towing Lexus ES330 2006 Basic Functions In Frequent Use / (OM33703U) User Guide

DRIVING TIPS
ccxcv
3. Release the
parking brake and brake pedal and slowly pull
or back away from the wheel blocks. Stop and apply your
brakes.
4. Have someone retrieve the blocks.
CAUTION
 Do not exceed 72 km/h (45 mph) or the posted towing
speed limit, whichever is lower. Because instability
(swaying) of a towing vehicletrailer combination
usually increases as the speed increases, exceeding
72 km/h (45 mph) may cause loss of control.
 Slow down and downshift before descending steep
or long downhill grades. Do not make sudden
downshifts.
 Avoid holding the brake pedal down too long or too
frequently. This could cause the brakes to overheat
and result in reduced braking efficiency.
HOW TO SAVE FUEL AND MAKE
YOUR VEHICLE LAST LONGER
Improving fuel economy is easy — just take it easy. It will help
make your vehicle last longer, too. Here are some specific tips
on how to save money on both fuel and repairs:
 Keep your tires inflated at the correct pressure. Check
the pressure every two weeks, or at least once a month.
Underinflation causes tire wear and wastes fuel.
 Do not carry unneeded weight in your vehicle. Excess
weight puts a heavier load on the engine, causing greater
fuel consumption.
 Avoid lengthy warmup idling. Once the engine is
running smoothly, begin driving — but gently. Remember,
however, that on cold winter days this may take a little
longer.
 Always drive with the automatic transmission selector
lever in the “D” position when engine braking is not
required. Driving with the overdrive off will reduce the fuel
economy. (For details, see “Automatic transmission” on
page cclxiii.)
 Accelerate slowly and smoothly. Avoid jackrabbit starts.
 Avoid long engine idling. If you have a long wait and you
are not in traffic, it is better to turn off the engine and start
again later.

DRIVING TIPS
ccxcvii
VEHICLE LOAD LIMITS
Vehicle load limits include total load capacity, seating
capacity, towing capacity and cargo capacity. Follow
the load limits shown below. Total load capacity and
seating capacity are also described on the tire and
loading information label. For location of the tire and
loading information label, see “Checking tire inflation
pressure” on page ccclxix.
Total load capacity: 410 kg (900 lb.)
Total load capacity means combined weight of
occupants, cargo and luggage. Tongue load is
included when trailer towing.
Seating capacity: Total 5 (Front 2, Rear 3)
Seating capacity means the maximum number of
occupants whose estimated average weight is 68 kg
(150 lb.) per person. Depending on the weight of
person, the seating capacity given may exceed the
total load capacity.
NOTICE
Even if the number of occupants are within the
seating capacity, do not exceed the total load
capacity.
Towing capacity: 907 kg (2000 lb.)
Towing capacity means the maximum gross trailer
weight (trailer weight plus its cargo weight) that your
vehicle is able to tow.
Cargo capacity
Cargo capacity may increase or decrease depending
on the size (weight) and the number of occupants.
For details, see “Capacity and distribution” that
follows.
CAUTION
Do not apply the load more than each load limit.
That may cause not only damage to the tires,
but also deterioration to the steering ability and
braking ability, which may cause an accident.

DRIVING TIPS
ccxcviii
CARGO AND LUGGAGE
Stowage precautions
When stowing cargo and luggage in the vehicle,
observe the following:
Put cargo and luggage in the trunk when at all
possible. Be sure all items are secured in place.
 Be careful to keep the vehicle level. Placing the
weight as far forward as possible helps maintain
vehicle balance.
 For better fuel economy, do not carry unnecessary
weight.
CAUTION
Do not place anything on the package tray
behind the rear seatback. Such items may
be thrown about and possibly injure people
in the vehicle during sudden braking or an
accident.
Do not drive with objects left on top of the
instrument panel. They may interfere with the
driver’s field of view. Or they may move
during sharp vehicle acceleration or turning,
and impair the driver’s control of the vehicle.
In an accident they may injure the vehicle
occupants.
Capacity and distribution
Cargo capacity depends on the total weight of the
occupants.
(Cargo capacity) = (Total load capacity) – (Total weight
of occupants)
Steps for determining correct load limit
1. Locate the statement “The combined weight of
occupants and cargo should never exceed XXX
pounds” on your vehicle’s placard.
2. Determine the combined weight of the driver and
passengers that will be riding in your vehicle.
3. Subtract the combined weight of the driver and
passengers from XXX kilograms or XXX pounds.

DRIVING TIPS
ccxcix
4. The resulting figure equals the available amount of
cargo and luggage load capacity. For example, if the
“XXX” amount equals 1400 lbs. and there will be five
150 lb. passengers in your vehicle, the amount of
available cargo and luggage load capacity is 650 lbs.
(1400 – 750 (5 x 150) = 650 lbs).
5. Determine the combined weight of luggage and
cargo being loaded on the vehicle. That weight may
not safely exceed the available cargo and luggage
load capacity calculated in Step 4.
6. If your vehicle will be towing a trailer, load from your
trailer will be transferred to your vehicle. Consult this
manual to determine how this reduces the available
cargo and luggage load capacity of your vehicle.
For details about trailer towing, see page cclxxxix.Example on your vehicle
1Cargo capacity
2Total load capacity
In case that 2 people with the combined weight of
166 kg (366 lb.) are riding in your vehicle with the
total load capacity of 410 kg (900 lb.), the available
amount of cargo and luggage load capacity will be
as follows:
410 kg – 166 kg = 244 kg.
(900 lb. – 366 lb. = 534 lb.)
From this condition, if 3 more passengers with the
combined weight of 176 kg (388 lb.) get on, the
available cargo and luggage load will be reduced as
follows:
244 kg – 176 kg = 68 kg.
(534 lb. – 388 lb. = 146 lb.)

