CHASSIS
cccxc
SUSPENSION AND CHASSIS
CAUTION
Do not modify the suspension/chassis with lift kits,
spacers, springs, etc. It can cause dangerous handling
characteristics, resulting in loss of control.

ELECTRICAL COMPONENTS
cccxcv
No.FUSEAMPERECIRCUIT
1A/F25Multiport fuel injection
system/sequential multiport
fuel injection system
2DOOR125
Multiplex communication
system (power door lock
system, auto−door locking
system, wireless remote
control system)
3TEL5No circuit
4AM230All components in “IGN” and
“IG2” fuses and starting system
5EFI20Multiport fuel injection
system/sequential multiport
fuel injection system
6ALTS5Charging system
7HEAD LH
UPR10Left −hand headlight (high
beam)
No.FUSEAMPERECIRCUIT
8ETCS10Multiport fuel injection
system/sequential multiport
fuel injection system
9HORN10Horns
10IGN15Starting system
11HEAD RH
UPR10Right −hand headlight (high
beam)
12HAZ15Emergency flashers
13D.C.C30All components in “ECU− B”,
“RAD NO.1” and “DOME” fuses
14IG210
Multiport fuel injection
system/sequential multiport
fuel injection system, SRS
airbag system, seat belt
pretensioners, cruise control
system
15ST5Starting system
16ADJ PDL30Power adjustable pedals
17CDS30Electric cooling fan

ELECTRICAL COMPONENTS
cccxcvi
No.FUSEAMPERECIRCUIT
18ABS No.240
Anti−lock brake system,
vehicle stability control system,
traction control system, brake
assist system
19MAIN40
All components in “HEAD LH
LWR”, “HEAD RH LWR”, “HEAD
LH UPR”, “HEAD RH UPR” and
“DRL” fuses
20ABS No.330
Anti −lock brake system,
vehicle stability control system,
traction control system, brake
assist system
21HTR50Air conditioning system
22RDI30Electric cooling fan
23SPARE5Spare fuse
24SPARE10Spare fuse
No.FUSEAMPERECIRCUIT
25ABS NO.150
All components in “RDI FAN”,
“ABS No.2”, “ABS No.3”, “CDS”,
“HTR (50 A)” and “ADJ PDL”
fuses and anti −lock brake
system, vehicle stability control
system, traction control
system, brake assist system
26ALT120
All components in “DEF”, “PWR
NO.1”, “PWR NO.2”, “PWR
NO.3”, “PWR NO.4”, “STOP”,
“DOOR NO.2”, “OBD”, “PWR
SEAT”, “FUEL OPEN”, “FOG”,
“AMP”, “PANEL”, “TAIL”,
“AM1”, “CIG”, “POWER
POINT”, “RAD NO.2”,
“ECU− ACC”, “GAUGE1”,
“GAUGE2”, “ECU− IG”,
“WIPER”, “WASHER”, “HTR
(10 A)”, “SEAT HTR” and
“SUN− SHADE” fuses
27SPARE15Spare fuse
28A/C10No circuit
29DRL5Daytime running light system
30HEAD RH
LW R15Right −hand headlight (low
beam)
31HEAD LH
LW R15Left −hand headlight (low
beam) and front fog lights

ELECTRICAL COMPONENTS
cccxcvii
No.FUSEAMPERECIRCUIT
32ECUB10
Multiplex communication
system (power door lock
system, security system,
auto−door locking system,
automatic light control system,
headlight delay off system, tail
light auto cut system,
illuminated entry system,
daytime running light system,
wireless remote control
system) air conditioning
system, electronic modulated
suspension, driving position
memory system, front
passenger seat position
memory system
33DOME7.5
Ignition switch light, interior
light, personal lights, foot
lights, door courtesy lights,
trunk light, vanity lights, garage
door opener, clock, outside
temperature gauge,
multi− information display
No.FUSEAMPERECIRCUIT
34CIG15Cigarette lighter
35ECU
ACC5
Power rear view mirrors, clock,
multi− information display,
driving position memory
system, front passenger seat
position memory system
36RAD NO.210Audio system, navigation
system
37POWER
POINT15Power outlet
38RAD NO.120Audio system, navigation
system
39GAUGE110
Gauges and meters, clock,
outside temperature gauge,
multi −information display, shift
lock system
40ECUIG10
SRS airbag system, power
windows, anti− lock brake
system, electronic modulated
suspension, driving position
memory system, front
passenger seat position
memory system
41WIPER25Windshield wipers
42HTR10Air conditioning system

