start stop button Lexus ES350 2020 / LEXUS 2020 ES350 FROM OCT. 2019 PROD. (OM06194U) User Guide

3777-2. Steps to take in an emergency
7
When trouble arises
open.
■Key linked functions
1
Closes the windows and the moon roof
(if equipped) or panoramic moon roof
(if equipped) (turn and hold)
2
Opens the windows and the moon roof
(if equipped) or panoramic moon roof
(if equipped) (turn and hold)
These settings must be customized at your
Lexus dealer.
1Ensure that the shift lever is in P and
depress the brake pedal.
2
Touch the Lexus emblem side of the
electronic key to the engine switch.
When the electronic key is detected, a
buzzer sounds and the engine switch will
turn to IGNITION ON mode.
When the smart access system with push-
button start is deactivated in customization
setting, the engine switch will turn to
ACCESSORY mode.
3Firmly depress the brake pedal and
check that is shown on the
multi-information display.
4
Press the engine switch shortly and
firmly.
In the event that the engine still cannot
be started, contact your Lexus dealer.
■Stopping the engine
Set the parking brake, shift the shift lever to
P and press the engine switch as you nor-
mally do when stop ping the engine.
■Electronic key battery
As the above procedure is a temporary
measure, it is recommended that the elec-
tronic key battery be replaced immediately
when the battery is depleted. (P.334)
■Changing engine switch modes
Release the brake pedal and press the
WARNING
■When using the mechanical key and
operating the power windows or
moon roof (if equipped) or panoramic
moon roof (if equipped)
Operate the power window, moon roof
or panoramic moon roof after checking
to make sure that there is no possibility of
any passenger having any of their body
parts caught in the window, moon roof or
panoramic moon roof.
Also, do not allow ch ildren to operate the
mechanical key. It is possible for children
and other passengers to get caught in
the power window, moon roof or pan-
oramic moon roof.
Starting the engine

435Alphabetical index
Warning message..................................... 362
Distance until next engine oil change71, 76
Do-it-yourself maintenance .................... 306
Door courtesy lights ................................... 270
Door lock Doors .................................................................. 95
Smart access system with push-button start ................................................................. 106
Wireless remote control........................... 93
Doors ................................................................... 95 Automatic door lock ing and unlocking
system ............................................................. 98
Door glasses .................................................. 124
Door lock.......................................................... 95
Open door warning buzzer .......... 96, 98
Outside rear view mirrors ........................121
Rear door child-protectors ..................... 98
Drive distance ...................................................79
Drive info 1/Drive info 2 ...............................79
Driver’s seat position memory .................. 114 Driving position memory ...........................114
Memory recall function ............................. 115
Drive-start control ........................................135
Driving................................................................134 Break-in tips ...................................................135
Correct driving posture .............................23
Driving Mode Select switch .................208
Procedures ..................................................... 134
Winter drive tips......................................... 248
Driving information display .........................79
Driving Mode Select switch....................208
Driving range ....................................................79
Driving support system information display ............................................................................. 82
Dynamic radar cruise control with full- speed range..................................................193Warning message.......................................201
E
Eco drive mode ............................................208
Eco Driving Indicator.................... 80, 81, 87
Eco Driving Indicator Light ........................ 80 EDR (Event data recorder) ............................7
Elapsed time ......................................................79
Electric Power Steering (EPS)
Function .......................................................... 244
Warning light ...............................................354
Electronic key .................................................. 92 Battery-saving function............................ 107
If the electronic key does not operate properly ....................................................... 376
Replacing the battery ...............................334
Electronic roof sunshade Jam protection function ........................... 130
Operation ........................................................129
Emergency, in case of If a warning buzzer sounds...................352
If a warning light turns on.......................352
If a warning message is displayed .....362
If the battery is discharged ....................378
If the electronic key does not operate properly ....................................................... 376
If the engine will not start........................ 373
If the fuel filler do or cannot be opened
..........................................................................375
If the vehicle is trapped in rising water ..........................................................................345
If you have a flat tire ................................. 366
If you lose your keys .................................375
If you think something is wrong......... 350
If your vehicle becomes stuck ............ 383
If your vehicle has to be stopped in an emergency ................................................. 344
If your vehicle needs to be towed ..... 347
If your vehicle overheats ......................... 381
Emergency flashers .................................... 344
Engine ................................................................143 ACCESSORY mode............................... 146
Compartment................................................314
Engine switch .................................................143
Fuel pump shut off system...................... 351
Hood ..................................................................312
How to start the engine ............................143
Identification number ...............................387
