garage door opener Lexus ES350 2019 Owner's Manual / LEXUS 2019 ES350 OWNER'S MANUAL (OM06130U)

3TABLE OF CONTENTS
1
2
3
4
5
6
7
8
9
Automatic transmission...............141
Turn signal lever............................. 145
Parking brake ................................. 146
Brake Hold....................................... 148
4-3. Operating the lights and wipers Headlight switch ............................ 150
Automatic High Beam ................ 153
Windshield wipers and washer 155
4-4. Refueling Opening the fuel tank cap.......... 161
4-5. Using the driving support systems Lexus Safety System+2.0 .......... 163
PCS (Pre-Collision System)..... 169
LTA (Lane Tracing Assist)......... 176
RSA (Road Sign Assist) .............. 185
Dynamic radar crui se control with
full-speed range.......................... 187
BSM (Blind Spot Monitor) ........ 197
Driving Mode Select switch .... 202
PKSA (Parking Support Alert) 204
Intuitive parking assist ................ 205
RCTA (Rear cross traffic alert) function ............................................ 211
RCD (Rear Camera Detection) function ........................................... 215
PKSB (Parking Support Brake) 218
Parking Support Brake function (static objects) ............................ 224
Parking Support Brake function (rear-crossing vehicles).......... 229
Parking Support Brake function (rear pedestrians) ..................... 233
Driving assist systems ................. 236
4-6. Driving tips Winter driving tips ....................... 2405-1. Remote Touch
Remote Touch................................ 244
5-2. Lexus Climate Concierge Lexus Climate Concierge........ 249
5-3. Using the air conditioning system Automatic air conditioning system............................................................ 251
Heated steering wheel/seat heat- ers/seat ventilators................... 258
5-4. Using the interior lights Interior lights list ............................ 262
5-5. Using the storage features List of storage features .............. 265
Trunk features ............................... 268
5-6. Using the other interior features Other interior features .............. 269
Garage door opener .................. 281
Compass ......................................... 286
Lexus Enform Safety Connect 289
Lexus Enform Remote ............... 293
Lexus Enform Service Connect .......................................................... 294
6-1. Maintenance and care Cleaning and protecting the vehi-cle exterior................................... 296
Cleaning and protecting the vehi- cle interior ..

.................................. 299
6-2. Maintenance Maintenance re quirements ......301
General maintenance................ 302
5Interior features
6Maintenance and care

20Pictorial index
■Ceiling
Interior lights ...........................................................................................................P.263
Personal lights.........................................................................................................P.263
Moon roof switches
*..............................................................................................P.120
Panoramic moon roof switches
*.........................................................................P.123
“SOS” button
*........................................................................................................ P.289
Door-linked interior light switch .......................................................................P.263
Vanity mirrors ......................................................................................................... P.269
Sun visors .................................................................................................................. P.2 69
Inside rear view mirror ........................................................................................... P.114
Garage door opener buttons ..............................................................................P.281
*:If equipped
A
B
C
D
E
F
G
H
I

243
5
5
Interior features
Interior features
5-1. Remote TouchRemote Touch ............................ 244
5-2. Lexus Climate Concierge Lexus Climate Concierge ..... 248
5-3. Using the air conditioning system Automatic air conditioning system........................................................ 250
Heated steering wheel/seat heat- ers/seat ventilators ................ 257
5-4. Using the interior lights Interior lights list.......................... 261
5-5. Using the storage features List of storage features............ 264
Trunk features............................. 267
5-6. Using the other interior features Other interior features ........... 268
Garage door opener............... 280
Compass....................................... 285
Lexus Enform Safety Connect ........................................................ 288
Lexus Enform Remote ............ 292
Lexus Enform Service Connect ........................................................ 293

