fuel fill door release Lexus ES350 2020 Owner's Manuals / LEXUS 2020 ES350 THROUGH SEPT. 2019 PROD. OWNER'S MANUAL (OM06174U)

1684-4. Refueling
1Press the opener switch.
2
Turn the fuel tank cap slowly and
remove it, then hang it on the back
of the fuel filler door.
■If the fuel filler door cannot be opened
 P.377
After refueling, turn the fuel tank cap
until you hear a click. Once the cap is
released, it will turn slightly in the oppo-
site direction.
Opening the fuel tank cap
Closing the fuel tank cap
WARNING
■When replacing the fuel tank cap
Do not use anything but a genuine Lexus
fuel tank cap designed for your vehicle.
Doing so may cause a fire or other inci-
dent which may result in death or serious
injury.

448
GAS STATION INFORMATION
Auxiliary catch lever (P.314)
Trunk opener ( P.101)
Fuel filler door opener ( P.168)
Fuel filler door ( P.168)
Hood lock release lever ( P.314)
Tire inflation pressure ( P.393)
Fuel tank capacity (Reference)16.0 gal. (60.6 L, 13.3 Imp.gal.)
Fuel typeUnleaded gasoline onlyP.389
Cold tire inflation
pressureP.393
Engine oil capacity (Drain and
refill  reference)P.390
Engine oil typeP.390
A
B
C
D
E
F