ELECTRICAL COMPONENTS
cccxcviii
No.FUSEAMPERECIRCUIT
43MIR
HTR10Outside rear view mirror
defogger
44AM15Starting system
45FOG15Front fog lights
46SUN
SHADE15Rear sunshade
47GAUGE210
Auto anti −glare inside rear
view mirror, compass, back −up
lights, automatic light control
system, automatic headlight
leveling system, cruise control
system, seat belt reminder
lights
48PANEL10
Glove box light, console box
light, clock, outside
temperature gauge,
multi− information display,
instrument cluster lights,
instrument panel lights
49TAIL10Tail lights, parking lights,
license plate lights
50PWR NO.420Rear passenger’s power
window (left side)
No.FUSEAMPERECIRCUIT
51PWR NO.220Front passenger’s door lock
system, front passenger’s
power window
52OBD7.5On −board diagnosis system
53SEAT
HTR20Seat ventilators/heaters
54WASHER15Windshield washer
55FA NRLY10Electric cooling fans
56STOP15Stop lights, high mounted
stoplight
57FUEL
OPEN5Fuel filler door opener
58DOOR NO.225
Multiplex communication
system (power door lock
system, auto −door locking
system, wireless remote
control system)
59AMP25Audio system
60PWR NO.320Rear passenger’s power
window (right side)

BODY
cdxiv
PROTECTING YOUR VEHICLEFROM CORROSION
Proper care of your Lexus can help ensure long −term
corrosion prevention.
The most common causes of corrosion to your vehicle
are:
 The accumulation of road salt, dirt and moisture in
hard−to−reach areas under the vehicle.
 Chipping of paint or undercoating caused by minor
accidents or by stones and gravel.
The following conditions will cause or accelerate
corrosion of your vehicle, so it is important to keep your
vehicle, particularly the underside, as clean as possible
and to repair any damage to paint or protective coatings
as soon as possible.
 The presence of road salt or dust control chemicals, salt in
the air near the sea coast, industrial air pollution.
 High humidity, especially at temperatures just above
freezing point.
 Certain parts of your vehicle are wet or damp for an
extended period of time, even though other parts of the
vehicle are dry.
 Components of the vehicle which are prevented from
quick−drying due to lack of proper ventilation are exposed
to high temperature. To help prevent corrosion on your Lexus, follow these
guidelines:
Keep your vehicle clean by regular washing.
In addition,
observe the following points.
 If you drive on salted roads in the winter or if you live near
the ocean, you should hose off the undercarriage at least
once a month to minimize corrosion.
 High pressure water or steam is effective for cleaning the
vehicle’s underside and wheel housings. Pay particular
attention to these areas as it is difficult to see all the mud and
dirt. It will do more harm than good to simply wet the mud
and debris without removing. The lower edge of doors,
rocker panels and frame members have drain holes which
should not be allowed to clog with dirt as trapped water in
these areas can cause corrosion.
 Wash the underside of the vehicle thoroughly when winter
is over.
See “Washing and waxing” on page cdxv for more tips.
Check the condition of your vehicle’s paint and trim. If you
find any chips or scratches in the paint, touch them up
immediately to prevent corrosion from starting. If the chips or
scratches have gone through the bare metal, have a qualified
body shop make the repair.

BODY
cdxxThe seat belts may be cleaned with mild soap and water or
with lukewarm water.
Use a cloth or sponge. As you are cleaning, check the belts for
excessive wear, fraying or cuts.
NOTICE

Use a good foamtype shampoo to clean the carpets.
 Do not use dye or bleach on the belts — it may
weaken them.
 Do not use the belts until they become dry.
 The windows may be cleaned with any household
window cleaner.
 Do not apply detergent to or wet the automatic wiper
control sensor when cleaning the inside of the
windshield.
 When cleaning the inside of the rear window, be
careful not to scratch or damage the heater wires or
connectors.
Air Conditioning Control Panel, Audio Panel,
Instrument Panel, Console Panel and
Switches
Use a soft damp cloth for cleaning.
Soak a clean soft cloth in water or lukewarm water then lightly
wipe off any dirt.
NOTICE
 Do not use organic substances (solvents, kerosene,
alcohol, gasoline, etc.) or alkaline or acidic solutions.
These chemicals can cause discoloring, staining or
peeling of the surface.
 If you use cleaners or polishing agents, make sure
their ingredients do not include the substances
mentioned above.
 If you use a liquid car freshener , do not spill the liquid
onto the vehicle’s interior surfaces. It may contain
the ingredients mentio ned above. Immediately clean
any spill using the method mentioned above.
If you have any questions about the cleaning of your
Lexus, your local Lexus dealer will be pleased to answer
them.
