by indicator
Check the battery condition by the indicator color.
1BLUE — Good condition
2WHITE — Charging necessary. Have the battery
checked by your Lexus dealer.
3RED — Have the battery checked by your Lexus dealer.
NOTICE
Do not refill the battery with water.

ELECTRICAL COMPONENTS
399
BATTERY RECHARGINGPRECAUTIONS
During recharging, the battery is producing hydrogen
gas.
Therefore, before recharging:
1. If recharging with the battery installed on the vehicle, be
sure to disconnect the ground cable.
2. Make sure the power switch on the recharger is off when
connecting the charger cables to the battery and when
disconnecting them.
CAUTION
Always charge the battery in an unconfined area. Do
not charge the battery in a garage or closed room
where there is not sufficient ventilation.
 Only do a slow charge (5 A or less). Charging at a
quicker rate is dangerous. The battery may explode
causing personal injuries.
NOTICE
Never recharge the battery while the engine is running.
Also, be sure all accessories are turned off.
CHECKING AND REPLACING THE BLADE TYPE FUSES
Engine compartment 1 Pullout tool 2 Spare fuses

ELECTRICAL COMPONENTS
402
CHECKING THE CARTRIDGE TYPEFUSES
Engine compartment
Driver’s side instrument panel
Good Blown
If the headlights or other electrical components do not
work and the blade type fuses are O.K., check the
cartridge type fuses. If any of the cartridge type fuses are
blown, they must be replaced.
If there is an overload in the circuits from the battery, the fuses
are designed to blow before the entire wiring harness is
damaged.
CAUTION
Always use a genuine Lexus fuse or equivalent for
replacement. Never install an ordinary wire — even for
a temporary fix. This may cause extensive damage and
possibly a fire.

ELECTRICAL COMPONENTS
403
NOTICE
Before replacing the fuses, have the cause of electrical
overload determined and repaired by your Lexus dealer.
ADDING WASHER FLUID
If the washer tank becomes nearly empty, add washer
fluid.
You may use plain water as washer fluid. However, in cold
areas where temperatures range below the freezing point, use
washer fluid containing antifreeze. This product is available at
your Lexus dealer and most auto parts stores. Follow the
manufacturer’s directions for how much to mix with water.
NOTICE
 Do not use engine antifreeze or any other substitute
because it may damage your vehicle’s paint.
 Do not fill washer fluid over the “NORMAL” level.

BODY
413
Fuel
filler door: Do not apply water (high −pressure car wash,
for example) at or near the fuel tank inlet with the fuel filler door
opened. If the water enters the air vent, you may experience
trouble with refueling or rough engine idling.
Plastic wheel ornaments: The plastic wheel ornaments are
damaged easily by organic substances. If any organic
substances splashes an ornament, be sure to wash it off with
water and check if the ornament is damaged.
CAUTION
Do not attach the heavily damaged plastic wheel
ornament. It may fly off the wheel and cause accidents
while the vehicle is moving.
Aluminum wheels: Use only a mild soap or neutral detergent.
Urethane bumpers and side moldings: Wash carefully. Do
not scrub with abrasive cleaners. The bumper and side
molding faces are soft.
Road tar: Remove with turpentine or cleaners that are marked
safe for painted surfaces.
NOTICE
Do not use organic substances (gasoline, kerosene,
benzine or strong solvents), which may be toxic or
cause damage.
3. Rinse thoroughly — dried soap can cause streaking. In hot
weather you may need to rinse each section right after you
wash it.
4. To prevent water spots, dry the vehicle using a clean soft
cotton towel. Do not rub or press hard — you might scratch the
paint.
Automatic car wash
Your vehicle may be washed in an automatic car wash, but
remember that the paint can be scratched by some types of
brushes, unfiltered washing water, or the washing process
itself. Scratching reduces paint durability and gloss, especially
on darker colors. The manager of the car wash should be able
to advise you whether the process is safe for the paint on your
vehicle.
Waxing your Lexus
Polishing and waxing is recommended to maintain the
original beauty of your Lexus’ finish.
Apply wax once a month or if the vehicle surface does not repel
water well.
1. Always wash and dry the vehicle before you begin waxing,
even if you are using a combined cleaner and wax.
2. Use a good quality polish and wax. If the finish has become
extremely weathered, use a car −cleaning polish, followed by
a separate wax. Carefully follow the manufacturer’s
instructions and precautions. Be sure to polish and wax the
chrome trim as well as the paint.

GAS STATION INFORMATION
Fuel selection:
Select unleaded gasoline with an Octane Rating of 87
(Research Octane Number 91) or higher. For improved
vehicle performance, the use of premium unleaded
gasoline with an Octane Rating of 91 (Research Octane
Number 96) or higher is recommended.
 Fuel tank capacity:
70 L (18.5 gal., 15.4 Imp. gal.)
 Engine oil:
“Toyota Genuine Motor Oil” or equivalent
Oil grade: API grade SL “Energy −Conserving” or ILSAC
multigrade engine oil
Recommended oil viscosity: SAE 5W −30
Oil capacity: L (qt., Imp. qt.)
Drain and refill With filter 4.7 (5.0, 4.1)
Without filter 4.5 (4.8, 4.0)
See page 351 for detailed information.
 Engine coolant:
Capacity: 9.2 L (9.7 qt., 8.2 Imp. qt.)
Coolant type — “T oyota Super Long Life Coolant” or similar
high quality ethylene glycol based non −silicate, non −amine,
non−nitrite, and non −borate coolant with long −life hybrid
organic acid technology (Coolant with long −life hybrid
organic acid technology is a combination of low phosphates
and organic acids.)
Do not use plain water alone.
For checking the engine coolant, see page 355 .
Automatic transaxle:
Fluid type — Toyota Genuine ATF Type T −IV
See page 360 for detailed information.
 Tire information:
See pages 366 through 386 for detailed information.
 Tire inflation pressure:
cold tires
kPa (kgf/cm
2 or bar, psi)
Tire size: P215/60R16 94V
Front tires 200 (2.0, 29) . . . . . . . . .
Rear tires 200 (2.0, 29) . . . . . . . . .
For sustained high speeds above 160 km/h (99 mph), in
countries where such speeds are permitted by law, add 40
kPa (0.4 kgf/cm
2 or bar, 6 psi) to the front tires and rear tires,
but never exceed the maximum cold tire inflation pressure
molded on the tire sidewall.
Tire size: P215/55R17 93V
Front tires 210 (2.1, 30)
. . . . . . . . .
Rear tires 210 (2.1, 30)
. . . . . . . . .
For sustained high speeds above 160 km/h (99 mph), in
countries where such speeds are permitted by law, add 30
kPa (0.3 kgf/cm
2 or bar, 4 psi) to the front tires and rear tires,
but never exceed the maximum cold tire inflation pressure
molded on the tire sidewall.
See page 362 or 363 for detailed information.
