STARTING AND DRIVING
cclxxiii
TRACTION CONTROL SYSTEM
The traction control system automatically helps prevent
the spinning of front wheels when the vehicle is started or
accelerated on slippery road surfaces.
When the ignition key is turned to “ON”, the system
automatically turns on.
CAUTION
Under certain slippery road conditions, full traction of
the vehicle and power against front wheels cannot be
maintained, even though the traction control system is
in operation. Do not drive the vehicle under any speed
or maneuvering conditions which may cause the
vehicle to lose traction control. In situations where the
road surface is covered with ice or snow, your vehicle
should be fitted with snow tires or tire chains. Always
drive at an appropriate and cautious speed for the
present road conditions.
Normal driving mode
 Slip indicator light
Leave the system on during the ordinary driving so that it
can operate when needed.
You may hear a sound in the engine compartment for a few
seconds when the engine is started or just after the vehicle
begins to move. This means that the traction control system
is in the self −check mode, but does not indicate a malfunction.
When the traction control system is operating, the following
conditions occur:
 The system controls the spinning of the front wheels. At this
time, the slip indicator light blinks.
 You may feel vibration or noise in your vehicle, caused by
operation of the brakes. This indicates the system is
functioning properly.

STARTING AND DRIVING
cclxxvi
VEHICLE STABILITY CONTROLSYSTEM
The vehicle stability control system helps provide
integrated control of the systems such as antilock brake
system, traction control, engine control, etc. This system
automatically controls the brakes and engine to help
prevent the vehicle from skidding when cornering on a
slippery road surface or operating steering wheel
abruptly.
This system will activate when your vehicle speed reaches or
exceeds 15 km/h (9 mph), and will deactivate when the vehicle
speed reduces to below 15 km/h (9 mph).
You may hear a sound in the engine compartment for a few
seconds when the engine is started or just after the vehicle
begins to move. This means that the system is in the
self−check mode but does not indicate a malfunction.
CAUTION
 Do not rely excessively on the vehicle stability
control system. Even if the vehicle skid control
system is operating, you must always drive carefully
and attentively to avoid serious injury. Reckless
driving will result in an unexpected accident. If the
slip indicator light blinks, sounding an alarm, special
care should be taken while driving.
 Only use tires of specified size. The size,
manufacture, brand and tread pattern for all 4 tires
should be the same. If you use the tires other than
specified, or different type or size, the vehicle
stability control system may not function correctly.
When replacing the tires or wheels, contact your
Lexus dealer.
 In situations where the road surface is covered with
ice or snow, your vehicle should be fitted with snow
tires or tire chains.
 Slip indicator light
If the vehicle is going to skid during driving, the slip indicator
light blinks and an alarm sounds intermittently. Special care
should be taken while driving.
The slip indicator light comes on for a few seconds when the
ignition key is turned to “ON”. If the indicator light does not
come on when the ignition is turned on, contact your Lexus
dealer.

STARTING AND DRIVING
cclxxix
You may hear a click or motor sound in the engine
compartment for a
few seconds when the engine is started or
just after the vehicle begins to move. This means that the
anti−lock brake system is in the self −check mode, and does not
indicate a malfunction.
When the antilock brake system is activated, the
following conditions may occur. They do not indicate a
malfunction of the system:
 You may hear the anti −lock brake system operating and feel
the brake pedal pulsating and the vibrations of the vehicle
body and steering wheel. You may also hear the motor
sound in the engine compartment even after the vehicle is
stopped.
 At the end of the anti−lock brake system activation, the
brake pedal may move a little forward.
CAUTION
Do not overestimate the antilock brake system:
Although the antilock brake system assists in
providing vehicle control, it is still important to drive
with all due care and maintain a moderate speed and
safe distance from the vehicle in front of you, because
there are limits to the vehicle stability and effectiveness
of steering wheel operation even with the antilock
brake system on.
If tire grip performance exceeds its capability, or if
hydroplaning occurs during high speed driving in the
rain, the antilock brake system does not provide
vehicle control.
Antilock brake system is not designed to shorten the
stopping distance: Always drive at a moderate speed
and maintain a safe distance from the vehicle in front of
you. Compared with vehicles without an antilock
brake system, your vehicle may require a longer
stopping distance in the following cases:
 Driving on rough, gravel or snowcovered roads.
 Driving with tire chains installed.
 Driving over the steps such as the joints on the road.
 Driving on roads where the road surface is pitted or
has other differences in surface height.
Install all 4 tires of specified size at appropriate inflation
pressure: The antilock brake system detects vehicle
speeds using the speed sensors for respective wheels’
turning speeds. The use of tires other than specified
may fail to detect the accurate turning speed resulting
in a longer stopping distance.

