15Pictorial index
Parking brake switch ............................................................................................. P.152
Applying/releasing ........................................................................................................... P.152
Precautions against winter season ................... ......................................................... P.249
Warning buzzer/message............................................................................................ P.363
Turn signal lever ....................................................................................................... P.151
Headlight switch...................................................................................................... P.156
Headlights/parking lights/tail lights/daytime running lights ........................... P.156
Automatic High Beam ..................................................................................................... P.159
Windshield wiper and washer switch ................................................................. P.161
Usage........................................................................................................................................ P.161
Adding washer fluid .......................................................................................................... P. 319
Warning messages .......................................................................................................... P.363
Emergency flasher switch ...................................................................................P.344
Hood lock release lever ........................................................................................P.312
Tilt and telescopic steering control swit ch/tilt and telescopic steering lock
release lever .............................................................................................................. P.11 9
Adjustment ..................................................................................................................... ........ P.119
Driving position memory
*1............................................................................................... P.114
Air conditioning system .......................................................................................P.259
Usage.......................................................................................................................... ........... P.259
Rear window defogger................................................................................................... P.260
Audio system
*2
Trunk opener main switch ....................................................................................P.105
*1: If equipped
*2: Refer to “NAVIGATION AND MULTIMEDIA SYSTEM OWNER’S MANUAL”.
E
F
G
H
I
J
K
L
M

943-1. Key information
To take out the mechanical key, push
the release button and take the key out.
The mechanical key can only be inserted in
one direction, as the key only has grooves
on one side. If the key cannot be inserted in
a lock cylinder, turn it over and re-attempt
to insert it.
After using the mechanical key, store it in
the electronic key. Carry the mechanical
key together with the electronic key. If the
electronic key battery is depleted or the
entry function does not operate properly,
you will need the mechanical key.
( P.376)
■When required to leave the vehicle’s
key with a parking attendant
Turn the trunk opener main switch off
(  P.105), lock the glove box ( P.274) and
armrest door ( P.287) as circumstances
demand.
Remove the mechanical key for your own
use and provide the attendant with the elec-
tronic key only.
■If you lose your mechanical keys
 P.375
Using the mechanical key

953-2. Opening, closing and locking the doors and trunk
3
Before driving
3-2.Opening, closing and locking the doors and trunk
■Smart access system with push-
button start
Carry the electronic key to enable this
function.
1 Grip the driver’s door handle to
unlock the door. Holding the
driver’s door ha ndle for approxi-
mately 2 seconds unlocks all the
doors. Grip the passenger’s door
handle to unlock all the doors.
*
Make sure to touch the sensor on the back
of the handle.
The doors cannot be unlocked for 3 sec-
onds after the doors are locked.
*: The door unlock settings can be changed.
2 Touch the lock sensor (the indenta-
tion on the upper part of the door
handle) to lock all the doors.
Check that the door is securely locked.
■Wireless remote control
1 Locks all the doors
Check that the door is securely locked.
2Unlocks all the doors
Pressing the button unlocks the driver’s
door. Pressing the button again within 5
seconds unlocks the other doors.
Press and hold to open the windows and
moon roof (if equipped) or panoramic
moon roof (if equipped).
*
*
: This setting must be customized at your Lexus dealer.
■Switching the door unlock function
It is possible to set which doors the entry
function unlocks using the wireless remote
control.
1 Turn the engine switch off.
2 When the indicator light on the key sur-
face is not on, press and hold ,
or for approximately 5
seconds while pre ssing and holding
.
The setting changes each time an operation
is performed, as shown below. (When
changing the setting continuously, release
the buttons, wait for at least 5 seconds, and
repeat step 2 .)
Doors
Unlocking and locking the doors
from the outside

