350
3-7. Other interior features
ES350_U
Safety Connect∗
∗: If equipped
Safety Connect is a subscription-based telematics service that uses Global
Positioning System (GPS) data and embedded cellular technology to pro-
vide safety and security features to subscribers. Safety Connect is sup-
ported by Lexus’ designated response center, which operates 24 hours per
day, 7 days per week.
Safety Connect service is available by subscription on select, telematics
hardware-equipped vehicles.
By using the Safety Connect service, you are agreeing to be bound by the
Telematics Subscription Service Agreement and its Terms and Conditions,
as in effect and amended from time to time, a current copy of which is avail-
able at Lexus.com. All use of the Safety Connect service is subject to such
then-applicable Terms and Conditions.
■ System components
“SOS” button
Microphone
LED light indicators

353
3-7. Other interior features
3
Interior features
ES350_U
Safety Connect LED light IndicatorsWhen the “ENGINE START STOP” switch is turned to IGNITION ON
mode, the red indicator light comes on for 2 seconds then turns off.
Afterward, the green indicator light comes on, indicating that the service
is active.
The following indicator light patterns indicate specific system usage con-
ditions:
● Green indicator light on = Active service
● Green indicator light flashing = Safety Connect call in process
● Red indicator light (except at vehicle start-up) = System malfunction
(contact your Lexus dealer)
● No indicator light (off) = Safety Connect service not active
Safety Connect services
■ Automatic Collis ion Notification
In case of either airbag deployment or severe rear-end collision, the
system is designed to automatically call the response center. The
responding agent receives the vehicle’s location and attempts to speak
with the vehicle occupants to assess the level of emergency. If the
occupants are unable to communicate, the agent automatically treats
the call as an emergency, contacts the nearest emergency services
provider to describe the situation, an d requests that assistance be sent
to the location.

369
4-2. Maintenance
4
Maintenance and care
ES350_U
Emission inspection and maintenance (I/M) programs
Some states have vehicle emission inspection programs which include
OBD (On Board Diagnostics) checks. The OBD system monitors the oper-
ation of the emission control system.
■If the malfunction indicator lamp comes on
The OBD system determines that a problem exists somewhere in
the emission control system. Your vehicle may not pass the I/M test
and may need to be repaired. Cont act your Lexus dealer to service
the vehicle.
■ Your vehicle may not pass the I/M test:
●When the battery is disconnected or discharged
Readiness codes that are set du ring ordinary driving are erased.
Also, depending on your driving habits, the readiness codes may
not be completely set.
● When the fuel tank cap is loose
The malfunction indicator lamp comes on as a temporary mal-
function and your vehicle may not pass the I/M test.
■ When the malfunction indicator la mp goes off after several driv-
ing trips
The error code in the OBD system will not be cleared unless the
vehicle is driven 40 or more times.
■ If your vehicle does not pass the I/M test
Contact your Lexus dealer to prepare the vehicle for re-testing.

497
6-1. Specifications
6
Vehicle specifications
ES350_U
■Lexus recommends the use of cleaner burning gasoline
Cleaner burning gasoline, including reformulated gasoline that contains oxygen-
ates such as ethanol or MTBE (Methyl Tertiary Butyl Ether) is available in many
areas.
Lexus recommends the use of cleaner burning gasoline and appropriately blended
reformulated gasoline. These types of gasoline provide excellent vehicle perfor-
mance, reduce vehicle emissions and improve air quality.
■Lexus does not recommend blended gasoline
●If you use gasohol in your Lexus, be sure that it has an octane rating no lower
than 87.
●Lexus DOES NOT recommend the use of gasoline containing methanol.
■Lexus does not recommend gasoline containing MMT
Some gasoline contains octane enhancing additive called MMT (Methylcyclopen-
tadienyl Manganese Tricarbonyl).
Lexus DOES NOT recommend the use of gasoline that contains MMT. If fuel con-
taining MMT is used, your emission control system may be adversely affected.
The malfunction indicator lamp on the instrument cluster may come on. If this hap-
pens, contact your Lexus dealer for service.
●Use only gasoline containing a maxi-
mum of 10% ethanol.
DO NOT use any flex-fuel or gasoline
that could contain more than 10% etha-
nol, including from any pump labeled
E15, E30, E50, E85 (which are only
some examples of fuel containing more
than 10% ethanol).DO NOT use gasoline contain-
ing more than 10% ethanol.(15% ethanol)
(50% ethanol)
(85% ethanol)

546
Alphabetical index
ES350_U
SeatsAdjustment............................................... 50
Adjustment precautions....................50
Child seats/child restraint
system installation ........................... 108
Cleaning...................................................361
Driver’s seat position memory......... 51
Front passenger seat position
memory.................................................. 55
Head restraint......................................... 57
Properly sitting in the seat ................ 86
Seat heaters............................. 328, 330
Ventilated seats ..................................330
Service reminder indicators ............. 140
Shift lever Automatic transmission.................... 132
If the shift lever cannot be shifted from P ....................................472
Shift lever lighting .................................. 312
Shift lock system .................................... 472
Side airbags............................................... 88
Side marker lights Replacing light bulbs........................ 420
Switch ........................................................149
Wattage.................................................. 495
Side mirror
Adjusting and folding ......................... 68
Mirror position memory ..................... 51
Smart access system with push-button start
Entry function.......................................... 28
Starting the engine ..............................128 “SOS” button..........................................350
Spare tire
Inflation pressure ............................... 399
Storage location .................................. 461
Spark plug .................................................491
Specifications ......................................... 486
Speedometer .......................................... 138
Steering wheel Audio switches*..................................257
Power adjustment................................ 65
Steering wheel position memory ................................................... 51
Stop lights Replacing light bulbs ....................... 420
Wattage ................................................. 495
Storage feature ...................................... 315
Stuck If your vehicle becomes stuck .... 483
Sun visors ................................................. 322
Sunshade Rear .......................................................... 333
Roof..............................................................75
Switch Emergency flasher switch............. 430
Engine switch ........................................ 128
Fog light switch .................................... 154
Hazard light switch .......................... 430
Ignition switch ....................................... 128
Light switches........................................ 149
Power door lock switch..................... 42
Power window switch ........................70
Window lock switch ............................70
Wiper and washer switch............... 156
