Lexus ES350 2020 Owner's Manuals / LEXUS 2020 ES350 THROUGH SEPT. 2019 PROD. OWNER'S MANUAL (OM06174U)

4118-2. Customization
8
Vehicle specifications
*:If equipped
■Power windows, and moon roof* or panoramic moon roof* ( P.124, 126, 129)
*:If equipped
■Automatic light control system ( P.156)
■Lights ( P.156)
*1:Except for Canada
*2: If equipped
■PCS (Pre-Collision System) ( P.175)
FunctionDefault settingCustomized setting
Mechanical key linked operationOffOnO
Wireless remote control linked
operationOffOn (open only)O
Wireless remote control linked
operation signal (buzzer)OnOffO
FunctionDefault settingCustomized setting
Light sensor sensitivityStandard-2 to 2OO
Time elapsed before headlights
automatically turn off after doors
are closed
30 seconds
Off
OO60 seconds
90 seconds
Windshield wiper linked headlight
illuminationOnOffO
FunctionDefault settingCustomized setting
Daytime running lightsOnOff*1OO
Welcome lightingOnOffO
AFS (Adaptive Front-lighting Sys-
tem)
*2OnOffO
FunctionDefault settingCustomized setting
PCS (Pre-Collision System)OnOffO
ABC
ABC
ABC
ABC

4128-2. Customization
■LTA (Lane Tracing Assist) (P.182)
■RSA (Road Sign Assist)* ( P.191)
*:If equipped
■BSM (Blind Spot Monitor)* ( P.203)
Adjust alert timingMiddleEarlyOLate
FunctionDefault settingCustomized setting
Lane centering functionOnOffO
Steering assist functionOnOffO
Alert typeSteering wheel
vibrationBuzzerO
Alert sensitivityHighStandardO
Vehicle sway warning functionOnOffO
Vehicle sway warning sensitivityStandardHighOLow
FunctionDefault settingCustomized setting
RSA (Road Sign Assist)OnOffO
Excess speed noti fication methodDisplay onlyNo notificationODisplay and buzzer
Excess speed notification level1 mph (2 km/h)3 mph (5 km/h)O5 mph (10 km/h)
Other notifications method (No-
entry notification)Display onlyNo notificationODisplay and buzzer
FunctionDefault settingCustomized setting
BSM (Blind Spot Monitor)OnOffO
Outside rear view mirror indicator
brightnessBrightDimO
FunctionDefault settingCustomized settingABC
ABC
ABC
ABC

4138-2. Customization
8
Vehicle specifications
*:If equipped
■PKSA (Parking Support Alert) (P.211)
■Intuitive parking assist* ( P.212)
*:If equipped
■RCTA (Rear Cross Traffic Alert) function* ( P.219)
*:If equipped
■RCD (Rear Camera Detection) function* ( P.223)
*:If equipped
Alert timing for presence of
approaching vehicle (sensitivity)Intermediate
Early
O
Late
Only when vehicle
detected in blind spot
FunctionDefault settingCustomized setting
Buzzer volumeLevel2Level1OLevel3
FunctionDefault settingCustomized setting
Intuitive parking assistOnOffO
FunctionDefault settingCustomized setting
RCTA (Rear Cross Traffic Alert)
functionOnOffO
Buzzer volume*Level2Level1OLevel3
FunctionDefault settingCustomized setting
RCD (Rear Camera Detection)
functionOnOffO
FunctionDefault settingCustomized settingABC
ABC
ABC
ABC
ABC

4148-2. Customization
■PKSB (Parking Support Brake)* ( P.226)
*:If equipped
■Driving Mode Select switch ( P.209)
*:If equipped
■Automatic air conditioning system ( P.261)
■Seat heater*/seat ventilators* ( P.268)
*:If equipped
■Heated steering wheel* ( P.268)
*:If equipped
FunctionDefault settingCustomized setting
PKSB (Parking Support Brake)
functionOnOffO
FunctionDefault settingCustomized setting
Powertrain control in custom
mode
*NormalPowerOEco
Chassis control in custom mode*NormalSportO
Air conditioning operation in cus-
tom mode
*NormalEcoO
FunctionDefault settingCustomized setting
A/C auto switch operationOnOffOO
Exhaust gas sensor sensitivityStandard-3 to 3OO
FunctionDefault settingCustomized setting
Driver’s seat temperature prefer-
ence in automatic modeStandard-2 (cooler) to 2
(warmer)OO
Passenger’s seat temperature pref-
erence in automatic modeStandard-2 (cooler) to 2 (warmer)OO
FunctionDefault settingCustomized setting
Steering wheel heating preference
in automatic modeStandard-2 (low) to 2 (high)OO
ABC
ABC
ABC
ABC
ABC

