GAUGES, METERS AND SERVICE REMINDER INDICATORS
lxix
The following information is displayed in the instrument
cluster
when you push the “DISP” button with the ignition
switch turned on.
Each time you push the “DISP” button, the display toggles
through this information.
(1) Instantaneous fuel consumption
(2) Average fuel consumption
(3) Driving range
(4) Average vehicle speed
(5) Driving time
The displayed values in the multi −information display indicate
general driving conditions. Accuracy varies with driving habits
and road conditions.
When the ignition switch is on, the last previously used mode
displayed just before the ignition switch is off will appear.
If the electrical power source has been disconnected from the
multi−information display, the display will automatically be set
to the initial mode.
When the instrument panel lights are turned on, the brightness
of the display will be reduced.
CAUTION
Do not adjust the display while the vehicle is moving.
Be sure to adjust the display only when the vehicle is
stopped.
(1) Instantaneous fuel consumption (“MPG” or “L/100km”)
The instantaneous fuel consumption is calculated and
displayed based on distance and fuel consumption for 2
seconds with the engine running.
The displayed value is updated every 2 seconds.
Note that an accurate figure may not be shown in the following
cases.
 The vehicle is stopped with the engine running. (The display
will indicate the extremely high fuel consumption.)
 The vehicle is driving down a long slope applying the engine
brake. (The display will indicate the extremely low fuel
consumption.)
The calculation is reset when the ignition switch is turned off.
(2) Average fuel consumption (“AVG. MPG” or “AVG. L/100 km”)
Average fuel consumption is calculated and displayed
based on total driving distance and total fuel consumption
with the engine running.
The displayed value is updated every 10 seconds.
To reset the calculations, push and hold the “DISP” button.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
lxx
(3) Driving range(“RANGE MI” or “RANGE km”)
The distance the vehicle can travel with the remaining fuel
is calculated and displayed based on the quantity of
remaining fuel and past fuel consumption.
The driving range display indicates the approximate distance
that you can drive until the fuel gauge reaches “E”. It is dif ferent
from the actual distance traveled.
The displayed value is updated every time the fuel equivalent
for 1 mile or 1 km is consumed.
Every time you refuel the vehicle, the calculation is reset.
The actual driving range varies with driving habits and road
conditions. If fuel consumption is good, the driving range will
be longer than indicated. If fuel consumption is poor, the
driving range will be shorter than indicated.
If the low fuel level warning light comes on, refuel the vehicle
even if the display indicates that the vehicle can be driven
further.
(4) Average vehicle speed (“AVG. MPH” or “AVG. km/h”)
Average vehicle speed is calculated and displayed based
on total driving distance and total driving time with the
engine running.
The displayed value is updated every 10 seconds.
To reset the calculations, push and hold the “DISP” button.
(5) Driving time(“E/T”)
The elapsed time after the engine starts is displayed.
When the engine is started, driving time is counted from 0:00.
Up to 99:59 (99 hours, 59 minutes) can be displayed. When
the driving time exceeds 99:59, the counter returns to 0:00.
To reset the calculations, push and hold the “DISP” button.

Finish
INTERIOR EQUIPMENT
lxxvi
CLOCK
The digital clock indicates the time with the ignition key at
the “ACC” or “ON” position. To reset the hour, press the
“H” button. To reset the minutes, press the “M” button.
To adjust the time to the nearest hour, press the “:00”
button.
For example, if the “:00” button is pressed when the time is
between 9:30 — 9:59 or between 10:01 — 10:29, the time will
change to 10:00.
With the tail lights on, the brightness of the time indication will
be reduced.
If the electrical power source has been disconnected from the
clock, the time display will automatically be set to 1:00 (one
o’clock).
CIGARETTE LIGHTER AND ASHTRAY
Cigarette lighter and ashtray
To use the cigarette lighter and ashtray, first push against
the ashtray cover. Then when the ashtray opens out,
press in the cigarette lighter. After it finishes heating up,
it automatically pops out ready for use.
Do not hold the cigarette lighter pressed in.
If the engine is not running, the ignition key must be in the
“ACC” position to use the lighter.
When finished with your cigarette, thoroughly extinguish it in
the ashtray to prevent other cigarette butts from catching fire.
After using the ashtray, close the lid completely.
To remove the ashtray, just pull it up.

Finish
INTERIOR EQUIPMENT
lxxvii
Use a Lexus genuine cigarette lighter or equivalent for
replacement.
CAUTION
To reduce the chance of injury in case of an accident or
sudden stop while driving, always completely close the
ashtray after use.
POWER OUTLET
The power outlet is designed for power supply for car
accessories.
The ignition key must be in the “ACC” or “ON” position for t\
he
power outlet to be used.
NOTICE

To prevent the fuse from being blown, do not use the
electricity over the total vehicle capacity of
12V/120W.
 To prevent the battery from being discharged, do not
use the power outlet longer than necessary when the
engine is not running.