963-2. Opening, closing and locking the doors and trunk
To prevent unintended triggering of the
alarm, unlock the doors using the wireless
remote control and open and close a door
once after the settings have been changed.
(If a door is not opened within 60 seconds
after is pressed, the doors will be
locked again and the alarm will automati-
cally be set.)
In a case that the alarm is triggered, imme-
diately stop the alarm. (P.63)
■Impact detection door lock release sys-
tem
In the event that the vehicle is subject to a
strong impact, all the doors are unlocked.
Depending on the force of the impact or the
type of accident, however, the system may
not operate.
■Operation signals
A buzzer sounds and the emergency flash-
ers flash to indicate that the doors have
been locked/unlocked. (Locked: once;
Unlocked: twice)
Windows and moon roof (if equipped) or
panoramic moon roof (if equipped): A
buzzer sounds to indicate that the windows
and moon roof or panoramic moon roof are
opening.
■Security feature
If a door is not opened within approximately
60 seconds after the vehicle is unlocked,
the security feature automatically locks the
vehicle again. (However, depending on the
location of the electronic key, the key may
be detected as being in the vehicle. In this
case, vehicle may be unlocked.)
■When the doors cannot be locked by the
lock sensor on the upper part of the
door handle
When the doors cannot be locked even if
the lock sensor on the surface of the door
handle is touched by a finger, touch the lock
sensor with the palm.
If you are wearing gloves, remove them.
■Open door warning buzzer
If an attempt to lock the doors is made when
a door is not fully closed, a buzzer sounds
continuously for 5 seconds. Fully close the
door to stop the buzzer, and lock the vehi-
cle once more.
■Setting the alarm
Locking the doors will set the alarm system.
(  P.63)
■Conditions affecting the operation of
the smart access system with push-but-
ton start or wireless remote control
 P.107
■If the smart access system with push-
button start or the wireless remote con-
trol does not operate properly
Use the mechanical key to lock and unlock
the doors. ( P.376)
Replace the key battery with a new one if it
is depleted. ( P.334)
■If the battery is discharged
The doors cannot be locked and unlocked
using the smart access system with push-
Multi-information display/BeepUnlocking function
Exterior: Beeps 3 times
Interior: Pings once
Holding the driver’s
door handle unlocks
only the driver’s door.
Holding a passenger’s
door handle unlocks all
the doors.
Exterior: Beeps twice
Interior: Pings onceHolding a door handle
unlocks all the doors.

1033-2. Opening, closing and locking the doors and trunk
3
Before driving
■Trunk grip
Using the trunk grip, pull down the
trunk lid without applying sideways
force and push the trunk lid down from
the outside to close it.
■Trunk light
The trunk light turns on when the trunk is
opened.
■Trunk easy closer (v ehicles with power
trunk lid)
In the event that the trun k lid is left slightly
open, the trunk easy closer will automati-
cally close it to the fully closed position.
●The trunk easy closer will operate
regardless of the en gine switch mode.
●If the trunk easy closer does not operate,
open the trunk to the half open position
or more and then close it.
■Function to prevent the trunk being
locked with the electronic key inside
●When all doors are locked, closing the
trunk lid with the electr onic key left inside
the trunk will sound an alarm.
In this case, the trunk lid can be opened
by pressing the trunk release button on the trunk lid.
●If the spare electronic
key is put in the
trunk with all the doors locked, the key
confinement prevention function is acti-
vated so the trunk can be opened. In
order to prevent theft, take all electronic
keys with you when leaving the vehicle.
●If the electronic key is put in the trunk with
all the doors locked, the key may not be
detected depending on the location of
the key and the surrounding radio wave
conditions. In this case, the key confine-
ment prevention function cannot be acti-
vated, causing the doors to lock when the
trunk is closed. Make sure to check
where the key is before closing the trunk.
●The key confinement prevention function
cannot be activated if any one of the
doors is unlocked. In this case, open the
trunk using the trunk opener.
■Overload protection function (vehicles
with power trunk lid)
The trunk lid will not operate when exces-
sive load is present on the top of the trunk
lid.
■Fall-down protection function (vehicles
with power trunk lid)
While the trunk lid is opening automatically,
applying excessive forc e to it will stop the
opening operation to prevent the trunk lid
from rapidly falling down.
■Jam protection function (vehicles with
power trunk lid)
While the trunk lid is closing automatically,
the trunk lid will stop closing and open if
something gets caught.
■Internal trunk release lever
The trunk lid can be opened by pulling the
glow-in-the-dark lever located on the inside
of the trunk to the side. The lever will con-
tinue to glow for some time after the trunk
lid is closed.

