2555-1. Remote Touch
5
Interior features
■Split-screen display (12.3-inch display model)
Different information can be displayed on the left and right of the screen. For
example, air conditioning system screen can be displayed and operated while the
fuel consumption information screen is be ing displayed. The large screen on the
left of the display is called the main display, and the small screen to the right is
called the side display.
■Main display
For details about the functions and
operation of the main display, refer to
the respective section and “NAVIGA-
TION AND MULTIMEDIA SYSTEM
OWNER’S MANUAL”.
■Side display (12.3-inch display
model)
The following functions can be dis-
played and operated on the side dis-
play.
Select or to display the desired
screen. Navigation system
*
Audio*
Vehicle information (
P.89)
Air conditioning system ( P.263)
Show/hide the side display
*: Refer to the “NAVIGATION AND MULTIMEDIA SYSTEM OWNER’S
MANUAL”.
■Screen display during low temperatures
When the ambient temperature is
A
B
C
D
E

2615-3. Using the air conditioning system
5
Interior features
■Outside/recirculated air mode
●Setting to the recirculated air mode tem-
porarily is recommended in preventing
dirty air from entering the vehicle interior
and helping to cool the vehicle when the
outside air temperature is high.
●Outside/recirculated air mode may auto-
matically switch regardless of the air con-
ditioning setting depending on the
temperature setting or inside tempera-
ture.
■Registering air conditioning settings to
electronic keys
●Unlocking the vehicle using an electronic
key and turning the engine switch to
IGNITION ON mode will recall that
key’s registered air conditioning settings.
●When the engine switch is turned off, the
current air conditioning settings will auto-
matically be registered to the electronic
key that was used to unlock the vehicle.
●The system may not operate correctly if
more than one electronic key is in the
vicinity or if the smart access system with
push-button start is used to unlock the
passenger door.
●Vehicles with the driving position mem-
ory: The doors that can recall the air con-
ditioning setting
* when unlocked using
the smart access system with push-but-
ton start can be changed. For details,
contact your Lexus dealer.
*: The doors that can recall the driving posi-
tion memory are changed at the same
time.
■Operation of the air conditioning sys-
tem in Eco drive mode
In Eco drive mode, the air conditioning sys-
tem is controlled as follows to prioritize fuel
efficiency:
●Engine speed and compressor operation
controlled to restri ct heating/cooling
capacity
●Fan speed restricted when automatic
mode is selected
To improve air conditioning performance,
perform the following operations:
●Turn off eco air conditioning mode
(  P.263)
●Adjust the fan speed
●Turn off Eco drive mode ( P.208)
■When the outside temperature falls to
nearly 32°F (0°C)
The dehumidification function may not
operate even when “A/C” is selected.
■Ventilation and air conditioning odors
●To let fresh air in, set the air conditioning
system to the outside air mode.
●During use, various odors from inside and
outside the vehicle may enter into and
accumulate in the air conditioning sys-
tem. This may then cause odor to be
emitted from the vents.
●When parking, the system automatically
switches to fresh air intake mode to
encourage better air circulation through-
out the vehicle, helping to reduce odors
that occur when starting the vehicle.
■Using the voice command system
Air conditioning system can be operated
using voice commands. For details, refer to
the “NAVIGATION AND MULTIMEDIA
SYSTEM OWNER’S MANUAL”.
■Air conditioning filter
 P.333
■Customization
Settings (e.g. A/C Auto switch operation)
can be changed.
(Customizable features P.404)
WARNING
■To prevent the windshield from fog-
ging up
Do not use the windshield defogger
switch during cool air operation in
extremely humid weather. The difference
between the temperature of the outside
air and that of the windshield can cause
the outer surface of the windshield to fog
up, blocking your vision.

