Lexus ES350 2020 / LEXUS 2020 ES350 FROM OCT. 2019 PROD. QUICK GUIDE (OM06198U) Manual Online

81
ES350_QG_OM06198U_(U)
All SiriusXM services, including satellite radio and data services, plus streaming services,
require a subscription, sold separately or as a package by Sirius XM Radio Inc. (U.S.A.) or
Sirius XM Canada Inc. (Canada), after any tr ial subscription which may be included with
your vehicle purchase or lease. To subscri be after your trial subscription, call 1-877-447-
0011 (U.S.A.) or 1-877-438-9677 (Canada).
SiriusXM Satellite Radio
Most in-car trials today include SiriusXM’s best package  All Access. It includes every
channel available on your radio, plus streaming.
For details, refer to the “NAVIGATION AND MULTIMEDIA SYSTEM OWNER’S
MANUAL”.
Subscription

82
ES350_QG_OM06198U_(U)
■Door lock switches (to lock/unlock)1
Locks all the doors
2Unlocks all the doors
■Inside lock buttons (to lock)
Push down the inside lock button to lock the
door.
■Inside door handles (to unlock)
For the front doors
Pull the handle to unlock and open the
door.
When the door is unlocked, the inside
lock button will pop up.
 For the rear doors
Pull the handle to unlock the door. Pull
the handle a second time to open the
door.
When the door is unlocked, the inside
lock button will pop up.
Door Locks
The vehicle can be locked and unlocked using the entry function, wireless remote control
or door lock switches.
For details about the entry function or wi reless remote control, refer to P.12, 13.
Unlocking and locking the doors from the inside

83
ES350_QG_OM06198U_(U)
●Turn the engine switch off and ensure that all the doors and windows are closed.
● Confirm the type of fuel.
1Press the opener switch.
2Turn the fuel tank cap slowly and
remove it, then hang it on the back of
the fuel filler door.
After refueling, turn the fuel tank cap until
you hear a click. Once the cap is released, it
will turn slightly in the opposite direction.
Fuel Tank Cap
Before refueling the vehicle
Opening the fuel tank cap
Closing the fuel tank cap

84
ES350_QG_OM06198U_(U)

What to do if...
85
ES350_QG_OM06198U_(U)
List of Warning/Indicator Lights
Immediately stop the vehicle in a safe pl ace and contact your Lexus dealer. Continu-
ing to drive the vehicle may be dangerous.
(U.S.A.)
Brake system warning light
(Red)
(Canada)
Immediately stop the vehicle in a safe place and contact your Lexus dealer.
Low engine oil pressure warn-
ing light(U.S.A.)Malfunction
indicator lamp
Charging system warning light(Canada)
Have the vehicle inspected by your Lexus dealer immediately.
SRS warning light
(Flashes)
Brake hold operated indicator
(U.S.A.)
ABS warning light(Flashes)(U.S.A.)Parking brake
indicator
(Canada)
(Flashes)
(Canada)
(Red or
yellow)
Electric power steering
system warning light
(Yellow)
Brake system warning light
(Flashes or
illuminates)PCS warning light
(Flashes)
RCTA OFF indicator (if
equipped)
Slip indicator
(Flashes)
RCD OFF indicator (if
equipped)
(Flashes)
Intuitive parking assist OFF
indicator (if equipped)
(Flashes)
PKSB OFF indicator (if
equipped)
For further information, refe r to the “OWNER’S MANUAL”.

86
What to do if...
ES350_QG_OM06198U_(U)
Follow the correction procedures.
Brake Override System
warning light/Drive-Start
Control warning lightRear passengers’ seat belt
reminder lights
(Blinking and then
continu-
ously on)
Tire pressure warning lightMaster warning light
(Orange)
LTA indicator
Low fuel level warning light
(Illuminates without
blinking)
Tire pressure warning light*
Driver’s and front passenger’s
seat belt reminder light
Stop and check.
High coolant temperature
warning light
For further information, refe r to the “OWNER’S MANUAL”.

What to do if...
87
ES350_QG_OM06198U_(U)
See the “OWNER’S MANUAL”
Turn signal indicatorBSM outside rear view mirror
indicators
Headlight indicator (U.S.A.)BSM indicator
Tail light indicator (Canada)Intuitive parking assist OFF
indicator (if equipped)
Headlight high beam indicator
RCTA OFF indicator (if
equipped)
Automatic High Beam
indicatorRCD OFF indicator (if
equipped)
Cruise control indicatorPKSB OFF indicator (if
equipped)
Dynamic radar cruise control
indicatorBrake hold standby indicator
Cruise control “SET” indicatorBrake hold operated
indicator
(White or green)LTA indicatorSmart access system with
push-button start indicator
(Flashes in orange)LTA indicatorLow outside temperature
indicator
(Flashes)
Slip indicatorEco Driving Indicator Light
VSC OFF indicator(U.S.A.)Parking brake
indicator
PCS warning light(Canada)
For further information, refe r to the “OWNER’S MANUAL”.

88
What to do if...
ES350_QG_OM06198U_(U)
*: It also comes on due to natural causes such as natural air leaks and tire inflation pressure
changes caused by temperature. Adjust the tire inflation pressure to the specified level.
The light will turn off after a few minutes. In case the light does not turn off even if the tire
inflation pressure is adjusted, have th e system checked by your Lexus dealer.
See the “OWNER’S MANUAL”
(U.S.A.)
“AIR BAG ON/OFF” indica-
tor
(Canada)
“AIR BAG ON/OFF” indica-
tor
●Drive mode indicators
Except F SPORT modelsF SPORT models
Eco drive mode indicatorCustom mode indicator
Sport mode indicatorEco drive mode indicator
Sport S mode indicator
Sport S+ mode indicator
For further information, refe r to the “OWNER’S MANUAL”.

What to do if...
89
ES350_QG_OM06198U_(U)
■Unlocking the door1
Pull the driver’s door handle and insert
the mechanical key.
2Unlock the door.
3Remove the key, return the handle, and then pull the handle again.
■Locking the door
1
With the door open, push down the
inside lock button.
2Close the door.
If the electronic key does not operate properly
Locking and unlocking the door

90
What to do if...
ES350_QG_OM06198U_(U)
Turn the mechanical key clockwise to open.
1Ensure that the shift lever is in P and depress the brake pedal.
2Touch the Lexus emblem side of the
electronic key to the engine switch.
When the electronic key is detected, a
buzzer sounds and the engine switch
will turn to IGNITION ON mode.
When the smart access system with
pushbutton start is deactivated in cus-
tomization setting, the engine switch
will turn to ACCESSORY mode.
3Firmly depress the brake pedal and check that is shown on the multi-informa-
tion display.
4Press the engine switch shortly and firmly.
In the event that the engine still cannot be started, contact your Lexus dealer.
Opening the trunk
Starting the engine
If the electronic key battery becomes depleted, a warning message will be shown on the
multi-information display. Replace the battery wi th a new one. For instructions on replacing
the battery, refer to the “OWNER’S MANUAL”.
If you need further assistance , contact your Lexus dealer.
