AIR CONDITIONING
194
1. Open the glove box. Remove the screw with a
Phillipshead screwdriver.
2. Remove the 2 pins installed on the upper part of the
glove box and lower the glove box.
3. Take out the filter case.
4. Remove the filter from the filter case.
5. Inspect the filter on the surface.
If it is dirty, it should be replaced.

AIR CONDITIONING
195
INFORMATION
The air conditioning filter should be installed properly
in position. The use of air conditioning with the filter
removed may cause deteriorated dustproof
performance and then affect air conditioning
performance.

AIR CONDITIONING
196

SECTION 2 – 2
197
AIR CONDITIONING AND AUDIO
Audio
Audio system (with single−CD player) 198
. . . . . . . . . . . . . . . . . . . . . .
Audio system (with six −CD changer) 222
. . . . . . . . . . . . . . . . . . . . . . .
For vehicles equipped with Navigation System,
please refer to the separate “Navigation System
Owner’s Manual”.

AUDIO
198
AUDIO SYSTEM (with singleCD player)
Quick reference for your audio system
You can adjust the brightness of the display. See “Instrument panel light control” on page 70 for details.

AUDIO
199
1Ejecting a CD
(See page 209 for details.)
2Function buttons
1 — 6: Station selector buttons
(See page 205 for details.)
SCAN: Scan tuning
(See page 206 for details.)
P.SCAN: Preset scan tuning
(See page 206 for details.)
3Display of functions in TAPE or CD mode
:DOLBY NR
(See page 207 for details.)
 : Rewinding or reversing
(See page 207 or 213 for details.)
 : Fast forwarding
(See page 207 or 213 for details.)
RPT: Automatic repeat
(See page 208 or 213 for details.)
:CD selection
(See page 211 for details.)
RAND: Random access
(See page 214 for details.)
SCAN: Scan selection
(See page 212 for details.)
4CD slot
(See page 209 for details.)
5Automatic Sound Levelizer (ASL)/Mute
(See page 201 or 203 for details.)
6TUNE/AUDIO CONTROL knob
(See page 202 for details.)
7 :Side change
(See page 207 for details.)
8Mode selectors
(See page 201 for details.)
9Stopping and ejecting a cassette tape
(See page 206 for details.)
10Turning the system on and adjusting the volume
(See page 200 for details.)
11Cassette tape slot
(See page 206 for details.)
12Radio mode: Seek tuning
(See page 205 for details.)
TAPE mode: Direct access to a desired program
(See page 208 for details.)
CD mode: Direct access to a desired program
(See page 213 for details.)

AUDIO
200
Using your audio system: some basics
This section describes some of the basic features of the Lexus
audio system. Some information may not pertain to your
system.
Your audio system works when the ignition switch is in the
“ACC” or “ON” position.
NOTICE
To prevent the battery from being discharged, do not
leave the audio system on longer than necessary when
the engine is not running.
(a) Turning the system on and off
Push this knob to turn the audio system on and off. Turn
this knob to adjust the volume.
The system turns on in the last mode used.

AUDIO
201
Push the “MUTE” button to decrease the volume
momentarily.
To return to its original volume, push the same button again.
When the audio system is turned on, the mute is always off
regardless of the previous mode.Push the “AM”, “FM”, “TAPE” or “DISC” button to turn on
that mode. The selected mode turns on directly.
Push these buttons if you want to switch from one mode to
another.
If the tape or CD is not set, the cassette player or CD player
does not turn on.
You can turn off each player by ejecting the cassette tape or
CD. If the audio system was previously off, then the entire
audio system will be turned off when you eject the cassette
tape or CD. If the another function was previously playing, it
will come on again.

AUDIO
202
In the “TAPE” or “CD” mode, the applicable functions are
shown in the lowest part of the display. Push the switch
just below to turn on each function.
(b) Tone and balance
How good an audio program sounds to you is largely
determined by the mix of the treble, mid −range, and bass
levels. In fact, different kinds of music and vocal programs
usually sound better with different mixes of treble, mid −range
and bass.
A good balance of the left and right stereo channels and of the
front and rear sound levels is also important.
Keep in mind that if you are listening to a stereo recording or
broadcast, changing the right/left balance will increase the
volume of one group of sounds while decreasing the volume
of another.Each time you push the “AUDIO CONTROL” knob, the
display changes as in the following. To adjust the tone and
balance, turn the knob.
BAS: Adjusts low −pitched tones.
MID: Adjusts mid− pitched tones.
TRE: Adjusts high− pitched tones.
FAD: Adjusts the sound balance between the front and rear
speakers.
BAL: Adjusts the sound balance between the right and left
speakers.

AUDIO
203
(c) Automatic Sound Levelizer (ASL)
When the audio sound becomes difficult to be heard due to
road noise,
wind noise, etc. during driving, the system adjusts
to the optimum volume and tone quality according to the noise
level. While the Automatic Sound Levelizer is on, “ASL”
appears on the display.
(d) Your radio antennas
The wire antenna is mounted inside the rear window.
NOTICE
 When cleaning the inside of the rear window, be
careful not to scratch or damage the wire antenna.
 Putting a window tint (especially, conductive or
metallic type) on the rear window may affect the
reception of radio or mobile telephone. For the
installation of the window tint, consult with your
Lexus dealer.
(e) Your cassette player
When you insert a cassette, the exposed tape should face to
the right.
NOTICE
Do not oil any part of the cassette player, and do not
insert anything except a cassette tape into the slot.
(f) Your CD player
When you insert a CD, gently push it in with the label face up.
(The player will automatically eject a CD if the label face is
down.) The CD player will play from track 1 through the end
of the CD. Then it will play from track 1 again. On models with
the CD changer, next CD will be played from track 1.
NOTICE
 Never try to disassemble or oil any part of the CD
player. Do not insert anything other than CD’s into
the slot.
 Do not insert a CD upon another one.
The player is intended for use with 12 cm (4.7 in.) CD’s only.