DRIVING TIPS
cclxxxviiiCheck the condition of the battery and cables.
Cold temperatures reduce the capacity of any battery, so it
must be in top shape to provide enough power for winter
starting. Page cccxcix tells you how to visually inspect the
battery. Your Lexus dealer and most service stations will be
pleased to check the battery charge level.
Make sure the engine oil viscosity is suitable for the cold
weather.
See page ccclviii
for recommended viscosity. Leaving a heavy
summer oil in your vehicle during winter months may cause
harder starting. If you are not sure about which oil to use, call
your Lexus dealer — they will be pleased to help.
Check the electronic ignition system for loose
connections or obvious damage.
Keep the door locks from freezing.
Squirt lock de− icer or glycerine into the locks to keep them from
freezing.
Use a washer fluid containing an antifreeze solution.
This product is available at your Lexus dealer and most auto
parts stores. Follow the manufacturer’s directions for how
much to mix with water.
NOTICE
Do not use engine antifreeze or any other substitute
because it may damage your vehicle’s paint.
Do not use your parking brake when there is a possibility
it could freeze.
When parking, put the transmission into “P” and block the rear
wheels. Do not use the parking brake, or snow or water
accumulated in and around the parking brake mechanism may
freeze the parking brake, making it hard to release.
Keep ice and snow from accumulating under the fenders.
Ice and snow built up under your fenders can make steering
difficult. During bad winter driving, stop and check under the
fenders occasionally.
Depending on where you are driving, we recommend you
carry some emergency equipment.
Some of the things you might put in the vehicle are tire chains,
window scraper, bag of sand or salt, flares, small shovel,
jumper cables, etc.

SECTION 6 – 3
ccclxii
SERVICE PROCEDURES AND
SPECIFICATIONS
Chassis
Specificationsccclxiii
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . .
Checking brake fluid ccclxvii
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Checking power steering fluid ccclxviii
. . . . . . . . . . . . . . . . . . . . . . . . .
Checking tire inflation pressure ccclxix
. . . . . . . . . . . . . . . . . . . . . . . . .
Tire information ccclxxiii
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
.
Types of tires ccclxxxii
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . .
Rotating tires ccclxxxiii
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. .
Checking and replacing tires ccclxxxiv
. . . . . . . . . . . . . . . . . . . . . . . . .
Installing snow tires and chains ccclxxxvi
. . . . . . . . . . . . . . . . . . . . . . .
Replacing wheels ccclxxxviii
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Aluminum wheel precautions ccclxxxix
. . . . . . . . . . . . . . . . . . . . . . . . .
Suspension and chassis cccxc
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

CHASSIS
ccclxxxv
This applies also to the spare tire and tires stored
for future use.
Tire selection
When replacing a tire, use a tire of the same size
and construction, and the same or greater
maximum loads as the originally installed tires.
Using any other size or type of tire may seriously
affect handling, ride, speedometer/odometer
calibration, ground clearance, and clearance between
the body and tires or snow chains.
Check that the maximum load of the replaced tire is
greater than 1/2 of the Gross Axle Weight Ratings
(GAWR) of either the front axle or the rear axle,
whichever is greater. As for the maximum load of
the tire, see the load limit at maximum cold tire
inflation pressure mentioned on the sidewall of the tire,
and as for the Gross Axle Weight Ratings (GAWR),
see the Certification Label. For details about
Certification Label and sidewall of the tire, see pages
cccxxxix and ccclxxiii.
CAUTION
Observe the following instructions. Otherwise,
an accident may occur resulting in death or
serious injuries.
Do not mix radial, bias belted, or biasply tires
on your vehicle, as this may cause dangerous
handling characteristics resulting in loss of
control.
 Do not use tires other than the manufacturer’s
recommended size, as this may cause
dangerous handling characteristics resulting
in loss of control.

CHASSIS
ccclxxxvi
INSTALLING SNOW TIRES ANDCHAINS
When to use snow tires or chains
Snow tires or chains are recommended when driving on
snow or ice.
On wet or dry roads, conventional or radial tires provide better
traction than snow or studded tires.
Snow tire selection
If you need snow tires, select tires of the same size,
construction and load capacity as the originally installed
tires.
Do not use tires other than stated above. Since your vehicle
has radial tires as original equipment, make sure your snow
tires also have radial construction. Do not install studded tires
without first checking local regulations for possible restrictions.
CAUTION
Do not use snow tires other than the manufacturer’s
recommended size, as this may cause dangerous
handling characteristics resulting in loss of control.
Otherwise, an accident may occur resulting in death or
serious injuries.
Snow tire installation
Snow tires should be installed on all wheels.
Installing snow tires on the front wheels only can lead to an
excessive difference in road grip capability between the front
and rear tires which could cause loss of vehicle control.
CAUTION
 Snow tires should be inflated to the same pressure as
the original tires.
 Never drive over 120 km/h (75 mph) with any type of
snow tires.

CHASSIS
ccclxxxix
Wheel selection
When replacing wheels, care should be taken to ensure
that they are equivalent to those removed in load capacity,
diameter, rim width, and offset.
Correct replacement wheels are available at your Lexus
dealer.
A wheel of a different size or type may adversely affect
handling, wheel and bearing life, brake cooling,
speedometer/odometer calibration, stopping ability, headlight
aim, bumper height, vehicle ground clearance, and tire or snow
chain clearance to the body and chassis.
CAUTION
Do not use wheels other than the manufacturer’s
recommended size, as this may cause dangerous
handling characteristics resulting in loss of control.
Otherwise, an accident may occur resulting in death or
serious injuries.
ALUMINUM WHEEL PRECAUTIONS
 When installing aluminum wheels, check that the wheel nuts
are tight after driving your vehicle the first 1600 km (1000
miles).
 If you have rotated, repaired, or changed your tires, check
that the wheel nuts are still tight after driving 1600 km (1000
miles).
 When using tire chains, be careful not to damage the
aluminum wheels.
 Use only Lexus wheel nuts and wrench designed for your
aluminum wheels.
 When balancing your wheels, use only Lexus balance
weights or equivalent and a plastic or rubber hammer.
 As with any wheel, periodically check your aluminum
wheels for damage. If damaged, replace immediately.