1063-2. Opening, closing and locking the doors and trunk
■Antenna location
Antennas outside the cabin
Antennas inside the cabin
Antenna inside the trunk
Antenna outside the trunk
■Effective range (areas within which the
electronic key is detected)When locking or unlocking the doors
The system can be operated when the
electronic key is within about 2.3 ft. (0.7
m) of an outside door handle. (Only the
doors detecting the key can be oper-
ated.)
When opening the trunk
The system can be operated when the
electronic key is within about 2.3 ft. (0.7
m) of the trunk release button.
When starting the engine or changing
engine switch modes
The system can be operated when the
electronic key is inside the vehicle.
■If an alarm sounds or a warning message
is displayed
An alarm sounds and warning messages
are displayed on the multi-information dis-
play to protect against unexpected acci-
dents or theft of the vehicle resulting from
erroneous operation. When a warning mes-
sage is displayed, take appropriate mea-
sures based on the displayed message.
When only an alarm sounds, circumstances
and correction procedures are as follows.
●When an exterior alarm sounds once for
5 seconds
Smart access system with
push-button start
The following operations can be
performed simply by carrying the
electronic key on your person, for
example in your pocket. The driver
should always carry the electronic
key.
 Locks and unlocks the doors
( P.95)
 Opens the trunk ( P.101)
 Starts the engine ( P.143)
A
B
C
D
A
B
C

2745-5. Using the storage features
1Open (press the glove box opener)
2
Unlock with the mechanical key
3
Lock with the mechanical key
■Glove box light
The glove box light turns on when the tail
lights are on.
■Trunk opener main switch
 P.105
Press a button to open the console box.
The console box can be opened from
either side.
■Console box light
The console box light turns on when the tail
lights are on.
Front (type A)
To open, press down and release the
cup holder lid.
Front (type B)
Adjust the depth of the cup holder.
Shallow (press the button)
Glove box
Console box
WARNING
■Caution while driving
Keep the console box closed.
Injuries may result in the event of an acci-
dent or sudden braking.
NOTICE
■To prevent damage to the console
box
●When the console box is open, do not
apply excessive force in the direction
that it was opened.
Cup holders
A

3497-2. Steps to take in an emergency
7
When trouble arises
If a tow truck is not available in an
emergency, your vehicle may be tem-
porarily towed using cables or chains
secured to the emergency towing eye-
lets. This should only be attempted on
hard surfaced roads for at most 50
miles (80 km) at under 18 mph (30
km/h).
A driver must be in the vehicle to steer
and operate the brakes. The vehicle’s
wheels, drive train, axles, steering and
brakes must be in good condition.
To have your vehicle towed by another
vehicle, the towing eyelet must be
installed to your vehicle. Install the tow-
ing eyelet using the following proce-
dure.
1 Take out the towing eyelet.
(P.367)
2 Remove the eyelet cover using a
flathead screwdriver.
To protect the bodywork, place a rag
between the screwdriver and the vehicle
body as shown in the illustration.
3Insert the towing eyelet into the
hole and tighten partially by hand.
4 Tighten down the towing eyelet
securely using a wheel nut wrench
or hard metal bar.
5 Securely attach cables or chains to
the towing eyelet.
Take care not to damage the vehicle body.
6Enter the vehicle being towed and
start the engine.
If the engine does not start, turn the engine
switch to IGNITION ON mode.
7Shift the shift lever to N and release
the parking brake.
When the shift lever cannot be shifted:
P.149
■While towing
If the engine is not running, the power assist
for the brakes and steer ing will not function,
making steering and braking more difficult.
■Wheel nut wrench
Wheel nut wrench is installed in trunk.
Emergency towing (vehicles
with a towing eyelet)
Emergency towing procedure
(vehicles with a towing eyelet)