2815-6. Using the other interior features
5
Interior features
The HomeLink® wireless control sys-
tem in your vehicle has 3 buttons which
can be programmed to operate 3 dif-
ferent devices. Refer to the program-
ming methods on the following pages
to determine the method which is
appropriate for the device. HomeLink
® indicator light
Garage door operation indicators
HomeLink
® icon
Illuminates while HomeLink® is operating.
Buttons
■Codes stored in the HomeLink® mem-
ory
●The registered codes are not erased even
if the battery cable is disconnected.
●If learning failed when registering a dif-
ferent code to a HomeLink® button that
already has a code registered to it, the
already registered code will not be
erased.
■Certification for the garage door opener
Garage door opener
The garage door opener can be
programmed using the Home-
Link
® to operate garage doors,
gates, entry doors, door locks,
home lighting systems, security sys-
tems, and other devices.
System components
A
B
C
D

2825-6. Using the other interior features
■When support is necessary
Visit on the web at www.home-
link.com/lexus or call 1-800-355-3515.
■Before programming HomeLink®
 During programming, it is possible
that garage doors, gates, or other devices may operate. For this rea-
son, make sure that people and
objects are clear of the garage door
or other devices to prevent injury or
other potential harm.
 It is recommended that a new bat-
tery be placed in the remote control
transmitter for more accurate pro-
gramming.
 Garage door opener motors manu-
factured after 1995 may be
equipped with rolling code protec-
tion. If this is the case, you may need
a stepladder or other sturdy, safe
device to reach the “Learn” or
“Smart” button on the garage door
opener motor.
■Programming HomeLink®
Steps 1 through 3 must be performed
within 60 seconds, otherwise the indi-
cator light will stop flashing and pro-
gramming will not be able to be
completed.
1 Press and release the HomeLink
®
button you want to program and
check that the HomeLink
® indica-
tor light flashes (orange).
WARNING
■When programming a garage door or
other remote control device
The garage door or other device may
operate, so ensure people and objects
are out of danger to prevent potential
harm.
■Conforming to federal safety stan-
dards
Do not use the HomeLink
® compatible
transceiver with any garage door opener
or device that lacks safety stop and
reverse features as required by federal
safety standards.
This includes any garage door that can-
not detect an interfering object. A door
or device without these features
increases the risk of death or serious
injury.
■When operating or programming
HomeLink®
Never allow a child to operate or play
with the HomeLink® buttons.
Programming the HomeLink®

2835-6. Using the other interior features
5
Interior features
2Point the remote control transmit-
ter for the device at the rear view
mirror, 1 to 3 in. (25 to 75 mm)
from the HomeLink
® buttons.
Keep the HomeLink® indicator light in
view while programming.
3 Program a device.
Programming a device other than
an entry gate (for U.S.A. owners)
Press and hold th e remote control
transmitter button until the Home-
Link
® indicator light changes from
slowly flashing orange to rapidly flash-
ing green (rolling code) or continu-
ously lit green (fixed code), then
release the button.
Programming an entry gate (for
U.S.A. owners)/Programming a
device in the Canadian market
Press and release th e remote control
transmitter button at 2 second inter- vals, repeatedly, until the HomeLink
®
indicator light changes from slowly
flashing (orange) to rapidly flashing
(green) (rolling code) or continuously
lit (green) (fixed code).
4 Test the HomeLink
® operation by
pressing the newly programmed
button and observing the indicator
light:
 Indicator light illuminates: Program-
ming of a fixed code device has
completed. The garage door or
other device should operate when a
HomeLink
® button is pressed and
released.
 Indicator light flashes rapidly: The
garage door opener motor or other
device is equipped with a rolling
code. To complete programming,
firmly press and hold the Home-
Link
® button for 2 seconds then
release it.
 If the garage door or other device
does not operate, proceed to “Pro-
gramming a rolling code system”.
5 Repeat the steps above to program
another device for any of the
remaining HomeLink
® buttons.
■Programming a rolling code sys-
tem
2 or more people may be necessary to
complete rolling code programming.
1 Locate the “Learn” or “Smart” but-
ton on the garage door opener
motor in the garage.
This button can usually be found where the
hanging antenna wire is attached to the