4158-2. Customization
8
Vehicle specifications
■Illumination (P.272)
*:If equipped
■Vehicle customization
●When the smart access system with
push-button start is off, the entry unlock
function cannot be customized.
●When the doors remain closed after unlocking the doors and the timer acti-
vated automatic door lock function acti-
vates, signals will be generated in
accordance with the operation buzzer
volume and operational signal (Emer-
gency flashers) function settings.●Some settings can be changed using a
FunctionDefault settingCustomized setting
Time elapsed before the interior
lights turn off15 seconds
Off
OO7.5 seconds
30 seconds
Operation after the engine switch
is turned offOnOffO
Operation when the doors are
unlockedOnOffO
Operation when you approach the
vehicle with the electronic key on
your person
OnOffO
Footwell lightsOnOffO
Instrument panel ornament light*
and door trim ornament lights
*OnOffO
Time elapsed before the outer foot
lights turn off15 seconds
Off
OO7.5 seconds
30 seconds
Operation of the outer foot lights
when you approach the vehicle
with the electronic key on your per-
son
OnOffO
Operation of the outer foot lights
when the doors are unlockedOnOffO
Operation of the outer foot lights
when a door is openedOnOffO
Fading out of the outer foot lights
when they turn offLongShortO
ABC

4168-2. Customization
switch or the Center Display. If a setting is
changed using a switch, the changed set-
ting will not be reflected on the Center
Display until the engine switch is turned
off and then to IGNITION ON mode.
■Clock settings screen
If the clock adjustment screen is displayed
continuously when attempting to change
the clock settings, the system may be mal-
functioning. Have the vehicle inspected by
your Lexus dealer.

4178-3. Items to initialize
8
Vehicle specifications
8-3.Items to initialize
Items to initialize
The following items must be initialized for normal system operation after such
cases as the battery being reconnected, or maintenance being performed on
the vehicle:
List of the items to initialize
ItemWhen to initializeReference
Intuitive parking assist*After reconnecting or changing the
batteryP.215
PKSB (Parking Support Brake)*After reconnecting or changing the
batteryP.230
Tire pressure warning system
• When rotating the tires.
• When the tire inflation pressure is changed by changing tire size.
(When there are multiple speci-
fied pressures)
• After registering the ID codes.
• When the tire inflation pressure is changed such as when changing
traveling speed.
P.328
Power windowsWhen functioning abnormallyP.124
Lexus parking assist monitor*
•Battery has be en reinstalled.
• The steering wheel has been moved while the battery was
being reinstalled.
• Battery power is low.
Refer to “NAV- IGATION
AND MULTI- MEDIA SYS- TEM
OWNER’S
MANUAL”.
Panoramic view monitor*
•Battery has be en reinstalled.
• The steering wheel has been moved while the battery was
being reinstalled.
• Battery power is low.
Refer to the
“NAVIGA-
TION AND
MULTIMEDIA SYSTEM
OWNER’S
MANUAL”.

4188-3. Items to initialize
*:If equipped
Message indicating maintenance is
requiredAfter the maintenance is performedP.307
Oil maintenanceAfter the maintenance is performedP.318
ItemWhen to initializeReference

419
9
9
For owners
For owners
9-1. For ownersReporting safety defects for U.S. owners ........................................ 420
Seat belt instructions for Cana- dian owners (in French)....... 420
SRS airbag instructions for Cana- dian owners (in French)....... 422
Headlight aim instructions for Canadian owners (in French)
........................................................ 428

4209-1. For owners
9-1.For owners
Tirez sur la ceinture épaulière
jusqu’à ce qu’elle recouvre entière-
ment l’épaule; elle ne doit cepen-
dant pas toucher le cou ni glisser de
l’épaule.
 Placez la ceinture abdominale le
plus bas possible sur les hanches.
 Réglez la position du dossier. Tenez-
vous assis bien au fond du siège, le
dos droit.
 Ne vrillez pas la ceinture de sécu-
rité.
Reporting safety defects for
U.S. owners
If you believe that your vehicle has a
defect which could cause a crash or
could cause injury or death, you
should immediately inform the
National Highway Traffic Safety
Administration (NHTSA) in addi-
tion to notifying the Lexus Division
of Toyota Motor Sa les, U.S.A., Inc.
(Toll-free: 1-800-25-LEXUS).
If NHTSA receives similar com-
plaints, it may open an investiga-
tion, and if it finds that a safety
defect exists in a group of vehicles,
it may order a recall and remedy
campaign. However, NHTSA can-
not become involved in individual
problems between you, your dealer,
or Lexus Division of Toyota Motor
Sales, U.S.A., Inc.
To contact NHTS A, you may call
the Vehicle Safety Hotline toll-free
at 1-888-327-4236 (TTY: 1-800-
424-9153); go to
http://www.safer-
car.gov
; or write to: Administrator,
NHTSA, 1200 New Jersey Ave,
S.E., Washington, DC 20590. You
can also obtain other information
about motor vehicle safety from
http://www.safercar.gov.
Seat belt instructions for
Canadian owners (in French)
The following is a French explana-
tion of seat belt instructions
extracted from the seat belt section
in this manual.
See the seat belt section for more
detailed seat belt instructions in
English.
Utilisation adéquate des cein-
tures de sécurité