438Alphabetical index
K
Keyless entrySmart access system with push-button start ................................................................. 106
Wireless remote control........................... 93
Keys...................................................................... 92 Battery-saving function ............................107
Electronic key ................................................. 92
Engine switch................................................. 143
If the electronic key does not operate properly....................................................... 376
If you lose your keys................................. 375
Key number plate ......................................... 92
Keyless entry .......................................... 95, 101
Mechanical key.............................................. 92
Replacing the battery............................... 334
Warning buzzer .......................................... 106
Wireless remote control........................... 93
Knee airbags .................................................... 28
L
Lane Tracing Assist (LTA) .........................182 Operation........................................................182
Warning messages ................................... 190
Language (multi-information display) ... 82
LATCH anchors ............................................. 49
Lever Auxiliary catch lever ................................... 312
Hood lock release lever........................... 312
Internal trunk release lever .................... 103
Shift lever.......................................................... 147
Turn signal lever ............................................ 151
Wiper lever...................................................... 161
Lexus climate concierge .......................... 257
Lexus Enform Safety Connect.................. 54
Lexus Safety System + 2.0 ........................169 Automatic High Beam ............................. 159
Dynamic radar cruise control with full-speed range ................................................193
LTA (Lane Tracing Assist)......................182
PCS (Pre-Collision System).................. 175 RSA (Road Sign Assist)............................. 191
License plate lights........................................156 Light switch .................................................... 156
Replacing light bulbs ................................339
Light bulbs Replacing .......................................................339
Wattage ..........................................................392
Lights Automatic High Beam system ............. 159
Front interior lights ...................................... 271
Front personal lights................................... 271
Headlight switch.......................................... 156
Interior lights list .......................................... 270
Interior lights .................................................270
Rear interior lights ....................................... 271
Rear personal lights .................................... 271
Trunk light ....................................................... 103
Turn signal lever ............................................ 151
Vanity lights .................................................. 277
Wattage ..........................................................392
Welcome light illumination control ....157
Lock steering column ..................................144
Low profile tire................................................321
LTA (Lane Tracing Assist) .........................182 Operation ....................................................... 182
Warning messages.................................... 190
Luggage mat ..................................................276
M
Maintenance Do-it-yourself maintenance .................. 310
General maintenance ............................ 306
Maintenance data ..................................... 386
Maintenance requirements ................. 305
Malfunction indicator la mp ..................... 353
Master warning light .................................. 359
Menu icons........................................................ 78
Meter Changing the main meter location.......77
Clock.......................................................... 70, 73
Indicators...........................................................68
Instrument panel light control......... 72, 76

443Alphabetical index
Tire information ............................................ 395 Glossary.........................................................399
Size.................................................................... 397
Tire identification number ..................... 397
Uniform Tire Quality Grading............398
Tire pressure warning system ................ 323 Function .......................................................... 323
Initializing ....................................................... 326
Installing tire pressure warning valves and transmitters ...................................... 325
Registering ID codes ............................... 327
Warning light ...............................................356
Tires................................................................... 320 Chains ............................................................. 249
Checking ....................................................... 320
If you have a flat tire ..................................366
Inflation pressure........................................ 329
Information ....................................................395
Replacing .......................................................366
Rotating tires ................................................ 322
Size......................................................................391
Snow tires ...................................................... 248
Spare tire........................................................366
Tire inflation pressu re display function
......................................................................... 323
Tire pressure warning system ............. 323
Warning light ...............................................356
Tools.................................................................. 367
Top tether strap.................................................51
Total load capacity ....... ............................... 386
Towing Dinghy towing ............................................... 142
Emergency towing ................................... 347
Towing eyelet .............................................. 349
Trailer towing ...................................................141
TRAC (Traction Control) ........................ 244
Traction Control (TRAC) ........................ 244
Trailer towing ................................................... 141
Transmission Automatic transmission ............................ 147
Driving Mode Select switch .................208
Paddle shift switches ................................. 150 S mode ............................................................. 150
Trip meters .................................................. 71, 76
Trunk .................................................................... 99 Hands Free Power Trunk Lid............... 102
Internal trunk release lever..................... 103
Power trunk lid ...............................................99
Smart access system with push-button start ................................................................... 101
Trunk closer switch .................................... 102
Trunk easy closer........................................ 103
Trunk features .............................................. 276
Trunk grip ....................................................... 103
Trunk light ....................................................... 103
Trunk opener main switch...................... 105
Trunk opener switch ................................... 101
Trunk storage extension......................... 287
Wireless remote control ........................... 101
Trunk light ........................................................ 103
Turn signal lights ............................................. 151 Replacing light bulbs ................... 339, 340
Turn signal lever ............................................ 151
U
USB charging ports.................................... 278
V
Vanity lights.....................................................277
Vanity mirrors ................................................277
Vehicle data recordings ..................................6
Vehicle identification number ................ 386
Vehicle Stability Control (VSC) ........... 244
Ventilators (seat ventilators)................... 266
VSC (Vehicle Stability Control) ........... 244
W
Warning buzzersABS ...................................................................354
Airbags............................................................353
Approach warning..................................... 199
Brake hold .................................................... 359