Finish
INTERIOR EQUIPMENT
xci
CAUTION
Do not touch the brackets fastening the sunshade to
avoid injuring your fingers or hands.
 Do not put your fingers in the sunshade groove while
the sunshade is operating to avoid getting them
caught or injured by the runner.
NOTICE
To prevent the vehicle battery from being discharged,
always operate the sunshade while the engine is
running.
 Observe the following to avoid damage and/or
malfunction:
Do not overload the sunshade motor and other parts
(for instance by pushing down on the sunshade
bracket while it is opening).
Do not place anything where they may hinder the
opening/closing of the sunshade.
Do not affix anything to the sunshade.
Clean the sunshade groove if there is any foreign
matter or dust on it.
Do not operate the rear electric sunshade repeatedly
for a long time as its motor may overheat.
TIEDOWN HOOKS
To secure your luggage, use the tiedown hooks as shown
above.
See “Stowage precautions” on page ccxcviii for precautions
when loading luggage.

EXTERIOR EQUIPMENT
xcvii
FUEL TANK CAP
This indicates that the fuel filler door is on the left side of
your vehicle.
1. To open the fuel filler door, push the switch.
When refueling, turn off the engine.
CAUTION
Do not smoke, cause sparks or allow open flames
when refuelling. The fumes are flammable.
 When opening the cap, do not remove the cap
quickly. In hot weather, fuel under pressure could
cause injury by spraying out of the filler neck if the
cap is suddenly removed.

STEERING WHEEL AND MIRRORS
clxxivWhen you set your driving position:
1. Set the parking brake firmly.
2. Move the accelerator and brake pedals to the front most
position.
3. Adjust the seat position and steering wheel angle properly.
(See pages cviii and clxxiii.)
4. Move the pedals toward you
until you can fully depress the
brake pedal.
5. After adjusting, depress the pedals a few times to get used
to the feel.
CAUTION
 Never put your foot on the accelerator pedal while the
pedals are moving. It may cause racing of the engine
or sudden acceleration.
 Make sure that you can fully depress the brake pedal
before driving. Otherwise, you may not be able to
hold down the brake pedal firmly in an emergency
stop.
OUTSIDE REAR VIEW MIRRORS
Adjust the mirror so that you can just see the side of your
vehicle in the mirror.
Be careful when judging the size or distance of any object seen
in the outside rear view mirror on the passenger’s side
because it is a convex mirror. Any object seen in a convex
mirror will look smaller and farther away than if seen in a normal
flat mirror.
When the inside rear view mirror darkens in AUTO mode, the
outside rear view mirrors also darken to reduce the reflection
of the headlights of the following vehicle. For details, see
“Inside rear view mirror” on page clxxvii.

AIR CONDITIONING
clxxxviThe automatic air conditioning automatically maintains
the set temperature.
In the automatic operation mode, the air conditioning selects
the most suitable fan speed, air flow, air intake and on−
off the
air conditioning according to the temperature.
The ignition key must be in the “ON” position.
NOTICE
To prevent the battery from being discharged, do not
leave the air conditioning on longer than necessary
when the engine is not running.
1“TEMP” (driver side temperature control) button
2Driver side temperature display (in degrees
Fahrenheit or Centigrade)
3Fan speed display
4Outside temperature display
5Air flow display
6Passenger side temperature display (in degrees
Fahrenheit or Centigrade)
7“PASSENGER TEMP” (passenger side temperature
control) button
8“DUAL” (temperature setting mode change) button
9Windshield air flow button
10“MODE”(air flow control) button
11Air intake control button
12Fan speed control button
13“OFF” button
14“AUTO” button
15“A/C” button

AUDIO
cciii
Using your audio system: some basics
This section describes some of the basic features of the Lexus
audio system. Some information may not pertain to your
system.
Your audio system works when the ignition switch is in the
“ACC” or “ON” position.
NOTICE
To prevent the battery from being discharged, do not
leave t he audio system on longer than necessary when
the engine is not running.
(a) Turning the system on and off
Push this knob to turn the audio system on and off. Turn
this knob to adjust the volume.
The system turns on in the last mode used.

AUDIO
ccxxvii
Using your audio system: some basics
This section describes some of the basic features of the Lexus
audio system. Some information may not pertain to your
system.
Your audio system works when the ignition switch is in the
“ACC” or “ON” position.
NOTICE
To prevent the battery from being discharged, do not
leave t he audio system on longer than necessary when
the engine is not running.
(a) Turning the system on and off
Push this knob to turn the audio system on and off. Turn
this knob to adjust the volume.
The system turns on in the last mode used.