2845-6. Using the other interior features
unit. The name and color of the button may
vary by manufacturer. Refer to the owner’s
manual supplied with the garage door
opener motor for details.
2Press and release the “Learn” or
“Smart” button.
Perform 3 within 30 seconds after per-
forming 2.
3 Press and hold the desired Home-
Link
® button (inside the vehicle)
for 2 seconds and release it. Repeat
this sequence (press/hold/release)
up to 3 times to complete pro-
gramming.
If the garage door opener motor
operates when the HomeLink
®
button is pressed, the garage door opener motor recognizes the
HomeLink
® signal.
■Enabling 2-way communication
with a garage door (only available
for compatible devices)
When enabled, 2-way communication
allows you to check the status of the
opening and closing of a garage door
through indicators in your vehicle.
2-way communication is only available
if the garage door opener motor used
is a compatible device. (To check
device compatibility, refer to
www.homelink.com.)
1 Within 5 seconds after program-
ming the garage door opener has
been completed, if the garage door
opener motor is trained to Home-
Link
®, both garage door operation
indicators will flash rapidly (green)
and the light on the garage door
opener motor will blink twice, indi-
cating that 2-way communication is
enabled.
If the indicators do not flash, perform 2 and
3 within the first 10 presses of the Home-
Link
® button after programming has been
completed.
2 Press a programmed HomeLink®
button to operate a garage door.

2855-6. Using the other interior features
5
Interior features
3Within 1 minute of pressing the
HomeLink
® button, after the
garage door operation has
stopped, press the “Learn” or
“Smart” button on the garage door
opener motor. Within 5 seconds of
the establishment of 2-way com-
munication with the garage door
opener, both garage door opera-
tion indicators in the vehicle will
flash rapidly (green) and the light
on the garage door opener motor
will blink twice, indicating that 2-
way communication is enabled.
■Reprogramming a single Home-
Link
® button
When the following procedure is per-
formed, buttons which already have
devices registered to them can be
overwritten:
1 With one hand, press and hold the
desired HomeLink
® button.
2 When the HomeLink
® indicator
starts flashing (orange), continue to
hold the HomeLink
® button and
perform “Programming Home-
Link
®” 1 (it takes 20 seconds for
the HomeLink
® indicator to start
flashing).
■Before programming
●Install a new battery in the transmitter.
●The battery side of the transmitter must
be pointed away from the HomeLink®.
Press the appropriate HomeLink®
button. The HomeLink
® indicator light
should turn on.
The status of the opening and closing
of a garage door is shown by the indi-
cators.
Opening
Closing
This function is only available if the garage
door opener motor used is a compatible
device. (To check device compatibility,
refer to www.homelink.com.)
The indicators can operate within
approximately 820 ft. (250 m) of the
garage door. However, if there are
obstructions between the garage door
and the vehicle, such as houses and
trees, feedback signals from the
garage door may not be received.
Operating HomeLink®
ColorStatus
Orange (flashing)Currently open-ing/closing
GreenOpening/closing has completed
Red (flashing)Feedback signals
cannot be received
A
B