2775-6. Using the other interior features
5
Interior features
5-6.Using the other interior features
1To set the visor in the forward posi-
tion, flip it down.
2
To set the visor in the side position,
flip down, unhook, and swing it to
the side.
3
To use the side extender, place the
visor in the side position, then slide
it backward.
Slide the cover to open.
The light turns on when the cover is
opened.
The GPS clock’s time is automatically
adjusted by utilizing GPS time infor-
mation.
For details, refer to the “NAVIGATION
AND MULTIMEDIA SYSTEM OWNER’S
MANUAL”.
Please use as a power supply for elec-
tronic goods that use less than 12
VDC/10 A (power consumption of
120 W).
Front
Open the lid.
Rear
Open the lid.
Other interior features
Sun visors
Vanity mirrors
NOTICE
■To prevent battery discharge
Do not leave the lights on longer than
necessary when the engine is off.
Clock
Power outlets

3727-2. Steps to take in an emergency
76 ft•lbf (103 N•m, 10.5 kgf•m)
5Stow the flat tire, tire jack and all
tools.
■The compact spare tire
●The compact spare tire is identified by the
label “TEMPORARY USE ONLY” on
the tire sidewall.
Use the compact spare tire temporarily,
and only in an emergency.
●Make sure to check the tire inflation pres-
sure of the compact spare tire. (P.391)
■After completing the tire change
The tire pressure warning system must be
reset. ( P.326)
■When using the compact spare tire
As the compact spare tire is not equipped
with a tire pressure warning valve and trans-
mitter, low inflation pressure of the spare
tire will not be indicated by the tire pressure
warning system. Also, if you replace the
compact spare tire after the tire pressure
warning light comes on, the light remains
on.
■When the compact spare tire is
attached
The vehicle becomes lower when driving
with the compact spar e tire compared to
when driving with standard tires.
■If you have a flat front tire on a road cov-
ered with snow or ice
Install the compact spare tire on one of the
rear wheels of the vehicle. Perform the fol-
lowing steps and fit tire chains to the front
tires: 1
Replace a rear tire with the compact
spare tire.
2
Replace the flat front tire with the tire
removed from the rear of the vehicle.
3
Fit tire chains to the front tires.
WARNING
■When using the compact spare tire
●Remember that the compact spare tire
provided is specific ally designed for
use with your vehicle. Do not use your
compact spare tire on another vehicle.
●Do not use more than one compact
spare tire simultaneously.
●Replace the compact spare tire with a
standard tire as soon as possible.
●Avoid sudden acceleration, abrupt
steering, sudden braking and shifting
operations that cause sudden engine
braking.
■When the compact spare tire is
attached
The vehicle speed may not be correctly
detected, and the following systems may
not operate correctly:
• ABS & Brake assist
• VSC
• TRAC
• Dynamic radar cruise control with full- speed range
• PCS (Pre-Collision System)
• EPS
• LTA (Lane Tracing Assist)
• Panoramic view monitor (if equipped)
• Lexus parking assist monitor (if equipped)
• Intuitive parking assist (if equipped)
• Navigation system (if equipped)
• BSM (Blind spot monitor) (if equipped)
• Automatic high Beam

4048-2. Customization
8-2.Customization
■Changing by using the meter con-
trol switches
1
Press or to select .
2
Operate the meter control
switches to select the desired item
to be customized.
3
According to the display, select the
desired setting.
To go back to the previous screen or exit
the customize mode, press .
■Changing by using the Remote
Touch
1
Press the “MENU” button on the
Remote Touch.
2
Select “Setup” on the menu screen
and select “Vehicle”. 3
Select “Vehicle Customization” or
“Drive Mode Customization”.
Various setting can be changed. Refer to
the list of settings th
at can be changed for
details.
For details on the Remote Touch, refer
to the “NAVIGATION AND MULTI-
MEDIA SYSTEM OWNER’S MAN-
UAL”.
■When customizing using the Remote
Touch
Stop the vehicle in a safe place, apply the
parking brake, and shift the shift lever to P.
Also, to prevent battery discharge, leave
the engine running while customizing the
features.
Some function settings are changed simultaneously with other functions being cus-
tomized. Contact your Lexus dealer for further details.
Settings that can be changed using the Remote Touch
Settings that can be changed using the meter control switches
Customizable features
Your vehicle includes a variety of
electronic features that can be per-
sonalized to your preferences. The
settings of these features can be
changed by using the meter control
switches, the Remote Touch or at
your Lexus dealer.
Customizing vehicle features
WARNING
■During customization
As the engine needs to be running
during customization, ensure that the
vehicle is parked in a place with ade-
quate ventilation. In a closed area such as
a garage, exhaust gases including harm-
ful carbon monoxide (CO) may collect
and enter the vehicle. This may lead to
death or a serious health hazard.
NOTICE
■During customization
To prevent battery discharge, ensure that
the engine is running while customizing
features.
Customizable features
A
B