IN CASE OF AN EMERGENCY
cccxi
1. Lift up the deck board and hang the deck board
hook on the right hinge of the trunk lid.
Make sure the board does not fall down.
When closing the board, replace the hook in its
original position.1 Spare tire 2 Jack handle 3 Wrench
4 Jack 5 Towing eyelet
2. Get the jack, wrench and spare tire.
To prepare yourself for an emergency, you should
familiarize yourself with the use of the jack and each
tool, and their storage locations. The jack handle and
wrench are attached at the reverse side of the cover.

IN CASE OF AN EMERGENCY
cccxx
NOTICE
If you rock your vehicle, observe the following
precautions to prevent damage to the transmission and
other parts.
Do not depress the accelerator pedal while shifting
the selector lever or before the transmission is
completely shifted to forward or reverse gear.
 Do not race the engine and avoid spinning the
wheels.
 If your vehicle remains stuck after rocking the vehicle
several times, consider other ways such as towing.
IF YOUR VEHICLE NEEDS TO BE
TOWED
If towing is necessary, we recommend you to have it done
by your Lexus dealer or a commercial tow truck service.
In consultation with them, have your vehicle towed using
either (a) or (b).
(a) Towing with a wheel lift type truck
(b) Using a flat bed truck
(c) Never tow with a sling type truck
Only when you cannot receive a towing service from a
Lexus dealer or commercial tow truck service, tow your
vehicle carefully in accordance with the instructions
given in “(d) Emergency towing” on page cccxxiv.
Proper equipment will help ensure that your vehicle is not
damaged while being towed. Commercial operators are
generally aware of the state/provincial and local laws
pertaining to towing.
Your vehicle can be damaged if it is towed incorrectly. Although
most operators know the correct procedure, it is possible to
make a mistake. To avoid damage to your vehicle, make sure
the following precautions are observed. If necessary, show
this page to the tow truck driver.
TOWING PRECAUTIONS:
Use a safety chain system for all towing, and abide by the
state/provincial and local laws. The wheels and axle on the
ground must be in good condition. If they are damaged, use
a towing dolly.

IN CASE OF AN EMERGENCY
cccxxi
(a) Towing with a wheel lift type truck
From front
Release the parking brake.
NOTICE
When lifting wheels, take care to ensure adequate
ground clearance for towing at the opposite end of the
raised vehicle. Otherwise, the bumper and/or
underbody of the towed vehicle will be damaged during
towing.
From rear
Use a towing dolly under the front wheels.
NOTICE
Never tow a vehicle with an automatic transmission
from the rear with front wheels on the ground, as this
may cause serious damage to the transmission.

IN CASE OF AN EMERGENCY
cccxxiii
Rear emergency towing eyelets
NOTICE
Do not use the rear emergency towing eyelets.
Tie down angle
If you use chains or wires to tie down your vehicle, the
angles shaded black must be at 45.

IN CASE OF AN EMERGENCY
cccxxiv
(c) Towing with a sling type truck
NOTICE
Do not tow with a sling type truck, either from the front
or rear. This may cause body damage.
(d) Emergency towing
If towing is necessary, we recommend you to have it done
by your Lexus dealer or a commercial tow truck service.
If towing service is not available in an emergency, your
vehicle may be temporarily towed by a cable or chain
secured to the emergency towing eyelet. Use extreme
caution when towing the vehicle.
To install the front towing eyelet, see “(e) Installing front towing
eyelet” on page cccxxv.
NOTICE
 Only use specified towing eyelet; otherwise your
vehicle may be damaged.
 Never tow a vehicle from the rear with four wheels on
the ground. This may cause serious damage to the
transmission.

IN CASE OF AN EMERGENCY
cccxxv
A driver must be in the vehicle to steer it and operate the
brakes.
Towing in this manner may be done only on hard
−surfaced
roads for a short distance and at low speeds. Also, the wheels,
axles, drive train, steering and brakes must all be in good
condition.
CAUTION
Use extreme caution when towing the vehicle. Avoid
sudden starts or erratic driving maneuvers which would
place excessive stress on the emergency towing eyelet
and towing cable or chain. The eyelet and towing cable
or chain may break and cause serious injury or damage.
NOTICE
Use only a cable or chain specifically intended for use
in towing vehicles. Securely fasten the cable or chain
to the towing eyelet provided.
Before towing, release the parking brake and put the
transmission in “N”. The ignition key must be in “ACC” (engine
off) or “ON” (engine running).
CAUTION
If the engine is not running, the power assist for the
brakes and steering will not work so steering and
braking will be much harder than usual.
(e) Installing front towing eyelet
1. Remove the front towing eyelet cover on the front bumper
using a flathead screwdriver. To protect the bodywork, place
a piece of rag over the cover.