433What to do if... (Troubleshooting)Alphabetical index433
Fuses ...................................................................331
G
Garage door opener ...................................281
Gauges ....................................................... 64, 67
Gear Position....................................................75
G-force................................................................75
Glove box ....................................................... 266
Glove box light ............................................. 266
Grocery bag hooks .................................... 268
H
Hands Free Power Trunk Lid .................... 96
Headlights ....................................................... 150Adaptive Front-lighting System (AFS)...........................................................................152
Automatic High Beam system..............153
Light switch .................................................... 150
Replacing light bulbs................................ 335
Headlights aim .............................................. 333
Head restraints ..................................................111
Head-up display.............................................. 78 Driving information display area........... 78
Driving support system display area ..80
Eco Driving Indicator ...................................81
HUD (Head-up display) switch............ 79
Navigation system-linked display ........ 78
Pop-up display...............................................80
Settings .............................................................. 79
Heated steering wheel .............................. 258
Heaters Air conditioning system............................251
Heated steering wheel............................258
Outside rear view mirrors .................... 252
Seat heaters ..................................................258
High mounted stoplight Replacing light bulbs................................ 335
Hill-start assist control ............................... 236
Hood .................................................................308 Open .............................................................. 308 Hooks
Cargo hooks............................................... 268
Coat hooks .................................................. 280
Grocery bag hooks................................. 268
Retaining hooks (floor mat) ..................... 22
Horn ..................................................................... 114
HUD (Head-up display) switch .................79
I
I/M test ............................................................305
Identification Engine............................................................. 383
Vehicle ............................................................382
Ignition switch (engine switch)................. 137 Auto power off function........................... 139
Changing the engine switch modes . 139
If your vehicle has to be stopped in an emergency ................................................ 340
Starting the engine ......................................137
Immobilizer system........................................ 54
Indicators ........................................................... 62
Initialization Items to initialize .......................................... 410
Maintenance........................................ 301, 312
Power windows ............................................. 118
Tire pressure warning system ...............321
Inside rear view mirror ................................. 114
Instrument panel light control ........... 66, 70
Interior lights.................................................. 262
Intuitive parking assist.................... 204, 205 Function ......................................................... 205
Warning message .................................... 208
J
JackPositioning a floor jack ........................... 308
Vehicle-equipped jack ...........................363
Jack handle .................................................... 363
Jam protection function Electronic roof sunshade .........................124
Moon roof ........................................................ 121

438Alphabetical index
Sport mode .................................................... 202
Steering lockColumn lock release................................. 138
Steering lock system warning message.......................................................................... 138
Steering wheel ................................................. 113 Adjustment....................................................... 113
Heated steering wheel............................258
Meter control switches ...............................72
Power easy access system .................... 108
Steering wheel positi on memory ....... 108
Stop lights Replacing light bulbs................................ 335
Storage feature ............................................ 265
Stuck If the vehicle becomes stuck................ 379
Suggestion function........................................ 77
Sunshade Roof ........................................................... 121, 123
Sun visors ........................................................ 269
Switches “ODO TRIP”switch ............................ 65, 70
“SOS” button ...............................................289
Automatic High Beam system..............153
Brake Hold switch ..................................... 148
BSM (Blind Sport Monitor) switch..... 197
Door lock switches ........................................ 91
Driving Mode Select switch ................. 202
Driving position memory switches .... 108
Dynamic radar cruise control with full-speed range switch ................................ 188
Electronic roof sunshade switches ..... 123
Emergency flashers switch ...................340
Engine switch................................................. 137
Garage door opener sw itches ............281
Heated steering wheel switch.............258
HUD (Head-up display) switch............ 79
Ignition switch................................................ 137
Instrument panel light control switches ................................................................... 66, 70
Intuitive parking assist switch...............206
Light switches ............................................... 150 LTA (Lane Tracing Assist) switch ....... 181
Meter control switches .............................. 72
Moon roof switches................................... 120
Outside rear view mirr
or switches ...... 115
Paddle shift switches ....................... 143, 144
Panoramic moon roof switches ...........123
Parking brake switch................................. 146
PCS OFF switch ........................................... 171
PKSB (Parking Support Brake) switch ............................................................................219
Power door lock switch ..............................91
Power window switches ........................... 118
RCD (Rear Camera Detection) switch ........................................................................... 215
RCTA switch .................................................. 212
Rear sunshades switch............................ 278
Rear window and outside rear view mir- ror defoggers switch ............................. 251
Seat heater switches................................ 258
Seat ventilator switches ......................... 258
Tilt and telescopic steering control switch ............................................................................. 113
Tire pressure warning reset switch.....321
Trunk closer switch ......................................96
Trunk opener main switch........................ 99
Trunk opener switch ...................................95
Vehicle-to-vehicle distance switch.... 188
VSC OFF switch ....................................... 237
Window lock switch.................................... 119
Windshield wiper and washer switch155
Windshield wiper de-icer switch.......255
T
Tachometer............................................... 64, 67 Rev indicator ...................................................69
Rev peak............................................................69
Tail lights........................................................... 150 Light switch .................................................... 150
Replacing light bulbs ................................335
Theft deterrent system Alarm...................................................................56
Engine immobilizer system...................... 54