437Alphabetical index
G
Garage door opener ................................. 289
Gauges ....................................................... 70, 73
Gear Position.....................................................81
G-force.................................................................81
Glove box ........................................................274
Glove box light ..............................................274
Grocery bag hooks .....................................276
H
Hands Free Power Trunk Lid ...................102
Headlights ........................................................156Adaptive Front-lighting System (AFS).......................................................................... 158
Automatic High Beam system............. 159
Light switch .................................................... 156
Replacing light bulbs................................ 339
Headlights aim .............................................. 338
Head restraints ................................................ 117
Head-up display.............................................. 84 Driving information display area........... 84
Driving support system display area .. 86
Eco Driving Indicator ................................. 87
HUD (Head-up display) switch............85
Navigation system-linked display ........ 84
Pop-up display............................................... 86
Settings .............................................................. 85
Heated steering wheel .............................. 266
Heaters Air conditioning system.......................... 259
Heated steering wheel............................ 266
Outside rear view mirrors ....................260
Seat heaters .................................................. 266
High mounted stoplight Replacing light bulbs................................ 339
Hill-start assist control ............................... 244
Hood ...................................................................312 Open ................................................................. 312
Hooks Cargo hooks................................................ 276
Coat hooks ...................................................288 Grocery bag hooks.................................. 276
Retaining hooks (floor mat) ..................... 22
Horn ....................................................................120
HUD (Head-up display) switch ................ 85
I
I/M test ............................................................ 309
Identification Engine..............................................................387
Vehicle ........................................................... 386
Ignition switch (engine switch).................143 Auto power off function........................... 146
Changing the engine switch modes . 146
If your vehicle has to be stopped in an emergency ................................................. 344
Starting the engine ......................................143
Immobilizer system.......................................... 61
Indicators ........................................................... 68
Initialization Items to initialize .......................................... 415
Maintenance......................................305, 316
Power windows ............................................124
Tire pressure warning system .............326
Inside rear view mirror ................................120
Instrument panel light control ............72, 76
Interior lights.................................................. 270
Intuitive parking assist......................... 210, 211 Function ............................................................. 211
Warning message .......................................214
J
JackPositioning a floor jack ..............................312
Vehicle-equipped jack ........................... 367
Jack handle .................................................... 367
Jam protection function Electronic roof sunshade ........................ 130
Moon roof ....................................................... 127
Panoramic moon roof .............................. 130
Power trunk opener and closer .......... 103
Power windows ............................................124

439Alphabetical index
Meter control switches .............................. 78
Meters ........................................................70, 73
Multi-information display ........................... 77
Settings .............................................................. 82
Units ......................................................................81
Warning lights ............................................. 352
Warning message..................................... 362
Mirrors Inside rear view mirror..............................120
Outside rear view mirror defoggers260
Outside rear view mirrors ........................121
Vanity mirrors...............................................277
Moon roof Door lock linked moon roof operation................................................................ 127, 130
Jam protection function................. 127, 130
Operation..............................................126, 129
Multi-information display ............................. 77 Audio system-linked display.....................81
Boost gauge....................................................80
Drive information 1/Drive information 2............................................................................ 79
Driving information display...................... 79
Driving support system information dis- play ................................................................... 82
Dynamic radar cruise control with full- speed range ................................................193
Eco Driving Indicator ................................. 87
Gear Position ...................................................81
G-force................................................................81
LTA (Lane Tracing Assist)......................187
Menu icons ...................................................... 78
Meter control switches .............................. 78
Navigation system-linked display ..........81
Pop-up display............................................... 82
Settings .............................................................. 82
Suggestion function..................................... 83
Tire pressure ................................................ 323
Units ......................................................................81
Warning message..................................... 362
N
Navigation system-linked display..... 81, 84
Noise from under vehicle ...............................6
O
Odometer ................................................... 71, 76
Odometer and trip meter display “ODO TRIP” switch ............................. 71, 76
Display items ............................................ 71, 76
Pop-up display .......................................72, 76
“ODO TRIP”switch ................................. 71, 76
Oil Engine oil....................................................... 388
Opener Fuel filler door ................................................167
Hood ..................................................................312
Trunk ................................................................... 101
Outside door handle lig hts...................... 270
Outside rear view mirrors .......................... 121 Adjustment ....................................................... 121
BSM (Blind Spot Monitor)....................203
Folding............................................................... 122
Linked mirror functi on when reversing
............................................................................123
Mirror position memory ............................ 114
Outside rear view mirror defoggers260
RCTA function ............................................. 218
Outside temperature............................ 70, 73
Overheating ................................................... 381
P
Paddle shift switches ................................... 150
Panic mode ....................................................... 93
Panoramic moon roof Jam protection function ........................... 130
Operation ........................................................129
Parking assist sensors (intuitive parking assist) ................................................................ 211
Parking brake..................................................152 Operation ....................................................... 152

444Alphabetical index
Brake Override System ......................... 354
Brake system ............................................... 352
Charging system ....................................... 353
Downshifting ........................................ 150, 151
Drive-Start Control .................................. 354
Electric power steering .......................... 354
Engine ............................................................. 353
High coolant temperature .................... 352
Intuitive parking assist....................217, 356
Low engine oil pressure......................... 353
LTA (Lane Tracing Assist)......... 182, 356
Open door.............................................. 96, 98
Open hood...................................................... 98
Open trunk ...................................................... 98
Open window ...............................................125
PKSA (Parking Support Alert) ...............211
PKSB (Parking Support Brake) ......... 357
Pre-collision braking.................................. 175
RCD (Rear Camera Detection) ........ 357
RCTA (Rear Cross Traffic Alert) ...... 357
Seat belt ..........................................................355
Warning lights............................................... 352 ABS .................................................................. 354
Brake hold operated indicator ...........359
Brake Override System ......................... 354
Brake system ............................................... 352
Charging system ....................................... 353
Drive-Start Control .................................. 354
Electric power steering .......................... 354
High coolant temperature .................... 352
Intuitive parking assist OFF indicator.........................................................................356
Low engine oil pressure......................... 353
Low fuel level ...............................................355
LTA indicator ...............................................356
Malfunction indicator lamp................... 353
Master warning light ................................359
Parking brake indicator ......................... 358
PKSB OFF indicator ................................ 357
Pre-collision system ................................ 358
RCD OFF indicator ................................. 357
RCTA OFF indicator............................... 357 Seat belt reminder light.......................... 355
Slip indicator ................................................ 358
SRS ....................................................................353
Tire pressure ............................................... 356
Warning messages ..................................... 362
Washer ............................................................... 161 Checking ........................................................ 319
Preparing and checking before winter..........................................................................248
Switch.................................................................. 161
Washing and waxing..................................300
Weight Cargo capacity .............................................. 141
Load limits ........................................................ 141
Weight............................................................ 386
Wheel lock key............................................. 367
Wheels ...............................................................331 Size ..................................................................... 391
Window lock switch .....................................125
Windows ........................................................... 124 Power windows ............................................124
Rear window defogger.......................... 260
Washer .............................................................. 161
Windshield wiper de-icer ........................ 263
Windshield wipers ......................................... 161 Position............................................................. 165
Rain-sensing windshield wipers ............ 161
Winter driving tips....................................... 248
Wireless charger ......................................... 279
Wireless remote control ............................. 93 Battery-Saving Function.......................... 107
Locking/Unlocking ..................................... 93
Replacing the battery ...............................334
For information regarding the equipment listed below, refer to
the “NAVIGATION AND MULTI-
MEDIA SYSTEM OWNER’S
MANUAL”.

445Alphabetical index
· Audio/video system
· Navigation system
· Lexus parking assist monitor
· Panoramic view monitor
· Lexus Enform
